Investigating Collaboration Dynamics in Different Ontology Development Environments Marco Rospocher Tania Tudorache and Mark Musen DKM, Fondazione Bruno Kessler BMIR, Stanford University rospocher@fbk.eu


slide-1
SLIDE 1

The 7th International Conference on Knowledge Science, Engineering and Management - KSEM 2014 16–18 October 2014, Sibiu, Romania

Marco Rospocher Tania Tudorache and Mark Musen

DKM, Fondazione Bruno Kessler rospocher@fbk.eu

Investigating Collaboration Dynamics in Different Ontology Development Environments

BMIR, Stanford University tudorache@stanford.edu, musen@stanford.edu

slide-2
SLIDE 2

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Introduction

  • Understanding processes and dynamics behind the collaborative

development of ontologies is important

  • for Ontology tool engineers
  • to understand how to optimize their tools to make the work of the users

more straightforward and effective

  • for Ontology project managers
  • to obtain tools and metrics to assess and monitor the development

status and the quality of the ontology under their responsibility

slide-3
SLIDE 3

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Our Contribution

  • We conducted some exploratory investigations on
  • the way people edit an ontology in collaborative settings
  • the role of discussion activities in collaborative ontology development
  • Novelty:
  • two different ontology development frameworks
  • discussion activities
  • Key Aspects:
  • analysis based on truly objective data
  • five real ontology development projects
slide-4
SLIDE 4

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Investigations

I1.

Is the editing process localized?

I2.

Is the formalization of an ontology entity truly collaborative?

I3.

Are discussed ontology entities actually discussed by two or more users?

I4.

Are highly discussed ontology entities also highly edited?

I5.

Do users tend to edit more than to discuss?

slide-5
SLIDE 5

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

  • A collaborative ontology authoring tool for the Web
  • Form-based mechanism
  • Extensive collaboration support
  • tracking of all changes that users perform in a structured log
  • notes and (threaded) discussions
  • Ontology entity/branch watch mechanism (with email notifications)
  • highly configurable access policies
  • In this study we used iCAT
  • a custom configuration of WebProtégé used by medical experts

Tools:

slide-6
SLIDE 6

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Tools:

slide-7
SLIDE 7

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Tools:

  • A collaborative wiki-based tool for modeling ontological and

procedural knowledge

  • Form-based editing
  • Different ways to navigate the ontology under development
  • class hierarchy tree / list in a tabular form all entities defined in the
  • ntology / search for a specific entity
  • Support for user collaboration
  • discussions, by means of talk pages
  • watchlists and notifications
  • recent activity awareness features
slide-8
SLIDE 8

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Tools:

slide-9
SLIDE 9

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

and

  • Main similarities
  • web-based
  • functionalities for supporting both editing and discussion
  • user editing mainly via forms
  • similar collaboration features (e.g., notification, watchlist, history)
  • Main differences
  • granularity and the modality of editing and discussion activities
  • navigation and hierarchy awareness
  • discussion awareness
  • Motivations for using WebProtègè and MoKi in our study
  • provide detailed change and discussion logs
  • used in several real-world projects
slide-10
SLIDE 10

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Ontologies

  • WebProtégé Ontology Development projects considered:
  • The 11th Revision of the International Classification of Diseases (ICD)
  • led by the World Health Organization (WHO)
  • a taxonomy and descriptions of diseases used in United Nations countries
  • The International Classification of Traditional Medicine (ICTM)
  • led by the World Health Organization (WHO)
  • standard terminology and classification for diagnoses and interventions in

Traditional Medicine

  • 4 languages covered: English, Chinese, Japanese and Korean
slide-11
SLIDE 11

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Ontologies

  • MoKi Ontology Development projects considered:
  • Organic Agriculture (OA)
  • classify educational material in a multilingual web-portal containing
  • rganic agriculture and agro-ecology resources
  • 15 languages
  • Viticulture (Vit)
  • concepts related to the science, production, and study of grapes
  • no discussion functionalities
  • Motivation and Emotion (ME)
  • motivational and emotional aspects of the learning process in pedagogy
  • educational material and the interventions to be used for facing

motivational or emotional difficulties

slide-12
SLIDE 12

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Ontologies

ICD ICTM OA Vit ME

Developed with

  • No. of ontology:
  • classes
  • individuals
  • properties
  • 50,609
  • 228,629
  • 228
  • 1,511
  • 18,364
  • 219
  • 284
  • 81
  • 31
  • 481
  • 72
  • 13
  • 13
  • No. of active users

109 23 10 3 3

  • No. of edits

331,147 40,840 2,915 2,227 407

  • No. of discussions

71,371 1,726 452 52 Status

  • ngoing
  • ngoing
  • ngoing
  • ngoing

completed Development period (ca) 42 months 30 months 5 months 3 months 1 week Used for investigations All All All I1, I2 All

slide-13
SLIDE 13

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I1: Is the editing process localized?

  • We tested whether users, after editing a class A, tend to edit

another class B closely or semantically related to the previous one

  • Six cases considered:
  • We counted the number of these occurrences, normalizing over

the total number of cases

siblings

A B A

child

B

parent

B A

descendant ancestor none

A B A B B A

slide-14
SLIDE 14

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I1: Is the editing process localized?

  • Most of the times (60% to 73%),

next edited entity is a sibling, a child or a parent

  • Exception: OA
  • strong multilingual focus
  • editing following the

alphabetically-sorted list of concepts

  • Outcome: users tend to work locally on the ontology
  • may be due to class navigation functionalities, similar yet different

in the tools

  • (to be further investigated) Do tool functionalities impact the way

people perform their editing activities?

slide-15
SLIDE 15

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I2: Is the editing truly collaborative?

  • We examined how many distinct users usually edit an ontology

entity, whether a class, individual, or property

  • We classified ontology entities in three categories
  • edited by only one user
  • edited by two distinct users
  • edited by three or more distinct users
slide-16
SLIDE 16

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I2: Is the editing truly collaborative?

  • Most of the ontology entities (75%

to 96%) edited by at most 2 users

  • Exception: OA
  • 65% of the entities edited by at

least five distinct users

  • strong multilingual focus
  • rather low entities / user ratio

(∼40), multiple users editing activities more likely to occur

  • This kind of analysis may provide useful insights also to ontology

project managers:

  • to detect entities having a very few number of editors (may require

some intervention)

slide-17
SLIDE 17

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I3: Are discussions truly collaborative?

  • We examined how many distinct users usually discuss an ontology

entity, whether a class, individual, or property

  • Similarly to I2, we classified ontology entities in three categories
  • discussed by only one user
  • discussed by two distinct users
  • discussed by three or more distinct users
slide-18
SLIDE 18

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I3: Are discussions truly collaborative?

  • ICD and ICTM: most of the
  • ntology entities (∼ 91%) are

discussed by a single users

  • OA and ME: most of the ontology

entities (resp., 97% and 75%) are discussed by at least 2 users

  • Possible explanations:
  • difference in size of the ontology and the number of users
  • entity / user ratio (ICD: ∼382 and ICTM: ∼171; OA: ∼40 and ME: ∼33)
  • different discussion-awareness support provided by the tools
  • ICD and ICTM have used the notes mechanism not only for

discussion, but mostly for notes or additional documentation

slide-19
SLIDE 19

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I4: Are highly discussed entities also highly edited?

  • We examined a possible correlation between the discussion

activities and the editing activities on an entity

  • We classified the ontology entities in two groups:
  • those having at least two distinct users discussing each of them
  • those having zero or at most one user discussing them
  • We then computed
  • the average/median of the number of editing activities on an entity
slide-20
SLIDE 20

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I4: Are highly discussed entities also highly edited?

  • More editing activities on the set of entities having at least two

users discussing them (p<0.05 with Wilcoxon test)

  • Encouraging and facilitating the use of discussion support

functionalities, to favor the increase of editing activities?

  • to be further investigated

Number of distinct users median average

pages discussed by at most one user pages discussed by two or more users

slide-21
SLIDE 21

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Results

I5: Do users edit more than discuss?

  • We examined whether users tend to perform more editing

activities than discussion activities

  • For each user, we counted the number of editing activities and

discussion activities performed

slide-22
SLIDE 22

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

  • In most of the cases, users performed much more editing

activities than discussion activities

  • a few exceptions in which the contrary holds → they may indicate

the existence of different types of users

  • users who prefer sharing thoughts and opinions
  • users that mainly review and comment work performed by others

Results

I5: Do users edit more than discuss?

editings discussions

ICD Users ICTM Users OA Users ME Users

slide-23
SLIDE 23

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Limitations

  • We used ontologies developed with WebProtégé and MoKi
  • we plan to perform the analysis with additional tools
  • The ontologies we analyzed in our study vary in size and in the

number of users participating in their development

  • we will consider additional ontology projects
  • e.g., development of some large ontologies with MoKi, or the modeling
  • f a small focused ontology with WebProtégé
  • Our analysis is based exclusively on the logs of the activities

performed by users while using the tools

  • we plan to complement our analysis with additional experimental

study techniques covering activities taking place outside the modelling tool

slide-24
SLIDE 24

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

Conclusions and Future Work

  • We investigated the collaborative process behind the development
  • f some ontologies modeled with WebProtégé and MoKi
  • focus: the way users edit the ontology and the role of discussion
  • Among the findings:
  • users tend to edit ontology entities that closely related to the

previously edited one

  • any ontology entity is edited/discussed by few users (≤2)
  • the more an ontology entity is discussed, the more likely it is highly

edited as well

  • users tend to edit more than to discuss
slide-25
SLIDE 25

Investigating Collaboration Dynamics in Different Ontology Development Environments - Rospocher, Tudorache, Musen

  • The results of our analysis raise some suggestions for ontology tool

engineers:

  • ffering different ontology browsing functionalities
  • better support discussion activities by enhancing discussion awareness
  • Future Work
  • extend our study to consider additional ontology development projects
  • include ontologies developed with other tools
  • a detailed tracking of user editing and discussion activities is required for

computing the metrics applied in our study

  • in-depth investigation of the influence of the user interface / tool

features on the dynamics of the collaboration processes

Conclusions and Future Work

slide-26
SLIDE 26

Thank you! Questions?

Marco Rospocher Tania Tudorache and Mark Musen

DKM, Fondazione Bruno Kessler rospocher@fbk.eu BMIR, Stanford University tudorache@stanford.edu, musen@stanford.edu

http://webprotege.stanford.edu http://moki.fbk.eu
