Highly Available Database Architectures in AWS Santa Clara, California | April 23th 25th, 2018 Mike Benshoof, Technical Account Manager, Percona Hello, Percona Live Attendees! What this talk is meant to be... High level overview of a

slide-1
SLIDE 1

Santa Clara, California | April 23th – 25th, 2018 Mike Benshoof, Technical Account Manager, Percona

Highly Available Database Architectures in AWS

slide-2
SLIDE 2

2

Hello, Percona Live Attendees!

What this talk is meant to be...

  • High level overview of a highly available

(HA) database solution

  • What is it and why do we need it?
  • General concepts
  • Examples of HA architectures using

different AWS components

  • EC2, RDS, Aurora, and ProxySQL
  • General best practices from a design

and application standpoint

  • High level considerations of issues and

planning for failure

slide-3
SLIDE 3

3

Hello, Percona Live Attendees!

What this talk is meant to be...

  • High level overview of a highly available

(HA) database solution

  • What is it and why do we need it?
  • General concepts
  • Examples of HA architectures using

different AWS components

  • EC2, RDS, Aurora, and ProxySQL
  • General best practices from a design

and application standpoint

  • High level considerations of issues and

planning for failure

What this talk is not meant to be...

  • A deep dive into AWS or MySQL

internals

  • Won’t be any mention of provisioned

IOPS or buffer pool size

  • A listing of several benchmarks with a

recommendation of which is “best”

  • Benchmarks can be misleading, your

application is unique

  • A description of a “silver bullet”

architecture that will fit every use case

  • There is no single solution
slide-4
SLIDE 4

4

So let’s dig in...

What is a highly available database solution? An architecture that is designed to continue to function normally in the event of hardware or network failure within the system

slide-5
SLIDE 5

5

So let’s dig in...

In practice, this generally translates to some level of automatic failover that generally results in some level (however brief) of downtime.

slide-6
SLIDE 6

6

What does it look like?

  • Application servers sending

R/W traffic to primary database

  • Failover database in the

background - unused

  • Some synchronization

mechanism between primary and failover

slide-7
SLIDE 7

7

What does it look like?

  • Primary database fails!!
slide-8
SLIDE 8

8

What does it look like?

  • R/W traffic is re-routed to the

failover node

  • No application changes are

needed, but some level of retry logic is recommended

slide-9
SLIDE 9

9

Some general concepts...

  • Virtual Endpoint

○ Application connects to an alias and not the physical servers ○ This allows the endpoint to handle the routing to backend resources ○ Some examples

■ Load balancer (physical or logical) ■ DNS ■ Floating IP address

slide-10
SLIDE 10

10

Some general concepts...

  • Virtual Endpoint

○ Application connects to an alias and not the physical servers ○ This allows the endpoint to handle the routing to backend resources ○ Some examples

■ Load balancer (physical or logical) ■ DNS ■ Floating IP address

  • Synchronization

○ Data is kept in sync between primary and failover resources ○ Can be synchronous or asynchronous, but done automatically in real-time ○ Some examples

■ MySQL Replication (async) ■ Block level replication (sync) ■ Clustering solution - i.e. Galera (sync)

slide-11
SLIDE 11

11

Let’s take this to the cloud...

AWS Components at our disposal

  • Elastic Compute Cloud (EC2)
  • Self managed MySQL instances, generally built on Linux AMI
  • Highly customizable / flexible
slide-12
SLIDE 12

12

Let’s take this to the cloud...

AWS Components at our disposal

  • Elastic Compute Cloud (EC2)
  • Self managed MySQL instances, generally built on Linux AMI
  • Highly customizable / flexible
  • Relational Database Service (RDS)
  • Can run MySQL native or Aurora (or other engines such as SQL Server, Postgres, Oracle)
  • Less flexible, but fully managed (point-and-click snapshots, replicas, etc)
slide-13
SLIDE 13

13

Let’s take this to the cloud...

AWS Components at our disposal

  • Elastic Compute Cloud (EC2)
  • Self managed MySQL instances, generally built on Linux AMI
  • Highly customizable / flexible
  • Relational Database Service (RDS)
  • Can run MySQL native or Aurora (or other engines such as SQL Server, Postgres, Oracle)
  • Less flexible, but fully managed (point-and-click snapshots, replicas, etc)
  • Miscellaneous Building Blocks
  • Elastic Load Balancer (ELB)
  • Route 53 (DNS failover strategies)
  • Elastic IP (virtual IP that can be assigned to EC2 instances)
slide-14
SLIDE 14

14

So Many Choices!

  • The options are endless!
  • Here are the solutions we’ll discuss

○ Percona XtraDB Cluster on EC2 ○ RDS for MySQL ○ Amazon Aurora

slide-15
SLIDE 15

Percona XtraDB Cluster

slide-16
SLIDE 16

16

Percona XtraDB Cluster (PXC)

Percona XtraDB Cluster

  • Percona Server for MySQL
  • Galera Cluster (for replication)
  • Synchronous replication
  • Transaction based replication
  • Transaction is verified locally
  • Certified as valid on other nodes before local commit
  • Can read/write to any node in the cluster
  • Preferred architecture
  • Write to single node, read from any node
  • Software load balancer for HA
slide-17
SLIDE 17

17

PXC Use Cases

  • Need the ability for multi-node writing

○ Ideally architected to avoid collisions ○ I.e. each nodes writes to dedicated schema/tables

slide-18
SLIDE 18

18

PXC Use Cases

  • Need the ability for multi-node writing

○ Ideally architected to avoid collisions ○ I.e. each nodes writes to dedicated schema/tables

  • Require consistent reads

○ Application requires additional read replicas ○ Application cannot tolerate any replica lag

slide-19
SLIDE 19

19

PXC Use Cases

  • Need the ability for multi-node writing

○ Ideally architected to avoid collisions ○ I.e. each nodes writes to dedicated schema/tables

  • Require consistent reads

○ Application requires additional read replicas ○ Application cannot tolerate any replica lag

  • Maximum data durability

○ Guarantee transactions are remotely received

slide-20
SLIDE 20

20

PXC Use Cases

  • Need the ability for multi-node writing

○ Ideally architected to avoid collisions ○ I.e. each nodes writes to dedicated schema/tables

  • Require consistent reads

○ Application requires additional read replicas ○ Application cannot tolerate any replica lag

  • Maximum data durability

○ Guarantee transactions are remotely received

  • Require cross-WAN (region) synchronous replication

○ Will add latency to writes (business decision)

slide-21
SLIDE 21

21

PXC in AWS

EC2 Based deployment

  • 3 base Linux AMI instances
slide-22
SLIDE 22

22

PXC in AWS

EC2 Based deployment

  • 3 base Linux AMI instances
  • Nodes located in different AZs

○ Mitigates split-brain from AZ failure

slide-23
SLIDE 23

23

PXC in AWS

EC2 Based deployment

  • 3 base Linux AMI instances
  • Nodes located in different AZs

○ Mitigates split-brain from AZ failure

  • Provisioned IOPs or local storage

○ I3 instances with local NVMe

■ Note - relies on PXC for redundancy

○ GP2 not suitable for high throughput

slide-24
SLIDE 24

24

PXC in AWS

EC2 Based deployment

  • 3 base Linux AMI instances
  • Nodes located in different AZs

○ Mitigates split-brain from AZ failure

  • Provisioned IOPs or local storage

○ I3 instances with local NVMe

■ Note - relies on PXC for redundancy

○ GP2 not suitable for high throughput

  • Cross region supported, higher write latency

○ Same for multiple VPCs - supported, but with potential latency increase

slide-25
SLIDE 25

25

So how do we route??

Enter ProxySQL…

  • Layer 7 software load balancer
slide-26
SLIDE 26

26

So how do we route??

Enter ProxySQL…

  • Layer 7 software load balancer
  • Monitors backend nodes

○ Handles failed nodes transparently ○ Configurable retries

slide-27
SLIDE 27

27

So how do we route??

Enter ProxySQL…

  • Layer 7 software load balancer
  • Monitors backend nodes

○ Handles failed nodes transparently ○ Configurable retries

  • Potential for advanced routing

○ Read/write splitting ○ Table/schema based routing

slide-28
SLIDE 28

28

So how do we route??

Enter ProxySQL…

  • Layer 7 software load balancer
  • Monitors backend nodes

○ Handles failed nodes transparently ○ Configurable retries

  • Potential for advanced routing

○ Read/write splitting ○ Table/schema based routing

  • Run locally or own layer

○ Local preferred for fewer app servers (< 10) ○ Use ELB for HA when separate layer

slide-29
SLIDE 29

29

And finally the full stack...

  • App servers point to ProxySQL

behind ELB

  • ProxySQL configured with

○ Writes pointed to single PXC node ○ Reads pointed to all three nodes in the cluster

  • In the event of primary failure:

○ Write traffic shifted to another PXC node ○ Reads continue to be sent to all healthy nodes

slide-30
SLIDE 30

RDS for MySQL / Amazon Aurora

slide-31
SLIDE 31

31

Relational Database Service (RDS)

  • Fully managed RDBMS, built on AWS components

○ EC2 instances ○ EBS volumes

slide-32
SLIDE 32

32

Relational Database Service (RDS)

  • Fully managed RDBMS, built on AWS components

○ EC2 instances ○ EBS volumes

  • Operational features

○ Snapshots (restoring from snapshots) ○ Point-in-time recovery ○ On-demand replicas

slide-33
SLIDE 33

33

Relational Database Service (RDS)

  • Fully managed RDBMS, built on AWS components

○ EC2 instances ○ EBS volumes

  • Operational features

○ Snapshots (restoring from snapshots) ○ Point-in-time recovery ○ On-demand replicas

  • Availability features

○ Multi A/Z with failover (MySQL) ○ Automatic replica promotion (Aurora) ○ Master DNS endpoint (Virtual endpoint)

slide-34
SLIDE 34

34

RDS Use Cases

  • Desire (or need) fully managed DBaaS

○ Limited DBA staff ○ Developer/Application focused DBA staff

slide-35
SLIDE 35

35

RDS Use Cases

  • Desire (or need) fully managed DBaaS

○ Limited DBA staff ○ Developer/Application focused DBA staff

  • Variable (but predictable) traffic patterns

○ Add/remove replicas quickly as needed ○ I.e. every weekend, traffic triples so add 2 new replicas each Friday evening, terminate each Monday morning (saves $)

slide-36
SLIDE 36

36

RDS Use Cases

  • Desire (or need) fully managed DBaaS

○ Limited DBA staff ○ Developer/Application focused DBA staff

  • Variable (but predictable) traffic patterns

○ Add/remove replicas quickly as needed ○ I.e. every weekend, traffic triples so add 2 new replicas each Friday evening, terminate each Monday morning (saves $)

  • Application tolerates stale reads

○ Can’t guarantee consistent reads, replication lag is possible

slide-37
SLIDE 37

37

RDS Use Cases

  • Desire (or need) fully managed DBaaS

○ Limited DBA staff ○ Developer/Application focused DBA staff

  • Variable (but predictable) traffic patterns

○ Add/remove replicas quickly as needed ○ I.e. every weekend, traffic triples so add 2 new replicas each Friday evening, terminate each Monday morning (saves $)

  • Application tolerates stale reads

○ Can’t guarantee consistent reads, replication lag is possible

  • Non-complex design required

○ Standard read/write 90/10 traffic pattern, single node writes, read pool

slide-38
SLIDE 38

38

Aurora vs RDS for MySQL

Aurora

  • Shared backend storage

○ Replicated across multiple A/Z ○ Workload optimized by role (write master vs read replica)

  • Cluster endpoints provided

○ Writer endpoint (DNS failover) ○ Reader endpoint (DNS round-robin)

  • Hot-spare (replica) promoted to

master is accessible

slide-39
SLIDE 39

39

Aurora vs RDS for MySQL

Aurora

  • Shared backend storage

○ Replicated across multiple A/Z ○ Workload optimized by role (write master vs read replica)

  • Cluster endpoints provided

○ Writer endpoint (DNS failover) ○ Reader endpoint (DNS round-robin)

  • Hot-spare (replica) promoted to

master is accessible RDS for MySQL

  • Independent storage

○ Block level replication for standby ○ MySQL async for replica

  • Writer endpoint managed by

DNS

○ DNS Failover to hot-spare in different A/Z

  • Hot-spare is EBS block level

replication and not accessible

slide-40
SLIDE 40

40

High Availability in RDS / Aurora

  • Endpoints are unique DNS entries

○ Provided by RDS ○ Can be fronted by Route 53 CNAME as needed

slide-41
SLIDE 41

41

High Availability in RDS / Aurora

  • Endpoints are unique DNS entries

○ Provided by RDS ○ Can be fronted by Route 53 CNAME as needed

  • RDS for MySQL

○ Writer DNS is failover only to hot-spare ○ Hot-spare isn’t reachable under normal operation

■ I.e. can’t use as a slave for long queries, etc

○ On master failure, potential for slight (~1 minute) data loss

slide-42
SLIDE 42

42

High Availability in RDS / Aurora

  • Endpoints are unique DNS entries

○ Provided by RDS ○ Can be fronted by Route 53 CNAME as needed

  • RDS for MySQL

○ Writer DNS is failover only to hot-spare ○ Hot-spare isn’t reachable under normal operation

■ I.e. can’t use as a slave for long queries, etc

○ On master failure, potential for slight (~1 minute) data loss

  • Aurora

○ Writer DNS is failover to active replica ○ Replica can be normal read-only replica in pool ○ On master failure, near instant failover with no data loss

slide-43
SLIDE 43

43

RDS for MySQL Architecture

  • App servers point to ProxySQL

behind ELB

  • ProxySQL configured with

○ Writes pointed DNS of primary ○ Reads pointed to pool of read replicas

  • In the event of primary failure,

write traffic shifted to RDS standby, read traffic still sent to replica pool

slide-44
SLIDE 44

44

Aurora Architecture

  • App servers point to ProxySQL

behind ELB*

  • ProxySQL configured with

○ Writes pointed to primary ○ Reads pointed to pool of read replicas

  • In the event of primary failure,

write traffic shifted to replica automatically promoted, read traffic still sent to replica pool

* Note: Requires ProxySQL 2.0+ due to Aurora using innodb_read_only for replicas

slide-45
SLIDE 45

45

So why do we add ProxySQL to the RDS stack when DNS already handles failover??

slide-46
SLIDE 46

46

More than just failover...

ProxySQL adds flexibility to the stack far beyond DNS failover:

  • Rule based Read/Write splitting

○ Inspect queries, send plain selects to read-only hostgroup ○ Simplifies application logic

slide-47
SLIDE 47

47

More than just failover...

ProxySQL adds flexibility to the stack far beyond DNS failover:

  • Rule based Read/Write splitting

○ Inspect queries, send plain selects to read-only hostgroup ○ Simplifies application logic

  • Seamlessly handles query retry on failover - i.e.

2018-04-12 21:37:16 MySQL_Session.cpp:2816:handler(): [ERROR] Detected a broken connection during query on (11,10.1.3.162,3306) , FD (Conn:50 , MyDS:50) : 2013, Lost connection to MySQL server during query 2018-04-12 21:37:16 MySQL_Session.cpp:2824:handler(): [WARNING] Retrying query.

slide-48
SLIDE 48

48

More than just failover...

ProxySQL adds flexibility to the stack far beyond DNS failover:

  • Rule based Read/Write splitting

○ Inspect queries, send plain selects to read-only hostgroup ○ Simplifies application logic

  • Seamlessly handles query retry on failover - i.e.

2018-04-12 21:37:16 MySQL_Session.cpp:2816:handler(): [ERROR] Detected a broken connection during query on (11,10.1.3.162,3306) , FD (Conn:50 , MyDS:50) : 2013, Lost connection to MySQL server during query 2018-04-12 21:37:16 MySQL_Session.cpp:2824:handler(): [WARNING] Retrying query.

  • Route queries for sharding

○ Inspect query for schema/table name, route to specific hostgroup

slide-49
SLIDE 49

49

More than just failover...

  • Dynamic rewrites / routing

○ At runtime, transparently rewrite or route problem queries ○ Leverages the query rules engine

slide-50
SLIDE 50

50

More than just failover...

  • Dynamic rewrites / routing

○ At runtime, transparently rewrite or route problem queries ○ Leverages the query rules engine

  • Route queries for sharding

○ Inspect query for schema/table name, route to specific hostgroup ○ Can be done dynamically if new shards are added

slide-51
SLIDE 51

51

More than just failover...

  • Dynamic rewrites / routing

○ At runtime, transparently rewrite or route problem queries ○ Leverages the query rules engine

  • Route queries for sharding

○ Inspect query for schema/table name, route to specific hostgroup ○ Can be done dynamically if new shards are added

  • More intelligent Query Cache

○ Selectively cache queries by fingerprint ○ Query cache purging outside of mysql in background ○ No application changes needed to call external cache (i.e. memcache)

slide-52
SLIDE 52

52

For your reading pleasure...

RDS / Aurora Details:

  • https://aws.amazon.com/rds/aurora/faqs/
  • https://aws.amazon.com/rds/mysql/faqs/

PXC

  • https://www.percona.com/doc/percona-xtradb-cluster/LATEST/howtos/centos_howto.html
  • https://www.percona.com/doc/percona-xtradb-cluster/LATEST/howtos/proxysql.html

ProxySQL

  • https://github.com/sysown/proxysql/wiki
  • https://www.percona.com/blog/2018/04/03/how-to-implement-proxysql-with-aws-aurora/
slide-53
SLIDE 53

53

Summary

  • Multiple options for HA in AWS

○ PXC on EC2 (consistent reads, data durability, multi-region support)* ○ RDS / Aurora (fully managed, general workload/pattern, elastic)

  • Need HA at each level

○ Application, load balancer (routing), database ○ Several AWS components available

  • ProxySQL acts as intelligent (layer 7) load balancer

○ Dynamic rules/routing ○ Query / connection retry logic ○ Run locally or behind ELB

slide-54
SLIDE 54

54

Thank You Sponsors!!

slide-55
SLIDE 55

55

Rate My Session

slide-56
SLIDE 56

Thank You!
