Hierarchical and Ensemble Clustering

Ke Chen Reading: [7.8-7.10, EA], [25.5, KPM], [Fred & Jain, 2005]

COMP24111 Machine Learning

COMP24111 Machine Learning

2

Outline

• Introduction
• Cluster Distance Measures
• Agglomerative Algorithm
• Example and Demo
• Key Concepts in Hierarchal Clustering
• Clustering Ensemble via Evidence Accumulation
• Summary

COMP24111 Machine Learning

3

Introduction

• Hierarchical Clustering Approach

– A typical clustering analysis approach via partitioning data set sequentially – Construct nested partitions layer by layer via grouping objects into a tree of clusters (without the need to know the number of clusters in advance) – Use (generalised) distance matrix as clustering criteria

• Agglomerative vs. Divisive

– Agglomerative: a bottom-up strategy

• Initially each data object is in its own (atomic) cluster
• Then merge these atomic clusters into larger and larger clusters

– Divisive: a top-down strategy

• Initially all objects are in one single cluster
• Then the cluster is subdivided into smaller and smaller clusters
• Clustering Ensemble

– Using multiple clustering results for robustness and overcoming weaknesses of single clustering algorithms.

COMP24111 Machine Learning

4

Introduction: Illustration

• Illustrative Example: Agglomerative vs. Divisive

Agglomerative and divisive clustering on the data set { a, b, c, d ,e }

• Cluster distance
• Termination condition

Step 0 Step 1 Step 2 Step 3 Step 4

b d c e a a b d e c d e a b c d e

Step 4 Step 3 Step 2 Step 1 Step 0

Agglomerative Divisive

COMP24111 Machine Learning

5

single link (min) complete link (max) average

Cluster Distance Measures

• Single link: smallest distance

between an element in one cluster and an element in the other, i.e., d(Ci, Cj) = min{ d(xip, xjq)}

• Complete link: largest distance

between an element in one cluster and an element in the other, i.e., d(Ci, Cj) = max{ d(xip, xjq)}

• Average: avg distance between

elements in one cluster and elements in the other, i.e., d(Ci, Cj) = avg{ d(xip, xjq)}

d(C, C)=0

COMP24111 Machine Learning

6

Cluster Distance Measures

Example: Given a data set of five objects characterised by a single continuous feature, assume

that there are two clusters: C1: { a, b} and C2: { c, d, e} .

• 1. Calculate the distance matrix . 2. Calculate three cluster distances between C1 and C2.

a b c d e

Feature 1 2 4 5 6

a b c d e a

1 3 4 5

b

1 2 3 4

c

3 2 1 2

d

4 3 1 1

e

5 4 2 1 Single link Complete link Average

2 4} 3, 2, 5, 4, min{3, e)} (b, d), (b, c), (b, e), (a, d), a, ( , c) a, ( min{ ) C , C ( dist

2 1

= = = d d d d d d 5 4} 3, 2, 5, 4, max{3, e)} (b, d), (b, c), (b, e), (a, d), a, ( , c) a, ( max{ ) C , dist(C

2 1

= = = d d d d d d

5 . 3 6 21 6 4 3 2 5 4 3 6 e) (b, d) (b, c) (b, e) (a, d) a, ( c) a, ( ) C , dist(C

2 1

= = + + + + + = + + + + + = d d d d d d

COMP24111 Machine Learning

7

Agglomerative Algorithm

• The Agglomerative algorithm is carried out in three steps:

1) Convert all object features into a distance matrix 2) Set each object as a cluster (thus if we have N objects, we will have N clusters at the beginning) 3) Repeat until number of cluster is one (or known # of clusters)

• Merge two closest clusters
• Update “distance matrix”

COMP24111 Machine Learning

8

• Problem: clustering analysis with agglomerative algorithm

Example

data matrix distance matrix Euclidean distance

COMP24111 Machine Learning

9

• Merge two closest clusters (iteration 1)

Example

COMP24111 Machine Learning

10

• Update distance matrix (iteration 1)

Example

COMP24111 Machine Learning

11

• Merge two closest clusters (iteration 2)

Example

COMP24111 Machine Learning

12

• Update distance matrix (iteration 2)

Example

COMP24111 Machine Learning

13

• Merge two closest clusters/update distance matrix

(iteration 3)

Example

COMP24111 Machine Learning

14

• Merge two closest clusters/update distance matrix

(iteration 4)

Example

COMP24111 Machine Learning

15

• Final result (meeting termination condition)

Example

COMP24111 Machine Learning

16

• Dendrogram tree representation

Key Concepts in Hierarchal Clustering

• 1. In the beginning we have 6

clusters: A, B, C, D, E and F

• 2. We merge clusters D and F into

cluster (D, F) at distance 0.50

• 3. We merge cluster A and cluster B

into (A, B) at distance 0.71

• 4. We merge clusters E and (D, F)

into ((D, F), E) at distance 1.00

• 5. We merge clusters ((D, F), E) and C

into (((D, F), E), C) at distance 1.41

• 6. We merge clusters (((D, F), E), C)

and (A, B) into ((((D, F), E), C), (A, B)) at distance 2.50

• 7. The last cluster contain all the objects,

thus conclude the computation

2 3 4 5 6

• bject

lifetime

COMP24111 Machine Learning

17

• Lifetime vs K-cluster Lifetime

2 3 4 5 6

• bject

lifetime

Key Concepts in Hierarchal Clustering

• Lifetime

The distance between that a cluster is created and that it disappears (merges with other clusters during clustering). e.g. lifetime of A, B, C, D, E and F are 0.71, 0.71, 1.41, 0.50, 1.00 and 0.50, respectively, the life time of (A, B) is 2.50 – 0.71 = 1.79, ……

• K-cluster Lifetime

The distance from that K clusters emerge to that K clusters vanish (due to the reduction to K-1 clusters). e.g. 5-cluster lifetime is 0.71 - 0.50 = 0.21 4-cluster lifetime is 1.00 - 0.71 = 0.29 3-cluster lifetime is 1.41 – 1.00 = 0.41 2-cluster lifetime is 2.50 – 1.41 = 1.09

COMP24111 Machine Learning

18

Demo

Agglomerative Demo

COMP24111 Machine Learning

19

Relevant Issues

• How to determine the number of clusters

– If the number of clusters known, termination condition is given! – The K-cluster lifetime as the range of threshold value on the dendrogram tree that leads to the identification of K clusters – Heuristic rule: cut a dendrogram tree with maximum life time to find a “proper” K

• Major weakness of agglomerative clustering methods

– Can never undo what was done previously – Sensitive to cluster distance measures and noise/outliers – Less efficient: O (n2 logn), where n is the number of total objects

• There are several variants to overcome its weaknesses

– BIRCH: scalable to a large data set – ROCK: clustering categorical data – CHAMELEON: hierarchical clustering using dynamic modelling

COMP24111 Machine Learning

20

Clustering Ensemble

• Motivation

– A single clustering algorithm may be affected by various factors

• Sensitive to initialisation and noise/outliers, e.g. the K-means is sensitive to initial centroids!
• Sensitive to distance metrics but hard to find a proper one
• Hard to decide a single best algorithm that can handle all types of cluster shapes and sizes

– An effective treatments: clustering ensemble

• Utilise the results obtained by multiple clustering analyses for robustness

COMP24111 Machine Learning

21

Clustering Ensemble

• Clustering Ensemble via Evidence Accumulation (Fred & Jain, 2005)

– A simple clustering ensemble algorithm to overcome the main weaknesses of different clustering methods by exploiting their synergy via evidence accumulation

• Algorithm summary

– Initial clustering analysis by using either different clustering algorithms or running a single clustering algorithm on different conditions, leading to multiple partitions e.g. the K-mean with various initial centroid settings and different K, the agglomerative algorithm with different distance metrics and forced to terminated with different number of clusters… – Converting clustering results on different partitions into binary “distance” matrices – Evidence accumulation: form a collective “distance” matrix based on all the binary “distance” matrices – Apply a hierarchical clustering algorithm (with a proper cluster distance metric) to the collective “distance” matrix and use the maximum K-cluster lifetime to decide K

Clustering Ensemble

 Example: convert clustering results into binary “Distance” matrix

A B C D Cluster 1 (C1) Cluster 2 (C2)

            = 1 1 1 1 1 1 1 1

1

D

A D C B D C A B

“distance” Matrix

22

COMP24111 Machine Learning

Clustering Ensemble

Example: convert clustering results into binary “Distance” matrix

A B C D Cluster 1 (C1) Cluster 2 (C2)

            = 1 1 1 1 1 1 1 1 1 1

2

D

A D C B D C A B

“distance Matrix”

23

Cluster 3 (C3)

COMP24111 Machine Learning

Clustering Ensemble

 Evidence accumulation: form the collective “distance” matrix

24

            = 1 1 1 1 1 1 1 1 1 1

2

D             = 1 1 1 1 1 1 1 1

1

D             = + = 1 2 2 1 2 2 2 2 2 2

2 1

D D DC

COMP24111 Machine Learning

COMP24111 Machine Learning

25

Clustering Ensemble

 Application to “non-convex” dataset

– Data set of 400 data points – Initial clustering analysis: K-mean (K= 2,…,11), 3 initial settings per K  totally 30 partitions – Converting clustering results to binary “distance” matrices for the collective “distance matrix” – Applying the Agglomerative algorithm to the collective “distance matrix” (single-link) – Cut the dendrogram tree with the maximum K-cluster lifetime to decide K

COMP24111 Machine Learning

26

Summary

• Hierarchical algorithm is a sequential clustering algorithm

– Use distance matrix to construct a tree of clusters (dendrogram) – Hierarchical representation without the need of knowing # of clusters (can set termination condition with known # of clusters)

• Major weakness of agglomerative clustering methods

– Can never undo what was done previously – Sensitive to cluster distance measures and noise/outliers – Less efficient: O (n2 logn), where n is the number of total objects

• Clustering ensemble based on evidence accumulation

– Initial clustering with different conditions, e.g., K-means on different K, initialisations – Evidence accumulation – “collective” distance matrix – Apply agglomerative algorithm to “collective” distance matrix and max k-cluster lifetime

Online tutorial: how to use hierarchical clustering functions in Matlab:

https://www.youtube.com/watch?v= aYzjenNNOcc
