SLIDE 1
A Two-Pronged Defense against Adversarial Examples
Dongyu Meng Hao Chen
ShanghaiTech University, China University of California, Davis, USA
2
Neural networks in real-life applications
user authentication autonomous vehicle
Mag Net A Two-Pronged Defense against Adversarial Examples Dongyu - - PowerPoint PPT Presentation
Mag Net A Two-Pronged Defense against Adversarial Examples Dongyu - - PowerPoint PPT Presentation
Mag Net A Two-Pronged Defense against Adversarial Examples Dongyu Meng Hao Chen ShanghaiTech University, China University of California, Davis, USA Neural networks in real-life applications user authentication autonomous
SLIDE 2
SLIDE 3
Neural networks as classifier
3
Panda 0.62 Tiger 0.03 Gibbon 0.11
Classifier Input Output
(distribution)
SLIDE 4
Adversarial examples
p(x is panda) = 0.58
4
p(x is gibbon) = 0.99
[ICLR 15] Goodfellow, Shlens, and Szegedy. EXPLAINING AND HARNESSING ADVERSARIAL EXAMPLES
+ x
Examples carefully crafted to
- look like normal examples
- cause misclassification
x
gibbon panda
SLIDE 5
Attacks
Fast gradient sign method(FGSM) Carlini’s attack Iterative gradient sign Deepfool ……
5
confidence
[Goodfellow, 2015] [Carlini, 2017] [Kurakin, 2016] [Moosavi-Dezfooli, 2015]
SLIDE 6
Defenses
Adversarial training Defensive distillation Detecting specific attacks ……
6
[Goodfellow, 2015] [Papernot, 2016] [Metzen, 2017]
target specific attack
Yes Yes
modify classifier
Yes Yes
SLIDE 7
Desirable properties
7
Does not modify target classifier.
- Can be deployed more easily as an add-on.
Does not rely on attack-specific properties.
- Generalizes to unknown attacks.
SLIDE 8
Manifold hypothesis
8
Possible inputs take up dense sample space. Manifold But inputs we care about lie on a low dimensional manifold.
SLIDE 9
Our hypothesis for adversarial examples
9
Some adversarial examples are far away from the manifold. Classifiers are not trained to work on these inputs. Manifold
SLIDE 10
Our hypothesis for adversarial examples
10
Other adversarial example are close to the manifold boundary where the classifier generalizes poorly. Manifold
SLIDE 11
Sanitize your inputs.
11
SLIDE 12
Our solution
12
Detector: Decides if the example is far from the manifold. Manifold
SLIDE 13
Our solution
13
Reformer: Draws the example towards the manifold. Manifold
SLIDE 14
14
MagNet rejects the input MagNet returns y
Workflow
SLIDE 15
Autoencoder
15
- Neural nets.
- Learn to copy input to output.
- Trained with constraints.
Reconstruction error:
SLIDE 16
Autoencoder
16
Autoencoders
- learn to map inputs towards manifold.
- approximate input-manifold distance with reconstruction error.
Train autoencoders on normal examples only as building blocks.
SLIDE 17
Detector
17
- - based on reconstruction error
autoencoder
?
?
yes Input is normal. MagNet accepts the input. no Input is adversarial. MagNet rejects the input.
||X-X’||2< threshold?
x x’ x’
SLIDE 18
Detector
18
- - based on probability divergence
autoencoder
?
?
classifier
Panda ... Tiger ... Gibbon ...
classifier
Panda 0.62 Tiger 0.03 Gibbon 0.11
?
DKL(P||Q)
P Q
Panda ... Tiger ... Gibbon ... Panda 0.62 Tiger 0.03 Gibbon 0.11
?
P Q
DKL(P||Q) < threshold?
yes Input is normal. MagNet accepts the input. no Input is adversarial. MagNet rejects the input.
x x’ x’
SLIDE 19
Reformer
19
autoencoder
?
?
classifier
Panda ... Tiger ... Gibbon ...
Q
MagNet returns Q as final classification result.
x x’ x’
SLIDE 20
Threat model
20
target classifier defense blackbox defense whitebox defense knows the parameters of ...
SLIDE 21
Blackbox defense on MNIST dataset
21
accuracy on adversarial examples
SLIDE 22
Blackbox defense on CIFAR-10 dataset
22
accuracy on adversarial examples
SLIDE 23
Detector vs. reformer
23
Detector and reformer complement each other.
(distortion)
large distortion more transferable small distortion less noticeable
complete MagNet: detector+reformer detector reformer no defense
confidence
SLIDE 24
Whitebox defense is not practical
24
To defeat whitebox attacker, defender has to either
- make it impossible for attacker to find adversarial examples,
- or create a perfect classification network.
SLIDE 25
Graybox model
25
- Attacker knows possible defenses.
- Exact defense is only known at run time.
classifier defense blackbox defense graybox defense whitebox defense
Defense strategy
- Train diverse defenses.
- Randomly pick one for each session.
A B C D
knows the parameters of...
SLIDE 26
Train diverse defenses
26
With MagNet, this means training diverse autoencoders.
Our Method:
Train n autoencoders at the same time. Minimize
reconstruction error autoencoder diversity average reconstructed image
SLIDE 27
Train diverse defense
27
Idea Penalize the resemblance of autoencoders. generate attack on defend with Graybox classification accuracy
SLIDE 28
Limitations
28
The effectiveness of MagNet depends on assumptions that
- detector and reformer functions exist.
- we can approximate them with autoencoders.
We show empirically that these assumptions are likely correct.
SLIDE 29
Conclusion
29
We propose MagNet framework:
- Detector detects examples far from the manifold
- Reformer moves examples closer to the manifold
We demonstrated effective defense against adversarial examples in blackbox scenario with MagNet. Instead of whitebox model, we advocate graybox model, where security rests on model diversity.
SLIDE 30
Thanks & Questions?
30
Find more about MagNet:
- https://arxiv.org/abs/1705.09064 Paper
- https://github.com/Trevillie/MagNet Demo code
- mengdy.me Author homepage
