Lattice gauge theories with Tensor Networks Luca Tagliacozzo Based on: L. Tagliacozzo G. Vidal Entanglement renormalization and gauge symmetry Phys. Rev. B 83, 115127 (2011) L. Tagliacozzo, A. Celi, M. Lewenstein Tensor Networks for

slide-1
SLIDE 1

Lattice gauge theories with Tensor Networks

Luca Tagliacozzo Based on:

  • L. Tagliacozzo G. Vidal

“Entanglement renormalization and gauge symmetry”

  • Phys. Rev. B 83, 115127 (2011)
  • L. Tagliacozzo, A. Celi, M. Lewenstein “Tensor

Networks for Lattice Gauge Theories with continuous groups”, arXiv:1405.4811

slide-2
SLIDE 2

07/13/16 Luca Tagliacozzo, LGT and TN 2

Outline

Gauge theories in HEP 5 min Lattice gauge theory 5 min Motivation for TN and LGT 1 min Symmetries and superposition 15 min BB Exotic phases of matter 5 min Intro to Tensor Networks 5 min Intro to LGT (Z2) 20 min BB TN for Gauge theories (Z2) 20 min BB Generalization 10 min Example of results (2D MERA + PEPS) 5 min

slide-3
SLIDE 3

07/13/16 Luca Tagliacozzo, LGT and TN 3

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-4
SLIDE 4

07/13/16 Luca Tagliacozzo, LGT and TN 4

Gauge Theories

→ HEP, form QED, QCD, Standard Model, elementary gauge bosons → COND-MAT spin liquids, dimers (electrons in a material), emerging gauge bosons → Lattice allows for non-perturbative formulation of QCD

Wilson, K. G. Confinement of quarks.

  • Phys. Rev. D 10, 2445–2459 (1974).
slide-5
SLIDE 5

07/13/16 Luca Tagliacozzo, LGT and TN 5

slide-6
SLIDE 6

07/13/16 Luca Tagliacozzo, LGT and TN 6

slide-7
SLIDE 7

07/13/16 Luca Tagliacozzo, LGT and TN 7

slide-8
SLIDE 8

07/13/16 Luca Tagliacozzo, LGT and TN 8

slide-9
SLIDE 9

07/13/16 Luca Tagliacozzo, LGT and TN 9

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-10
SLIDE 10

07/13/16 Luca Tagliacozzo, LGT and TN 10

Lattice gauge theories

slide-11
SLIDE 11

07/13/16 Luca Tagliacozzo, LGT and TN 11

Achievements LGT

  • Evidences of mass-gap in Yang Mills from

first principles.

  • Precise determination
  • f the lowest excitations

(agreement with experiments)

  • Matrix elements input for

phenomenology of Standard model

Fodor, Z. & Hoelbling, C. Light Hadron Masses from Lattice QCD.

  • Rev. Mod. Phys. 84, 449–495 (2012).

Aoki, S. et al. Review of lattice results concerning low energy particle physics. ArXiv:1310.8555

slide-12
SLIDE 12

07/13/16 Luca Tagliacozzo, LGT and TN 12

Limitations LGT

  • Classification of phases
  • QCD at non-zero temperature and density

(nuclear matter)?

  • Real time dynamics (experiments at RICH and

CERN)

slide-13
SLIDE 13

07/13/16 Luca Tagliacozzo, LGT and TN 13

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-14
SLIDE 14

07/13/16 Luca Tagliacozzo, LGT and TN 14

Achievements in TN/Quantum Many Body

  • Study of frustrated and fermionic systems
  • Out of equilibrium dynamics
  • Characterization of topological phases

Corboz, P., Evenbly, G., Verstraete, F. & Vidal, G. Simulation of interacting fermions with entanglement renormalization.

  • Phys. Rev. A 81, 010303 (2010).

SEE PHILIPPE/TAO

  • Vidal, G. Efficient Classical Simulation of Slightly

Entangled Quantum Computations.

  • Phys. Rev. Lett. 91, 147902 (2003).
  • White, S. R. & Feiguin, A. E.

Real time evolution using the density matrix renormalization group.

  • Phys. Rev. Lett. 93, (2004).
  • Kitaev, A. & Preskill, J.

Topological Entanglement Entropy. Phys. Rev. Lett. 96, 110404 (2006).

  • Levin, M. & Wen, X.-G.

Detecting Topological Order in a Ground State Wave Function.

  • Phys. Rev. Lett. 96, 110405 (2006).

See also FRANK/NORBERT/FRANK

slide-15
SLIDE 15

07/13/16 Luca Tagliacozzo, LGT and TN 15

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-16
SLIDE 16

07/13/16 Luca Tagliacozzo, LGT and TN 16

Symmetry and superpositon

  • We can try to construct local H whose ground

state has large superpositions

  • One possibility is Hamiltonian with a

symmetry

PRODUCT GROUND STATE ENTANGLED GROUND STATE

slide-17
SLIDE 17

07/13/16 Luca Tagliacozzo, LGT and TN 17

Fate of large superpositions

  • If there is a global discrete symmetry, it is

spontaneously broken in the ground state (Absence of macroscopic cat states)

  • If there is a local discrete symmetry the

symmetry is not broken in the ground state (Presence of long range entanglement and short correlations)

  • Phase transition without symmetry breaking....
slide-18
SLIDE 18

07/13/16 Luca Tagliacozzo, LGT and TN 18

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-19
SLIDE 19

07/13/16 Luca Tagliacozzo, LGT and TN 19

slide-20
SLIDE 20

07/13/16 Luca Tagliacozzo, LGT and TN 20

slide-21
SLIDE 21

07/13/16 Luca Tagliacozzo, LGT and TN 21

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-22
SLIDE 22

07/13/16 Luca Tagliacozzo, LGT and TN 22

Notation

slide-23
SLIDE 23

07/13/16 Luca Tagliacozzo, LGT and TN 23

Quantum Many Body

slide-24
SLIDE 24

07/13/16 Luca Tagliacozzo, LGT and TN 24

slide-25
SLIDE 25

07/13/16 Luca Tagliacozzo, LGT and TN 25

Tensor Networks for LGT

slide-26
SLIDE 26

07/13/16 Luca Tagliacozzo, LGT and TN 26

What do TN describe

slide-27
SLIDE 27

07/13/16 Luca Tagliacozzo, LGT and TN 27

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) (Blackboard) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-28
SLIDE 28

Constructing Z2 LGT

Discussed by Kogut & Susskind, M. Creutz 70s

  • Definition of a group
  • Group algebra
  • Building regular representation

matrices

  • Irreducible representations
  • The local symmetry
  • Interactions
  • Hamiltonian
  • Phases
  • TN ansatz
slide-29
SLIDE 29

07/13/16 Luca Tagliacozzo, LGT and TN 29

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) (Blackboard) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-30
SLIDE 30

Hamiltonian LGT

Discussed by Kogut & Susskind, M. Creutz 70s

slide-31
SLIDE 31

07/13/16 Luca Tagliacozzo, LGT and TN 31

Constructing a LGT

  • Constituents on links
  • Local symmetry operators
  • Left right rotations of the state

Tagliacozzo, L., Celi, A. & Lewenstein, M. TN for LGT with continuous groups. ArXiv:1405.4811

Notion of symmetry

slide-32
SLIDE 32

07/13/16 Luca Tagliacozzo, LGT and TN 32

Tensors

a) b)

slide-33
SLIDE 33

07/13/16 Luca Tagliacozzo, LGT and TN 33

Orthogonality theorem

Matrix representation of g in irrep r:

Serre, J.-P. Linear representations of finite groups. (Springer-Verlag, 1977).

slide-34
SLIDE 34

07/13/16 Luca Tagliacozzo, LGT and TN 34

LR multiplication

slide-35
SLIDE 35

07/13/16 Luca Tagliacozzo, LGT and TN 35

Generalized cross

  • perators
slide-36
SLIDE 36

07/13/16 Luca Tagliacozzo, LGT and TN 36

Generalized disentanglers

  • U operators
slide-37
SLIDE 37

07/13/16 Luca Tagliacozzo, LGT and TN 37

Gauge invariant Hilbert space

slide-38
SLIDE 38

07/13/16 Luca Tagliacozzo, LGT and TN 38

Dynamic on Hp

Kogut, J. & Susskind, L. Phys. Rev. D 11, 395 408 (1975). – Creutz, M. Phys. Rev. D 15, 1128 (1977).

slide-39
SLIDE 39

07/13/16 Luca Tagliacozzo, LGT and TN 39

Outline

Gauge theories in HEP Lattice gauge theory Motivation for TN and LGT Symmetries and superposition Exotic phases of matter Intro to Tensor Networks Intro to LGT (Z2) (Blackboard) Tensor Networks for Gauge theories (Z2) Generalization Example of results (2D MERA + PEPS)

slide-40
SLIDE 40

07/13/16 Luca Tagliacozzo, LGT and TN 40

The two ways

MERA,Hierarchical TN

Tagliacozzo, L. & Vidal, G.

  • Phys. Rev. B 83, 115127 (2011)

Tagliacozzo, L., Celi, A. & Lewenstein, M. ArXiv:1405.4811

TPS/PEPS

slide-41
SLIDE 41

07/13/16 Luca Tagliacozzo, LGT and TN 41

Variational Ansatz for gauge invariant states

  • Phys. Rev. B 83, 115127 (2011)
slide-42
SLIDE 42

07/13/16 Luca Tagliacozzo, LGT and TN 42

Low energy spectrum MERA

Z2 LGT 8x8 torus

  • Phys. Rev. B 83, 115127 (2011)
slide-43
SLIDE 43

07/13/16 Luca Tagliacozzo, LGT and TN 43

Disorder parameter MERA

Z2 LGT 8x8 torus

  • Phys. Rev. B 83, 115127 (2011)
slide-44
SLIDE 44

07/13/16 Luca Tagliacozzo, LGT and TN 44

Topological fidelities MERA

  • Phys. Rev. B 83, 115127 (2011)
slide-45
SLIDE 45

07/13/16 Luca Tagliacozzo, LGT and TN 45

Topological QPT with TPS

From the ground state of to the ground state of

Through a wave function modification

ArXiv:1405.4811

slide-46
SLIDE 46

07/13/16 Luca Tagliacozzo, LGT and TN 46

Topological Entropy

ArXiv:1405.4811

Stéphan et. al. Phys. Rev. B 80, 184421 (2009). Stéphan et. al. J. Stat 2012, P02003 (2012).

slide-47
SLIDE 47

07/13/16 Luca Tagliacozzo, LGT and TN 47

Schmidt-gap

Does not detect the topological phase transition

ArXiv:1405.4811

Li, H. & Haldane, F. D. M. Phys. Rev. Lett. 101, 010504 (2008). De Chiara et. al Phys. Rev. Lett. 109, (2012).

  • A. Läuchli, arXiv:1303.0741

Luitz, D. et al. J. Stat. 2014, P08007 (2014).

slide-48
SLIDE 48

07/13/16 Luca Tagliacozzo, LGT and TN 48

Conclusions

  • I have justified the need of TN framework to

analyze LGT

  • It is suited both for theoretical analysis

and to design numerical ansatz

  • Discrete, continuous Abelian and Non-Abelian

model can be considered

  • Both hierarchical TN and TPS/PEPS
  • Already have benchmark numerical results in

2D

  • Easily extended to include matter
  • Interesting time to come...

THANKS FOR THE ATTENTION !!!
