SLIDE 1
6.870 Object Recognition and Scene Understanding
student presentation
MIT
6.870
Template matching and histograms
Nicolas Pinto
Object Recognition and Scene Understanding MIT student - - PowerPoint PPT Presentation
Object Recognition and Scene Understanding MIT student - - PowerPoint PPT Presentation
Object Recognition and Scene Understanding MIT student presentation 6.870 6.870 Template matching and histograms Nicolas Pinto Introduction Hosts a guy... Antonio T... a frog... (who has big arms) (who knows a lot about vision) (who
SLIDE 2
SLIDE 3
Introduction
SLIDE 4
Hosts
Antonio T...
(who knows a lot about vision)
a frog...
(who has big eyes) and thus should know a lot about vision...
a guy...
(who has big arms)
SLIDE 5
Object Recognition from Local Scale-Invariant Features
David G. Lowe Computer Science Department University of British Columbia Vancouver, B.C., V6T 1Z4, Canada lowe@cs.ubc.ca Abstract An object recognition system has been developed that uses a new class of local image features. The features are invariant to image scaling, translation,and rotation, and partially in- variant to illuminationchanges and affine or 3D projection. translation, scaling, and rotation, and partially invariant to illumination changes and affine or 3D projection. Previous approaches to local feature generation lacked invariance to scale and were more sensitive to projective distortion and illumination change. The SIFT features share a number of properties in common with the responses of neurons in infe-Lowe (1999)
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
- f Histograms of Oriented Gradient (HOG) descriptors sig-
- tion. We study the influence of each stage of the computation
Nalal and Triggs (2005)
3 papers
A Discriminatively Trained, Multiscale, Deformable Part Model
Pedro Felzenszwalb University of Chicago pff@cs.uchicago.edu David McAllester Toyota Technological Institute at Chicago mcallester@tti-c.org Deva Ramanan UC Irvine dramanan@ics.uci.edu Abstract This paper describes a discriminatively trained, multi- scale, deformable part model for object detection. Our sys- tem achieves a two-fold improvement in average precision- ver the best performance in the 2006 PASCAL person de-
Felzenszwalb et al. (2008)
yey!!
SLIDE 6
Object Recognition from Local Scale-Invariant Features
David G. Lowe Computer Science Department University of British Columbia Vancouver, B.C., V6T 1Z4, Canada lowe@cs.ubc.ca Abstract An object recognition system has been developed that uses a new class of local image features. The features are invariant to image scaling, translation,and rotation, and partially in- variant to illuminationchanges and affine or 3D projection. translation, scaling, and rotation, and partially invariant to illumination changes and affine or 3D projection. Previous approaches to local feature generation lacked invariance to scale and were more sensitive to projective distortion and illumination change. The SIFT features share a number of properties in common with the responses of neurons in infe-Lowe (1999)
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
- f Histograms of Oriented Gradient (HOG) descriptors sig-
- tion. We study the influence of each stage of the computation
Nalal and Triggs (2005)
A Discriminatively Trained, Multiscale, Deformable Part Model
Pedro Felzenszwalb University of Chicago pff@cs.uchicago.edu David McAllester Toyota Technological Institute at Chicago mcallester@tti-c.org Deva Ramanan UC Irvine dramanan@ics.uci.edu Abstract This paper describes a discriminatively trained, multi- scale, deformable part model for object detection. Our sys- tem achieves a two-fold improvement in average precision- ver the best performance in the 2006 PASCAL person de-
Felzenszwalb et al. (2008)
SLIDE 7
Scale-Invariant Feature Transform (SIFT)
adapted from Kucuktunc SLIDE 8
Scale-Invariant Feature Transform (SIFT)
adapted from Brown, ICCV 2003 SLIDE 9
SIFT local features are
invariant...
adapted from David Lee SLIDE 10
like me they are robust...
Text
... to changes in illumination, noise, viewpoint, occlusion, etc.
SLIDE 11
I am sure you want to know
how to build them
Text
- 1. find interest points or “keypoints”
- 2. find their dominant orientation
- 3. compute their descriptor
- 4. match them on other images
SLIDE 12
Text
- 1. find interest points or “keypoints”
SLIDE 13
Text
keypoints are taken as maxima/minima
- f a DoG pyramid
in this settings, extremas are invariant to scale...
SLIDE 14
a DoG (Difference of Gaussians) pyramid is simple to compute...
even him can do it! before after
adapted from Pallus and Fleishman SLIDE 15
then we just have to find
neighborhood extremas
in this 3D DoG space
if a pixel is an extrema in its neighboring region he becomes a candidate
keypoint
SLIDE 16
too many keypoints?
- 1. remove
low contrast
- 2. remove
edges
adapted from wikipedia SLIDE 17
Text
- 2. find their dominant orientation
SLIDE 18
each selected keypoint is assigned to one or more “dominant” orientations... ... this step is important to achieve rotation invariance
SLIDE 19
How?
using the DoG pyramid to achieve scale invariance:
- a. compute image gradient
magnitude and orientation
- b. build an orientation histogram
- c. keypoint’s orientation(s) = peak(s)
SLIDE 20
- a. compute image gradient
magnitude and orientation
SLIDE 21
- b. build an orientation histogram
SLIDE 22
- c. keypoint’s orientation(s) = peak(s)
*
* the peak ;-)
SLIDE 23
Text
- 3. compute their descriptor
SLIDE 24
SIFT descriptor = a set of orientation histograms
4x4 array x 8 bins = 128 dimensions (normalized) 16x16 neighborhood
- f pixel gradients
SLIDE 25
Text
- 4. match them on other images
SLIDE 26
How to atch?
nearest neighbor hough transform voting least-squares fit etc.
SLIDE 27
SIFT is great!
Text
\\ invariant to affine transformations \\ easy to understand \\ fast to compute
SLIDE 28
Extension example: Spatial Pyramid Matching using SIFT
Text
Beyond Bags of Features: Spatial Pyramid Matching for Recognizing Natural Scene Categories
Svetlana Lazebnik1
slazebni@uiuc.edu
1Beckman Institute
University of Illinois
Cordelia Schmid2
Cordelia.Schmid@inrialpes.fr
2INRIA Rhˆ
- ne-Alpes
Montbonnot, France
Jean Ponce1,3
ponce@cs.uiuc.edu
3Ecole Normale Sup´
erieure Paris, France
CVPR 2006
SLIDE 29
Object Recognition from Local Scale-Invariant Features
David G. Lowe Computer Science Department University of British Columbia Vancouver, B.C., V6T 1Z4, Canada lowe@cs.ubc.ca Abstract An object recognition system has been developed that uses a new class of local image features. The features are invariant to image scaling, translation,and rotation, and partially in- variant to illuminationchanges and affine or 3D projection. translation, scaling, and rotation, and partially invariant to illumination changes and affine or 3D projection. Previous approaches to local feature generation lacked invariance to scale and were more sensitive to projective distortion and illumination change. The SIFT features share a number of properties in common with the responses of neurons in infe-Lowe (1999)
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
- f Histograms of Oriented Gradient (HOG) descriptors sig-
- tion. We study the influence of each stage of the computation
Nalal and Triggs (2005)
A Discriminatively Trained, Multiscale, Deformable Part Model
Pedro Felzenszwalb University of Chicago pff@cs.uchicago.edu David McAllester Toyota Technological Institute at Chicago mcallester@tti-c.org Deva Ramanan UC Irvine dramanan@ics.uci.edu Abstract This paper describes a discriminatively trained, multi- scale, deformable part model for object detection. Our sys- tem achieves a two-fold improvement in average precision- ver the best performance in the 2006 PASCAL person de-
Felzenszwalb et al. (2008)
SLIDE 30
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ
- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
{Navneet.Dalal,Bill.Triggs}@inrialpes.fr, http://lear.inrialpes.fr Abstract
We study the question of feature sets for robust visual ob- ject recognition, adopting linear SVM based human detec- tion as a test case. After reviewing existing edge and gra- dient based descriptors, we show experimentally that grids
- f Histograms of Oriented Gradient (HOG) descriptors sig-
nificantly outperform existing feature sets for human detec-
- tion. We study the influence of each stage of the computation
- n performance, concluding that fine-scale gradients, fine
- rientation binning, relatively coarse spatial binning, and
high-quality local contrast normalization in overlapping de- scriptor blocks are all important for good results. The new We briefly discuss previous work on human detection in §2, give an overview of our method §3, describe our data sets in §4 and give a detailed description and experimental evaluation of each stage of the process in §5–6. The main conclusions are summarized in §7.
2 Previous Work
There is an extensive literature on object detection, but here we mention just a few relevant papers on human detec- tion [18,17,22,16,20]. See [6] for a survey. Papageorgiou et al [18] describe a pedestrian detector based on a polynomial SVM using rectified Haar wavelets as input descriptors, with
first of all, let me put this paper in context
SLIDE 31
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ
- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
{Navneet.Dalal,Bill.Triggs}@inrialpes.fr, http://lear.inrialpes.fr
histograms of local image measurement have been quite successful
Swain & Ballard 1991 - Color Histograms Schiele & Crowley 1996 - Receptive Fields Histograms Lowe 1999 - SIFT Schneiderman & Kanade 2000 - Localized Histograms of Wavelets Leung & Malik 2001 - Texton Histograms Belongie et al. 2002 - Shape Context Dalal & Triggs 2005 - Dense Orientation Histograms ...
λ λ λ SLIDE 32
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ
- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
{Navneet.Dalal,Bill.Triggs}@inrialpes.fr, http://lear.inrialpes.fr
tons of “feature sets” have been proposed
features
Gravrila & Philomen 1999 - Edge Templates + Nearest Neighbor Papageorgiou & Poggio 2000, Mohan et al. 2001, DePoortere et al. 2002 - Haar Wavelets + SVM Viola & Jones 2001 - Rectangular Differential Features + AdaBoost Mikolajczyk et al. 2004 - Parts Based Histograms + AdaBoost Ke & Sukthankar 2004 - PCA-SIFT ...
SLIDE 33
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ
- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
{Navneet.Dalal,Bill.Triggs}@inrialpes.fr, http://lear.inrialpes.fr
localizing humans in images is a challenging task...
difficult!
Wide variety of articulated poses Variable appearance/clothing Complex backgrounds Unconstrained illuminations Occlusions Different scales ...
SLIDE 34
Approach
- robust feature set (HOG)
- simple classifier (linear SVM)
- fast detection (sliding window)
SLIDE 35 adapted from Bill Triggs
SLIDE 36
- Gamma normalization
- Space: RGB, LAB or Gray
- Method: SQRT or LOG
SLIDE 37
- Filtering with simple
masks
diagonal Sobel uncentered centered cubic-corrected * centered performs the best *
SLIDE 38
- Filtering with simple
masks
centered
remember SIFT ?
SLIDE 39
...after filtering, each “pixel” represents an oriented gradient...
SLIDE 40
...pixels are regrouped in “cells”, they cast a weighted vote for an
- rientation histogram...
HOG (Histogram of Oriented Gradients)
SLIDE 41
a window can be represented like that
SLIDE 42
then, cells are locally normalized using overlapping “blocks”
SLIDE 43
they used two types of blocks
- rectangular
- similar to SIFT (but dense)
- circular
- similar to Shape Context
SLIDE 44
and four different types of block
normalization
SLIDE 45
like SIFT, they gain invariance... ...to illuminations, small deformations, etc.
SLIDE 46
finally, a sliding window is classified by a simple linear SVM
SLIDE 47
during the learning phase, the algorithm “looked” for hard examples
Training
adapted from Martial Hebert SLIDE 48
average gradients positive weights negative weights
SLIDE 49
Example
SLIDE 50
Example
adapted from Bill Triggs SLIDE 51
Example
adapted from Martial Hebert SLIDE 52
Results
10 −6 10 −5 10 −4 10 −3 10 −2 10 −1 0.01 0.02 0.05 0.1 0.2 DET − different descriptors on MIT database false positives per window (FPPW) miss rate- Lin. R−HOG
- Lin. C−HOG
- Lin. EC−HOG
- Lin. G−ShaceC
- Lin. E−ShaceC
- Ker. R−HOG
- Lin. R2−HOG
- Lin. R−HOG
- Lin. C−HOG
- Lin. EC−HOG
- Lin. G−ShapeC
- Lin. E−ShapeC
Figure 3. The performance of selected detectors on (left) MIT and (right) INRIA data sets. See the text for details.
not good good
90% @ 1e-5 FPPW
SLIDE 53
Experiments
10 −6 10 −5 10 −4 10 −3 10 −2 10 −1 0.01 0.02 0.05 0.1 0.2 0.5 DET − effect of gradient scale σ false positives per window (FPPW) miss rate σ=0 σ=0.5 σ=1 σ=2 σ=3 σ=0, c−cor 10 −6 10 −5 10 −4 10 −3 10 −2 10 −1 0.01 0.02 0.05 0.1 0.2 0.5 DET − effect of number of orientation bins β false positives per window (FPPW) miss rate bin= 9 (0−180) bin= 6 (0−180) bin= 4 (0−180) bin= 3 (0−180) bin=18 (0−360) bin=12 (0−360) bin= 8 (0−360) bin= 6 (0−360) 10 −5 10 −4 10 −3 10 −2 0.02 0.05 0.1 0.2 DET − effect of normalization methods false positives per window (FPPW) miss rate L2−Hys L2−norm L1−Sqrt L1−norm No norm Window norm(a) (b) (c)
10 −6 10 −5 10 −4 10 −3 10 −2 10 −1 0.01 0.02 0.05 0.1 0.2 0.5 DET − effect of overlap (cell size=8, num cell = 2x2, wt=0) false positives per window (FPPW) miss rate- verlap = 3/4, stride = 4
- verlap = 1/2, stride = 8
- verlap = 0, stride =16
(d) (e) (f)
Figure 4. For details see the text. (a) Using fine derivative scale significantly increases the performance. (‘c-cor’ is the 1D cubic-corrected point derivative). (b) Increasing the number of orientation bins increases performance significantly up to about 9 bins spaced over 0◦– 180◦. (c) The effect of different block normalization schemes (see §6.4). (d) Using overlapping descriptor blocks decreases the miss rate by around 5%. (e) Reducing the 16 pixel margin around the 64×128 detection window decreases the performance by about 3%. (f) Using a Gaussian kernel SVM, exp(−γx1 − x22), improves the performance by about 3%. SLIDE 54
Experiments
t
- ).
r i- ,
- er
4x4 6x6 8x8 10x10 12x12
Cell size (pixels)
1x1 2x2 3x3 4x4 Block size (Cells) 5 10 15 20
Miss Rate (%)
Figure 5. The miss rate at 10−4 FPPW as the cell and block sizes
- change. The stride (block overlap) is fixed at half of the block size.
3×3 blocks of 6×6 pixel cells perform best, with 10.4% miss rate.
SLIDE 55
Further Development
- Detection on Pascal VOC (2006)
- Human Detection in Movies (ECCV 2006)
- US Patent by MERL (2006)
- Stereo Vision HoG (ICVES 2008)
SLIDE 56
Extension example:
Pyramid HoG++
SLIDE 57
A simple demo...
SLIDE 58
A simple demo...
VIDEO HERE
SLIDE 59
so, it doesn’t work ?!? no no, it works... ...it just doesn’t work well...
SLIDE 60
Object Recognition from Local Scale-Invariant Features
David G. Lowe Computer Science Department University of British Columbia Vancouver, B.C., V6T 1Z4, Canada lowe@cs.ubc.ca Abstract An object recognition system has been developed that uses a new class of local image features. The features are invariant to image scaling, translation,and rotation, and partially in- variant to illuminationchanges and affine or 3D projection. translation, scaling, and rotation, and partially invariant to illumination changes and affine or 3D projection. Previous approaches to local feature generation lacked invariance to scale and were more sensitive to projective distortion and illumination change. The SIFT features share a number of properties in common with the responses of neurons in infe-Lowe (1999)
Histograms of Oriented Gradients for Human Detection
Navneet Dalal and Bill Triggs INRIA Rhˆ- ne-Alps, 655 avenue de l’Europe, Montbonnot 38334, France
- f Histograms of Oriented Gradient (HOG) descriptors sig-
- tion. We study the influence of each stage of the computation
Nalal and Triggs (2005)
A Discriminatively Trained, Multiscale, Deformable Part Model
Pedro Felzenszwalb University of Chicago pff@cs.uchicago.edu David McAllester Toyota Technological Institute at Chicago mcallester@tti-c.org Deva Ramanan UC Irvine dramanan@ics.uci.edu Abstract This paper describes a discriminatively trained, multi- scale, deformable part model for object detection. Our sys- tem achieves a two-fold improvement in average precision- ver the best performance in the 2006 PASCAL person de-
Felzenszwalb et al. (2008)
SLIDE 61
This paper describes one
- f the best algorithm in
- bject detection...
SLIDE 62
They used the following methods:
HOG Features Deformable Part Model Latent SVM
SLIDE 63
They used the following methods:
HOG Features
Introduced by Dalal & Triggs (2005)
SLIDE 64
They used the following methods:
Deformable Part Model
Introduced by Fischler & Elschlager (1973)
SLIDE 65
They used the following methods:
Latent SVM
Introduced by the authors
SLIDE 66
HOG Features
SLIDE 67
Model Overview
detection root filter part filters deformation models
SLIDE 68
HOG Features
// 8x8 pixel blocks window // features computed at different resolutions (pyramid)
SLIDE 69
HOG Pyramid
SLIDE 70
Deformable Part Model
SLIDE 71
Deformable Part Model
// each part is a local property // springs capture spatial relationships // here, the springs can be “negative”
SLIDE 72
root filter part filters deformable model Deformable Part Model
detection score =
sum of filter responses - deformation cost
SLIDE 73
Deformable Part Model filters feature vector (at position p in the pyramid H) position relative to the root location coefficients of a quadratic function on the placement
score of a placement
SLIDE 74
Latent SVM
SLIDE 75
Latent SVM filters and deformation parameters features part displacements
SLIDE 76
Latent SVM
SLIDE 77
Bonus
// Data Mining Hard Negatives // Model Initialization
SLIDE 78
Results
Pascal VOC 2006
SLIDE 79
Results
Models learned
SLIDE 80
Experiments ~ Dalal’s model ~ Dalal’s + LSVM
SLIDE 81
Examples
errors
SLIDE 82
A simple demo...
SLIDE 83
A simple demo...
SLIDE 84
Conclusions
so, it doesn’t work ?!? no no, it works... ...it just doesn’t work well... ...or there is a problem with the seat-computer interface...
SLIDE 85
Conclusion
SLIDE 86
