better design less parts N channel MOSFETs with integrated drivers for load switch applications December 2012 Silego Technology www.silego.com GFET2 Product Line Dimension, Min. Min/Max Min/Max RDS ON , Part Number Description Package

slide-1
SLIDE 1

December 2012 Silego Technology www.silego.com

better design less parts

N channel MOSFETs with integrated drivers for load switch applications

slide-2
SLIDE 2

www.silego.com Silego Technology Inc. proprietary & confidential

2

Part Number Description Package Dimension, mm (LxWxH) Min/Max VDD Min/Max VD IDS, A RDSON, mOhm Min. TON time, us SLG59M237 (-20 to +70C) Dual GreenFET2 Load Switch TDFN-14 3x2x0.75 4.75/5.25 1/VDD 4.5 17 500 SLG59M247 (-40 to +85C) Dual GreenFET2 Load Switch TDFN-14 3x2x0.75 4.75/5.25 1/VDD 3 17 500

GFET2 Product Line

slide-3
SLIDE 3

www.silego.com Silego Technology Inc. proprietary & confidential

3

GFET2 Advantages

FEATURES

2x3mm TDFN-14 package 0.1uA Sleep and 50uA Active Mode power consumption External capacitor to adjust VS ramp rate VD 1.0V to VDD Two internal discharges per channel for gate and source Independent Ramp Control Integrated VGS Charge Pumps

BENEFITS

Smallest complete load switch with Rds(ON) <20 mohm Direct connect to controller Saves battery power when directly connected to a Li-Ion battery Improves power supply voltage margin Safer design as compared to discrete components Easy to use

slide-4
SLIDE 4

www.silego.com Silego Technology Inc. proprietary & confidential

4

Example Product SLG59M237

slide-5
SLIDE 5

www.silego.com Silego Technology Inc. proprietary & confidential

5

Ramp Rates

slide-6
SLIDE 6

www.silego.com Silego Technology Inc. proprietary & confidential

6

GFET2 Ramp Rate

Voltage Ramp rate capacitance value (pF) VD 250 500 986 1500 1960 2450 5 0.228 0.67 1.13 2.18 2.9 4.23 5.2 3.3 0.19 0.5 0.83 1.6 2.13 3.07 3.7 1 0.13 0.265 0.407 0.735 0.97 1.37 1.67

Typical ramp rate in mS (10%-90% risetime)

slide-7
SLIDE 7

www.silego.com Silego Technology Inc. proprietary & confidential

7

GFET2 Ramp Rate

VDD ON Vs

Conditions: VDD = 5.0V; CCAP = 0pF

VDD ON Vs VDD ON Vs

slide-8
SLIDE 8

www.silego.com Silego Technology Inc. proprietary & confidential

8

GFET2 Ramp Rate

Conditions: VDD = 5.0V; CCAP = 500pF

VDD ON Vs VDD ON Vs ON Vs VDD

slide-9
SLIDE 9

www.silego.com Silego Technology Inc. proprietary & confidential

9

GFET2 Ramp Rate

Conditions: VDD = 5.0V; CCAP = 1000pF

VDD ON Vs VDD ON Vs ON Vs VDD

slide-10
SLIDE 10

www.silego.com Silego Technology Inc. proprietary & confidential

10

GFET2 Ramp Rate

Conditions: VDD = 5.0V; CCAP = 1500pF

VDD ON Vs VDD ON Vs ON Vs VDD

slide-11
SLIDE 11

www.silego.com Silego Technology Inc. proprietary & confidential

11

GFET2 Ramp Rate

Conditions: VDD = 5.0V; CCAP = 2000pF

VDD ON Vs VDD ON Vs ON Vs VDD

slide-12
SLIDE 12

www.silego.com Silego Technology Inc. proprietary & confidential

12

Application example

slide-13
SLIDE 13

www.silego.com Silego Technology Inc. proprietary & confidential

13

Before GFET2

Discharge Circuit

slide-14
SLIDE 14

www.silego.com Silego Technology Inc. proprietary & confidential

14

After GFET2

slide-15
SLIDE 15

www.silego.com Silego Technology Inc. proprietary & confidential

15

Tools to help you

  • GreenFET2 Test board
  • GreenFET2 Datasheets for SLG59M237, SLG59M247
