Matriaux Mtallurgie Electronique Nanomatriaux Plasmas Surfaces Journes SEMPA Nancy 14 & 15 mars 2018 www.ijl.univ-lorraine.fr NANCY: The city of the Duke of LORRAINE Stanislas Leszczy ski, King of Poland (1704

slide-1
SLIDE 1

Matériaux – Métallurgie – Electronique Nanomatériaux – Plasmas – Surfaces

www.ijl.univ-lorraine.fr

Journées SEMPA Nancy – 14 & 15 mars 2018

slide-2
SLIDE 2

NANCY: The city of the Duke of LORRAINE

Stanislas Leszczyński, King of Poland (1704 - 1709), Duke of Lorraine (1737-1766)

Lunéville

Marie Leszczyńska, Queen of France (1725 – 1768) Spouse of Louis XV

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-3
SLIDE 3

NANCY: The city of the Duke of LORRAINE

The Stanislas Place in Nancy One wrought iron gate made by Jean Lamour Metallurgy Nanostructures Surface Gold on iron

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-4
SLIDE 4

The Institut Jean Lamour: a merging of 5 former labs

01/2009 Creation of IJL J.-M. Dubois

  • Dep. Dir. Th. Belmonte

Creation of

  • Dept. 4

Head

  • E. Gaffet

2012 01/2013 Head

  • Th. Belmonte

01/2018 Relocation to new building

03/2017

28 400 m2

Workforce : 550 36 researchers 133 lecturers 100 engineers, technicians and administrative staff 150 doctoral students 35 post-doctoral fellows 46 visitors 50 interns Publications : 500 per year (including 300 articles in peer-reviewed journals) & about 50 theses per year

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-5
SLIDE 5

Directory

Council of Unit Scientific advisory board Directory + team leaders Director Deputy-director

Physics of Matter and Materials Department (P2M) Chemistry and Physics of Solids and Surfaces Department (CP2S) Materials Science and Engineering - Metallurgy Department (SI2M) Nanomaterials, Electronics and Living Systems Department (N2EV)

CC

MEM (Met) Magn.

  • E. Héré

ERMIONE X-Gamma MiNaLor Daµm OL Health Safety

Technical

  • Direct. (DT)

Administration & Financial Office

Task officers Correspondents Cenacle Technol. Rech. MPA VIT Inter. Relat. CLHSCT

Communication Mediation

Topical Projects Central secretariat

General affairs & Exec. Secret. Logistic and technical support

Indus. Relat.

IJL organization chart

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-6
SLIDE 6

23 research groups organized into 4 scientific departments

  • Dept. 2

Chemistry and Physics of Solids and Surfaces (CP2S)

201 - Experiments and Simulations of Reactive Plasmas - Plasma-surface Interaction and Surface Processing 202 - Development of functional thin films 203 - Metallurgy and Surfaces 204 - Materials with thermoelectric properties 205 - Carbon-based materials 206 - Surface and Interface: Chemical Reactivity of Materials 207 - Materials for Civil Engineering 208 - Chemistry and electrochemistry of materials

  • Dept. 1

Physics of Matter and Materials

101 - Nanomagnetism and spintronics 102 - Surfaces and spectroscopy 103 - Intermetallic compounds and hybrid materials 104 - Nanomaterials 107 - Physics of warm plasmas

  • Dept. 4

Nanomaterials, Electronics and Living Systems (N2EV)

401 - Nanomaterials for life and sustainable development 402 - Bio-sourced materials 403 - Nanomateriaux et santé 404 - Micro and Nanomechanics for the living 405 - Micro and nanosystems 406 - Electronic Measurements and Architectures

Dept.3 Materials Science and Engineering - Metallurgy

301 - Metallurgical Process Engineering 302 - Solidification 303 - Microstructures and Stresses 304 - Physics, Mechanics and Plasticity

6 transversal Axes

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-7
SLIDE 7

International collaboration

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-8
SLIDE 8

Industrial partnership

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-9
SLIDE 9

Technical platforms and equipments

1800 scientific instruments, most of them are gathered within competence centers Measurements of magnetic properties Scientific computation X ray diffraction and Mössbauer spectroscopy Electron microscopies and microprobes Micro and Nanotechnologies Deposition and analysis of nanomaterials under ultra-high vacuum Materials development for additive manufacturing technologies Mechanical and electronic workshop

2 JEOL ARM 200F TEM Machining centre

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-10
SLIDE 10

D8 Advance CuKα X'Pert Pro MRD D8 Discover CoKα

  • D8 Advance CuKα1D8 Advance (Open use)
  • D8 Discover Co Kα (Texture and stress measurements)
  • D8 Advance MoKα1 (For transmission and reflection + euler circle and XRK900 furnace)
  • Xpert Pro MRD CuKαX (HR for thin films)
  • Xpert Pro MPD CuKαX (Analysis of powder - 2 furnaces HTK1200 & TT450 and steam chamber)
  • INEL CPS120 CoKα grazing angle (Open use)
  • Kappa APEX II (for single crystals)
  • SAXS/WAXS
  • Laue chamber (Large single crystals)
  • X-ray fluorescence
  • Tomograph
  • Topograph : Defects in single crystals (Lang method)

X'Pert Pro MPD

X-ray diffraction and Mössbauer spectroscopy (5 pers.)

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-11
SLIDE 11

3 TEM ⊃ 2 JEOL ARM 200F 2 SEM ⊃ 1 FEI Quanta 650 1 FIB/SEM FEI Helios Nanolab 600 i 1 SIMS - CAMECA IMS 7F

Electron microscopies and microprobes (5 pers.)

1 JEOL JXA 8530-F WDS

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-12
SLIDE 12

Lithography Optical lithography: MJB4 and Karl Süss MA-750 Electronic lithography: RAITH 150-II Resin coating and baking: 2 spin-coaters, 2 heating plates, 1 drying oven SEM FEG JEOL 6500 + Raith Elphy+ Nanoimprint: Nanonex 2500 Thin film deposition Cathodic sputtering: Alliance Concept AC450, 4 targets 4 pouces, RF & DC sputtering Evaporation by Joule effect: MECA 2000, 3 crucibles Evaporation by electron gun Etching IBE: 4wave system (ICP source, SIMS detection) RIE: plasmalab O2 plasma Characterization and others Micro-welding : Hybond Optical microscopy Mecanical profilometre : Tencor P6

Micro and Nanotechnologies (4 pers.)

MJB4 SEM JEOL 6500

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-13
SLIDE 13

Deposition and analysis of nanomaterials under ultra-high vacuum (DAνM) (4 pers.)

The transfer tunnel Examples of experimental devices mounted on the tube among the 23 available

70-metre long

3 trollies with 12 substrate-holders under ultra-high vacuum (10−10 mbar)

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-14
SLIDE 14

12 reactors for thin layer deposition:

  • 4 MBE
  • 6 cathodic sputtering chambers
  • 1 PLD
  • 1 ALD

10 devices for physical, structural and chemical characterization :

  • 1 AFM-MFM-STM microscope,
  • 1 Angle-resolved photoemission spectroscopy

(ARPES)

  • 1 Kerr effect instrument (MOKE)
  • 1 SEM device coupled with surface chemical

analysis (SCAN)

  • 2 XPS

Deposition and analysis of nanomaterials under ultra-high vacuum

Connection to "open-access" area for semi-industrial facilities

www.ijl.univ-lorraine.fr

Journées SEMPA 2018 Nancy

slide-15
SLIDE 15

Merci pour votre attention

L’Institut Jean Lamour est membre de : Il bénéficie du soutien de :
