Lynas Environmental Management

Lynas Occupational and Environmental Safety and Health Management Systems

• Hazards and risks regulated

primarily by the AELB, DOE and DOSH

• Management involves hazards

identification, Risks assessment, Risks Control and Continuous Improvements

• Management involves:

– Regulatory control through license conditions – Regulators audits and inspections – Third party audit and monitoring – Self-regulations – Recognition by peers, stakeholders and independent parties

Safety and Health at LAMP and the environment

Regulatory Compliance Regulatory Monitoring Self Regulation by Lynas Third Party Monitoring Recognition by peers and stakeholders

Lynas is compliant with its License Conditions

FOSL EIA OSH

• thers

TOL 1st (2 yrs)FOSL 2nd (2 yrs) FOSL 3rd FOSL (3 yrs) [50 major conditions]

78 EIA AC Conditions

NOT under CIMAH regulations MBK, MOH etc Routine audits inspections by AELB Routine audits and inspection by DOE/3rd party Routine inspection by DOSH Inspections

4

Lynas implements TWO Environmental Management Systems: RADIOLOGICAL and NON-RADIOLOGICAL

Safety, Health and Environmental Management

Radiation Safety and Health Management (RSHM) at LAMP

Radiation Safety and Health Radiation Protection Program (adopts RSMS and OHSAS 18001) AELB regulatory Monitoring and Audit AELB FOSL conditions

RSHM is an integral and important part of the

• verall SHES Systems at the LAMP
• 1. Occupational

exposure

• 2. AMS

Public and environmental exposure and impact Carried out by 3rd party

Monitoring Programs - radiation

• Radiation:

– 4 types of monitoring programs by Lynas: a) Occupational Exposure Monitoring Program, b) Environmental Radiation Monitoring Program, c) Aerosol Monitoring System and d) AELB monitoring – Lynas monitoring is carried out by 3rd party consultant accredited by the AELB up to 20 km – Real time and online monitoring using AMS located at LAMP and Kuantan – AELB independent monitoring – Lynas self regulatory monitoring – Data available on line, and reported routinely. (The web address is: https://175.142.36.205/public/map/) – To date Lynas carried out 43 environmental and

• ccupational monitoring

Monitoring is carried out independently by the regulators and 3rd party and Lynas Monitoring Programs

• environment
• Environmental:

– 3rd party audit and inspection approved by DOE – DOE routine regulatory inspection – Lynas carries out it own monitoring and inspections – Data presented on-line and display on digital board located at gate 1 for public to view

Monitoring Monitoring frequency Vendor Monitoring, YTD (Jan,2010 – July,2018) Ambient air Monthly PERMULAB 91 Balok River Monthly PERMULAB 91 Groundwater Monthly PERMULAB 91 Noise level Monthly PERMULAB 91 Stack sampling Half- yearly PERMULAB 17 Final Discharge Point Daily Weekly ESM 2,795 394 (starts 2011) Storm Retention Pond Daily Weekly ESM 2,795 394 (starts 2011) Sewerage Treatment Plant Weekly ESM 342 (starts 2012)

PERFORMANCES

9

Lynas is ISO certified with 3 integrated certifications

▪ Lynas Malaysia Sdn. Bhd. accredited with world- class certifications by Bureau Veritas and NIOSH Certification Sdn Bhd:

• 1. Occupational Health and Safety

Management Systems - OHSAS 18001:2007

• 2. Environmental Management Systems- ISO

14001:2015

• 3. Quality Management Systems - ISO

9001:2015 Our Operational Standards align with International Standards for Safety, Environment, Quality and Social Responsibility

RADIATION PERFORMANCE

43 monitoring from December 2012 – March 2018 showed

NO radiological impact to public and environment

Permissible Limit for public = 1 mSv per year; Permissible Limit for radiation workers = 20 mSv per year

1 1

Work Section Off-site of LAMP Critical Group External Radiation (mSv/year)

222Rn

(mSv/year)

220Rn

(mSv/year) Dust (mSv/year) Total Dose (mSv/year)

238U 232Th

1 km workers working at adjacent plants Equals background 0.002 0.01 Equals background 0.03 5 km Public Equals background Equals background Equals background Equals background Equals background 10 km Public Equals background Equals background Equals background Equals background Equals background 20 km Public Equals background Equals background Equals background Equals background Equals background

NOTE: Dose values given an overestimate, MDL values were used for values less than MDL in calculating doses

NO change in External Radiation Dose Rates since LAMP started operation

0.5 1 1.5 2 2.5 3 3.5 4 December 2012 (1st… January 2013 (2nd Round) February 2013 (3rd Round) March 2013 (4th Round) April 2013 (5th Round) May 2013 (6th Round) June 2013 (7th Round) July 2013 (8th Round) August 2013 (9th Round) September 2013 (10th… October 2013 (11th… November 2013 (12th… December 2013 (13th… January 2014 (14th Round) February 2014 (15th… March 2014 (16th Round) April 2014 (17th Round) May 2014 (18th Round) June 2014 (19th Round) July 2014 (20th Round) August 2014 (21th Round) September 2014 (22th… Nov 2014 (1st Round) January 2015 (2nd Round) March 2015 (3rd Round) May 2015 (4th Round) July 2015 (5th Round) September 2015 (6th… November 2015 (7th… January 2016 (8th Round) March 2016 (9th Round) May 2016 (10th Round) July 2016 (11th Round) September 2016 (12th… November 2016 (13th… January 2017 (14th Round) March 2017 (15th Round) May 2017 (16th Round) July 2017 (7th Round) September 2017 (18th… November 2017 (19th… January 2018 (20th Round) March 2018 (21st Round)

mSv/year

Environmental Radiological Monitoring Program (ERMP)

External Radiation mSv/year (Excluding Background)

Offsite LAMP - 1 km Offsite LAMP - 5 km Offsite LAMP - 10 km Offsite LAMP - 20 km

Genting Highland = 3.4 mSv/year Public Dose Limit = 1mSv/year

Spikes at distances further than 5 km from LAMP indicates higher background radiation levels

NO CHANGE in Radon-Thoron levels since LAMP started operation

2 4 6 8 10 12 14 16 18 20 1/10/2012 1/12/2012 1/02/2013 1/04/2013 1/06/2013 1/08/2013 1/10/2013 1/12/2013 1/02/2014 1/04/2014 1/06/2014 1/08/2014 1/10/2014 1/12/2014 1/02/2015 1/04/2015 1/06/2015 1/08/2015 1/10/2015 1/12/2015 1/02/2016 1/04/2016 1/06/2016 1/08/2016 1/10/2016 1/12/2016 1/02/2017 1/04/2017 1/06/2017 1/08/2017 1/10/2017 1/12/2017 1/02/2018 1/04/2018 1/06/2018

Bq/m3 Monitoring Date

Radon-Thoron (EEC) Measured by AMS at the LAMP & IPD

Radon 222 EEC LAMP (Radon) Radon 220 EEC LAMP (Thoron) Radon 222 EEC IPD (Radon) Radon 220 EEC IPD (Thoron) Radon 220 Background Radon 222 Background

AELB occupational limits: Radon = 1481.6 Bq/m3 Thoron = 330 Bq/m3

1 4

ENVIRONMENTAL PERFORMANCE

Envirnmental Monitoring Frequency

15

Monitoring Monitoring frequency Vendor Monitoring, YTD (Jan,2010 – July,2018) Ambient air Monthly PERMULAB 91 Balok River Monthly PERMULAB 91 Groundwater Monthly PERMULAB 91 Noise level Monthly PERMULAB 91 Stack sampling Half- yearly PERMULAB 17 Final Discharge Point Daily Weekly ESM 2,795 394 (starts 2011) Storm Retention Pond Daily Weekly ESM 2,795 394 (starts 2011) Sewerage Treatment Plant Weekly ESM 342 (starts 2012)

16

MONITORING TREATED EFFLUENT DISCHARGED

0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 8.00 9.00 10.00 January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May 2013 2014 2015 2016 2017 2018 pH

Effluent pH

pH Lower Limit Upper Limit

17

MONITORING TREATED EFFLUENT DISCHARGED

0.00 20.00 40.00 60.00 80.00 100.00 120.00 January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May 2013 2014 2015 2016 2017 2018 mg/L

Total Suspended Solid (TSS)

SS Limit

18

MONITORING TREATED EFFLUENT DISCHARGED

0.00 50.00 100.00 150.00 200.00 250.00 January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May 2013 2014 2015 2016 2017 2018 mg/L

Effluent Chemical Oxygen Demand (COD)

COD Limit

19

MONITORING TREATED EFFLUENT DISCHARGED

0.00 1.00 2.00 3.00 4.00 5.00 6.00 January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May 2013 2014 2015 2016 2017 2018 mg/L

Iron (Fe)

Fe Limit

20

MONITORING TREATED EFFLUENT DISCHARGED

0.00 0.50 1.00 1.50 2.00 2.50 3.00 January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May June July August September October November December January February March April May 2013 2014 2015 2016 2017 2018 mg/L

Manganese (Mn)

Mn limit

Lynas has improved and rectified this issue

RADIATION AND RADIOACTIVITY IN PERSPECTIVE

2 1

22

Material Typical Radioactivity (ppm) References Uranium thorium Lynas NORM Lanthanide concentrate (3000 samples) 30 1413 Lynas WLP (ERMP 13 - 19) 31 1789 Amang Raw tailing 189 – 1064 622 - 4965 Alnour et al. (2017) AIP Conference Proceedings Monazite 1076 – 1988 3467 - 33578 Zenotime 4053 5540 Zircon 309 – 3090 387 - 6339 Ilmenite 104 – 583 88 - 1205 Waste 5 – 338 9 - 1218

Comparison Between Radioactivity in Amang (Tin Tailing) and Lynas NORM

Lyas residue is comparabe

23

Lynas is DIFFERENT from Asia Rare Earth, Bukit Merah

Lynas Asia Rare Earth Remark Raw Material Ore from Mt Weld, Australia Tin mining tailing (amang) Malaysia Thorium content in raw material 0.16 % 6 % ARE is 37.5 x higher than Lynas Thorium Concentration in residue 0.165 % 10 % ARE is 60 x higher than Lynas

24

General Radiation Exposure relative to exposure from Lynas Operation

Normal Human Activity Annual Exposure (mSv/y) Dose to lungs from smoking a pack of cigarette daily 150 Yearly dose to airline crew 9 Medical or dental X-ray > 0.39 Doses from Background radiation: Worldwide average Kerala coast, India Norther Iran (Ramsar, Iran) 2.4 12.5 260 Lynas operation: a. Workers at WLP RSF (radiation workers) b. I km away (public) 2 Background Permissible Dose Limit for Radiation Workers Permissible Dose Limits for members of the public 20 1

• 25-

WLP Residue Storage Facility is designed and constructed to meet PDF standards

CONTROLLED FILL DUAL LINER SYSTEM

POLYETHYLENE (HDPE) LINER CLAY LINER SCARIFY AND RECOMPACT

PLACED AND TRAFFIC COMPACTED WLP RESIDUE RAISES OF CONTROLLED FILL EXISTING GROUND LEVEL EXISTING GROUND LEVEL EROSION PROTECTION

DETAIL

Dual liner consists of a 300 mm low permeability compacted clay liner overlaid with a 1.0 mm thick HDPE liner The RSF is built on top (not excavated!!)
