KTH ROYAL INSTITUTE OF TECHNOLOGY

IncidentResponseSim: An Agent-Based Simulation Tool for Risk Management of Online Fraud

Dan Gorton Center for Safety Research Department of Transport Science

Outline

Background Scenarios Directions for future research

Background

The incident response process of online banking, and the incident response tree (IRT) tool

Online Banking and Fraud 1 (2)

”Online banking (OLB) is an electronic payment system that enables customers of a financial institution to conduct financial transactions on a website operated by the institution” [Wikipedia]

An online bank may have several ”channels” providing different means for login, and a different set of online services depending on the level of security provided by the channel. The size of online banking fraud is ”channel” specific and depends on many parameters, including …

• The number of customers
• Countermeasures
• Transaction limit
• Distribution of wealth on customer accounts

Online Banking and Fraud 2 (2)

Prevention

(e.g., authentication + IDS)

Detection

(e.g., real time or batch fraud detection)

Response

(e.g., automatic or manual)

Front End Security Measures Back End Security Measures

• Fig. Overview of electronic payment system [Julisch].

Threats

Impersonation

• Phishing, Man-in-the-middle, Man-in-the-browser, etc.

Deception

• Attacks where the customer performs the transaction on

behalf of the attacker Server side attacks

• Attacks directed at the online bank servers

Ref: [Julisch]

Countermeasures

… Updating prevention to include additional authentication methods, e.g.,

• ut-of-band authentication or adding control questions to customer

support personnel Updating detection using more aggressive intrusion and fraud detection Blocking fraudulent transactions before clearing them Closing down one or more channels Closing down certain services (e.g., wire transfers) within specific online channels Restricting functionality within services Restricting the possibility to add new beneficiary accounts Blacklisting fraudulent accounts (known money mules) Grey listing potentially fraudulent accounts, to initiate manual review before allowing transactions to clear Letting the fraud response team contact the customer for extra verification …

The Incident Response Process of Online Banking

On a high level

• Event driven
• Risks are evaluated against the current production

environment

• Shortage of time
• Large scale incidents will typically activate crisis

management teams On a low level

• The fraud response team works with each separate

incident

• Limited time for documentation

There is a need for a “quick” tool, which is “easy to grasp” for higher management

Existing Visual tools for Cyber Security

Attack Trees

• A methodical way or describing threats against, and

countermeasures protecting a system [Schneier] Protection Trees

• An explicit protection tree that mitigates the attack steps

modeled in the corresponding attack tree [Edge] Problem: “Fault tree” models fail to capture the chronological

• rdering of events [Pat-Cornell]

Solution: Event trees have been used for cyber threats [Ezell] Problem: Critique; huge problem with under-reporting [GAO] Solution: Make sure under-reporting is a limited problem [Gorton]

Idea: Fraud is an area where under-reporting may be a minor problem, because ”the customers want their money back”

Incident Response Tree (IRT)

Prevention Detection Response

Just Register the Frequencies…

Frequencies, C1 to C4

Ref: [Gorton]

Conditional Probabilities of Prevention Pp, Detection PD, and Response PR

The conditional probabilities change during the attack, up or down, depending

• n the effectiveness of the countermeasures against the threat at hand

Ref: [Gorton]

Relative frequencies, RFC1 to RFC4

RFC1 = PIE (1 – PP) (1 – PD) RFC2 = PIE (1 – PP) PD (1 – PR) RFC3 = PIE (1 – PP) PD PR RFC4 = PIE PP RFFraud = RFC1 + RFC2 = PIE (1 – PP) (1 – PDPR)

Ref: [Gorton]

Quality assurance

Use statistics for thresholds:

• Threshold for monthly reporting
• Threshold for weekly reporting
• Threshold for daily reporting
• Threshold for minor countermeasures
• Threshold for major countermeasures

Expected loss from fraud (EF)

Credit Risk Approach [BIS]: "𝐹𝑀 = 𝑄𝐸 ∙ 𝐹𝐵𝐸 ∙ 𝑀𝐻𝐸”

• Probability of default (PD)
• Exposure at default (EAD)
• Loss given default (LGD)

Expected Fraud: 𝐹𝐺 = 𝑄𝐺 ∙ 𝑗=1

𝑂 (𝐹𝐵𝐺𝑗 ∙ 𝑀𝐻𝐺𝑗)

• Probability of fraud (PF)

– 𝑄𝐺 =

# 𝑔𝑠𝑏𝑣𝑒 # 𝑑𝑣𝑡𝑢𝑝𝑛𝑓𝑠𝑡

• Exposure at fraud (EAF)

– 𝐹𝐵𝐺𝑗 = min(𝑈𝑠𝑏𝑜𝑡𝑏𝑑𝑢𝑗𝑝𝑜 𝑀𝑗𝑛𝑗𝑢, 𝐵𝑑𝑑𝑝𝑣𝑜𝑢 𝐶𝑏𝑚𝑏𝑜𝑑𝑓)

• Loss given fraud (LGF)

– 𝑀𝐻𝐺𝑗 = 𝑇𝑢𝑝𝑚𝑓𝑜 𝐵𝑛𝑝𝑣𝑜𝑢

𝐹𝐵𝐺

Conditional fraud value at risk

Credit Risk Approach [BIS]

• VaR at 99.75th percentile

– Once every 400 years

• Unexpected Losses (UL)
• UL = VaR - EL

Online Fraud Approach

• VaR at 95th percentile

– Once every 20 years

• Simple Random Sampling of

Fraud Losses (FL) – 𝐺𝑀𝑙 = 𝑗=1

𝐽

(𝐹𝐵𝐺𝑗 ∙ 𝑀𝐻𝐺𝑗)

IncidentResponseSim – Simplified Model

IncidentResponseSim – GUI

IncidentResponseSim – Customer Inspector

IncidentResponseSim – Example output

Simulations

Scenarios for IRT and the design of new methods for calculating the number of defrauded customers

Current Situation

In the following examples, we will use the following fictional statistics to describe the current situation. We assume that:

• Probability of initiating event, PIE = 1
• Conditional probability of prevention, PP = 0.8
• Conditional probability of detection, PD = 0.9
• Conditional probability of response, PR = 0.9

Current Situation

We assume:

• 100,000 customers
• A maximum transaction limit of 30,000
• Fraud may not continue over several days
• Account balance drawn from an up-scaled Beta (below)
• Stolen amount drawn from a truncated Normal

IncidentResponseSim – SRS of Defrauded Customers (current situation)

Output from IncidentResponseSim (999 iterations): Number of Defrauded Customers Bootstrap Mean: 38,10 Number of Defrauded Customers Bootstrap Std: 6,07 Number of Defrauded Customers Bootstrap 95%: 48,00 Number of Defrauded Customers Bootstrap Min: 22 Number of Defrauded Customers Bootstrap Max: 62

IncidentResponseSim – SRS of Direct Economic Consequences (current situation)

Output from IncidentResponseSim (999 iterations): EF Mean: 941 425,53 SEK EF Std: 62 547,99 SEK EF SE Mean: 9 028,02 SEK EF 95% (Fraud VaR): 1 042 430,61 SEK EF Min: 765 797,88 SEK EF Max: 1 110 622,08 SEK

Scenario 1 – Newly entered markets

Assume that we want to keep the number of fraud victims the same, and that we use the probability of a customer being infected as a proxy:

A: “reference risk of infection” vs B: e.g. 2.75 times as high risk of infection

Existing Online Bank New Online Bank Threat Environment A Threat Environment B PandaLabs

Results from IncidentResponseSim

SRS of Defrauded Customers: DC Mean: 104,58 DC Std: 10.186893976135476 DC 95% (Fraud VaR): 121.0 DC Min: 76.0 DC Max: 143.0 SRS of Direct Economic Consequences: EF Mean: 2 379 053,07 SEK EF Std: 97 137,15 SEK EF SE Mean: 8 830,65 SEK EF 95% (Fraud VaR): 2 545 100,11 SEK EF Min: 2 049 829,33 SEK EF Max: 2 679 394,95 SEK

Scenario 2 – Single point of failure

Prevention

(e.g., Authentication + IDS)

Detection

(e.g., fraud detection)

Response

(e.g., real time, batch, manual)

History: RFFraud = 1(1-0.8)(1-0.9*0.9) = 0.038 Failed prevention: RFFraud = 1(1-0)(1-0.9*0.9) = 0.19 Failed detection: RFFraud = 1(1-0.8)(1-0*0.9) = 0.20 Failed response: RFFraud = 1(1-0.8)(1-0.9*0) = 0.20

Scenario 3 – Emerging threats

Assume a new threat, highly contagious, 2 * infection rate, and very effective at overcoming current preventive measures, PP_B = 0.6. SRS of Defrauded Customers: Number of Defrauded Customers Bootstrap Mean: 152,05 Number of Defrauded Customers Bootstrap Std: 11,72 Number of Defrauded Customers Bootstrap 95%: 171,00 SRS of Direct Economic Consequences: EF Mean: 3 352 588,36 SEK EF Std: 114 012,55 SEK EF 95% (Fraud VaR): 3 545 783,33 SEK

Existing Online Bank Threat Environment A Threat Environment B

Max = min (Account Balance, Transaction Limit) Random = rnd (0, min (Account Balance, Transaction Limit)) Mean Transaction = 500 + rnd (0, 10 000)

Trojan Strategies vs Transaction Limits

Return on Security Investment (ROSI)

MLR = Monetary Loss Reduction COS = Cost of Solution 𝑆𝑃𝑇𝐽 = 𝑁𝑀𝑆 − 𝐷𝑃𝑇 𝐷𝑃𝑇

Action COS # Frauds COST MLR ROSI Do nothing 48 1,042,431 N/A Add +0.1 prevention 400,000 26 581,281 461,150 0.15 Add +0.05 detection 300,000 38 826,431 215,999

• 0.28

Add +0.05 response 200,000 38 826,431 215,999 0.08

Directions for future research

• The IRT, being a novel tool, needs to be investigated

further; preferably using real data from other financial institutions to make sure it is general enough for wide spread use

• Work in progress:

– More advanced multi-agent-based simulation (using Mason [Luke])

• Interesting future possibilities are to include, for example:

– the use of prior information using Bayes – dynamic models like game theory – social network analysis for estimating the effects of customer awareness.

References

[Wikipedia] Wikipedia, “Online Banking”, available at https://en.wikipedia.org/wiki/Online_banking (accessed on August 15, 2015). [Julisch] Julisch, K., “Risk-Based Payment Fraud Detection”, Research Report, IBM Research Zurich, available at https://domino.research.ibm.com/library/cyberdig.nsf/papers/E4D71715CD00934A8525779800431D47/$File/ rz3787.pdf (accessed on August 15, 2015). [Schneier] Schneier, B., “Secret & Lies: Digital Security in a Networked World”, New York, John Wiley & Sons, pp.318-333, 2000. [Edge] Edge, K. et al., “The Use of Protection Trees to Analyze Security for an Online Banking System” In the proceedings of the 40th Hawaii International Conference on Systems Science (HICSS 07), 2007. [Pat-Cornell] Pat-Cornell, M.E., “Fault trees vs. event trees in reliability analysis”, Journal of Risk Analysis, Volume 4 No. 3, pp.177-186, 1984. [Ezell] Ezell, BC. et al., “Probabilistic risk analysis and terrorism risk”, Journal of Risk Analysis, pp. 575-589, 2010. [GAO] GAO, “Information Security: Computer Attacks at Department of Defense Pose Increasing Risk”, 1996. [Gorton] Gorton, D., “Using Incident Response Trees as a Tool for Risk Management of Online Financial Services”, Journal of Risk Analysis, Volume 34, No. 9, pp. 1763-1774, 2014. [PandaLabs] PandaLabs, “PandaLabs Annual Report 2013 Summary”, available at http://www.pandasecurity.com/mediacenter/src/uploads/2014/07/Annual-Report-PandaLabs-2013.pdf (accessed

• n October 19, 2015).

[Franchot] Frachot, A., Moudoulaud, O., Roncalli, T., “Loss Distribution Approach in Practice”, Group de Recherche Oprationnelle, Credit Lyonnais, France, 2003. [BIS] Bank of International Settlements, “An Explanatory Note on the Basel II IRB Risk Weight Functions”, https://www.bis.org/bcbs/irbriskweight.pdf (accessed on August 15, 2015). [Luke] Luke, S. et al, “MASON: A Multi-agent Simulation Environment”, Simulation, July, 2005.
