Inheritance and Polymorphism Fall 2007 CS180 Definitions Inheritance object oriented way to form new classes from pre-existing ones Superclass The parent class If class is final, cannot inherit from this class

slide-1
SLIDE 1

Inheritance and Polymorphism

CS180 Fall 2007

slide-2
SLIDE 2

Definitions

  • Inheritance – object oriented way to form new

classes from pre-existing ones

– Superclass

  • The parent class
  • If class is final, cannot inherit from this class

– Subclass

  • Class which inherits all non-private properties from the

superclass

  • Generally a specific instance of a superclass
  • Polymorphism – a object can take many forms
  • Combining the two, can create subclasses with

different properties

slide-3
SLIDE 3

Inheriting From the Superclass

  • Two ways

– Use the protected keyword instead of the private keyword

  • Variables and methods which are protected are accessible by the subclass, but not the world

– Use public for methods to inherit, private for methods to not inherit and all variables

  • Variables no longer accessible directly in subclass
  • Use accessors and mutators to grab and modify them
  • Override methods as necessary

– If a method is declared final, then it cannot be overridden in a subclass – Can indicate with @override

  • Not required, but a good check
  • Constructors

– Not inherited! Must rewrite them – Use super keyword to call superconstructor from parent class

  • Can only use super as first line of a constructor (much like this)
  • If no superconstructor is explicitly called, then super() (the default superconstructor) is automatically

called as the first line

– Common error: if you don’t call super explicitly, make sure your superclass has a default constructor!

  • Must be first line of constructor
  • super keyword can also be used to call instances of methods from superclass
slide-4
SLIDE 4

Syntax

  • To extend a class,

use the extends keyword

  • The class will now

inherit all non-private characteristics of the superclass

– Do not have to re- write methods which are the same – Can introduce new methods and/or variables

public class A { private int x; public A() { set(0); } public A(int x) { set(x); } public void set(int x) { this.x = x; } public int get() { return x; } public void add1() { bump(); } private void bump() { x++; } } public class B extends A { public B() { super(); } public B(int x) { super(x); } public void add1() { set(get()+1); } }

slide-5
SLIDE 5

Inheriting From the Superclass

public class A { private int x; public A() { set(0); } public A(int x) { set(x); } public void set(int x) { this.x = x; } public int get() { return x; } public void add1() { bump(); } private void bump() { x++; } } public class B extends A { public B() { super(); } public B(int x) { super(x); } public void add1() { set(get()+1); } } public class A { protected int x; public A() { set(0); } public A(int x) { set(x); } public void set(int x) { this.x = x; } public int get() { return x; } public void add1() { bump(); } private void bump() { x++; } } public class B extends A { public B() { super(); } public B(int x) { super(x); } }

The add1() method is overridden here!

slide-6
SLIDE 6

Inheriting From the Superclass

public class A { A() { SOP(“A”); } } public class B extends A { public B() { SOP(“B”); } } public class C extends A { public C() { SOP(“C”); } } public class D extends B { public D() { SOP(“D”); } }

A = new A(); Output: A B = new B(); Output: AB C = new C(); Output: AC D = new D(); Output: ABD

On the superclass constructor calls, constructors wind up being executed top-down on the hierarchy.

slide-7
SLIDE 7

Object Class

  • Class Object is the superclass of all

superclasses in Java

– All classes defined implicitly inherit from Object if not explicitly extending from another class – Even if explicitly extending another class, that other class either extends from another class or implicitly extends from Object – Some useful methods which are commonly

  • verwritten
  • equals – for comparisons (defaults to reference address

comparision)

  • toString – translates your object into an appropriate String

(defaults to the reference address)

slide-8
SLIDE 8

Polymorphism

  • Allows a variable to

take on many forms

  • A variable of type

Animal may point to may different types of animals

  • Only methods scoped

within the variable type are available

– Not all animals fly, so even though an Animal identifier may point to a Bat object, you cannot call the fly() method directly

public class Animal { protected int age; public void eat() { SOP(“Yummy!”); } } public class Giraffe extends Animal { public Giraffe() { super(); } public void eat() { SOP(“Eating leaves!”); } public void gallop() { SOP(“Galloping away!”); } } public class Bat extends Animal { public Bat() { super(); } public void eat() { SOP(“Drinking blood!”); } public void fly() { SOP(“Flapping wings!”); } } _____________________________________________ Animal a = new Bat(); a.eat(); // legal! All animals make sounds! a.fly(); // illegal! Not all animals know how to fly! ((Bat)a).fly(); // legal! A bat knows how to fly! ((Giraffe)a).gallop(); // compiles, but runtime error!

slide-9
SLIDE 9

Dynamic Binding

  • On the call the eat(), what happens?

– If Animal object a is a Giraffe, then “Eating leaves!” – If Animal object a is a Bat, then “Drinking blood!” – Why not “Yummy!”? dynamic binding!

  • Objects have two types

– Static type – the type of the variable name – Dynamic type – the “actual type” of the variable in memory

  • Dynamic binding

– Resolved at runtime – Used for method lookup – Look up “most specific” instance of method call (look up the method in the dynamic type if it exists) – Most specific instance of a method may be in a parent class (and therefore inherited)

  • Static binding (optional)

– Resolved at compile time – Used for variable lookup – Also all static variables and methods are resolved during compilation

slide-10
SLIDE 10

Dynamic Binding

public class A { protected int x; public A() { set(0); } public A(int x) { set(x); } public void set(int x) { this.x = x; } public int get() { return x; } public void bump() { x+=2; } } public class B extends A { public B() { super(); } public B(int x) { super(x); } public void bump() { x++; } }

A a = new B(); a.bump(); SOP(“a=“+a.get());

Object a is of static type A, dynamic type B. On a method call, use dynamic type first!

static type dynamic type

slide-11
SLIDE 11

Determining Class Type

  • In order to access a method in a subclass from

an object with a static type of the superclass, need to downcast

– Downcasting is unsafe! Need to know that downcast is legal. – Use instanceof keyword or other methods

  • x instanceof A – true if x is an instance of class A or a

subclass of A

  • x.getClass().equals(A.class) – true if x is an instance of class

A

  • A.class.isAssignableFrom(x.getClass()) is true if x is an

instance of class A or a subclass of A

slide-12
SLIDE 12

Abstract Classes

  • Sometimes a superclass

never needs to be instantiated – you only make instances of the subclasses

  • Make class abstract

– Cannot be instantiated – May have some methods be abstract – Is like a blueprint for subclasses, with methods that need to be filled in

public abstract class Animal { protected int age; public abstract void eat(); } public abstract class Mammal { public Mammal() { super(); } public abstract void eat(); // other mammal-like behavior… } public class Giraffe extends Mammal { public Giraffe() { super(); } public void eat() { SOP(“Eating leaves!”); } }

slide-13
SLIDE 13

Interfaces

  • Contains method headers
  • Cannot instantiate interface
  • Cannot have any non-final variables
  • A class can implement many interfaces
  • Interfaces can extend from each other
  • Example: Comparable

– Contains one method, compareTo, which takes two objects and compares them

  • Returns a negative number if less than
  • Returns 0 if equal to
  • Returns a positive number if greater than

– Comparable is an interface and not an abstract class because not all things comparable are related

  • Numbers and people are both comparable, but have no reasonable

relationship between them

slide-14
SLIDE 14

Interfaces

public interface I { public void doStuff(); } public interface J extends I { public void doMoreStuff(); } public interface K { public void doEvenMoreStuff(); } public class A implements J, K { public void doStuff() {…} public void doMoreStuff() {…} public void doEvenMoreStuff {…} } J extends I, so interface J actually has 2 methods: doStuff() and doMoreStuff(). A implements J and K, so A must have a method for each method in the interfaces it implements.

slide-15
SLIDE 15

Abstract Class vs. Interface

  • Abstract classes are blueprints, interfaces are contracts

– Interface: “Here’s some methods. If your class implements this interface, you must provide an implementation of each method in the interface in the class.”

  • Method headers
  • final variables
  • A class can implement multiple interfaces
  • Cannot instantiate

– Abstract class: “Here’s a blueprint for a class. If your class extends this abstract class, you can use any functionality here and add onto it, but you must fill in what I have not.”

  • Abstract method headers
  • Methods
  • Variables
  • A class can extend only one class
  • Cannot instantiate
slide-16
SLIDE 16

Animal (Planet?)

Animal Bird Mammal Fish Owl Bat Penguin Giraffe Whale Shark Salmon

slide-17
SLIDE 17

Animal (Planet?)

Our animals:

public class Owl {…} public class Penguin {…} public class Bat {…} public class Giraffe {…} public class Whale {…} public class Shark {…} public class Salmon {…}

slide-18
SLIDE 18

Animal (Planet?)

Create appropriate superclasses:

public class Animal {…} public class Bird {…} public class Mammal {…} public class Fish {…} public class Owl {…} public class Penguin {…} public class Bat {…} public class Giraffe {…} public class Whale {…} public class Shark {…} public class Salmon {…}

slide-19
SLIDE 19

Animal (Planet?)

Connect the hierarchy:

public class Animal {…} public class Bird extends Animal {…} public class Mammal extends Animal {…} public class Fish extends Animal {…} public class Owl extends Bird {…} public class Penguin extends Bird {…} public class Bat extends Mammal {…} public class Giraffe extends Mammal {…} public class Whale extends Mammal {…} public class Shark extends Fish {…} public class Salmon extends Fish {…}

slide-20
SLIDE 20

Animal (Planet?)

Add in appropriate interfaces at the highest levels:

public class Animal {…} public class Bird extends Animal {…} public class Mammal extends Animal {…} public class Fish extends Animal implements Swimmer {…} public class Owl extends Bird implements Flyer {…} public class Penguin extends Bird {…} public class Bat extends Mammal implements Flyer {…} public class Giraffe extends Mammal {…} public class Whale extends Mammal implements Swimmer {…} public class Shark extends Fish {…} public class Salmon extends Fish {…}

slide-21
SLIDE 21

Animal (Planet?)

Make appropriate classes abstract:

abstract public class Animal {…} abstract public class Bird extends Animal {…} abstract public class Mammal extends Animal {…} abstract public class Fish extends Animal implements Swimmer {…} public class Owl extends Bird implements Flyer {…} public class Penguin extends Bird {…} public class Bat extends Mammal implements Flyer {…} public class Giraffe extends Mammal {…} public class Whale extends Mammal implements Swimmer {…} public class Shark extends Fish {…} public class Salmon extends Fish {…}

slide-22
SLIDE 22

Animal (Planet?)

abstract public class Animal {…} abstract public class Bird extends Animal {…} abstract public class Mammal extends Animal {…} abstract public class Fish extends Animal implements Swimmer {…} public class Owl extends Bird implements Flyer {…} public class Penguin extends Bird {…} public class Bat extends Mammal implements Flyer {…} public class Giraffe extends Mammal {…} public class Whale extends Mammal implements Swimmer {…} public class Shark extends Fish {…} public class Salmon extends Fish {…}

Which are valid instantiations? Animal a = new Animal(); Animal b = new Fish(); Animal c = new Flyer(); Mammal d = new Bat(); Fish e = new Swimmer(); Swimmer f = new Shark(); Flyer g = new Owl(); Swimmer h = new Whale(); Swimmer i = new Fish();
