Maarten L offler Marc van Kreveld Center for Geometry, Imaging - - PowerPoint PPT Presentation
Maarten L offler Marc van Kreveld Center for Geometry, Imaging - - PowerPoint PPT Presentation
Maarten L offler Marc van Kreveld Center for Geometry, Imaging and Virtual Environments Utrecht University ? PROPERTIES OF IMPRECISE POINTS ? PROPERTIES OF IMPRECISE POINTS connected ? PROPERTIES OF IMPRECISE POINTS connected
SLIDE 2
SLIDE 3
SLIDE 4
SLIDE 5
SLIDE 6
SLIDE 7
SLIDE 8
SLIDE 9
SLIDE 10
?
SLIDE 11
PROPERTIES OF IMPRECISE POINTS
?
SLIDE 12
PROPERTIES OF IMPRECISE POINTS
- connected
?
SLIDE 13
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
?
SLIDE 14
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
?
SLIDE 15
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
- constant
?
SLIDE 16
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
- constant
PROPERTIES OF IMPRECISE LINES
SLIDE 17
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
- constant
PROPERTIES OF
- connected
IMPRECISE LINES
SLIDE 18
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
- constant
PROPERTIES OF
- connected
- convex?
IMPRECISE LINES
SLIDE 19
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
- constant
PROPERTIES OF
- connected
- convex?
- polygonal?
IMPRECISE LINES
SLIDE 20
PROPERTIES OF IMPRECISE POINTS
- connected
- convex
- polygonal
- constant
PROPERTIES OF
- connected
- convex?
- polygonal?
- constant?
IMPRECISE LINES
SLIDE 21
WHAT ARE CONVEX SETS OF LINES?
SLIDE 22
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
SLIDE 23
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
SLIDE 24
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
SLIDE 25
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
SLIDE 26
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
- problem: vertical lines
SLIDE 27
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
- problem: vertical lines
SLIDE 28
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
- problem: vertical lines
SLIDE 29
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
- problem: vertical lines
- different mapping?
SLIDE 30
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
- problem: vertical lines
- different mapping?
SLIDE 31
WHAT ARE CONVEX SETS OF LINES?
- let’s use duality!
- problem: vertical lines
- different mapping?
[Rosenfeld, 1995]
SLIDE 32
WHAT ARE CONVEX SETS OF LINES?
SLIDE 33
WHAT ARE CONVEX SETS OF LINES?
- desirable properties of convex hull
- connectivity
- anti-exchange property
- affine transformation invariant
SLIDE 34
WHAT ARE CONVEX SETS OF LINES?
- desirable properties of convex hull
- connectivity
- anti-exchange property
- affine transformation invariant
SLIDE 35
WHAT ARE CONVEX SETS OF LINES?
- desirable properties of convex hull
- connectivity
- anti-exchange property
- affine transformation invariant
[Goodman, 1998]
- no such definition exists!
SLIDE 36
WHAT ARE CONVEX SETS OF LINES?
- desirable properties of convex hull
- connectivity
- anti-exchange property
- affine transformation invariant
[Goodman, 1998]
- no such definition exists!
- drop connectivity?
SLIDE 37
WHAT ARE CONVEX SETS OF LINES?
- desirable properties of convex hull
- connectivity
- anti-exchange property
- affine transformation invariant
[Goodman, 1998]
- no such definition exists!
- drop connectivity?
SLIDE 38
WHAT ARE CONVEX SETS OF LINES?
- desirable properties of convex hull
- connectivity
- anti-exchange property
- affine transformation invariant
[Goodman, 1998]
- no such definition exists!
- drop connectivity?
SLIDE 39
WHAT ARE CONVEX SETS OF LINES?
[Gates, 1993]
SLIDE 40
WHAT ARE CONVEX SETS OF LINES?
[Gates, 1993]
- what about directed lines?
SLIDE 41
WHAT ARE CONVEX SETS OF LINES?
[Gates, 1993]
- what about directed lines?
SLIDE 42
WHAT ARE CONVEX SETS OF LINES?
[Gates, 1993]
- what about directed lines?
SLIDE 43
WHAT ARE CONVEX SETS OF LINES?
[Gates, 1993]
- what about directed lines?
SLIDE 44
WHAT ARE CONVEX SETS OF LINES?
[Gates, 1993]
- what about directed lines?
- imprecise lines have a
“general direction”
SLIDE 45
WHAT ARE CONVEX SETS OF LINES?
SLIDE 46
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
SLIDE 47
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
SLIDE 48
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
SLIDE 49
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
SLIDE 50
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
SLIDE 51
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
SLIDE 52
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
- convex hull not defined
SLIDE 53
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
- convex hull not defined
- given by boundary
SLIDE 54
WHAT ARE CONVEX SETS OF LINES?
- a set of lines L is convex when:
- there is a line d /
∈ L such that no line in L is parallel to d d
- if ℓ, ℓ′ ∈ L, all lines between
ℓ and ℓ′ are also in L
- convex hull not defined
- given by boundary
- limit angle α
α
SLIDE 55
PROPERTIES OF IMPRECISE LINES
- connected
- convex
SLIDE 56
PROPERTIES OF IMPRECISE LINES
- connected
- convex
- polygonal
SLIDE 57
PROPERTIES OF IMPRECISE LINES
- connected
- convex
- polygonal
- constant
SLIDE 58
EXAMPLE: LINEAR PROGRAMMING
- important, well known problem
SLIDE 59
EXAMPLE: LINEAR PROGRAMMING
- given set of directed lines
- important, well known problem
SLIDE 60
EXAMPLE: LINEAR PROGRAMMING
- given set of directed lines
- determine the lowest point
to the left of all lines
- important, well known problem
SLIDE 61
EXAMPLE: LINEAR PROGRAMMING
- given set of directed lines
- determine the lowest point
to the left of all lines
- important, well known problem
- takes O(n) time
SLIDE 62
EXAMPLE: LINEAR PROGRAMMING
SLIDE 63
EXAMPLE: LINEAR PROGRAMMING
- given set of imprecise directed lines
SLIDE 64
EXAMPLE: LINEAR PROGRAMMING
- given set of imprecise directed lines
- determine all possible heights
- f the lowest point
to the left of all lines
SLIDE 65
EXAMPLE: LINEAR PROGRAMMING
- given set of imprecise directed lines
- determine all possible heights
- f the lowest point
to the left of all lines
- lowest possible point
SLIDE 66
EXAMPLE: LINEAR PROGRAMMING
- given set of imprecise directed lines
- determine all possible heights
- f the lowest point
to the left of all lines
- lowest possible point
- highest possible point
SLIDE 67
HIGHEST VALUE
SLIDE 68
HIGHEST VALUE
- only consider left borders of bundles
- find lowest point to the left of those
SLIDE 69
HIGHEST VALUE
- only consider left borders of bundles
- apply convex programming
- takes O(n) time
- find lowest point to the left of those
SLIDE 70
LOWEST VALUE
SLIDE 71
LOWEST VALUE
- only consider right borders of bundles
- find lowest point to the left of those
SLIDE 72
LOWEST VALUE
- only consider right borders of bundles
- find lowest point to the left of those
- takes Θ(n2) time
SLIDE 73
LOWEST VALUE
- only consider right borders of bundles
- find lowest point to the left of those
- takes Θ(n2) time
- if α < 180◦ − c
it takes Θ(n log n) time
