Domestic Solutions In ATFM The First Steps Graeme Fergus GAL Air Navigation Services L.L.C Proprietary Why Do We Need ATFM? Bottom line is: Demand Is Greater Than Capacity What can be done to improve capacity: CAPACITY Gate/Apron/Airfield

slide-1
SLIDE 1

GAL Air Navigation Services L.L.C Proprietary

Domestic Solutions In ATFM – The First Steps

Graeme Fergus

slide-2
SLIDE 2

GAL Air Navigation Services L.L.C Proprietary

Bottom line is: Demand Is Greater Than Capacity

Why Do We Need ATFM?

What can be done to improve capacity:

  • Gate/Apron/Airfield Design
  • Runway Efficiency (Departure and/or Arrival Rate)
  • En Route Sector Capacity

DEMAND CAPACITY

slide-3
SLIDE 3

GAL Air Navigation Services L.L.C Proprietary

Domestic Solutions

  • Airfield Design
  • Efficient Instrument Procedure Design
  • Vertical and Dynamic Sectorisation
  • Establishing Flow Management positions in ACCs
  • Airport Collaborative Decision Making (A-CDM)
slide-4
SLIDE 4

GAL Air Navigation Services L.L.C Proprietary

Airfield Design Optimisation KLGA

slide-5
SLIDE 5

GAL Air Navigation Services L.L.C Proprietary

Airfield Design Considerations

  • Apron Design
  • Taxi Route Design
  • Runway Entrance Design
slide-6
SLIDE 6

GAL Air Navigation Services L.L.C Proprietary

Avoid 1 Entrance Cul-De-Sac Apron Designs

1 Entrance = Generally 1 in 1 Out

slide-7
SLIDE 7

GAL Air Navigation Services L.L.C Proprietary

Multiple Entrance’s Gives GMC Controller Flexibility

slide-8
SLIDE 8

GAL Air Navigation Services L.L.C Proprietary

Design Optimum Taxi Routings

This design allows parallel or bi-directional taxiing aircraft on all portions of the airfield

slide-9
SLIDE 9

GAL Air Navigation Services L.L.C Proprietary

Design Multiple Runway Entrances EGKK

1 2 3

KATL

1 2 3 4

slide-10
SLIDE 10

GAL Air Navigation Services L.L.C Proprietary

Example of Good Re-Design

Before

1

slide-11
SLIDE 11

GAL Air Navigation Services L.L.C Proprietary

Example of Good Re-Design

After

1 2 3

slide-12
SLIDE 12

GAL Air Navigation Services L.L.C Proprietary

Efficient Instrument Procedure Design

  • Utilising PBN Diverging Departures
  • Reduces Departure Separation Intervals
  • Improve Runway Capacity
  • Links back to Airfield Design of Multiple

Runway Entrances

slide-13
SLIDE 13

GAL Air Navigation Services L.L.C Proprietary

Vertical and Dynamic Sectorisation

The capacity of an ATS unit is a function of the individual sector capacities and the flexibility and adaptability of the airspace configuration and sectorisation

European Air Traffic Management: Principles, Practice and Research

  • Andrew Cook
slide-14
SLIDE 14

GAL Air Navigation Services L.L.C Proprietary

Vertical Sectorisation

FL245 FL660

A

FL245 FL315 FL315 FL660

B

FL245 FL315 FL315 FL355 FL355 FL660

C

slide-15
SLIDE 15

GAL Air Navigation Services L.L.C Proprietary

Dynamic Sectorisation

  • NB. Purely for illustration purposes only, not actual sectorisation boundaries

Example Northern Flow Example Southern Flow Peak Traffic Flow

slide-16
SLIDE 16

GAL Air Navigation Services L.L.C Proprietary

Establishing Flow Management Positions in ACCs

The role of the FMP is to provide the direct link between ATC and the AOs in respect to ATFM measures and events

  • Runway landing and departure rates
  • Airport declared taxi times
  • Runway configuration
  • Sector configurations
  • Unusual events that will affect capacity

(such as adverse w/x ,blocked runways or military exercises)

slide-17
SLIDE 17

GAL Air Navigation Services L.L.C Proprietary

Pre –Tactical D-2/D-1 Planning

  • Analysing expected demand ‘v’ available capacity
  • Expected traffic flow and runway configurations

based on available FP data and w/x forecasts

  • Sector configurations ‘v’ Available Staff

ACC FMP Planning

All of this should involve direct link between the FMP, ATSUs and AOs

Tactical “On the day” Plan

  • Briefing the network stakeholders (teleconference)
  • Implementing the pre-tactical plan
  • Reacting to dynamic network changes on the day
slide-18
SLIDE 18

GAL Air Navigation Services L.L.C Proprietary

Airport Collaborative Decision Making A-CDM: The Missing Link

EN ROUTE APPROACH TAXI IN TAXI OUT DEPARTURE EN ROUTE AIRPORT AUTHORITY AIRLINES GROUND HANDLERS

slide-19
SLIDE 19

GAL Air Navigation Services L.L.C Proprietary

A-CDM Benefits

Airport

Ground Handlers Airlines

ATC By implementing A-CDM, the following benefits have already been realised at these airports:

Brussels Annual savings of 17022 tonnes of CO² 5400 tonnes of fuel saving 2.7m Euro/year in fuel saving Munich 10% average reduction in taxi time 2.65M euro/year in fuel saving Source: Eurocontrol

slide-20
SLIDE 20

GAL Air Navigation Services L.L.C Proprietary

A Local Perspective – Abu Dhabi International Airport

slide-21
SLIDE 21

GAL Air Navigation Services L.L.C Proprietary

OMAA A-CDM Project Highlights

  • Target Off Block Time (TOBT) accuracy trials ongoing
  • Departure Manager (D-MAN) system to integrate with

the A-CDM system (expected Q2 2017)

  • Target Start Up Approval Time (TSAT) trial expected by Q3 2017
  • Arrival Manager System (AMAN) to optimise runway efficiency

for independent parallel operations

slide-22
SLIDE 22

GAL Air Navigation Services L.L.C Proprietary

To Summarise:

  • 1. Employ best practice in airport design and expansion
  • 2. Utilise PBN airspace design processes to maximise

runway capacity

  • 3. Reduce complexity of en-route sectors to improve capacity
  • 4. Establish enhanced ATFM planning within ACCs with the

establishment of an FMP

  • 5. Explore the benefits of implementing A-CDM practices
slide-23
SLIDE 23

GAL Air Navigation Services L.L.C Proprietary

Thank You
