Kinetic Monte Carlo Simulations of Nanofilm Formation South Orange, August 5, 2014 Jan Willem Abraham CAU Kiel J.W. Abraham, CAU Kiel (Metal-Polymer) Nanocomposites Optics (surface plasmon resonances) Electronics Food packaging

slide-1
SLIDE 1

J.W. Abraham, CAU Kiel

Kinetic Monte Carlo Simulations of Nanofilm Formation

South Orange, August 5, 2014

Jan Willem Abraham CAU Kiel

slide-2
SLIDE 2

J.W. Abraham, CAU Kiel

(Metal-Polymer) Nanocomposites

  • Optics (surface plasmon resonances)
  • Electronics
  • Food packaging
  • Medicine
  • Biological systems
slide-3
SLIDE 3

J.W. Abraham, CAU Kiel

(Metal-Polymer) Nanocomposites

  • Optics (surface plasmon resonances)
  • Electronics
  • Food packaging
  • Medicine
  • Biological systems

Nacre, source: wikipedia

slide-4
SLIDE 4

J.W. Abraham, CAU Kiel

Questions

  • How do KMC simulations work?
  • Is KMC exact?
  • What are the advantages/disadvantages of

the method?

  • How can the formation of nanofilms be

simulated with KMC?

slide-5
SLIDE 5

J.W. Abraham, CAU Kiel

Reference for Details

Complex Plasmas: Scientific Challenges and Technological Opportunities Michael Bonitz, Jose Lopez, Kurt Becker and Hauke Thomsen (Eds.), Springer Series on Atomic, Optical, and Plasma Physics, Volume 82 2014

slide-6
SLIDE 6

J.W. Abraham, CAU Kiel

Motivation by Experiments

slide-7
SLIDE 7

J.W. Abraham, CAU Kiel

(Co-)Deposition1

  • 1M. Bonitz et al., Contrib. Plasma Phys. 52, 890 (2012)
slide-8
SLIDE 8

J.W. Abraham, CAU Kiel

(Co-)Deposition

Metal atoms (or clusters) are deposited on a polymer matrix, where they diffuse and form metallic structures. Or: Metal and polymer are deposited at the same time (co-deposition). What arrives at the substrate?

slide-9
SLIDE 9

J.W. Abraham, CAU Kiel

Surface vs. Bulk Diffusion

Au-trimethylcyclohexane- polycarbonate interface1

  • 1C. Bechtolsheim et al., Appl. Surf. Sci. 151, 119 (1999)
slide-10
SLIDE 10

J.W. Abraham, CAU Kiel

From Low to High Filling Factors

TEM micrographs of Nylon-Ag nanocomposites1

  • 1H. Takele, H. Greve, C. Pochstein, V. Zaporojtchenko, F. Faupel, Nanotechnology 17,

3499 (2006)

slide-11
SLIDE 11

J.W. Abraham, CAU Kiel

Controlling Electronic Properties

Au-Teflon AF nanocomposite1

  • 1H. Takele et al., Eur. Phys. J. Appl. Phys. 33, 83 (2006)
slide-12
SLIDE 12

J.W. Abraham, CAU Kiel

Metallic Nanocolumns1

Vapor-phase co-deposition

Metal Polymer Fe-Ni-Co Teflon

rates

  • 1H. Greve et. al, Appl. Phys. Lett. 88, 123103 (2006)

Self-organization of nanocolumnar structures

slide-13
SLIDE 13

J.W. Abraham, CAU Kiel

Theory

slide-14
SLIDE 14

J.W. Abraham, CAU Kiel

Probability Theory

Physical behavior Stochastic process

slide-15
SLIDE 15

J.W. Abraham, CAU Kiel

Probability Theory

Physical behavior Stochastic process

Example: random walk with jumps at discrete time points

slide-16
SLIDE 16

J.W. Abraham, CAU Kiel

Random Variable

sample space

Random variable for a two-jump process

state space

slide-17
SLIDE 17

J.W. Abraham, CAU Kiel

Random Variable

sample space

Random variable for a two-jump process

state space

slide-18
SLIDE 18

J.W. Abraham, CAU Kiel

Stochastic Process

family of random variables

slide-19
SLIDE 19

J.W. Abraham, CAU Kiel

Markov chain

Stochastic process “without memory“

past

slide-20
SLIDE 20

J.W. Abraham, CAU Kiel

Time Homogeneity

slide-21
SLIDE 21

J.W. Abraham, CAU Kiel

Transition Times

Jump rate

Keep the rate, but allow random transition/holding times.

GOAL

slide-22
SLIDE 22

J.W. Abraham, CAU Kiel

Transition Times

What are the transition/holding times of continuous-time Markov chains?

slide-23
SLIDE 23

J.W. Abraham, CAU Kiel

Transition Times

Exponential probability density function

  • Time homogeneity
  • Markov property

Exponential distribution of transition times

slide-24
SLIDE 24

J.W. Abraham, CAU Kiel

Transition Times

Exponential probability density function

  • Time homogeneity
  • Markov property

Exponential distribution of transition times

slide-25
SLIDE 25

J.W. Abraham, CAU Kiel

Master Equation

slide-26
SLIDE 26

J.W. Abraham, CAU Kiel

Simulations

slide-27
SLIDE 27

J.W. Abraham, CAU Kiel

Workflow

Physical Reality

Experimental observations Exact microscopic calculations

slide-28
SLIDE 28

J.W. Abraham, CAU Kiel

Workflow

Modeling

Idealized processes Rates

Physical Reality

Experimental observations Exact microscopic calculations

Simulations (KMC)

Statistical results Solution of the master equation Comparison

slide-29
SLIDE 29

J.W. Abraham, CAU Kiel

Algorithmic Constructions1

  • Variable Step Size Method
  • Random Selection Method
  • First Reaction Method

1A.P.J. Jansen, An Introduction to the Kinetic Monte Carlo Simulations of Surface

Reactions, Springer (2012)

. . .

slide-30
SLIDE 30

J.W. Abraham, CAU Kiel

First Reaction Method1

  • 1M. Bonitz et al. (Eds.), Complex Plasmas: Scientific Challenges and Technological

Opportunities, Springer Series on Atomic, Optical, and Plasma Physics, Volume 82 (2014)

slide-31
SLIDE 31

J.W. Abraham, CAU Kiel

First Reaction Method1

  • 1M. Bonitz et al. (Eds.), Complex Plasmas: Scientific Challenges and Technological

Opportunities, Springer Series on Atomic, Optical, and Plasma Physics, Volume 82 (2014)

Skipped: competition theorem

slide-32
SLIDE 32

J.W. Abraham, CAU Kiel

First Reaction Method1

Initialization Sample process times according to the exponential distribution f(t)=Ri exp(-Ri t) Monte Carlo step Execute process with the earliest time Update Advance the time Resample all affected processes Iterate

  • 1M. Bonitz et al. (Eds.), Complex Plasmas: Scientific Challenges and Technological

Opportunities, Springer Series on Atomic, Optical, and Plasma Physics, Volume 82 (2014)

slide-33
SLIDE 33

J.W. Abraham, CAU Kiel

Why are we doing this?

Experiment

slide-34
SLIDE 34

J.W. Abraham, CAU Kiel

Why are we doing this?

Experiment Model A Model B

slide-35
SLIDE 35

J.W. Abraham, CAU Kiel

Is KMC exact?

slide-36
SLIDE 36

J.W. Abraham, CAU Kiel

Is KMC exact?

Exact behavior as dictated by the corresponding master equation

But: systematic errors in the model

slide-37
SLIDE 37

J.W. Abraham, CAU Kiel

Example: Diffusion & Drift

Master equation Fokker-Planck equation

KRAMERS-MOYAL EXPANSION

Langevin equation

slide-38
SLIDE 38

J.W. Abraham, CAU Kiel

Example: Diffusion & Drift

slide-39
SLIDE 39

J.W. Abraham, CAU Kiel

Example: Diffusion in 2D

slide-40
SLIDE 40

J.W. Abraham, CAU Kiel

Example: Forces

19 charged particles in a 2D harmonic trap

  • 2

. 5

  • 2
  • 1

. 5

  • 1
  • .

5 . 5 1 1 . 5 2 2 . 5

  • 2

. 5

  • 2
  • 1

. 5

  • 1
  • .

5 0 0 . 5 1 1 . 5 2 2 . 5 y x

slide-41
SLIDE 41

J.W. Abraham, CAU Kiel

Applications

slide-42
SLIDE 42

J.W. Abraham, CAU Kiel

Simulation Model1,2

  • 1L. Rosenthal et al., J. Appl. Phys. 144, 044305 (2013)
  • 2L. Rosenthal et al., Contrib. Plasma Phys. 51, 971 (2011)

Processes with rates Growth mechanisms and trapping

slide-43
SLIDE 43

J.W. Abraham, CAU Kiel

Metal-Polymer Interfaces

slide-44
SLIDE 44

J.W. Abraham, CAU Kiel

Metal-Polymer Interfaces1

  • 1L. Rosenthal, PhD thesis, University of Kiel (2013)
slide-45
SLIDE 45

J.W. Abraham, CAU Kiel

Metal-Polymer Interfaces1

  • 1L. Rosenthal, PhD thesis, University of Kiel (2013)
slide-46
SLIDE 46

J.W. Abraham, CAU Kiel

Percolation1

  • 1L. Rosenthal, PhD thesis, University of Kiel (2013)
slide-47
SLIDE 47

J.W. Abraham, CAU Kiel

Metallic Nanocolumns

slide-48
SLIDE 48

J.W. Abraham, CAU Kiel

Metallic Filling Factor1,2

  • 1H. Greve et. al, Appl. Phys. Lett. 88, 123103 (2006)
  • 2L. Rosenthal et al., J. Appl. Phys. 144, 044305 (2013)
slide-49
SLIDE 49

J.W. Abraham, CAU Kiel

Growth Mechanisms

N=50 N=100

Spherical growth Columnar growth

“liquid drop“ atom

critical nucleus size

slide-50
SLIDE 50

J.W. Abraham, CAU Kiel

Video ...

cluster defect column

slide-51
SLIDE 51

J.W. Abraham, CAU Kiel

Nucleation at Defect Sites

slide-52
SLIDE 52

J.W. Abraham, CAU Kiel

Columnar Growth

slide-53
SLIDE 53

J.W. Abraham, CAU Kiel

Results

Rdefect / Rm= 10-8

slide-54
SLIDE 54

J.W. Abraham, CAU Kiel

Results

Rdefect / Rm= 10-8

slide-55
SLIDE 55

J.W. Abraham, CAU Kiel

Results

Rdefect / Rm= 10-3

slide-56
SLIDE 56

J.W. Abraham, CAU Kiel

Results

Rdefect / Rm= 10-3

slide-57
SLIDE 57

J.W. Abraham, CAU Kiel

Extensions of the Model

Temperature dependence

  • f critical nucleus size1
  • 1F. Ding et al. Phys. Rev. B 70, 075416 (2004)
slide-58
SLIDE 58

J.W. Abraham, CAU Kiel

Simulation vs. Experiment

slide-59
SLIDE 59

J.W. Abraham, CAU Kiel

Summary

  • How do KMC simulations work?
  • Is KMC exact?
  • What are the advantages/disadvantages of

the method?

  • How can the formation of nanofilms be

simulated with KMC?

slide-60
SLIDE 60

J.W. Abraham, CAU Kiel

Thank you!
