LArTPC Testbeam: CAPTAIN and LArIAT Jason St. John, University of Cincinnati On behalf of the LArIAT Collaboration and for the CAPTAIN Collaboration NuFact 2015, Rio de Janeiro Outline miniCAPTAIN (neutrons) & LArIAT (charged species) -

slide-1
SLIDE 1

LArTPC Testbeam: CAPTAIN and LArIAT

Jason St. John, University of Cincinnati On behalf of the LArIAT Collaboration and for the CAPTAIN Collaboration NuFact 2015, Rio de Janeiro

slide-2
SLIDE 2

Outline

2

miniCAPTAIN (neutrons) & LArIAT (charged species)

  • Liquid Argon TPC Test Beams for Neutrino Physics
  • Physics goals
  • R&D goals
  • Experimental Setups
  • Incident Beams
  • Inside the cryostat
  • Beautiful data
  • Future plans
slide-3
SLIDE 3

LArTPCs Test Beams for Neutrino Physics

Liquid argon time projection chambers (LArTPCs) capture neutrino interaction final products in unprecedented detail Dedicated calibration effort needed

3

MicroBooNE DUNE SBND ICARUS

slide-4
SLIDE 4

MiniCAPTAIN

Cryogenic Apparatus for Precision Tests of Argon Interactions with Neutrinos

4

slide-5
SLIDE 5

1m Ø LArTPC in neutron beam at Weapons Neutron Research facility

Physics goals: Ar* nuclear de-excitations Neutron scatters at known En Neutron-induced π± production

MiniCAPTAIN

5

The mini- CAPTAIN cryostat

slide-6
SLIDE 6

6

Los Alamos National Lab Los Alamos Neutron Science Center

slide-7
SLIDE 7

Incident Beam

Known neutron energy from Time of Flight

  • Beam on target starts

clock

  • Cryogenic PMTs stop it

7

Neutron beam energy spectrum will be closely matched to cosmic-induced neutron energy spectrum

slide-8
SLIDE 8

Inside the cryostat

8

1 m 32 cm

Cathode wires Wire/anode planes Readout ASICs

The time projection chamber

  • MicroBooNE cold electronics
  • 3 planes @ 3 mm pitch
  • Drift field ~500 V/cm
  • 16 x 1” PMTS
slide-9
SLIDE 9

LArIAT

Liquid Argon In A Testbeam

9

slide-10
SLIDE 10

LArIAT

“Table-top” (170L) LArTPC in a test beam at Fermilab Test Beam Facility

  • Repurposed ArgoNeuT detector
  • Physics goals:
  • π-Ar interactions
  • e/γ shower ID
  • μ-Ar capture
  • non-magnetic charge determination
  • kaon studies
  • Geant4 validation
  • R&D goals:

Optimize PID algorithm, calorimetry with charge & light, and 2D/3D event reconstruction

10

The ArgoNeuT/LArIAT TPC and cryostat

90 cm 47 cm 40 cm

slide-11
SLIDE 11

11 Linac Booster

Main Injector

Fermilab Test Beam Facility

slide-12
SLIDE 12

Beamline Plan View

12

Tertiary Beamline & LArIAT TPC Tunable 8 - 64 GeV π± Primary 120 GeV p Secondary Target (Cu) Primary Target (Al)

slide-13
SLIDE 13

Beamline Plan View

13

Primary Target (Al) Secondary Target (Cu) Tertiary Beamline & LArIAT TPC Tunable 8 - 80 GeV π± Primary 120 GeV p

next slide

slide-14
SLIDE 14

Tertiary Beamline

14

Secondary beam 8-64 GeV π±

collimator Cu target Time of flight scintillators Multi-wire proportional chambers (MWPCs) Bending dipole magnets Aerogel counters Cryostat & TPC μ punch- through paddles μ range stack

slide-15
SLIDE 15

Tertiary Beamline

15

slide-16
SLIDE 16

Incident Particle Beam

MWPCs + bending magnet

  • Charge-selected beam

200 - 1200 MeV/c

  • Single-particle momentum

measurements

16

Momentum windows in excellent agreement with simulation

Upstream MWPCs Downstream MWPCs

Δθ

  • J. St. John
slide-17
SLIDE 17

Incident Particle Beam

17

Full and Half momentum settings/magnet currents cover MicroBooNE neutrino event secondary momentum range

I.Nutini

MWPCs + bending magnet

slide-18
SLIDE 18

Incident Particle Beam

Time of flight (TOF) for separation between π’s/μ’s and protons ~2:1 ratio of π/µ to p

18

TOF vs reconstructed momentum

π/μ p p π/μ K

  • J. Ho
  • J. Ho
slide-19
SLIDE 19

Incident Particle Beam

Aerogel Cherenkov counters for further PID Possible π vs. μ discrimination using combination of thresholds and pulse height Effective for TPC-contained π/µ range: 230-400 MeV/c

19

Fast particles Slow particles

  • E. Iwai
slide-20
SLIDE 20

Incident Particle Beam

Muon range stack for discrimination of through- going muons/pions Effective for high-p π/µ range: 400+ MeV/c Some commissioning still

  • ngoing

20

π+/- μ+/-

slide-21
SLIDE 21

Inside the cryostat

21

9 c m 47 cm 40 cm

Cathode plane Wire/anode planes Pulse Shaping & Amplifying ASICs

The time projection chamber

  • Repurposed from ArgoNeuT
  • New wire planes, 240 wires each
  • shield
  • induction
  • collection
  • Drift field ~500 V/cm
slide-22
SLIDE 22

22

Light collection system

  • 2 PMTs + 3 SiPMs
  • VUV scintillation light wavelength-

shifted at TPB-coated reflector foils lining field cage

TPB reflector Field cage wall

Inside the cryostat

Photoelectron yield: ~40 p.e./MeV at zero E-field

slide-23
SLIDE 23

First data

▪ April 30, 2015 – TPC turned on, first cosmic-triggered track!

23

LArIAT

slide-24
SLIDE 24

First data

24

…and first beam events soon after…

LArIAT

slide-25
SLIDE 25

Tired, Happy Scientists

25

slide-26
SLIDE 26

Primer on beam events

26

Incident Beam Direction z y U z V y LArIAT d r i f t t i m e U wire V wire drift time drift time d r i f t t i m e

slide-27
SLIDE 27

π+/- p p γ γ γ γ π+/-

Some event topologies seen by LArIAT

27

π+/- single charge exchange p p

LArIAT

slide-28
SLIDE 28

Some event topologies seen by LArIAT

28

π- absorption on Ar Stopping/decaying π+/- π+/- π+/- μ+/- μ+/- π - π - p p p p e+/- e+/-

LArIAT LArIAT

slide-29
SLIDE 29

Some event topologies seen by LArIAT

29

Photon-initiated shower e+/- -initiated shower

Distinguishable using dE/dx at start of shower

LArIAT LArIAT

slide-30
SLIDE 30

Some event topologies seen by LArIAT

30

K+/- → π+/- π0 K- K- π - µ- e- γ γ γ γ π - µ- e-

LArIAT

slide-31
SLIDE 31

Some event topologies seen by LArIAT

31

K+/- → π+/- π0 K- K- π - µ- e- γ γ γ γ π - µ- e-

Monte Carlo LArIAT

slide-32
SLIDE 32

Summary of Run I

Beam data taking ran about 2 months

32

Beam-taking Low-E source running

slide-33
SLIDE 33

A few ongoing analyses…

33

slide-34
SLIDE 34

Eye scan of a small fraction of the data

34

Topology breakdown among the unambiguous, single-track events A rich physics program will emerge from analyses!

  • N. Birrer
  • K. Nelson
  • S. O’Neil
slide-35
SLIDE 35

Reconstruction status

Rapid progress in reconstructing both beamline & TPC ionization tracks

35

  • R. Acciarri
  • T. Yang
  • I. Nutini

Pion scatter Cosmic μ

Wire chamber tracks

  • M. Smylie

MWPC1

  • A. Olivier

MWPC2 MWPC3 MWPC4 TPC volume

slide-36
SLIDE 36

N2 levels with scintillation light

36

N2 content in LAr suppresses scintillation light From fits to scintillation light extract “late” light time component and determine N2 concentration

Results agree with gas analyzers

  • P. Kryczynski
  • A. Szelc

Slow component decay time (/ns) Nitrogen concentration (/ppm) Nitrogen contamination

Comparison with model from WArP

slide-37
SLIDE 37

Electron lifetime / O2 levels with cosmic μ’s

37

μ

Dedicated paddles for cosmic-μ triggers

  • R. Acciarri

Fit to charge vs. drift time for measurement of electron lifetime

Able to calculate O2 concentration below sensitivity of our gas analyzers

Current results show O2 < 1ppb, agreement with gas analyzers

slide-38
SLIDE 38

Pion interactions I – elastic scattering

38

inelastic scatter absorption

  • n Ar

charge exchange pion production

  • I. Nutini

Pion-Argon elastic scattering Look for kinks in incoming pion-tagged tracks

LArIAT

slide-39
SLIDE 39

39

Pion absorption

  • Incident tagged π, no π’s in final state
  • Often accompanied by protons/neutrons

Pion interactions II – absorption

LArIAT LArIAT

slide-40
SLIDE 40
  • R. Linehan

Reconstructed “clusters”

Pion single charge exchange

40

Active effort to ID and reconstruct

  • π0 mass peak from mγγ
  • Cross section

MC studies to understand containment

  • f these events in TPC

π+ + n π0 + p γ γ

  • J. Ho
  • J. Ho
slide-41
SLIDE 41

Michel electrons

41

LAr scintillation-based trigger to record stopping/decaying cosmic μ’ s Initial reconstruction focused on light signals only

  • Track/shower algorithms to follow

Eventual use as energy calibration source and measurement of μ- nuclear capture rate

Ideal e+/- spectrum for decaying free μ

Preliminary

Decay time of LArIAT Michel candidates (~10 hrs data) ns

LArIAT

slide-42
SLIDE 42

Summary

LArTPC test beams are getting underway! MiniCAPTAIN has just seen its calibration laser track

  • Neutron beam running will begin soon

LArIAT’s run 1 was a success – lots of new data to analyze

  • Offline event reconstruction actively evolving day-by-day
  • Several analyses underway with more to come
  • Actively preparing for Run II this Autumn

Detailed calibration, cross sections, etc. on the horizon!

42

slide-43
SLIDE 43

43

Thank you!

slide-44
SLIDE 44

Backup

44

slide-45
SLIDE 45

Beam commissioning

45

Installation of beamline detectors and TPC-less running to test them (and characterize the beam) Completed summer 2014

slide-46
SLIDE 46

Cryogenic Ultra-Pure LAr

46

slide-47
SLIDE 47

Powerful, flexible trigger system

47

slide-48
SLIDE 48

Incident Beam

Time of Flight → En

  • Beam on target starts

clock

  • Cryogenic PMTs stop it

Time structure of n beam:

  • 625 µs macropulses of

sub-ns micropulses @ 1.8 µs

  • 40 Hz macropulse rate

48

Neutron beam closely matched to cosmic-induced neutron spectrum

slide-49
SLIDE 49

4.2 seconds of beam per spill = 380k orbits * 18.8 ns * 7 * 84

1 spill every 60.8 seconds

Time Structure of the Beam

49

1.8 ns buckets 18.8 ns peak-to- peak 84 buckets per bunch 7 bunches per orbit abort gap
