Machine Learning Prediction of Blood Alcohol Content: A Digital - - PowerPoint PPT Presentation

Machine Learning Prediction

• f Blood Alcohol Content:

A Digital Signature of Behavior

KIRSTIN ASCHBACHER, PH.D.

A S S O C I AT E P RO F ES S O R , D I V I S I O N O F C A R D I O LO GY, S C H O O L O F M E D I C I N E U N I V E RS I T Y O F C A L I FO R N I A , SA N F R A N C I S CO K I RST I N . A S C H BAC H E R @ U C S F. E D U

The Cost of Excessive Alcohol Use

§ A leading cause of preventable death § 1 in 10 deaths among adults, ages 20-64 § US costs: $224 billion in 2006 § High comorbidity with other mental health disorders (e.g., PTSD/MDD)

https://www.cdc.gov/features/alcohol-deaths/index.html

How a BACtrack Works

§ Consumed alcohol is absorbed into the bloodstream § Alcohol in the bloodstream moves across the membranes of the lung’s air sacs (alveoli). § The concentration of the alcohol in the alveolar air is directly related to the concentration in the blood. § As the alveolar air is exhaled, the alcohol in it can be detected by the breath alcohol testing device.

https://www.bactrack.com/pages/bactrack-consumption-report

External Validation of Accuracy

Summary: Compared the accuracy of 3 smartphone-paired breathalyzers against a police-grade breathalyzer and against blood alcohol levels. Conclusions: Two devices – including BACtrack – were deemed accurate relative to the police- grade device with differences in BAC +/- 0.01. BACtrack was as closely related to blood alcohol levels as the police-grade device.

http://injuryprevention.bmj.com/content/injuryprev/23/Suppl_1/A15.1.full.pdf

The Business Need à The Data Product

• 1. Target Markets & Pain Points:

§ Some users/health providers would like tools to help make alcohol use safer

• 2. Data Product:

§ If we could predict when a given user will have a BAC >=.08, we could target them with messaging, or offer a chat-bot/coach

• 3. BAC Detection à Real-time Messaging

Mac Machine Learning Pr hine Learning Predic edictio tion o n of B f Blo lood A d Alc lcoho hol C l Conten ent: t:

K Aschbacher, R Avram, G Tison, K Rutledge, M Pletcher, J Olgin, G Marcus

• Objective:
• To identify a digital signature of self-monitored

BAC levels that predicts the times, locations, and circumstances under which a user is likely to exceed the legal BAC driving limit of 0.08%.

• Methods:
• >1 million observations from 33,452 distinct

users of the BACtrack device (accuracy comparable to police-grade devices).

• Behavioral, timestamp, geolocation data
• Machine learning was conducted by fitting data

to a Gradient Boosted Classification Tree (GBCT), using train/cv/test partitions

Are BACtrack data relevant to health at scale?

Is there an association between BAC levels and Motor Vehicle Death Rates?

Some of the states with the highest death rates have the fewest BACtrack users… more rural?

Higher BAC levels are associated with a Higher Death Rate, but more so in states with fewer users

Significance

Predicted MV death rate for any given value of BAC and n-users

Data Wrangling

Data Management

Machine Learning Clean & Organize ssh + conda + tmux + jupyter

Data Security

• Data is collected anonymously from users of the BACtrack app, which syncs

with BACtrack smartphone-enabled breathalyzers

• Data is viewed in aggregate only and is from users with with data storage

activated, location services turned on, and does not represent data from all users

• We use APS Redshift VPC security groups and S3 data encryption methods, and

the data itself is deidentified

• We analyze data on a secure cluster and interface with the data via ssh

Machine Learning:

Gradient Boosted Classification with XGBoost

Gradient Boosted Classification

• 1. Weak learners (trees) are combined to make strong learners
• 2. Generalization capability is high
• 3. Overfitting is low – especially with cross-validation & tuning
• 4. Handles missing data well
• 5. Models non-linearities
• 6. Can be productionized
• 7. Our Label/Outcome: BAC < .08 versus BAC >= .08

An Unfortunate Example of a Decision Tree

https://homes.cs.washington.edu/~tqchen/pdf/BoostedTree.pdf

Ensemble Learning Methods combine weak learners to create strong learners

https://homes.cs.washington.edu/~tqchen/pdf/BoostedTree.pdf

• Boosting Methods compute a set
• f weights for each training

example at each level of the tree

• Higher weights are given to

incorrectly classified examples

• Hence the tree attempts to find

features to explain those examples at the next round

Problem: We don’t have a lot of features!

• 1. BAC level
• 2. Timestamps
• 3. User-entered data
• BAC guess
• a user’s subjective guess prior to measuring
• “validated”
• Photos (sparse)
• Notes (sparse)
• 4. Geolocation (lat/lon) and zip codes

The Neurocircuitry of Reward & Addiction

• Neuroadaptations drive behavior

change over time, characterized by:

• Reactivity to cues/ triggers
• Loss of pleasure/ seeking stress relief
• Deficits in self-regulatory systems
• When, where, and for whom?
• Circadian variation in self-monitoring
• Geographic variation in boredom/stress
• The longer you’re engaging the more

entrenched this pattern may be for you

Substance Abuse and Mental Health Services Administration (US); Office of the Surgeon General (US). Facing Addiction in America: The Surgeon General's Report on Alcohol, Drugs, and Health [Internet]. Washington (DC): US Department of Health and Human Services; 2016 Nov. Figure 2.3, The Three Stages of the Addiction Cycle and the Brain Regions Associated with Them. Available from: https://www.ncbi.nlm.nih.gov/books/NBK424849/figure/ch2.f3/ Volkow et al., N Engl J Med 2016.

What’s the Digital Signature of a Habit?

Definition:

• “An acquired behavior pattern…

regularly followed until it has become almost involuntary.”

Pattern:

• Frequency à Time
• Triggers à Time/Location
• Engagement with self-monitoring

(reflects reward value of tracking)

Patterns in Time

• Temporal patterns are not investigated

as often in traditional scientific studies

• Self-monitoring has a temporal signature
• API-connected devices capture time-

based signatures

When do People Monitor?

• As expected, users are more likely to self-monitor on

weekends and in the evenings

• Specifically, users monitor their BAC about 5-6 times

more often on Friday and Saturday nights, compared to weekday work-hours

• Surprise! There’s a self-monitoring bump on weekdays

around 7am… Eye-openers?

(Note: values inside the graph are in units of thousands – e.g., 1.6 = 1.6k or 1600 measurements for that day and hour).

When is BAC highest?

• Supporting data validity, users have

higher measured BAC levels on weekends

• And in the evenings…
• Interestingly, measured BAC levels peak

around 1-2am… when the bars tend to close…

• BAC self-monitoring peaks in the “wee

hours” of the evening

• Tuesday is the “soberest” day

Is Location a Trigger for Drinking?

• Many animal studies of alcohol use

“conditioned place preference” (CPP).

• When you pair alcohol with a certain

place, an animal learns to prefer that place.

• This suggests that places (locations) can

be cues for alcohol consumption.

Getting distances from Geolocation:

• To scale efficiently – do as much as you can with tools like Redshift
• AWS Redshift does a lot of things… even trigonometry

Big Data can suffer from the problem of: Garbage In – Garbage Out

Striking but Accurate

Shorter Prior Distances since the prior measurement predicts higher BAC levels

• The distance a user has traveled

between subsequent BAC measures helps predict subsequent BAC levels

• Conditioned Place Preference

suggests that short distances will be associated with higher BAC values

• However, we may need to restrict

this to distances between drinking episodes rather than measurements

• INTERPRETATION: The highest BAC is predicted if,

since your last measure, you traveled less than 1.5 km (and your distance data was not missing (>-999).

Evaluating & Optimizing Performance of Gradient Boosted Classification Trees with XGBoost

• 1. Performance under default settings
• 2. Class Balancing
• 3. Tuning Learning Rate along with The

number of trees & max depth

• 4. Iterative Feature Engineering
• 5. Final Model Performance &

Interpretation

Balancing Classes

Default Model Performance & Impact of Class Balancing

DEV SET RESULTS (N=97,327) Imbalanced Classes Balanced Classes ROC-AUC 82.65% 82.70% Accuracy 77.97% 73.28% High BAC F1-Score 55% 63% Precision 69% 53% Recall 46% 77%

• Default settings are: 10 estimators, learning_rate=.3, max_depth=6
• Balancing: positive scale weight = 2.38

Imbalanced Balanced

Tuning Hyperparameters

Learning Rate Max_Depth Best # of Trees CV-AUC 1.0 12 4 81.38% 1.0 6 30 82.63% 0.3 12 82 84.27% 0.3 6 ~489 84.30% 0.1 12 >500 84.93% 0.1 6 >500 84.21%

• Used a 3-fold CV to evaluate
• Higher Learning rates à fewer

trees (n_estimators); faster!!

• However, maybe worse AUC
• Tune them together
• Also consider complexity of

trees – ‘max_depth’

Model Development is Iterative: Using Feature Importances to inform feature engineering

Highly Ranked Features (weight)

• 1. User’s ”guess” or subjective estimate of their BAC level
• 2. The hour of day
• 3. The average BAC level for all the prior BACs that user has measured
• 4. The number of times a user has previously measured his/her BAC level

Prior Behavior Predicts Future Behavior

• Prior Experience with BACs

near the limit + guessing your BAC is over the limit

• bac_cumulative_avg is the

average of all prior BAC measures for that user prior to the given measurement.

• bac_guess is the user’s

subjective guess about their BAC level

What About Repeated Measures? Time Delta Features Provide Insights

DEV SET RESULTS (N=97,327) Without Time Deltas With Time Deltas ROC-AUC 82.70% 86.70% Accuracy 73.28% 75.44% High BAC F1-Score 63% 67% Precision 53% 56% Recall 77% 83%

• Parameters: 10 estimators, learning_rate=.3, max_depth=6
• Balancing: positive scale weight = 2.38
• Users sometimes measure their BAC

repeatedly over a period of time because they are waiting for it to come down.

• Minutes since last measurement may

therefore be a very predictive feature

• Also, the distance feature is hard to

correctly interpret because it may simply be a proxy for measurements taken close together in time and space

Final Model Performance in Test Set

TEST SET RESULTS (N=194,653) Default Settings Tuned Settings ROC-AUC 86.70% 88.16% Accuracy 75.44% 77.43% High BAC F1-Score 67% 69% Precision 56% 58% Recall 83% 84%

ROC AUC: 88.16%

Final Model Params: learning_rate 0.03, max_depth 8, min_child_weight 1, subsample 0.8, colsample_bytree 0.8, num_boost_round 500

Final Model: Feature Importance

GAIN (Improvement in Accuracy):

• Time since last measurement (min, days)
• Your guess about your BAC
• Your average prior BAC
• How many times you’ve measured BAC
• Hour of Day
• The max and range of your prior BACs
• Average BAC levels over last few times

WEIGHT (Number of splits):

• Time since last measurement (min)
• Your average prior BAC
• How many times you’ve measured BAC
• Hour of Day
• Your guess about your BAC
• The average distance you’ve traveled between

prior BAC measures

• Length of engagement with the device
• Population of zip code

Big Picture Conclusions

• 1. BAC levels exceeding the safe legal driving limit of 0.08% can be

predicted with good accuracy using machine learning to quantify a digital phenotype.

• 2. BAC prediction from minimal information establishes the foundation to

conduct precision medicine behavioral interventions using a digital app and BAC tracking device.

Big Picture Conclusions

• 1. Feature engineering enhanced

performance more than hypertuning

• 2. Important to leverage time series

measurements and behavioral neuropsychology content knowledge

• 3. The impact and optimal handling of

repeated measures on ML models seems not well-defined in contrast to GLM – potentially an important area for future algorithms research.

Implications for Digital Interventions and Product Development

• 1. Habits vs Goals

2. Beyond Self-Monitoring

• States of mood, energy, self-consciousness
• Thoughts as triggers
• Reflections on BAC levels (self-relevant meaning of the data)

3. Breaking the Vicious Reward Cycle

• Trigger management strategies
• Anticipatory stress relief
• Willpower is a limited resource – known relationships to time/glucose
• Psychoeducation about withdrawal – emptiness, negative emotions, and

lack of joy can be withdrawal symptoms driven by reward neurocircuitry

• Brain-train behavioral inhibition
• Mindfulness for social/emotional distress tolerance
• Substitution strategies
• Information not advice (Motivational Interviewing
• Abstinence Violation strategies

Thank you. Kirstin.Aschbacher@ucsf.edu
