Internet Congestion Control Dr. Miled M. Tezeghdanti November 19, 2011 Dr. Miled M. Tezeghdanti () Internet Congestion Control November 19, 2011 1 / 21 Introduction Congestion Control Reduce the traffic in order to meet the network

slide-1
SLIDE 1

Internet Congestion Control

  • Dr. Miled M. Tezeghdanti

November 19, 2011

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 1 / 21

slide-2
SLIDE 2

Introduction

Congestion Control

Reduce the traffic in order to meet the network requirements

Senders will reduce the traffic if they notice a congestion in the network

Network Layer function in the OSI Model Transport Layer function in the Internet

Performed by TCP TCP friendly applications

Flow Control

Reduce the traffic in order to meet the reciever requirements

Recievers will inform senders by their available resources

Layer 2, 3 , and 4 function in the OSI Model Transport Layer function in the Internet

Performed by TCP

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 2 / 21

slide-3
SLIDE 3

Flow Control

TCP provides a means for the receiver to govern the amount of data sent by the sender. This is achieved by returning a ”window” with every ACK indicating a range of acceptable sequence numbers beyond the last segment successfully received. The window indicates an allowed number of bytes that the sender may transmit before receiving further permission. Window:

specifies the number of data bytes beginning with the one indicated in the acknowledgment field which the sender of this segment is willing to accept. 16 bits Maximum window size: 65,535 bytes

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 3 / 21

slide-4
SLIDE 4

Flow Control - Window Scale Option

Window Scale Option

KIND: 3 Length: 3 Scale (1 byte): power of 2 shift to the left The value ’shift.cnt’ may be zero (offering to scale, while applying a scale factor of 1 (20) to the receive window). The value ’shift.cnt’ may be n (offering to scale, while applying a scale factor of 2n to the receive window). The maximum value ’shift.cnt’ may be 14 (offering to scale, while applying a scale factor of 214 to the receive window). both sides must send Window Scale options in their SYN segments to enable window scaling in either direction. RFC 1323 +———+———+———+ + Kind +Length +shift.cnt+ +———+———+———+

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 4 / 21

slide-5
SLIDE 5

Definitions

SEGMENT

A segment is ANY TCP/IP data or acknowledgment packet (or both).

RECEIVER MAXIMUM SEGMENT SIZE (RMSS)

The RMSS is the size of the largest segment the receiver is willing to accept. This is the value specified in the MSS option sent by the receiver during connection startup. If the MSS option is not used, it is 536 bytes. The size does not include the TCP/IP headers and options.

SENDER MAXIMUM SEGMENT SIZE (SMSS)

The SMSS is the size of the largest segment that the sender can transmit. This value can be based on the maximum transmission unit of the network, the path MTU discovery algorithm, RMSS. The size does not include the TCP/IP headers and options.

FULL-SIZED SEGMENT

A segment that contains the maximum number of data bytes permitted (i.e., a segment containing SMSS bytes of data).

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 5 / 21

slide-6
SLIDE 6

Definitions

RECEIVER WINDOW (rwnd)

The most recently advertised receiver window.

CONGESTION WINDOW (cwnd)

A TCP state variable that limits the amount of data a TCP can send. At any given time, a TCP MUST NOT send data with a sequence number higher than the sum of the highest acknowledged sequence number and the minimum of cwnd and rwnd.

INITIAL WINDOW (IW)

The initial window is the size of the sender’s congestion window after the three-way handshake is completed.

LOSS WINDOW (LW)

The loss window is the size of the congestion window after a TCP sender detects loss using its retransmission timer.

RESTART WINDOW (RW)

The restart window is the size of the congestion window after a TCP restarts transmission after an idle period

FLIGHT SIZE

The amount of data that has been sent but not yet cumulatively acknowledged.

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 6 / 21

slide-7
SLIDE 7

Definitions

DUPLICATE ACKNOWLEDGMENT

An acknowledgment is considered a ”duplicate” when

1

the receiver of the ACK has outstanding data

2

the incoming acknowledgment carries no data

3

the SYN and FIN bits are both off

4

the acknowledgment number is equal to the greatest acknowledgment received on the given connection

5

the advertised window in the incoming acknowledgment equals the advertised window in the last incoming acknowledgment

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 7 / 21

slide-8
SLIDE 8

Congetion Detection

How does the source determine whether or not the network is congested? Implicit Feedback Long delays

It takes more time for ACKs to come back Large queueing delays

Retransmission timer expiration

No ACK is received before the timer expiration Packet loss is rarely due to transmission error (on wired lines) Lost packet implies congestion

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 8 / 21

slide-9
SLIDE 9

IW, RW, LW, ssthresh

IW

If SMSS > 2190 bytes:

IW = 2 * SMSS bytes and MUST NOT be more than 2 segments

If (SMSS > 1095 bytes) and (SMSS ¡= 2190 bytes):

IW = 3 * SMSS bytes and MUST NOT be more than 3 segments

if SMSS ≤ 1095 bytes:

IW = 4 * SMSS bytes and MUST NOT be more than 4 segments

RW = min(IW,cwnd) LW equals 1 full-sized segment (regardless of the value of IW) ssthresh

At startup, ssthresh = rwind After a loss detection, ssthresh = max (FlightSize / 2, 2*SMSS)

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 9 / 21

slide-10
SLIDE 10

Slow Start

How should TCP start sending data? Use Slow Start to increase window rapidly from a cold start

Determine the available capacity Add a new state variable for each connection cwind (CongestionWindow) Begin with cwind = 1 segment (SMSS bytes) (In fact: IW, LW, RW). SMSS is negociated at the connection setup Sender Maximum Segment Size: default value: 536 bytes Double cwind each RTT Increment cwind by 1 segment for each recieved ACK This is exponential increase to probe for available bandwidth

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 10 / 21

slide-11
SLIDE 11

Slow Start

Slow Start Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-12
SLIDE 12

Slow Start

Slow Start Server Client

Data (SMSS)

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-13
SLIDE 13

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-14
SLIDE 14

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-15
SLIDE 15

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-16
SLIDE 16

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-17
SLIDE 17

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-18
SLIDE 18

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-19
SLIDE 19

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-20
SLIDE 20

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-21
SLIDE 21

Slow Start

Slow Start Server Client

Data (SMSS) ACK

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 11 / 21

slide-22
SLIDE 22

Congestion Avoidance

Additive Increase/ Multiplicative Decrease (AIMD) Increment cwind by one segment (SMSS bytes) per RTT (linear increase) Divide cwind by two whenever a timeout occurs (multiplicative decrease) cwind always ≥ 1 SMSS In practice: increment a little for each ACK

Increment = 1/cwind cwind += Increment SMSS = max segment size = size of a single segment

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 12 / 21

slide-23
SLIDE 23

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-24
SLIDE 24

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-25
SLIDE 25

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-26
SLIDE 26

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-27
SLIDE 27

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-28
SLIDE 28

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-29
SLIDE 29

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-30
SLIDE 30

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-31
SLIDE 31

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-32
SLIDE 32

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-33
SLIDE 33

Congestion Avoidance

Congestion Avoidance Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 13 / 21

slide-34
SLIDE 34

Fast Retransmit

Receiving small number of duplicate ACKs (3) signals segment loss Lost segment can be retransmitted before the retransmission timer to expiration This improves channel utilization

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 14 / 21

slide-35
SLIDE 35

Fast Retransmit

Fast Retransmit Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 15 / 21

slide-36
SLIDE 36

Fast Retransmit

Fast Retransmit Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 15 / 21

slide-37
SLIDE 37

Fast Retransmit

Fast Retransmit Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 15 / 21

slide-38
SLIDE 38

Fast Retransmit

Fast Retransmit Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 15 / 21

slide-39
SLIDE 39

Fast Retransmit

Fast Retransmit Server Client

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 15 / 21

slide-40
SLIDE 40

Fast Recovery

After the Fast Retransmit algorithm sends what appears to be the missing segment, the ”Fast Recovery” algorithm governs the transmission of new data until a non-duplicate ACK arrives Each duplicate ACK indicates some packet has left pipe Skip the Slow Start phase Start at ssthresh and do additive increase after Fast Retransmit

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 16 / 21

slide-41
SLIDE 41

TCP Tahoe

TCP Tahoe (distributed with 4.3BSD Unix - 1988) Original implementation of Van Jacobson’s mechanisms Includes:

Slow Start Congestion Avoidance Fast Retransmit

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 17 / 21

slide-42
SLIDE 42

TCP Reno

TCP Reno (distributed with 4.3BSD Unix - 1990) TCP Reno skips Slow Start (Fast Recovery) after three duplicate ACKs Includes:

Slow Start Congestion Avoidance Fast Retransmit Fast Recovery

With Fast Recovery, Slow Start only occurs:

At cold start After a coarse-grain timeout This is the difference between TCP Tahoe and TCP Reno

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 18 / 21

slide-43
SLIDE 43

TCP New Reno

Reno with modified Fast Recovery New-Reno continues with Fast Recovery if a partial ACK is received cwind increased by 1 for each duplicate ACK until ACK for last packet sent before loss detection is received

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 19 / 21

slide-44
SLIDE 44

TCP SACKS

Reno + selective ACKs Added the SACK option within ACKs Allows receiver to specify the range of packets that were received out

  • f order
  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 20 / 21

slide-45
SLIDE 45

TCP Vegas

Idea: source watches for some sign that router’s queue is building up and congestion will happen too RTT grows Algorithm

Let BaseRTT be the minimum of all measured RTTs (commonly the RTT of the first packet) Compute ExpectedRate = cwind/BaseRTT Source calculates sending rate (ActualRate) once per RTT Source compares ActualRate with ExpectedRate

Diff = ExpectedRate - ActualRate if Diff < α increase cwind linearly if Diff > β decrease cwind linearly if α ≤ Diff ≤ β leave cwind unchanged In practice α = 2 segments( 2*SMSS) and β = 4 segments (4*SMSS)

Modified Slow Start Mechanism

Vegas allows exponentuial growth every other RTT In between, the cwind stays fixed so a valid comparaison of the expected and actual rates can be made when Diff < γ, Vegas changes from Slow Start mode to linear increase/decrease mode

  • Dr. Miled M. Tezeghdanti ()

Internet Congestion Control November 19, 2011 21 / 21
