SERDP & ESTCP Webinar Series Munitions Response: Land Based Program Closeout November 12, 2015 SERDP & ESTCP Webinar Series (#22) SERDP & ESTCP Webinar Series Welcome and Introductions Rula Deeb, Ph.D. Webinar Coordinator SERDP

slide-1
SLIDE 1

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Munitions Response: Land Based Program Closeout

November 12, 2015

slide-2
SLIDE 2

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Welcome and Introductions

Rula Deeb, Ph.D. Webinar Coordinator

slide-3
SLIDE 3

SERDP & ESTCP Webinar Series (#22)

Agenda

  • Webinar Logistics
  • Dr. Rula A. Deeb, Geosyntec Consultants

(5 minutes)

  • Overview of SERDP and ESTCP
  • Dr. Herb Nelson, SERDP and ESTCP

(5 minutes)

  • Advanced Geophysical Classification Lessons Learned at

Former Camp San Luis Obispo, California

  • Mr. David Wright, CH2M

(22 minutes + Q&A)

  • Risk Reduction Utilizing Advanced Geophysical Classification

at Fort Ord, California

  • Mr. John Jackson, USACE Sacramento

(22 minutes + Q&A)

  • Perspectives on Advanced Geophysical Classification for

Munitions Response

  • Mr. Doug Maddox, EPA

(12 minutes)

  • Final Q&A Session

5

slide-4
SLIDE 4

SERDP & ESTCP Webinar Series (#22)

How to Ask Questions

6

Type and send questions at any time using the Q&A panel

slide-5
SLIDE 5

SERDP & ESTCP Webinar Series (#22)

In Case of Technical Difficulties

  • Delays in the broadcast audio
  • Click the mute/connect button
  • Wait 3-5 seconds
  • Click the mute/connect button again
  • If delays continue, call into the conference line

− U.S./Canada: 1-877-776-3503 − International: 330-871-6014 − Required conference ID: 14239646

  • Submit a question using the chat box

7

slide-6
SLIDE 6

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

SERDP and ESTCP Overview

Herb Nelson, Ph.D. Munitions Response Program Manager

slide-7
SLIDE 7

SERDP & ESTCP Webinar Series (#22)

SERDP

  • Strategic Environmental Research and

Development Program

  • Established by Congress in FY 1991
  • DoD, DOE and EPA partnership
  • SERDP is a requirements driven program which

identifies high-priority environmental science and technology investment opportunities that address DoD requirements

  • Advanced technology development to address near

term needs

  • Fundamental research to impact real world

environmental management

9

slide-8
SLIDE 8

SERDP & ESTCP Webinar Series (#22)

ESTCP

  • Environmental Security Technology

Certification Program

  • Demonstrate innovative cost-effective

environmental and energy technologies

  • Capitalize on past investments
  • Transition technology out of the lab
  • Promote implementation
  • Facilitate regulatory acceptance

10

slide-9
SLIDE 9

SERDP & ESTCP Webinar Series (#22)

Program Areas

  • 1. Energy and Water
  • 2. Environmental Restoration
  • 3. Munitions Response
  • 4. Resource Conservation and

Climate Change

  • 5. Weapons Systems and

Platforms

11

slide-10
SLIDE 10

SERDP & ESTCP Webinar Series (#22)

Munition Response

  • Munitions on land
  • Classification
  • Munitions underwater
  • Wide area and detailed

surveys

  • Cost-effective recovery

and disposal

  • Characteristics of

munitions underwater, their environment and mobility

12

slide-11
SLIDE 11

SERDP & ESTCP Webinar Series (#22)

SERDP and ESTCP Webinar Series

DATE Topics December 3, 2015 Emerging Contaminants: DoD Overview and State of Knowledge

  • n Fluorochemicals and 1,4-

Dioxane December 17, 2015 Watershed and Stormwater Management

13

slide-12
SLIDE 12

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series http://serdp-estcp.org/Tools-and- Training/Webinar-Series

slide-13
SLIDE 13

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Advanced Geophysical Classification Lessons Learned at Former Camp San Luis Obispo, California

David Wright CH2M

slide-14
SLIDE 14

SERDP & ESTCP Webinar Series (#22)

Agenda

  • Results and lessons learned

from the geophysical classification treatability study at the former Camp San Luis Obispo (CSLO)

  • Background
  • Detection approach/results
  • Classification approach/results
  • Lessons learned

○ QC challenges successes

16

slide-15
SLIDE 15

SERDP & ESTCP Webinar Series (#22)

Mob/DeMob Surface Sweep IVS & Seeds Detection Survey Cued Survey Dig UXO & Seeds Dig Clutter Current Practice 80% Reduction

  • f Clutter

49% Savings

Advanced Geophysical Classification

  • Buried metal objects are

classified as hazardous (dig) or non-hazardous (no dig)

  • Based upon intrinsic target features

derived using physics-based analyses of purpose-built geophysical sensors

  • Significant potential for savings

(time and money) for munitions response site remediation

  • Depends upon site-specific

considerations

○ Ratio of TOI vs non-TOI ○ Types of TOI ○ Cost per dig

17

Time (ms) 0.1 1 10 Polarizability (m3/A) 0.001 0.01 0.1 1 10 Time (ms) 0.1 1 10 Polarizability (m3/A) 0.001 0.01 0.1 1

slide-16
SLIDE 16

SERDP & ESTCP Webinar Series (#22)

Advanced Geophysical Classification

  • New paradigm (leaving metal in the ground)

requires the following

  • Careful, detailed, scientifically sound planning

○ What are the project objectives? ○ How do we plan to achieve them?

  • Formalized quality management and reporting

○ What measurement quality objectives are required to achieve the project objectives? ○ Were they achieved?

  • Transparent processes
  • Stakeholder involvement

18

slide-17
SLIDE 17

SERDP & ESTCP Webinar Series (#22)

Project Description

Treatability Study

  • The overall objective of the treatability study is to evaluate the Advanced

Geophysical Classification process as an effective and efficient treatability

  • ption for potential future removal actions at the former CSLO

19

  • 7 acres
  • Hill-side
  • Grassland
  • Variable anomaly density
slide-18
SLIDE 18

SERDP & ESTCP Webinar Series (#22)

Project Planning

  • Extensive and inclusive planning process
  • USACE Project Team (John Jackson, Andy Schwartz,

Lloyd Godard, B. J. Allen, and others)

  • ESTCP (Herb Nelson, Anne Andrews)
  • DTSC (Ed Walker, Roman Racca, Jim Pastorick)
  • AcornSI (Tom Furuya, Dean Keiswetter)
  • CH2M (George DeMetropolis, Tamir Klaff, David Wright)
  • EDQW Advanced Geophysical Classification Subgroup

(Jordan Adelson, Ed Corl, Carla Garbarini)

  • Quality Assurance Project Plan (QAPP) format

used was forerunner to Geophysical Classification for Munitions Response (GCMR) QAPP template

  • Project objectives
  • Measurement quality objectives
  • Responses to QC failures
  • Reporting requirements

20

slide-19
SLIDE 19

SERDP & ESTCP Webinar Series (#22)

Treatability Study Detection Objective

  • Detection Objective: equivalent of 37-mm projectile at

30 cm (1.7 mV/A)

21

slide-20
SLIDE 20

SERDP & ESTCP Webinar Series (#22)

Detection Survey

  • Amplitude Response Detection

Threshold 1.5 mV: >18,000 anomalies

22

slide-21
SLIDE 21

SERDP & ESTCP Webinar Series (#22)

Detection Survey

23

  • High target density regions
  • Classification is not

appropriate for very high anomaly density (saturated response) regions

  • High density region

identified and excluded from Treatability Study

slide-22
SLIDE 22

SERDP & ESTCP Webinar Series (#22)

‘Amplitude Response’ Target Selection

  • Uses only Z component, monostatic data

(analogous to EM61)

  • Selects all anomalous responses > detection

threshold

  • Many small, shallow targets selected to capture

deeper targets of interest

24

slide-23
SLIDE 23

SERDP & ESTCP Webinar Series (#22)

Advanced Detection

  • Advanced Detection uses all 12 measurements

for each transmit event (Amplitude Response uses only 1 of 12)

  • Coherent signal from all 12 measurements

provides better depth of detection (better signal to noise due to more data)

25

slide-24
SLIDE 24

SERDP & ESTCP Webinar Series (#22)

‘Advanced Detection’ Target Selection

  • Step 1: Initial Dipole Fit

Coherence detection

  • For every 0.1 x 0.1 m grid

node use the surrounding data (1 x 1 m) to fit to a dipole

  • Map the fit coherence as the

initial detection metric and find ‘dipole detection areas’

  • Step 2: 1, 2 and 3 source

dipole fit routines to identify all potential sources (‘+’ symbols) and their features (size, wall thickness) within ‘dipole detection area’

26

slide-25
SLIDE 25

SERDP & ESTCP Webinar Series (#22)

‘Advanced Detection’ Target Selection

Step 4: Merge collocated sources to get final ‘Advanced Detection’ targets (‘O’ symbols)

27

Step 3: Remove sources too small or thin-walled to be possible TOIs

Step 3: Filter out sources based upon Size and Decay (robust features)

10-2 10-1 10 0 10 1 10 1 10 0 10-1 10-2 10-3

β amplitude Time (ms)

Size = (β12 + β22 + β32)1/2 Decay = ‘late’ size ÷ ‘early’ size

37 mm projectile

slide-26
SLIDE 26

SERDP & ESTCP Webinar Series (#22)

‘Advanced Detection’ Advantages

  • Rejects obvious ‘clutter’
  • Deeper depth of investigation
  • Separates and selects sources

with overlapping signatures

28

5 cm 30 cm

Amplitude Response Selections QC Seed (0.4 m MQO) Missed seed = RCA/CA = many more targets manually selected to cover anomaly ‘lobes’

slide-27
SLIDE 27

SERDP & ESTCP Webinar Series (#22)

‘Advanced Detection’ Advantages

  • Rejects obvious ‘clutter’
  • Deeper depth of investigation
  • Separates and selects sources

with overlapping signatures

29

5 cm 30 cm

Advanced Detection selections QC Seed (0.4 m MQO)

slide-28
SLIDE 28

SERDP & ESTCP Webinar Series (#22)

Classification Phase

  • >16,000 Amplitude

Response targets

  • 6,413 Advanced Detection

targets selected for cued investigations

  • 2 TEMTADS 2x2 units used

30

slide-29
SLIDE 29

SERDP & ESTCP Webinar Series (#22)

Classification Results

  • 575 excavations (plus

training digs)

  • 169 TOI recovered
  • Native TOI
  • 1 UXO (37-mm HE)
  • 3 MD with retained shape:

(2 x 81-mm bodies, 1 degraded 37-mm)

31

Partial ROC curve for SLO

slide-30
SLIDE 30

SERDP & ESTCP Webinar Series (#22)

Classification Cost Savings Projection

Estimated 73% reduction in costs for field activities

32

Advanced Geophysical Classification Conventional (EM61-MK2) Comments Dynamic Survey (mapping) $120,000 $35,000 Assumes $5,000/acre for EM61 surveys Cued Survey $440,000 Not Applicable Intrusive $300,000 $3,200,000 Assumes 16,000* anomalies (amplitude response) requiring intrusive investigation and a $200 per anomaly investigation cost TOTAL $860,000 $3,235,000

slide-31
SLIDE 31

SERDP & ESTCP Webinar Series (#22)

Lessons Learned

  • Effective and transparent internal quality

control is critical to success

  • Catches issues in a timely manner
  • Generates stakeholder and client confidence in

the results

  • Provides a basis for lessons learned to

advance the state of the art and avoid repetition of the same mistakes

33

slide-32
SLIDE 32

SERDP & ESTCP Webinar Series (#22)

QC Challenges Successes

34

QC Seed not identified as a TOI (caught with internal QC processes)

  • Detection (merged target O)

was within 0.4 m MQO of seed location

  • Array was within 0.2 m MQO
  • f detection location
  • Merge using 0.4 m put target

location too far from source

  • Re-merged sources using 0.2

m (O’s)

  • Recollected data over any

remerged targets not within 0.4 m of center of array

Root Cause Analysis (RCA) Corrective Action (CA)

slide-33
SLIDE 33

SERDP & ESTCP Webinar Series (#22)

QC Challenges Successes

35

QA Seed not recovered during intrusive investigation

  • Caught by internal QC check of dig results vs. classification prediction

Root Cause Analysis (RCA) Corrective Action (CA) Imprecision in placement of reacquisition flag put the seed

  • utside of the 0.4 m dig radius

Review of recorded flag locations and re-investigation of locations where flag location was greater than 0.15 m from fit location

≠ =

slide-34
SLIDE 34

SERDP & ESTCP Webinar Series (#22)

QC Challenges Successes

36 Predicted QA Seed positions relative to ground truth do not meet project MQO

Corrective Action (CA) No immediate CA indicated, but needs to be captured in ‘Lessons Learned’ Root Cause Analysis (RCA) Fit position vs QC seed ground truth and QA seed recovered positions suggests the problem is with the QA seed ground truth collected during emplacement

MQO 0.25 m

slide-35
SLIDE 35

SERDP & ESTCP Webinar Series (#22)

Lessons Learned

  • Positioning precision requirements are

much more stringent for all phases

  • QC/QA seeding*
  • Dynamic data collection
  • Target reacquisition for cued

investigations

  • Cued investigations
  • Target reacquisition for intrusive

investigations*

* These tasks are often done by personnel not involved in classification – must be retrained

37

slide-36
SLIDE 36

SERDP & ESTCP Webinar Series (#22)

Lessons Learned

  • QC documentation requires an extensive effort
  • For every ‘target’ left in the ground we must document all MQO’s

were met

○ Measurement verification (10 MQO’s) ○ Periodic tests - verify system against independent standards before/after data collection (6 MQO’s) ○ Project level verification/validation (4 MQO’s) 38

slide-37
SLIDE 37

SERDP & ESTCP Webinar Series (#22)

Lessons Learned

  • Intrusive investigation

might require a separate mob/de-mob for ‘Analyst Calibration’ digs

  • Analyst Calibration digs

(training digs) are used to finalize the site specific library as well as calibrate the final dig/no-dig threshold

  • The dig program can move through the ‘high

confidence’ TOI digs before the analysis determining the final prioritized list is finished

39

slide-38
SLIDE 38

SERDP & ESTCP Webinar Series (#22)

Lessons Learned

  • Early and detailed involvement of all

interested parties is a blueprint for success

  • Early involvement provides a comfort level with

the technology and processes

  • QC issues are inevitable

○Communication and transparency of process are critical for buy-in of interested parties

40

slide-39
SLIDE 39

SERDP & ESTCP Webinar Series (#22)

Conclusions

  • Advanced geophysical classification has

potential for significant savings

  • New paradigm (leaving metal in the

ground) requires the following:

  • Careful, detailed, scientifically sound planning
  • Formalized quality management and reporting
  • Transparent processes
  • Stakeholder involvement

41

slide-40
SLIDE 40

SERDP & ESTCP Webinar Series (#22)

Acknowledgments

  • USACE Project Team (John

Jackson, Andy Schwartz, Lloyd Godard, B. J. Allen, and others)

  • ESTCP (Herb Nelson, Anne

Andrews)

  • DTSC (Ed Walker, Roman

Racca, Jim Pastorick)

  • AcornSI (Tom Furuya, Dean

Keiswetter)

  • EDQW Advanced Geophysical

Classification Subgroup (Jordan Adelson, Ed Corl, Carla Garbarini)

42

slide-41
SLIDE 41

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series For additional information, please visit https://www.serdp-estcp.org/Tools-and- Training/Munitions-Response Speaker Contact Information

David.Wright@ch2m.com; 919-520-8673

slide-42
SLIDE 42

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Q&A Session 1

slide-43
SLIDE 43

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series Risk Reduction Utilizing Advanced Geophysical Classification at Fort Ord, CA

John Jackson Army Corps of Engineers, Sacramento

slide-44
SLIDE 44

SERDP & ESTCP Webinar Series (#22)

Agenda

  • Basis of need
  • ESTCP demonstration summary
  • Risk reduction summary
  • Conclusions

46

slide-45
SLIDE 45

SERDP & ESTCP Webinar Series (#22)

Site Background

  • Two purposes for prescribed burns at Fort Ord
  • Periodic burning to maintain natural habitat
  • Vegetation clearance to support MEC removal actions
  • Prescribed burns originally planned for Units 11 and 12

in 2011

  • Canceled due to the discovery of large MEC items on the

ground surface

  • Subsequent activities conducted in Units 11 and 12
  • Vegetation cutting
  • Surface MEC removal
  • Digital geophysical mapping
  • Prescribed burns rescheduled for Fall of 2015

47

slide-46
SLIDE 46

SERDP & ESTCP Webinar Series (#22)

ESTCP Demonstration Results

48

slide-47
SLIDE 47

SERDP & ESTCP Webinar Series (#22)

ESTCP Demonstration

  • Primary objectives
  • Demonstrate whether large munitions such as 155-mm

and 8-in projectiles at depths to 2 feet can be confidently classified within a challenging high metallic anomaly density background

  • Demonstrate whether large munitions at depths to 4

feet can be confidently classified within a challenging high metallic anomaly density background

  • Secondary objectives
  • Demonstrate if smaller munitions such as 40-mm

projectiles can be confidently classified within the range of high background conditions

49

slide-48
SLIDE 48

SERDP & ESTCP Webinar Series (#22)

ESTCP Grid Locations

50

slide-49
SLIDE 49

SERDP & ESTCP Webinar Series (#22)

Channel 25 (9.2 ms)

30 40 50 60 70 80

Channel 13 (0.63 ms) Channel 16 (1.23 ms) 400 ft 400 ft 51

slide-50
SLIDE 50

SERDP & ESTCP Webinar Series (#22)

52

1

T0-C4-M1

2

T0-C12-M1

3

T0-C20-M1

4

T0-C28-M1

5

T0-C36-M1

6

T0-C44-M1

7

T0-C52-M1

8

T0-C60-M1

9

T0-C68-M1

10

T0-C76-M1

11

T0-C84-M1

12

T0-C92-M1

13

T0-C100-M1

14

T0-C108-M1

15

T0-C116-M1

16

T0-C124-M1

17

T0-C132-M1

18

T0-C140-M1

19

T0-C148-M1

20

T0-C156-M1

21

T0-C164-M1

22

T0-C172-M1

23

T0-C180-M1

24

T0-C188-M1

25

T0-C196-M1

26

T0-C204-M1

27

T0-C212-M1

28

T0-C220-M1

29

T0-C228-M1

0.0005 0.001 0.005 0.01 10

  • 4

10

  • 2

10 10

2

Polarizabilities for 29 models

L1 L2 L3 Median

All cued IVS measurements IVS 4 = Large ISO at 75 cm

Cued IVS Example #1

slide-51
SLIDE 51

SERDP & ESTCP Webinar Series (#22)

Cued IVS Example #2

53

1

T0-C7-M1

2

T0-C15-M1

3

T0-C23-M1

4

T0-C31-M1 29 pols

5

T0-C39-M1

6

T0-C47-M1

7

T0-C55-M1

8

T0-C63-M1

9

T0-C71-M1

10

T0-C79-M1

11

T0-C87-M1

12

T0-C95-M1

13

T0-C103-M1

14

T0-C111-M1

15

T0-C119-M1

16

T0-C127-M1

17

T0-C135-M1

18

T0-C143-M1

19

T0-C151-M1

20

T0-C159-M1

21

T0-C167-M1

22

T0-C175-M1

23

T0-C183-M1

24

T0-C191-M1

25

T0-C199-M1

26

T0-C207-M1

27

T0-C215-M1

28

T0-C223-M1

29

T0-C231-M1

0.0005 0.001 0.005 0.01 10

  • 4

10

  • 2

10 10

2

10

4

Polarizabilities for 29 models

L1 L2 L3 Median

All cued IVS measurements IVS 7 = Large ISO at 100 cm

slide-52
SLIDE 52

SERDP & ESTCP Webinar Series (#22)

Cued IVS Example #3

54

1

T0-C8-M1

2

T0-C16-M1

3

T0-C24-M1

4

T0-C32-M1

5

T0-C40-M1

6

T0-C48-M1

7

T0-C56-M1

8

T0-C64-M1

9

T0-C72-M1

10

T0-C80-M1

11

T0-C88-M1

12

T0-C96-M1

13

T0-C104-M1

14

T0-C112-M1

15

T0-C120-M1

16

T0-C128-M1

17

T0-C136-M1

18

T0-C144-M1

19

T0-C152-M1

20

T0-C160-M1

21

T0-C168-M1

22

T0-C176-M1

23

T0-C184-M1

24

T0-C192-M1

25

T0-C200-M1

26

T0-C208-M1

27

T0-C216-M1

28

T0-C224-M1

29

T0-C232-M1

0.0005 0.001 0.005 0.01 10

  • 4

10

  • 2

10 10

2

10

4

Polarizabilities for 29 models

L1 L2 L3 Median

All cued IVS measurements IVS 8 = Large ISO at 125 cm

slide-53
SLIDE 53

SERDP & ESTCP Webinar Series (#22)

Initial ROC Curve (Primary)

55

slide-54
SLIDE 54

SERDP & ESTCP Webinar Series (#22)

Final(ish) ROC Curve (Primary)

56

slide-55
SLIDE 55

SERDP & ESTCP Webinar Series (#22)

Initial ROC Curve (Secondary)

57

slide-56
SLIDE 56

SERDP & ESTCP Webinar Series (#22)

Results and Conclusions

  • 2,804 unique cued locations
  • 35 total TOI 1 (100%)
  • 361 total TOI 2 (350/361 = 97%)
  • Achieving primary objective (large TOI to 2 ft) =

EASY!

  • Achieving secondary objective 1 (large TOI to 4 ft)

= DIFFICULT but DOABLE!

  • Achieving secondary objective 2 (all TOI to depth
  • f detection)= CLOSE, but NOT POSSIBLE!
  • Moving forward, need to address depth vs. signal

strength vs. anomaly density issues

  • Removal action vs. risk reduction

58

slide-57
SLIDE 57

SERDP & ESTCP Webinar Series (#22)

Risk Reduction Activities

59

slide-58
SLIDE 58

SERDP & ESTCP Webinar Series (#22)

Risk Reduction Tasks

  • Outer Zone
  • Removal of TOI to 2-ft depth

○Reduces the horizontal hazard distance for firefighters and prescribed burn personnel on the fuel break roads during burn operations

  • Inner Zone
  • Removal of TOI to 1-ft depth

○Reduces the vertical hazard distance for safe

  • verhead helicopter flight during burn operations

Outer Zone

60

slide-59
SLIDE 59

SERDP & ESTCP Webinar Series (#22)

MetalMapper Investigation Anomalies

61

Zone Response Value Threshold (mV) Anomalies Unit 11 - Outer 446 2,695 Unit 11 - Inner 114 192 Unit 12 - Outer 446 1,717 Unit 12 - Inner 114 21 TOTAL 4,625

slide-60
SLIDE 60

SERDP & ESTCP Webinar Series (#22)

QC&QA Seed Item Locations

62

slide-61
SLIDE 61

SERDP & ESTCP Webinar Series (#22)

Library Validation

  • Initial library was used,

validation performed to determine if additional entries can be added to the library

  • Cluster analysis performed
  • Selected 22 calibration digs
  • 6 for TOI threshold verification
  • 13 from unknown clusters
  • 2 for Parameter Space (size-

decay) verification

  • Updated initial library with

excavation results

  • 3 -155 mms for ranked dig list
  • 18 other munitions (non-TOI)

63

slide-62
SLIDE 62

SERDP & ESTCP Webinar Series (#22)

Key Thresholds for Classification

  • Validation digs were performed on each
  • f the key thresholds that were used
  • Library match statistic
  • Category 1 High Confidence TOI
  • Category 2 Cannot Decide
  • Category 2 Cannot Decide, Low Signal
  • Category 3 Non-TOI below library match

statistic threshold or outside limits on decay, size and signal amplitude

  • Cannot Analyze
  • Inversion failed or cannot extract reliable

betas

  • Poor Fit Coherence
  • Unreasonable depth
  • High Chi2
  • Modeled depth limit was set at 2 m

below the sensor, well below the depth

  • f clearance

64

slide-63
SLIDE 63

SERDP & ESTCP Webinar Series (#22)

Final Classification

  • Performed after completion of data

collection and refined as intrusive results were received

  • Combines all preliminary lists
  • Final library validation
  • Cluster and select additional

calibration digs

  • Review of dig results as they come

in

  • Mod based on 21187 QA seed to add

Chi2 threshold RCA-MM001

  • Mod based on 13147 to included

good library matches far from the cued and flag location – outside of the standard 40 cm offset

  • Review of QC and QA seeds

65

slide-64
SLIDE 64

SERDP & ESTCP Webinar Series (#22)

Recovered TOI

  • 302 TOI were

recovered from the 589 Calibration, Category 0, 1, and 2

  • 35 QC seed items

(large ISOs)

  • 24 QA seed items

(large ISOs and 155- mm projectiles)

  • 2 8-in projectiles

○ MEC/MPPEH: 2 ○ MD: 0

  • 241 155-mm projectiles

○ MEC/MPPEH: 17 ○ MD: 224

66

slide-65
SLIDE 65

SERDP & ESTCP Webinar Series (#22)

Recovered Non-TOI Munitions

  • In addition to recovered TOI, 407 non-TOI munitions items

were recovered from the targets identified for intrusive investigation

  • 7 105-mm projectiles

○ MEC/MPPEH: 4

  • 24 4.2-in mortar projectiles

○ MEC/MPPEH: 1

  • 36 40-mm projectiles

○ MEC/MPPEH:

  • 154 75-mm projectiles

○ MEC/MPPEH: 14

  • 148 81-mm mortar projectiles

○ MEC/MPPEH: 133

  • 1 66-mm rocket

○ MEC/MPPEH:

  • 67 unspecified MD components

67

slide-66
SLIDE 66

SERDP & ESTCP Webinar Series (#22)

Results

  • >550,000 EM61 anomalies
  • 4,625 anomalies investigated with MetalMapper
  • 688 anomalies identified for intrusive investigation and

subsurface removal

  • 22 analyst calibration digs
  • 567 ranked classification digs
  • 99 verification/validation digs
  • The 567 ranked classification digs were classified in the

following categories:

  • Category 0 (cannot analyze):

38

  • Category 1 (high-confidence TOI): 306
  • Category 2 (cannot decide):

223

  • 4,036 anomalies classified as Category 3 targets (high-

confidence clutter)

68

slide-67
SLIDE 67

SERDP & ESTCP Webinar Series (#22)

ROC Curve

69

slide-68
SLIDE 68

SERDP & ESTCP Webinar Series (#22)

The Team(s)

  • ESTCP
  • CB&I
  • Black Tusk Geophysics
  • U.S. Army Corps of Engineers
  • KEMRON
  • Gilbane, Inc.
  • NAEVA Geophysics
  • AcornSI
  • Fort Ord BRAC Office

70

slide-69
SLIDE 69

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series For additional information, please visit

https://www.serdp-estcp.org/Program-Areas/Munitions- Response/Land/Live-Site-Demonstrations/MR-201420 https://www.serdp-estcp.org/Program-Areas/Munitions- Response/Land/Live-Site-Demonstrations/MR-201421

Speaker Contact Information

John.M.Jackson@usace.army.mil; 916-557-6614

slide-70
SLIDE 70

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Q&A Session 2

slide-71
SLIDE 71

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series Perspectives on Advanced Geophysical Classification for Munitions Response

Doug Maddox EPA

slide-72
SLIDE 72

SERDP & ESTCP Webinar Series (#22)

Regulator Involvement

  • ESTCP Classification Advisory Group
  • Pilot sites
  • ITRC Team: Geophysical Classification for

Munitions Response

  • TechReg document (August 2015)

http://www.itrcweb.org/gcmr-2/

  • Fact sheets
  • Training

74

slide-73
SLIDE 73

SERDP & ESTCP Webinar Series (#22)

75

  • Applicability to a site
  • Contractor qualifications/ability
  • QA/QC
  • Implementation

Areas of Concern

slide-74
SLIDE 74

SERDP & ESTCP Webinar Series (#22)

76

  • Understand technology limitations (terrain,

geology, etc.)

  • Adequate characterization
  • Conceptual Site Model (CSM)
  • Treatability study?

Site Applicability

slide-75
SLIDE 75

SERDP & ESTCP Webinar Series (#22)

Accreditation

  • DAGCAP – DoD Advanced Geophysical

Classification Accreditation Program

  • Modeled after DoD Environmental Laboratory

Accreditation Program (ELAP)

  • Accrediting organization, not individual
  • Third party Accreditation Bodies (ABs) conduct

assessments

  • Enhances confidence in results by regulators

and stakeholders

77

slide-76
SLIDE 76

SERDP & ESTCP Webinar Series (#22)

Quality

  • Effective QA/QC critical for stakeholder

acceptance

  • Clear and specific DQO are necessary
  • UFP QAPP
  • UFP QAPP for geophysical classification
  • UFP QAPP for munitions response

78

slide-77
SLIDE 77

SERDP & ESTCP Webinar Series (#22)

Implementation

  • Need clear, concise, and factually correct

decision documents

  • Need clear remedial action objectives
  • LUC/ICs may still be required
  • Start with the end in mind
  • Effective planning and communication are key

to success

79

slide-78
SLIDE 78

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series For additional information, please visit http://www2.epa.gov/fedfac/military- munitionsunexploded-ordnance Speaker Contact Information

maddox.doug@epa.gov; 202-821-8794

slide-79
SLIDE 79

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Q&A Session 3

slide-80
SLIDE 80

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

The next webinar is on December 3, 2015

“Emerging Contaminants: DoD Overview and State of Knowledge on Fluorochemicals and 1,4-Dioxane”

slide-81
SLIDE 81

SERDP & ESTCP Webinar Series (#22)

SERDP & ESTCP Webinar Series

Survey Reminder

Please take a moment to complete the survey that will pop up on your screen when the webinar ends
