LLC UKRELEKTROAPARAT Company presentation 2019 LLC UKRELEKTROAPARAT The history of enterprise LLC UKRELEKTROAPARAT was founded in 1957 as the specialized enterprises for the production of power transformers and transformer


slide-1
SLIDE 1

2019

LLC «UKRELEKTROAPARAT»

Company presentation

slide-2
SLIDE 2

1

LLC «UKRELEKTROAPARAT» was founded in 1957 as the specialized enterprises for the production of power transformers and transformer substations. Throughout history, the company did not change its activities. At that time the company was called «Khmelnitsky plant of transformer substations». In just 15 years of operation, the company has become the industry leader in the Khmelnitsky region. In the 70's years the factory was awarded three awards for its activities: Order of the Red Flag, the challenge Red Banner of the Central Committee of the CPSU, the transition flag branch trade union. In the entire history of the plant more than 150 employees received state awards. In the 80's the company has significantly expanded the geography of deliveries, it helped to increase the speed of the volume production. In the 90's the plant was reoriented for new market conditions and save the staff after hard times at the collapse of the Soviet Union. 2000's, years - further development and technical plant re-equipment and year of successful work of the enterprise.

The history of enterprise

2019

LLC «UKRELEKTROAPARAT»

slide-3
SLIDE 3
  • The plant employs about 800 workers;
  • Production facilities are more than 60000 m²;
  • The company has a complete closed cycle for the production of power

transformers and substation, involved nine separate departments;

  • The plant has strong design departments, allowing to independently

develop all the company's products;

  • Product range includes more than 600 types of transformers and

substations;

  • The company has its own railway infrastructure on the territory, which

makes it possible to send the products for export to all corners of Eurasia;

  • Production capacity is more than 700 transformers and 200 substations per

month.

2

The company today

2019

LLC «UKRELEKTROAPARAT»

slide-4
SLIDE 4
  • power generating company (products for their own power needs);
  • utility companies are the main consumers of the whole enterprise

nomenclature;

  • products for manufacturers of electric (traction transformers and inductors);
  • products for railway electrification infrastructure;
  • products for the gas and oil companies;
  • products for green power plants (wind and solar);
  • products for the power of small and large industrial facilities.

3

The main consumers

2019

LLC «UKRELEKTROAPARAT»

slide-5
SLIDE 5
  • Oil-field tank power transformers with the power up to 6300 kVA;
  • Dry type transformers with «F» and «H» class of heat resistance;
  • One phase traction transformers;
  • Compact transformer substations;
  • Large transformer substations;
  • Concrete transformer substations;
  • High and low voltage switchboards.

5

The company's main nomenclature

2019

LLC «UKRELEKTROAPARAT»

slide-6
SLIDE 6

LLC «UKRELEKTROAPARAT»

6

The geography of supplies

The volume of exports is up to 70%

2019

slide-7
SLIDE 7

7

The main equipment for the manufacturing

LLC «UKRELEKTROAPARAT»

Coordinate-revolving and sheet-bending press «FINN-POWER», Finland

2019

slide-8
SLIDE 8

8

LLC «UKRELEKTROAPARAT»

The Line of the cutting of the electrical steel "L.A.E", Italy

2019

slide-9
SLIDE 9

9

LLC «UKRELEKTROAPARAT»

3D processing center "AVIA", Poland

2019

slide-10
SLIDE 10

10

LLC «UKRELEKTROAPARAT» Sheet-bending press «FINN-POWER», Finland

2019

slide-11
SLIDE 11

11

LLC «UKRELEKTROAPARAT» sheet-bending press «ERMAK», Turkey

2019

slide-12
SLIDE 12

12

LLC «UKRELEKTROAPARAT» Guillotine scissors «ERMAK», Turkey

2019

slide-13
SLIDE 13

13

LLC «UKRELEKTROAPARAT» Turret-lathe «HAAS», USA

2019

slide-14
SLIDE 14

14

LLC «UKRELEKTROAPARAT» Laser cutting machine «TRUMPF», Germany

2019

slide-15
SLIDE 15

15

Lines of cutting electrical steel «GEORG», Germany

2019

LLC «UKRELEKTROAPARAT»

slide-16
SLIDE 16

16

LLC «UKRELEKTROAPARAT»

2019

Stand-tilting for magnetic circuit assembly «L.A.E», Italy

slide-17
SLIDE 17

17

LLC «UKRELEKTROAPARAT» Winding machines LV and HV windings «TUBOLY», Switzerland

2019

slide-18
SLIDE 18

18

LLC «UKRELEKTROAPARAT» The line for corrugated walls production «L.A.E.», Italy

2019

slide-19
SLIDE 19

19

LLC «UKRELEKTROAPARAT» Italian powder coating line “Euroimpianti”

2019

slide-20
SLIDE 20

At the plant works an accredited testing center certified "by the National Accreditation Agency of Ukraine". The Centre is authorized to carry out tests of electrical products from

  • ther manufacturers.

In addition, the company has international certifications from leading electrical labs: «KEMA» The Netherlands, «Lloyds» England, «VNL» Hungary.

20

LLC «UKRELEKTROAPARAT»

The Quality Management System

In 1997, the company has implemented and successfully operates a quality management system ISO 9001. The plant is certified by the German certification center «TUV».

Certification and testing

2019

slide-21
SLIDE 21

21

LLC «UKRELEKTROAPARAT»

2019

slide-22
SLIDE 22

22

LLC «UKRELEKTROAPARAT»

2019

slide-23
SLIDE 23

23

LLC «UKRELEKTROAPARAT»

2019

slide-24
SLIDE 24

24

LLC «UKRELEKTROAPARAT»

2019

slide-25
SLIDE 25

25

2019

BASIC FACTORY PRODUCTS

(SHORT DESCRIPTION OF APPLICATION)

LLC «UKRELEKTROAPARAT»

slide-26
SLIDE 26

26

2019

Oil filled transformers of series ТМ (with a conservator, ranging from 10 to 6300 kVA) and TMG (oil sealed transformer with corrugated tank walls, ranging from 10 to 2500 kVA; up to 35 kilovolt voltage grade);

slide-27
SLIDE 27

27

2019

The stationary power oil transformers three-phase two-winding step- down with nominal capacity from 1000 up to 6300 kVA, voltage up to 35 kV with on-load (OLTC) are used for needs of national economy.

slide-28
SLIDE 28

28

2019

Power oil three-phase double winding transformers with the power from 630 to 2500 kVA and voltage up to 10 kV for indoor and outdoor transformer substations.

slide-29
SLIDE 29

29

2019

Dry type transformers, series TCZGL (with «Siemens» cast windings). Insulation class F (155°C). Power capacity is from 100 to 2500 kVA for voltage up to 10 kV.

slide-30
SLIDE 30

30

2019

Power oil transformers for oil industry of series TMPNG, up to10 kilovolt voltage grade with the opportunity of operation in the frequency transformation circuits from 35 to 70 Hz

slide-31
SLIDE 31

31

2019

The transformer ONDCE -4350 is used to convert line voltage into a voltage of traction engine chains through rectifying installation and for own locomotive needs.

slide-32
SLIDE 32

32

2019

The transformer ODCE-2000 is used to convert line voltage into a voltage of the circuits of traction engines and their own needs.

slide-33
SLIDE 33

33

2019

The transformer ONDCER-3000 is used to convert line voltage into a voltage of the circuits of traction motors connected through semiconductor converter, and also for smoothing pulsations

  • f rectified current.
slide-34
SLIDE 34

34

2019

Transformer substations container type for power supply (up to 1000 kVA) of residential and commercial complexes (with the reduced overall dimensions, improved lay-out and external view).

slide-35
SLIDE 35

35

2019

Power distribution substations indoor and outdoor installation for industrial use. (power supply up to 2500 kVA)

slide-36
SLIDE 36

36

2019

Complete transformer substations in the concrete housing type KTPB with the power of 63-1600 kVA. The technology allows to realize any customer project.

slide-37
SLIDE 37

37

2019

Inexpensive simple and comfort in service power substations of tower type with the power from 25 to 250 kVA.

slide-38
SLIDE 38

38

2019

ALTERNATIVE ENERGY

  • Developed
  • Production
  • Service

LLC «UKRELEKTROAPARAT»

slide-39
SLIDE 39

39

2019

LLC «UKRELEKTROAPARAT»

Products for alternative energy

  • power oil transformers;
  • power dry transformers;
  • complete transformer substations in concrete shell;
  • complete transformer substations in metal shell;
  • complete transformer substations in warmed-up shel;
  • cabinets for protection of inverters DC and AC voltage
  • distribution devices of RP 10-35 kV;
  • "Combiner box" - voltage cabinets DC;
  • structural elements for installation solar panels;
slide-40
SLIDE 40

40

2019

LLC «UKRELEKTROAPARAT»

Distribution transformers Specifications

  • Primary voltage 3-35 kV;
  • Secondary voltage 220 - 1000 V;
  • power rating 250-6300 kVA;
  • constructive performance: two-winding, three-winding;
  • Load losses and No-load losses: standard, advanced level,

and according to COMMISSION REGULATION (EU) #548/2014 of 21 May 2014 (Ecodesign Consultation)

slide-41
SLIDE 41

41

2019

LLC «UKRELEKTROAPARAT»

Connected hermetic oil transformer -1000 kVA

slide-42
SLIDE 42

42

2019

LLC «UKRELEKTROAPARAT»

Hermetic transformers 2000, 1600 kVA for solar energy

slide-43
SLIDE 43

43

2019

LLC «UKRELEKTROAPARAT»

Monitoring device for oil transformers R.I.S. (pressure, oil level, oil temperature)

slide-44
SLIDE 44

44

2019

LLC «UKRELEKTROAPARAT»

Concrete substation with transformer 1600 кVА

slide-45
SLIDE 45

45

2019

LLC «UKRELEKTROAPARAT»

Complete transformer substations Basic technical characteristics

  • rated voltage HV: 3-35 kV;
  • rated voltage of LV: 220 - 450 V;
  • power rate: 250-6300 kVA;
  • design of transformer substations: metal,

concrete building, sandwich panels (insulated);

  • climatic performance: -60° to +50° C;
  • lifespan: at least 30 years;
  • the possibility of individual project development ASAP.
slide-46
SLIDE 46

46

2019

LLC «UKRELEKTROAPARAT»

Shipment of substation in concrete shell 1600

slide-47
SLIDE 47

47

2019

LLC «UKRELEKTROAPARAT»

The installation of a substation 1600 kVA at the solar power plant . The company "Rengy Development"

slide-48
SLIDE 48

48

2019

LLC «UKRELEKTROAPARAT»

Low Voltage Compartment (Inverters of 880 kW - 2 pcs.)

slide-49
SLIDE 49

49

2019

LLC «UKRELEKTROAPARAT» The process of manufacturing concrete substations 1600 kVA

slide-50
SLIDE 50

50

Ukraine, 29000 Khmelnytsky, V. Chornovola str., 120
