Mercury: Enabling Remote Procedure Call for High-Performance Computing

• J. Soumagne, D. Kimpe, J. Zounmevo, M. Chaarawi, Q. Koziol,
• A. Afsahi, and R. Ross

The HDF Group, Argonne National Laboratory, Queen’s University

November 26, 2013

RPC and High-Performance Computing

Remote Procedure Call (RPC)

Allow local calls to be transparently executed on remote resources Already widely used to support distributed services

– Google Protocol Buffers, Facebook Thrift, CORBA, Java RMI, etc.

2

RPC and High-Performance Computing

Remote Procedure Call (RPC)

Allow local calls to be transparently executed on remote resources Already widely used to support distributed services

– Google Protocol Buffers, Facebook Thrift, CORBA, Java RMI, etc.

Typical HPC applications are SPMD No need for RPC: control flow implicit on all nodes A series of SPMD programs sequentially produce & analyze data

2

RPC and High-Performance Computing

Remote Procedure Call (RPC)

Allow local calls to be transparently executed on remote resources Already widely used to support distributed services

– Google Protocol Buffers, Facebook Thrift, CORBA, Java RMI, etc.

Typical HPC applications are SPMD No need for RPC: control flow implicit on all nodes A series of SPMD programs sequentially produce & analyze data Distributed HPC workflow Nodes/systems dedicated to specific task Multiple SPMD applications/jobs execute concurrently and interact

2

RPC and High-Performance Computing

Remote Procedure Call (RPC)

Allow local calls to be transparently executed on remote resources Already widely used to support distributed services

– Google Protocol Buffers, Facebook Thrift, CORBA, Java RMI, etc.

Typical HPC applications are SPMD No need for RPC: control flow implicit on all nodes A series of SPMD programs sequentially produce & analyze data Distributed HPC workflow Nodes/systems dedicated to specific task Multiple SPMD applications/jobs execute concurrently and interact Importance of RPC growing Compute nodes with minimal/non-standard environment Heterogeneous systems (node-specific resources) More “service-oriented” and more complex applications Workflows and in-situ instead of sequences of SPMD

2

Mercury

Objective

Create a reusable RPC library for use in HPC that can serve as a basis for services such as storage systems, I/O forwarding, analysis frameworks and other forms of inter-application communication

3

Mercury

Objective

Create a reusable RPC library for use in HPC that can serve as a basis for services such as storage systems, I/O forwarding, analysis frameworks and other forms of inter-application communication Why not reuse existing RPC frameworks?

– Do not support efficient large data transfers or asynchronous calls – Mostly built on top of TCP/IP protocols

◮ Need support for native transport ◮ Need to be easy to port to new machines

Similar approaches with some differences

– I/O Forwarding Scalability Layer (IOFSL) – NEtwork Scalable Service Interface (Nessie) – Lustre RPC

3

Overview

Client Server

RPC proc RPC proc

4

Overview

Function arguments / metadata transferred with RPC request

– Two-sided model with unexpected / expected messaging – Message size limited to a few kilobytes

Client Server

RPC proc RPC proc Metadata (unexpected + expected messaging)

4

Overview

Function arguments / metadata transferred with RPC request

– Two-sided model with unexpected / expected messaging – Message size limited to a few kilobytes

Bulk data (more later) transferred using separate and dedicated API

– One-sided model that exposes RMA semantics Client Server

RPC proc RPC proc Metadata (unexpected + expected messaging) Bulk Data (RMA transfer)

4

Overview

Function arguments / metadata transferred with RPC request

– Two-sided model with unexpected / expected messaging – Message size limited to a few kilobytes

Bulk data (more later) transferred using separate and dedicated API

– One-sided model that exposes RMA semantics

Network Abstraction Layer

– Allows definition of multiple network plugins – Two functional plugins MPI (MPI2) and BMI but implement

• ne-sided over two-sided

– More plugins to come Client Server

RPC proc Network Abstraction Layer RPC proc Metadata (unexpected + expected messaging) Bulk Data (RMA transfer)

4

Remote Procedure Call

Internal Details: Please forget soon!

Mechanism used to send an RPC request

Client Server

id1 ... idN id1 ... idN

5

Remote Procedure Call

Internal Details: Please forget soon!

Mechanism used to send an RPC request

Client Server

id1 ... idN id1 ... idN

• 1. Register call

and get request id

• 1. Register call

and get request id

5

Remote Procedure Call

Internal Details: Please forget soon!

Mechanism used to send an RPC request

Client Server

id1 ... idN id1 ... idN

• 2. Post unexpected send

with request id and serialized parameters + Pre-post receive for server response

• 2. Post receive for

unexpected request

5

Remote Procedure Call

Internal Details: Please forget soon!

Mechanism used to send an RPC request

Client Server

id1 ... idN id1 ... idN

• 3. Execute call

5

Remote Procedure Call

Internal Details: Please forget soon!

Mechanism used to send an RPC request

Client Server

id1 ... idN id1 ... idN

• 4. Test completion of

send / receive requests

• 4. Post send with

serialized response

5

Remote Procedure Call: Example Code

Client snippet:

• pen_in_t

in_struct;

• pen_out_t
• ut_struct ;

/* Initialize the interface */ [...] NA_Addr_lookup (network_class , server_name , & server_addr ); /* Register RPC call */ rpc_id = HG_REGISTER ("open", open_in_t , open_out_t ); /* Fill input parameters */ [...] in_struct.in_param0 = in_param0; /* Send RPC request */ HG_Forward (server_addr , rpc_id , &in_struct , &out_struct , & rpc_request ); /* Wait for completion */ HG_Wait(rpc_request , HG_MAX_IDLE_TIME , HG_STATUS_IGNORE ); /* Get

• utput

parameters */ [...]

• ut_param0 = out_struct .out_param0 ;

6

Remote Procedure Call: Example Code

Server snippet (main loop):

int main(int argc , void *argv []) { /* Initialize the interface */ [...] /* Register RPC call */ HG_HANDLER_REGISTER ("open", open_rpc , open_in_t ,

• pen_out_t );

/* Process RPC calls */ while (! finalized) { HG_Handler_process (timeout , HG_STATUS_IGNORE ); } /* Finalize the interface */ [...] }

7

Remote Procedure Call: Example Code

Server snippet (RPC callback):

int

• pen_rpc( hg_handle_t

handle) {

• pen_in_t

in_struct;

• pen_out_t
• ut_struct ;

/* Get input parameters and bulk handle */ HG_Handler_get_input (handle , &in_struct); [...] in_param0 = in_struct.in_param0; /* Execute call */

• ut_param0 = open(in_param0 , ...);

/* Fill

• utput

structure */

• pen_out_struct . out_param0 = out_param0 ;

/* Send response back */ HG_Handler_start_output (handle , &out_struct ); return HG_SUCCESS; }

8

Bulk Data Transfers

Definition

Bulk Data: Variable length data that is (or could be) too large to send eagerly and might need special processing. Transfer controlled by server (better flow control) Memory buffer(s) abstracted by handle handles must be serialized and exchanged using other means

Client Server

9

Bulk Data Transfers

Definition

Bulk Data: Variable length data that is (or could be) too large to send eagerly and might need special processing. Transfer controlled by server (better flow control) Memory buffer(s) abstracted by handle handles must be serialized and exchanged using other means

Client Server

• 1. Register local memory

segment and get handle

• 1. Register local memory

segment and get handle

9

Bulk Data Transfers

Definition

Bulk Data: Variable length data that is (or could be) too large to send eagerly and might need special processing. Transfer controlled by server (better flow control) Memory buffer(s) abstracted by handle handles must be serialized and exchanged using other means

Client Server

• 1. Register local memory

segment and get handle

• 1. Register local memory

segment and get handle

• 2. Send serialized

memory handle

9

Bulk Data Transfers

Definition

Bulk Data: Variable length data that is (or could be) too large to send eagerly and might need special processing. Transfer controlled by server (better flow control) Memory buffer(s) abstracted by handle handles must be serialized and exchanged using other means

Client Server

• 1. Register local memory

segment and get handle

• 1. Register local memory

segment and get handle

• 2. Send serialized

memory handle

• 3. Post put/get opera-

tion using local/deseri- alized remote handles

9

Bulk Data Transfers

Definition

Bulk Data: Variable length data that is (or could be) too large to send eagerly and might need special processing. Transfer controlled by server (better flow control) Memory buffer(s) abstracted by handle handles must be serialized and exchanged using other means

Client Server

• 1. Register local memory

segment and get handle

• 1. Register local memory

segment and get handle

• 2. Send serialized

memory handle

• 3. Post put/get opera-

tion using local/deseri- alized remote handles

• 4. Test completion
• f remote put/get

9

Bulk Data Transfers: Example

Client snippet (contiguous): Note: no client changes

/* Initialize the interface */ [...] /* Register RPC call */ rpc_id = HG_REGISTER (" write ", write_in_t , write_out_t ); /* Create bulk handle */ HG_Bulk_handle_create (buf , buf_size , HG_BULK_READ_ONLY , & bulk_handle ); /* Attach bulk handle to input parameters */ [...] in_struct. bulk_handle = bulk_handle ; /* Send RPC request */ HG_Forward (server_addr , rpc_id , &in_struct , &out_struct , & rpc_request ); /* Wait for completion */ HG_Wait(rpc_request , HG_MAX_IDLE_TIME , HG_STATUS_IGNORE );

10

Bulk Data Transfers: Example

Server snippet (RPC callback):

/* Get input parameters and bulk handle */ HG_Handler_get_input (handle , &in_struct); [...] bulk_handle = in_struct. bulk_handle ; /* Get size

• f

data and allocate buffer */ nbytes = HG_Bulk_handle_get_size ( bulk_handle ); buf = malloc(nbytes); /* Create block handle to read data */ HG_Bulk_block_handle_create (buf , nbytes , HG_BULK_READWRITE , & bulk_block_handle ); /* Start reading bulk data */ HG_Bulk_read_all (client_addr , bulk_handle , bulk_block_handle , & bulk_request ); /* Wait for completion */ HG_Bulk_wait (bulk_request , HG_MAX_IDLE_TIME , HG_STATUS_IGNORE );

11

Non-contiguous Bulk Data Transfers

Non contiguous memory is registered through bulk data interface...

int HG_Bulk_handle_create_segments ( hg_bulk_segment_t *bulk_segments , size_t segment_count , unsigned long flags , hg_bulk_t *handle);

...which maps to network abstraction layer if plugin supports it...

int NA_Mem_register_segments ( na_class_t *network_class , na_segment_t *segments , na_size_t segment_count , unsigned long flags , na_mem_handle_t *mem_handle );

...otherwise several na mem handle t created and hg bulk t may therefore have a variable size

– If serialized hg bulk t too large, use bulk data API to register memory and pull memory descriptors from server – In both cases, origin unaware of target memory layout

12

Non-contiguous Bulk Data Transfers: API

Non-blocking read

int HG_Bulk_read (na_addr_t addr , hg_bulk_t bulk_handle , size_t bulk_offset , hg_bulk_block_t block_handle , size_t block_offset , size_t block_size , hg_bulk_request_t * bulk_request );

Non-blocking write

int HG_Bulk_write (na_addr_t addr , hg_bulk_t bulk_handle , size_t bulk_offset , hg_bulk_block_t block_handle , size_t block_offset , size_t block_size , hg_bulk_request_t * bulk_request );

13

Non-contiguous Bulk Data Transfers: Example

Client snippet:

/* Initialize the interface */ [...] /* Register RPC call */ rpc_id = HG_REGISTER (" write ", write_in_t , write_out_t ); /* Provide data layout information */ for (i = 0; i < BULK_NX ; i++) { segments[i]. address = buf[i]; segments[i]. size = BULK_NY * sizeof(int); } /* Create bulk handle with segment info */ HG_Bulk_handle_create_segments (segments , BULK_NX , HG_BULK_READ_ONLY , & bulk_handle ); /* Attach bulk handle to input parameters */ [...] in_struct. bulk_handle = bulk_handle ; /* Send RPC request */ HG_Forward (server_addr , rpc_id , &in_struct , &out_struct , & rpc_request );

14

Non-contiguous Bulk Data Transfers: Example

Server snippet:

/* Get input parameters and bulk handle */ HG_Handler_get_input (handle , &in_struct); [...] bulk_handle = in_struct. bulk_handle ; /* Get size

• f

data and allocate buffer */ nbytes = HG_Bulk_handle_get_size ( bulk_handle ); buf = malloc(nbytes); /* Create block handle to read data */ HG_Bulk_block_handle_create (buf , nbytes , HG_BULK_READWRITE , & bulk_block_handle ); /* Start reading bulk data */ HG_Bulk_read_all (client_addr , bulk_handle , bulk_block_handle , & bulk_request ); /* Wait for completion */ HG_Bulk_wait (bulk_request , HG_MAX_IDLE_TIME , HG_STATUS_IGNORE );

15

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call 16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes)

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes)

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes)

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 W

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 W

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 W

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 3 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 2 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) 1 E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes) E

16

Fine-grained Transfers

Two issues with previous example

• 1. Server memory size is limited
• 2. Server waits for all the data to arrive before writing

◮ Makes us pay the latency of an entire RMA read

Solution

– Pipeline transfers and overlap communication / execution

◮ Transfers can complete while writing / executing the RPC call

Data buffer (nbytes)

16

Performance Evaluation

Scalability / aggregate bandwidth of RPC requests to single server with bulk data transfer (QDR 4X Infiniband cluster)

1000 2000 3000 4000 5000 6000 2 4 8 16 32 64 128 256 Aggregate bandwidth (MB/s) Number of client processes

mercury w/ pipelining mercury w/o pipelining

• su bw max

17

Performance Evaluation

Scalability / aggregate bandwidth of RPC requests to single server with bulk data transfer (Cray XE6)

1000 2000 3000 4000 5000 6000 7000 8000 9000 2 4 8 16 32 64 128 256 Aggregate bandwidth (MB/s) Number of client processes

mercury w/ pipelining mercury w/o pipelining

• su bw max

18

Performance Evaluation

NULL RPC request execution on Cray XE6

– With XDR encoding: 23 µs – Without XDR encoding: 20 µs

About 50 000 calls /s Still working on improving that result Can depend on server side CPU affinity etc

19

Macros

Generate as much boilerplate code as possible for

– Serialization / deserialization of parameters – Sending / executing RPC

Single include header file shared between client and server Make use of BOOST preprocessor for macro definition

– Generate serialization / deserialization functions and structure that contains parameters

20

Macros: Serialization / Deserialization

MERCURY_GEN_PROC (

• pen_in_t ,

(( hg_string_t )(path) ) (( int32_t)(flags)) (( uint32_t)(mode)) )

Macro

MERCURY_GEN_PROC ( struct_type_name , fields )

/* Define

• pen_in_t

*/ typedef struct { hg_string_t path; int32_t flags; uint32_t mode; } open_in_t; /* Define hg_proc_open_in_t */ static inline int hg_proc_open_in_t (hg_proc_t proc , void *data) { int ret = HG_SUCCESS ;

• pen_in_t * struct_data = (open_in_t

*) data; ret = hg_proc_hg_string_t (proc , &struct_data -> path); if (ret != HG_SUCCESS ) { HG_ERROR_DEFAULT ("Proc error "); ret = HG_FAIL; return ret; } ret = hg_proc_int32_t (proc , &struct_data ->flags) ; if (ret != HG_SUCCESS ) { HG_ERROR_DEFAULT ("Proc error "); ret = HG_FAIL; return ret; } ret = hg_proc_uint32_t (proc , &struct_data ->mode) ; if (ret != HG_SUCCESS ) { HG_ERROR_DEFAULT ("Proc error "); ret = HG_FAIL; return ret; } return ret; }

Generated Code

Generates proc and struct

21

Current and Future Work

Add true RMA capability NA plugins

(ibverbs, DMAPP, SSM, NNTI)

Checksum parameters for data integrity (done) Support cancel operations of ongoing RPC calls (ongoing) Change progress model to callback and trigger (done)

(both Mercury and NA)

Optimizations: batches and eager bulk data Integrate Mercury into other projects

– Mercury POSIX: Forward POSIX calls using dynamic linking – Triton (done) – IOFSL – HDF5 virtual object plugins

22

Where to go next

Mercury project page http://www.mcs.anl.gov/projects/mercury Download / Documentation / Source / Mailing-lists Work supported by

The Exascale FastForward project, LLNS subcontract no. B599860 The Office of Advanced Scientific Computer Research, Office of Science, U.S. Department of Energy, under Contract DE-AC02-06CH11357 This research was supported by the United States Department of Defense

23
