IST MUPBED: Multi-Partner European Test Network for Research Networking Multi-Partner European Test Beds for Research Networking IST FP6 Project in 2nd Call, Research Networking Test Beds IST FP6 Project in 2nd Call, Research

slide-1
SLIDE 1

0508 # 1

www.acreo.se

IST MUPBED: Multi-Partner European Test Network for Research Networking

  • Project Overview, September 2006

IST FP6 Project in 2nd Call, “Research Networking Test Beds”

Multi-Partner European Test Beds for Research Networking

  • Project Overview, November 2007

IST FP6 Project in 2nd Call, “Research Networking Test Beds”

Tove Madsen (tove.madsen@acreo.se) Anders Gavler (anders.gavler@acreo.se)

slide-2
SLIDE 2

0508 # 2

www.acreo.se

MUPBED Consortium

  • Equipment Manufacturers

– Ericsson (Germany); Project Co-ordinator – Marconi SpA (Italy) – Juniper Networks (Ireland)

  • Network Operators

– Telecom Italia (Italy) – Deutsche Telekom - T-Systems (Germany) – Telefonica I+D (Spain) – Magyar Telekom (Hungary)

  • Research Centres

– ACREO (Sweden) – TU Denmark (Denmark) – Politecnico di Milano (Italy) – University of Erlangen-Nuremberg (Germany) – DFN-Verein (Germany) – GARR (Italy) – RedIRIS/Red.es (Spain) – PSNC (Poland)

slide-3
SLIDE 3

0508 # 3

www.acreo.se

MUPBED Layer2 Network Realisation

Full mesh between test bed sites

Northern Europe test bed Central Europe test bed Western Europe test bed Southern Europe test bed Eastern Europe test bed

DFN PIONIER NORDUnet RedIRIS GARR DTU FAU GÉANT2 ACREO Telefonica I+D T-Systems DT PSNC

GE GE GE GE GE

GMPLS Ethernet IP/MPLS ASON/GMPLS ASON/GMPLS Telecom Italia

slide-4
SLIDE 4

0508 # 4

www.acreo.se

Relevance of MUPBED for NRENs

  • Harmonisation/convergence of “telecom operator” and NREN

solutions

  • Network architecture work, selected theoretical investigations
  • Leading edge control plane solutions:

– Focus on IETF GMPLS and ITU ASON approach, including multi-domain inter-working – Driving standardisation

  • Work on “application – network” inter-working

– Applications (requirements, interface, selected trials in test bed) – User groups (within and outside the MUPBED consortium)

  • Extended field trials for selected solutions: Set-up and operation of

European scale test bed

  • Collaboration with GEANT2 Project, TF-NGN
slide-5
SLIDE 5

0508 # 5

www.acreo.se

Future applications to support

Areas of NREN applications

  • High Energy Physics

(HEP)

  • Atmospheric Sciences
  • Medical Sciences
  • Grids/Computing
  • Geosciences
  • Fusion/ITER
  • Astronomy
  • Networking
slide-6
SLIDE 6

0508 # 6

www.acreo.se

NRENs attitude towards MUPBED technologies

  • PSNC, Poland:
  • Migrating to IP/MPLS
  • Highly interested in using MUPBED developments for on-demand bandwidth provisioning
  • Red.es, Spain:
  • Currently IP/MPLS-based network and manual L2VPN configuration
  • Demand on bandwidth and P2P connectivity is only increasing
  • Completed the upgrade of L2 (up to 4x10 GbE between nodes), L2 VLANs + VPNs are now provided to

customers

  • Decided on L1 upgrade (WDM), most likely deployment by 2008
  • Near future deployment of ASON/GMPLS for automatic bandwidth provisioning, participates in

AUTOBAHN testing of GMPLS

  • GARR, Italy:
  • already using IP/MPLS, DWDM, 10 Gb/s links (SDH, Ethernet)
  • interest in ASON/GMPLS as a tool for traffic engineering and optical equipment (L1) management
  • Actual deployment in a part of the production network on a time scale of 1-2 years
  • DFN, Germany:
  • Currently using DWDM up to 160 x 10 Gb/s, Ethernet (95% of links are GbE, including some 10GbE)

and SDH, VPN and best-effort IP

  • Follows the MUPBED developments in the ASON/GMPLS control plane
  • Most likely to start a GMPLS-based intra-domain pilot in the future
slide-7
SLIDE 7

0508 # 7

www.acreo.se

Demo Terena 2007 Uncompressed, on-demand video transmission Data plane: FAU-DT-Acreo-DTU/Exhibition (400 Mb/s, ca 2000 km)

Northern Europe test bed Central Europe test bed Western Europe test bed Southern Europe test bed Eastern Europe test bed

DFN PIONIER NORDUnet RedIRIS GARR DTU FAU GÉANT2 ACREO Telefonica I+D T-Systems DT PSNC

GE GE GE GE GE

GMPLS Ethernet IP/MPLS ASON/GMPLS ASON/GMPLS Telecom Italia

slide-8
SLIDE 8

0508 # 8

www.acreo.se

Further Information

  • Web:

– http://www.ist-mupbed.eu http://www.ist-mupbed.org

  • Project Co-ordinator:

– jan.spaeth@ericsson.com

slide-9
SLIDE 9

0508 # 9

www.acreo.se

Working Party (WP) 3

  • f MUPBED
  • MPLS / GMPLS “memory jogging”
  • The MUPBED network
  • User to Network Interface testing in MUPBED
  • GMPLS Ethernet in MUPBED
  • Multi-layer GMPLS in MUPBED
  • Technical summary

Anders Gavler Research engineer Acreo anders.gavler@acreo.se

slide-10
SLIDE 10

0508 # 10

www.acreo.se

Jogging your memory about MPLS

  • Multi Protocol Label Swapping
  • Traffic Engineering extensions

– E.g. RSVP with MPLS TE extensions for signaling – E.g. OSPF with MPLS TE extensions for routing

  • Label has link local significance
  • No data plane / control plane separation
slide-11
SLIDE 11

0508 # 11

www.acreo.se

The integrated GMPLS approach

LSR LSR LSR LSR LSR LSR

Data Plane

  • ntrol Plane

Layer n Layer n -1 Layer n -2 Layer n LSP Layer n -1 LSP Layer n -2 LSP

OSPF-TE LMP RSVP -TE OSPF-TE LMP RSVP -TE OSPF-TE LMP RSVP-TE OSPF-TE LMP RSVP -TE OSPF-TE LMP RSVP -TE OSPF-TE LMP RSVP -TE

  • Generalized MPLS
  • Data Plane (DP) and Control Plane (CP) separation
  • GMPLS TE extensions for signalling (RSVP), routing (e.g. OSPF)
  • Link Management Protocol (LMP) – new protocol

– Informs RSVP-TE and OSPF-TE about the data plane

  • Technology dependent labels (SDH, fiber port, wavelength etc)
slide-12
SLIDE 12

0508 # 12

www.acreo.se

The User to Network Interface - UNI

If you are allowed to signal the provider network this can be seen as a sort of bandwidth / VPN on demand, i.e., a service provisioning tool I-NNI - Interior Network to Network Interface

slide-13
SLIDE 13

0508 # 13

www.acreo.se

The MUPBED network

Date Plane transport

  • ver national/regional

NRENs + GEANT Control Plane established through IPSec tunnels UNI-C (Client) SW Agent by PSNC

slide-14
SLIDE 14

0508 # 14

www.acreo.se

Different UNI types in MUPBED

UNI proxy server

OIF UNI-C 2.0 module

IETF RSVP_TE module

ASON network domain

UNI

GMPLS network domain

UNI RSVP agent

  • IETF or OIF RSVP-TE
  • Packet labeling

ASON or GMPLS Network domain

UNI

command line client

mngt protocol

  • Two flavours: IETF UNI and OIF UNI

– OIF: UNI-C (Client) and UNI-N (Network)

  • No routing information
  • Both based on IETF RSVP-TE
  • Differences like

– LSP Session / Call and Connection segments – TNA address usage – Etc

This part could be integrated into an application, i.e., a service provisioning tool (which was actually done by DTU)

slide-15
SLIDE 15

0508 # 15

www.acreo.se

DT Network

OIF UNI test case

Acreo Router Juniper M5

192.168.1.4/32 lo0

DT SDH Equipment

lo0 Interface GbE.612 Interface GbE.612 LSP GMPLS LSP

LSP Setup and Teardown tested OK! GbE VLAN 612

Internet Internet

UNI-N Control Channel IPSec UNI Control Channel

OIF UNI

  • ver

IPSec UNI -C Agent PC

X

IETF UNI

  • ver

GRE or plain

Telecom Italia Network

TID UNI-C TID DP GbE

Telefonica Spain

TI UNI-C TI DP GbE

slide-16
SLIDE 16

0508 # 16

www.acreo.se

Acreo Router Juniper M5

192.168.1.4/32 lo0 Traffic Engineering Link Information: TE-link local adress 10.35.100.2 TE-link Local ID 43352 TE-link Remote ID 42543 Local adress 10.35.100.2 Local ID 54183 (label) Remote ID 54183 (label)

PSNC Router Juniper Mx

192.168.1.5/32 lo0 ge-x/x/x.612 172.16.13.2/24 Traffic Engineering Link ACREO - PSNC 10.35.100.0/30 ge-1/3/0.612 172.16.13.1/24 Traffic Engineering Link Information: TE-link local adress 10.35.100.1 TE-link Local ID 42543 TE-link Remote ID 43352 Local adress 10.35.100.1 Local ID 54183 (label) Remote ID 54183 (label) UNI Control Channel GRE 172.16.99.2 UNI Control Channel GRE 172.16.99.1 GMPLS LSP GMPLS LSP

LSP GbE Control Channel VLAN 612

IETF UNI test case

Result 1. Setup and teardown – OK! 2. Data plane separation through multiple VLANs – Not OK!

slide-17
SLIDE 17

# 17

www.acreo.se

GMPLS L2 Ethernet Network in MUPBED

  • Design and setup
  • Linux PC

–Ethernet Data Plane controller –Extended DRAGON Control Plane software

  • Ethernet DP

by Switch Core

  • Linux Virtual CP/DP

SwitchCore Dragon/Linux PC

OSPF -TE RSVP -TE

L2SC NE

R1 E1 E2 R2 R3 E3

Dragon/Linux PC

OSPF -TE RSVP -TE

Router NE Dragon/Linux PC

OSPF -TE RSVP -TE

Router NE Dragon/Linux PC

OSPF -TE RSVP -TE

Router NE

SwitchCore Dragon/Linux PC

OSPF -TE RSVP -TE

L2SC NE SwitchCore Dragon/Linux PC

OSPF -TE RSVP -TE

L2SC NE

Control Plane LSP - Label Switched Path Data Plane

  • Standardization just started

–VLAN ID = LSP label? –VID + MAC = LSP label? –802.1Q, 802.1ad, 802.1ah, 802.1Qay (PBB-TE)

  • LSP setup - OK!

–OSPF-TE - OK! –RSVP-TE - OK!

  • PCE – OK!
slide-18
SLIDE 18

0508 # 18

www.acreo.se

GMPLS: Multi-layer networking and multi-technology control

  • Design and setup of an GMPLS

three layered (MPLS, Ethernet and optical) network – DONE!

  • Some success in LSP setup
  • Much work remains

– GMPLS Ethernet – Multi-layer LSP signaling – Multi-layer routing

  • Technology specific

routing information

– PCE – Development / Implementation

  • MPLS DP control
  • Optical DP control

– Protection – Scalability – Virtual topolgies

Two layered GMPLS network (Router – Optical Cross Connect)

slide-19
SLIDE 19

0508 # 19

www.acreo.se

Summary of MUPBED technical results

  • UNI Tests in MUPBED

– OIF UNI RSVP-TE Agent tested ok – IETF UNI RSVP-TE tested ok

Include Ethernet in GMPLS due to possible resource de-optimization

  • Design and setup of an GMPLS Ethernet network

was successfully established

– LSP setup and teardown was successfully shown, i.e., working signalling and routing

  • Design and setup of an GMPLS three layered (MPLS,

Ethernet and optical) network was successfully established

– LSP setup and teardown has been partially successful – Much work remains in this area

slide-20
SLIDE 20

0508 # 20

www.acreo.se

Questions?

Your most welcome to do research and develop the multi- layer GMPLS testbed with us anders.gavler@acreo.se
