Modeling traffic flow in large-scale networks Guilhem Mariotte & Ludovic Leclercq June 19, 2017 Univ Lyon, ENTPE, IFSTTAR, LICIT SMRT, Grettia, Marne-la-Valle Introduction Macroscopic models Multi-routes Application example

slide-1
SLIDE 1

Modeling traffic flow in large-scale networks

Guilhem Mariotte & Ludovic Leclercq Univ Lyon, ENTPE, IFSTTAR, LICIT June 19, 2017 SMRT, Grettia, Marne-la-Vallée

slide-2
SLIDE 2

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

About traffic flow modeling

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 2

slide-3
SLIDE 3

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Why modeling traffic flow?

Traffjc state estimation Control Urban planning Public transports Gas emissions

photo credits: Lucas Gallone, Hermes Rivera, Markus Spiske – unsplash.com SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 3

slide-4
SLIDE 4

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Brief overview of traffic flow models

Microscopic Macroscopic

(individual vehicle motion) (vehicle fmow and density)

Microscopic

(vehicle level)

Mesoscopic

(link level)

Macroscopic

(network level) Car following (Gipps, IDM, ...) Lane changing Gap acceptance Car following (Newell) LWR LWR CTM

SCALE MODEL DYN.

LTM Vissim

(PTV)

Corsim

(Univ. of Florida)

Aimsum

(TSS)

Movsim

(Kesting, Germ, Budden, Treiber)

Symuvia

(LICIT)

??

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 4

slide-5
SLIDE 5

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Limitations of these models at the network scale

  • Computational complexity
  • Real-time calculations almost impossible
  • Large and detailed amount of information required (demand patterns,

shortest paths, assignment, ...) Road network of Lyon-Villeurbanne: 27,000 links 1700 entries 1700 exits

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 5

slide-6
SLIDE 6

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Brief overview of traffic flow models

Microscopic Macroscopic

(individual vehicle motion) (vehicle fmow and density)

Microscopic

(vehicle level)

Mesoscopic

(link level)

Macroscopic

(network level) Car following (Gipps, IDM, ...) Lane changing Gap acceptance Car following (Newell) MFD-based Bi-dimensional LWR LWR CTM

SCALE MODEL DYN.

LTM Vissim

(PTV)

Corsim

(Univ. of Florida)

Aimsum

(TSS)

Movsim

(Kesting, Germ, Budden, Treiber)

Symuvia

(LICIT)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 6

slide-7
SLIDE 7

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Macroscopic MFD-based models

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 7

slide-8
SLIDE 8

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Split the network into zones or “reservoirs”

Real network

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 8

slide-9
SLIDE 9

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Split the network into zones or “reservoirs”

Real network Clustering into zones

  • r “reservoirs”

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 8

slide-10
SLIDE 10

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Split the network into zones or “reservoirs”

Real network Clustering into zones

  • r “reservoirs”

Modeling of flow exchanges between zones

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 8

slide-11
SLIDE 11

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Flow dynamics in one zone: the single reservoir or bathtub problem

qin(t) qout(t) n(t) n(t) qin(t) qout(t)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 9

slide-12
SLIDE 12

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Traffic regimes

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 10

slide-13
SLIDE 13

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

The Macroscopic or Network Fundamental Diagram (MFD or NFD)

Density / number of vehicles Flow of circulating vehicles 1 2 3

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 11

slide-14
SLIDE 14

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Traffic flow dynamics: two approaches

n(t) P(n) or V(n), L qin(t) qout(t)

single reservoir

P(n) n V(n) = P(n)

n

n

production and speed MFD

dn dt = qin(t) − qout(t) qin(t) : defined by demand qout(t) : ?? → two modeling approaches No spatial extension in a reservoir!! → need to define a trip length

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 12

slide-15
SLIDE 15

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Accumulation-based model

(Daganzo, 2007, Geroliminis & Daganzo, 2007)

Use the principle of the queuing formula of Little (1961): qout(t) = n T = nV L = P L

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 13

t = 0 s L = 50 m n = 3 veh qin qout = 1.05 veh/s

n = 2.5 veh P Prod−MFD 52.7 veh.m/s n = 2.5 veh V Speed−MFD 21.1 m/s

slide-16
SLIDE 16

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Trip-based model

(Arnott, 2013)

Explicit formulation of the trip length L: L =

∫ t

t−T(t)

V(n(s))ds ⇐ ⇒ qout(t) = qin(t − T(t)) V(n(t)) V(n(t − T(t)))

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 14

t = 0 s L = 50 m n = 3 veh qin qout = 1.05 veh/s

n = 3 veh P Prod−MFD 60.9 veh.m/s n = 3 veh V Speed−MFD 20.3 m/s

slide-17
SLIDE 17

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Accumulation-based (free-flow conditions)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 15 1.5 veh/s 0 veh/s

t = 0 s − n = 0 veh

t Nin Nout N−curves 0 veh 0 veh t n Accumulation 0 veh t Travel time n qout Outflow−MFD 0 veh/s

slide-18
SLIDE 18

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Trip-based (free-flow conditions)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 16 10 20 30 40 50 t = 0 s − n = 0 veh distance traveled D [m] t Nin Nout N−curves 0 veh 0 veh t n Accumulation 0 veh t T Travel time 0 s n V Speed−MFD 25 m/s

slide-19
SLIDE 19

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Accumulation-based (congested conditions)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 17 1.5 veh/s 0 veh/s

t = 0 s − n = 0 veh

t Nin Nout N−curves 0 veh 0 veh t n Accumulation 0 veh t Travel time n qout Outflow−MFD 0 veh/s

slide-20
SLIDE 20

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Trip-based (congested conditions)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 18 10 20 30 40 50 t = 0 s − n = 0 veh distance traveled D [m] t Nin Nout N−curves 0 veh 0 veh t n Accumulation 1 veh t T Travel time 0 s n V Speed−MFD 23.4 m/s

slide-21
SLIDE 21

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Major differences

Accumulation-based: Trip-based:

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 19

slide-22
SLIDE 22

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Major differences

Accumulation-based:

  • flow exchange management at the reservoir borders

Trip-based:

  • track of individual vehicles

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 19

slide-23
SLIDE 23

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Major differences

Accumulation-based:

  • flow exchange management at the reservoir borders
  • outflow demand explicitly defined by the formula of Little (1961)

Trip-based:

  • track of individual vehicles
  • outflow demand implicitly defined: result of the vehicles traveling at the

reservoir mean speed

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 19

slide-24
SLIDE 24

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Major differences

Accumulation-based:

  • flow exchange management at the reservoir borders
  • outflow demand explicitly defined by the formula of Little (1961)
  • smooth and continuous evolution of flow

Trip-based:

  • track of individual vehicles
  • outflow demand implicitly defined: result of the vehicles traveling at the

reservoir mean speed

  • irregular and discontinuous representation of flow (stochasticity)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 19

slide-25
SLIDE 25

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Major differences

Accumulation-based:

  • flow exchange management at the reservoir borders
  • outflow demand explicitly defined by the formula of Little (1961)
  • smooth and continuous evolution of flow
  • algorithm complexity depending on the number of reservoirs and the

time step choice (fast)

Trip-based:

  • track of individual vehicles
  • outflow demand implicitly defined: result of the vehicles traveling at the

reservoir mean speed

  • irregular and discontinuous representation of flow (stochasticity)
  • algorithm complexity depending on the number of reservoirs and the

number of vehicles (slower)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 19

slide-26
SLIDE 26

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Multi-routes in a reservoir

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 20

slide-27
SLIDE 27

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Inner dynamics of a reservoir

We may define different travel distances inside the same reservoir, but all users/flows experience the same mean speed → Outflows from each different trips are all inter-dependent!!

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 21

slide-28
SLIDE 28

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Case of two routes

L1 L2 n2(t) L1 n1(t) L2

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 22

slide-29
SLIDE 29

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Accumulation-based, two routes, (free-flow)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 23 n1 n2

0 veh/s 0 veh/s 0 veh/s 0 veh/s

t = 0 s − n = 0 veh

n1 n2 Accumulation 0 veh 0 veh qin1 qin2 qout1 qout2 In/Outflow 0 veh/s 0 veh/s

slide-30
SLIDE 30

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Accumulation-based, two routes, (congestion)

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 24 n1 n2

0 veh/s 0 veh/s 0 veh/s 0 veh/s

t = 0 s − n = 0 veh

n1 n2 Accumulation 0 veh 0 veh qin1 qin2 qout1 qout2 In/Outflow 0 veh/s 0 veh/s

slide-31
SLIDE 31

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Application on a real network

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 25

slide-32
SLIDE 32

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Application example on the network of Lyon 6

1 2 3 4 5 6 7 8 9 10 11 O1 → O2 → O3 → O4 → O5 → O6 → O 7 → O8 → O 9 → O 1 → O 1 1 → O12 → O 1 3 → O 1 4 → O15 → O 1 6 → O17 → O18 → O19 → O 2 → → D1 → D2 → D3 → D4 → D5 → D6 → D 7 → D8 → D 9 → D10 → D 1 1 → D12 → D13 → D14 → D15 → D16 → D17 → D18

Satellite view of Lyon, France ( c ⃝ Google Maps) SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 26

slide-33
SLIDE 33

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Application example on the network of Lyon 6

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 27

slide-34
SLIDE 34

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Application example on the network of Lyon 6

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 28

R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 t = 0 s Accumulation [veh] Accumulation [-] 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

slide-35
SLIDE 35

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Application example on the network of Lyon 6

We can achieve a better distribution of trips among the reservoirs through assignment schemes (Probit here)

1 2 3 4 5 6 7 8 9 10 11 O1 → O2 → O3 → O4 → O5 → O6 → O 7 → O8 → O 9 → O 1 → O 1 1 → O12 → O 1 3 → O 1 4 → O15 → O 1 6 → O17 → O18 → O19 → O 2 → → D1 → D2 → D3 → D4 → D5 → D6 → D 7 → D8 → D 9 → D10 → D 1 1 → D12 → D13 → D14 → D15 → D16 → D17 → D18 1 2 3 4 5 6 7 8 9 10 11 O1 → O2 → O3 → O4 → O5 → O6 → O 7 → O8 → O 9 → O 1 → O 1 1 → O12 → O 1 3 → O 1 4 → O15 → O 1 6 → O17 → O18 → O19 → O 2 → → D1 → D2 → D3 → D4 → D5 → D6 → D 7 → D8 → D 9 → D10 → D 1 1 → D12 → D13 → D14 → D15 → D16 → D17 → D18

3 OD, 3 macro-routes 3 OD, 6 macro-routes

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 29

slide-36
SLIDE 36

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Application example on the network of Lyon 6

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 30

R1 R2 R3 R4 R5 R6 R7 R8 R9 R10 R11 t = 0 s Accumulation [veh] Accumulation [-] 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

slide-37
SLIDE 37

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Current research questions & further work

With real networks and data:

  • MFD definition and estimation
  • Network clustering
  • Trip length definition and estimation

Theoretical issues:

  • Flow merging problems between reservoirs
  • Congestion propagation within multi route frameworks

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 31

slide-38
SLIDE 38

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Acknowledgements

This project has received funding from the European Research Council (ERC) under the European Unions Horizon 2020 research and innovation programme (grant agreement No 646592 – MAGnUM project).

SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 32

slide-39
SLIDE 39

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

Thank you for your attention

Guilhem Mariotte & Ludovic Leclercq

  • guilhem.mariotte@ifsttar.fr
  • www.guilhemmariotte.com

Univ Lyon, ENTPE, IFSTTAR, LICIT UMR _T 9401, F-69518, LYON, France

  • Rue Maurice Audin

69518 Vaulx-en-Velin Cedex France

  • +33 (0)4 72 04 77 69

www.entpe.fr | www.ifsttar.fr | www.licit-lyon.eu | magnum.ifsttar.fr SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 33

slide-40
SLIDE 40

www.ifsar.fr

Introduction Macroscopic models Multi-routes Application example References

References

Arnott, R. (2013). A bathtub model of downtown traffic congestion. Journal of Urban Economics, 76:110–121. Daganzo, C. F. (2007). Urban gridlock: Macroscopic modeling and mitigation approaches. Transportation Research Part B: Methodological, 41(1):49–62. Geroliminis, N. & Daganzo, C. F. (2007). Macroscopic modeling of traffic in cities. In Transportation Research Board 86th Annual Meeting, 07-0413. Washington DC. Little, J. D. C. (1961). A proof for the queuing formula. Operations Research, 9(3):383–387. SMRT – June 19, 2017 – Guilhem Mariotte & Ludovic Leclercq 34
