SLIDE 1
Hierarchical Clustering
36-350: Data Mining 25 September 2006
Last time...
- Unsupervised learning problems; finding
clusters
- K means
- divide into k clusters to minimize within-
cluser variance*cluster size
- local search, local minima
Hierarchical Clustering 36-350: Data Mining 25 September 2006 Last - - PowerPoint PPT Presentation
Hierarchical Clustering 36-350: Data Mining 25 September 2006 Last - - PowerPoint PPT Presentation
Hierarchical Clustering 36-350: Data Mining 25 September 2006 Last time... Unsupervised learning problems; finding clusters K means divide into k clusters to minimize within- cluser variance*cluster size local search, local
SLIDE 2
SLIDE 3
Limits of k-Means
- Local search can get stuck
- Random starts help
- Sum-of-squares likes ball-shaped clusters
- How to pick k?
- No relations between clusters
SLIDE 4
Hierarchical Clustering
- Basic idea: cluster the clusters
- High-level clusters contain multiple low-level
clusters
- Clusters are now related
- Don’t need to chose k
- Assumes a hierarchy makes sense...
SLIDE 5
Ward’s Method
- 1. Start with every point in its own cluster
- 2. For each pair of clusters, calculate “merging
cost” = increase in sum of squares
- 3. Merge least-costly pair
- 4. Stop when merging cost takes a big jump
SLIDE 6
gray32
- rchid3
darkmagenta flower2 flower3
- rchid3
flower6
- rchid3
flower7 flower8 gray59.2 flower9 plum4 flower1 flower4 midnightblue gray10 gray36 tiger7 burlywood2 tiger3 tiger5 darkseagreen4 flower5 antiquewhite2 tiger6 darkseagreen4 darkseagreen4 tiger8 tiger9 lightgoldenrod3 tiger4 gray10 tiger1 tiger2 darkslategray.2 darkslategray.2
- cean3
- cean7
lightskyblue3 azure3
- cean2
- cean4
royalblue
- cean5
royalblue
- cean1
- cean6
2 4 6 8 10 0.0 0.5 1.0 1.5 2.0 2.5 3.0 clusters merging cost
Ward’s method applied to the images from lecture 3: ocean, tigers, flowers Jump in merging cost suggests 3 clusters - almost exactly right
- nes, too (but thinks
flower5 is a tiger)
SLIDE 7
- Don’t have to chose k
- Sum of squares is worse, generally, than k-
means (for equal k)
- more constrained search
- prefers to merge small clusters, all else
equal
SLIDE 8
k-Means Ward’s Minimizing the mean distance from the center tends to make spheres, which can be silly note how Ward’s is less balanced
SLIDE 9
Single-link clustering
- 1. Start with every point in its own cluster
- 2. Calculate gaps between every pair of
clusters = distance between 2 closest points in each cluster
- 3. Merge clusters with smallest gap
SLIDE 10
k-Means Ward’s Single-link
