NSF Midscale RI-2 Proposal for NSF Midscale RI-2 Proposal for DUNE APA Production in the US DUNE APA Production in the US Funding Subaward Funding Subaward Institution: University of Texas, Arlington Institution: University of Texas,

slide-1
SLIDE 1

1

NSF Midscale RI-2 Proposal for NSF Midscale RI-2 Proposal for DUNE APA Production in the US DUNE APA Production in the US Funding Subaward Funding Subaward

Institution: University of Texas, Arlington Institution: University of Texas, Arlington PIs: Jonathan Asaadi PIs: Jonathan Asaadi Work Package: X-plane wiring boards Work Package: X-plane wiring boards

slide-2
SLIDE 2

2

  • Jonathan Asaadi

– APA Consortium – Near Detector (ArgonCube) – Detector R&D

  • Jae Yu

– Field Cage/HV Consortium – Dual Phase – BSM Group Leader

  • One additional faculty member

aiming to join Intensity Frontier in our upcoming umbrella renewal (Apply this fall)

– Andrew Brandt: Will be based at UTA aiding

in DUNE and SBN projects

UTA Group: Faculty UTA Group: Faculty

slide-3
SLIDE 3

3

  • DOE IF-Base grant support

– 2 PI’s (Asaadi/Yu) – 1 post-doc: (50:50 SBN/DUNE) – 2 graduate students

  • 1 SBN (MicroBooNE / ICARUS)
  • 1 DUNE (protoDUNE single/dual phase)

– 3 undergraduates

  • Unfunded scientific labor (off-project labor)

– We are assuming 760 hours of a post-doc and 760 hours of a graduate student

during this five year period to suprivse/lead production

  • This is in addition to the current funded resources
  • This is only ~0.1 FTE per year, so represents a small risk from UTA overall, but is a

component of why we will ask for increased base support in our upcoming renewal

  • Obviously, we would like dedicated person (post-doc / student)

who can contribute to APA production at PSL/U. Chicago/Yale as part of this effort

– Help be a bridge between board level production and resources needed at

winding facilities

UTA Group: Post-doc & Students UTA Group: Post-doc & Students

slide-4
SLIDE 4

4

X-Plane Wire Boards X-Plane Wire Boards

DUNE DocDB 13208 describing changes to the boards between protoDUNE and DUNE

slide-5
SLIDE 5

5

  • F
  • t

B

  • a

r d s

– D

i m e n s i

  • n

s s t r e t c h e d t

  • fj

t l a r g e r f r a m e t u b e s

  • H

e a d B

  • a

r d s

– I

n c r e a s e d s p a c i n g b e t w e e n w i r e t r a c e s

– I

m p r

  • v

e d i n t e r f a c e f

  • r

e l e c t r i c a l t e s t i n g

X-Plane Wire Boards X-Plane Wire Boards

Old New

X-Plane Foot boards X-Plane Head boards

slide-6
SLIDE 6

6

X-Plane Wire Boards X-Plane Wire Boards

Slide taken from APA 60% Readiness Review

slide-7
SLIDE 7

7

X-Plane Labor Board Cost Estimate X-Plane Labor Board Cost Estimate

  • Currently using the Board Cost Estimate

provided from PSL to assess what will be needed for labor and setup costs

slide-8
SLIDE 8

8

  • Equipment costs for the X-Plane boards is $334,527 ($2001/APA)

– 30 boards per APA = $66.70 / board

  • Does this include tooth strips, solder mask, cleaning supplies?
  • UTA is requesting $5000 in setup costs

– Includes $1,500 for two dedicated workbenches ($750/bench)

  • One for expoxy, solder mask, cleaning
  • One for socket insertion and curing

– Expoxy and Solder mask ($1,500) – Generic lab supplies ($1,500)

  • Safety gloves/goggles, blades, ethyl alcohol, etc…

– Epoxy/Solder baking oven ($500)

  • UTA is assuming we will ship boards for each APA as they are

completed (20 head boards and 10 foot boards)

– Conservatively estimated the FedEx shipping for a 25 lb large box from UTA to

Yale overnight shipping (~$170)

– This cost estimate could be much lower if we assumed no urgency in the

shipping (express saver ~ $20)

X-Plane Equipment Cost Estimate X-Plane Equipment Cost Estimate

slide-9
SLIDE 9

9

  • Equipment cost estimate included in the pre-proposal

– Nothing has changed from UTA’s perspecitve – Could lower our shipping estimates if we don’t want to be quite as

conservative

  • Not the largest cost driver...but might be worthwhile to discuss
  • UTA has not pursued (yet) quotes from vendors or additional

suppliers

– Plan is to use the same vendors at PSL – Will work with PSL to try to find additional vendors based on their experience

X-Plane Equipment Cost Estimate X-Plane Equipment Cost Estimate

slide-10
SLIDE 10

10

  • Assuming 30 X-plane boards per APA and 152 APA’s produced over 5

years

– August 2020 – July 2025 – 4560 boards total

  • Assuming a schedule profile from the preproposal budget

– Year 1: 15.1% (688 boards = 23 APA’s) – Year 2: 21.7% (990 boards = 33 APA’s) – Year 3: 21.7% (990 boards = 33 APA’s) – Year 4: 21.7% (990 boards = 33 APA’s) – Year 5: 19.8% (902 boards = 30 APA’s)

  • From PSL numbers we used that there would be 304 hours of

engineering time and 7600 hours of technical staff hours for all 4560 boards

– 0.07 hours of engineering per board – 1.7 hours of technical staff per board

  • We are requesting support for use of UTA Machince Shop Engineer for all 304 hours over 5

years

  • We assume x2 multiplier for undergraduate labor to replace technical staff (3.4 hours per board)

X-Plane Wire Boards: Labor X-Plane Wire Boards: Labor

slide-11
SLIDE 11

11

Year 1 Year 1 Year 2 Year 2 Year 3 Year 3 Year 4 Year 4 Year 5 Year 5 Number of Boards 688 990 990 990 902 Number of UTA Undergrad Hours 2339 3366 3366 3366 3067 Number of UTA Undergrads 5 7 7 7 7 Hours/ week/UG 9.0 9.3 9.3 9.3 8.4 Salary $15/hr + 8.5% fringe $16.28 $16.61

(2% escalation)

$16.94

(2% escalation)

$17.28

(2% escalation)

$17.62

(2% escalation)

Total UG Labor $38,079 $55,909 $57,020 $58,164 $54,041 Original Numbers $37,286 $54,655 $55,748 $56,862 $52,920

X-Plane Wire Boards: UG Labor X-Plane Wire Boards: UG Labor

slide-12
SLIDE 12

12

Year 1 Year 1 Year 2 Year 2 Year 3 Year 3 Year 4 Year 4 Year 5 Year 5 Number of Boards 688 990 990 990 902 Number of Engineer Hours 48 70 70 70 63 Number of Engineers 1 1 1 1 1 Hours/ week/Eng. 0.92 1.3 1.3 1.3 1.2 Salary $65 (includes

fringe)

$65.00 $65.00 $65.00 $65.00 $65.00 Total Engineer Labor $3,120 $4,550 $4,550 $4,550 $4,095 Original Numbers $3,120 $4,550 $4,550 $4,550 $4,095

X-Plane Wire Boards: Engineering X-Plane Wire Boards: Engineering

slide-13
SLIDE 13

13

X-Plane Wire Boards: Labor X-Plane Wire Boards: Labor

  • Labor cost estimate updated since the pre-

proposal

– ~7% increase in labor to match the number of hours more

carefully

slide-14
SLIDE 14

14

Facilities for APA Project Facilities for APA Project

1 1 2 2 3 3

UTA has four lab spaces available immediately available immediately for use in this project 1) ~700 sq foot finished lab space with purified liquid argon capabilities (Asaadi’s Lab) 2) ~700 sq foot finished lab space (Yu’s Lab) 3) ~1000 sq foot unfinished lab space with class 100,000 clean tent, access to loading doc and physics machine shop

  • Space used for Dual Phase Field Cage Construction

4) ~300 sq foot clean storage space used for shipping and receiving

4 4

slide-15
SLIDE 15

15

Facilities for APA Project Facilities for APA Project

4 4 3 3

Unfinished lab space with class 100,000 clean tent, access to loading doc and physics machine shop

  • Space inside and outside the clean

tent for working space (depending

  • n what is required)

Clean storage space used for shipping and receiving (shown in orange)

Clean Tent Clean Tent

slide-16
SLIDE 16

16

Facilities for APA Project Facilities for APA Project

4 4 3 3

Unfinished lab space with class 100,000 clean tent, access to loading doc and physics machine shop

  • Space inside and outside the clean

tent for working space (depending

  • n what is required)

Clean storage space used for shipping and receiving (shown in orange)

Clean Tent Clean Tent

slide-17
SLIDE 17

17

Facilities for APA Project Facilities for APA Project

View from inside clean tent area

slide-18
SLIDE 18

18

  • UTA has had success using the model of

undergraduate labor supurvised by G.S and postdoc’s for construction level projects

– Jae often quotes how UTA delivered Dual Phase Field cage on

time and under budget!1

  • 1 I make no claim as to the validity of this statement (I assume it is true)

Facilities for APA Project Facilities for APA Project

slide-19
SLIDE 19

19

Facilities for APA Project Facilities for APA Project

Finished lab space with purified liquid argon capabilities (Asaadi’s Lab)

  • Floor space can be made

available for both stations in this lab as well (shown in red)

  • Any spot cyrotesting that may

want to be done can be done in this lab

1 1

slide-20
SLIDE 20

20

Facilities for APA Project Facilities for APA Project

Finished lab space with purified liquid argon capabilities (Asaadi’s Lab)

  • Floor space can be made

available for both stations in this lab as well (shown in red)

  • Any spot cyrotesting that may

want to be done can be done in this lab

1 1

slide-21
SLIDE 21

21

Facilities for APA Project Facilities for APA Project

Finished lab space (Yu’s Lab)

  • Clean tented area which

could be used (shown in yellow)

  • Has direct access to storage

area via unfinished work space

2 2

slide-22
SLIDE 22

22

Facilities for APA Project Facilities for APA Project

Finished lab space (Yu’s Lab)

  • Clean tented area which

could be used (shown in yellow)

  • Has direct access to storage

area via unfinished work space

2 2

slide-23
SLIDE 23

23

Facilities for APA Project Facilities for APA Project

1 1 2 2 3 3

An additional ~2100 sq feet of lab space is expected to be reallocated to the HEP group in 2020/2021 for use in DUNE construction projects

  • Currently occupied by chemistry group

– New building finished in Spring 2019 for chemistry researchers – Pending successful construction funding, commitment from University

VPR to help recapture this space

– Planned use for Field cage, APA, and near detector activities

4 4

slide-24
SLIDE 24

24

Year 1 Year 2 Year 3 Year 4 Year 5 Setup Costs $5,000

  • X-Plane

Boards $45,890 $66,033 $66,033 $66,033 $60,163 Undergrad Labor $38,079 $55,909 $57,020 $58,164 $54,041 Engineer Labor $3,120 $4,550 $4,550 $4,550 $4,095 Shipping $3,900 $5,610 $5,610 $5,610 $5,110 Total Direct $95,989 $132,102 $133,213 $134,357 $123,409

Summary Summary

  • UTA has little needed setup and a ready pool of undergraduate labor to

participate in this work

– Successfully used undergraduates for Dual Phase Field Cage construction project

already

– Working space can be made ready for use with 2-3 weeks lead time

  • 54% indirect cost will be applied to modified direct cost

– Excludes x-plane board material
