GPGPU 03 NVIDIA case study GeForce 7800 (2006) GeForce 7800 - - PowerPoint PPT Presentation

GPGPU 03

NVIDIA case study

GeForce 7800 (2006)

GeForce 7800

• Impossible to maximize throughput with such a rigid architecture: you can’t

keep vertex and fragment shading units busy all the time

• As a result, many bottlenecks in the pipeline (single triangle covering entire

screen VS extremely detailed geometry far away)

• So NVIDIA decided to unify their processor architectures

GeForce 8800 (2008 - Tesla)

GeForce 8800

processing element

GeForce 8800

shader core

GeForce 8800

• Processing element

○ A single processing unit (it can carry out an operation on a piece of data) ○ 128 of them in the full spec

• Shader core

○ Contains 16 processing elements ○ The smallest unit capable of executing code (e.g. “shade fragments with shader <X>”)

• CUDA is introduced

Fermi

NVIDIA GF100 - Fermi (2009)

• NVIDIA carried on with the unified architecture in this 2009 series too
• That is, unified steam processors switch between vertex and fragment

shading tasks, depending on workload needs

○ This requires more complex control logic than before

• Fermi is DirectX11 compatible

○ New challenge on the graphics side is the support for tessellation shaders (potentially extremely large data amplification)

• The focus with Fermi was on accelerating graphics applications

Fermi architecture

• Main elements:

○ GPC (Graphics Processing Cluster): a scalable unit of graphics processing units ○ SM (Streaming Multiprocessor): a unit of 32 streamprocessors (“GPU core” is now CUDA core) that work on the same task ○ CUDA core: the actual unit of ALU operations with a single, unified instruction set

• In particular, GF100 (=GeForce 480) houses

○ 4 GPCs ○ Each GPC contains 4 SMs (16 SMs in total in GF100) ○ 6 memory controllers

• Uses PCIe for accelerated CPU-GPU transfer speeds

CUDA code

• FP: IEEE 754-2008, FMA
• INT: bool, shift, move, ...

FMA

SM

SM

• 32 CUDA cores
• 4 special function units:

○ For evaluating transcendental functions (trig, inv trig, logs, length, rcp, etc.) ○ They also do interpolation in the graphics pipeline ○ 1 instruction per clock => finishing an entire warp takes 8 clocks

• Essentially, it is partitioned into 4 independent pipelines: 2 ALU, 1 memory, 1

SFU

• The dual warp scheduler selects two warps for execution each cycle (2x32

threads)

• The current instruction of each selected warps then goes to either

○ 16 CUDA cores, or ○ 16 L/S units, or ○ 4 SFUs

SM

• The ‘ALU’ pipelines are called execution blocks, consisting of 16-16 cores
• It takes 2 cycles to execute a single instruction of a warp’s all 32 threads for

the two execution blocks and L/S

• It takes 8 cycles to execute 32 SFU commands

SM scheduling

SM

• Each SM has 4 texture units (TU)

○ A TU can fetch 4 texture samples per cycle ○ And deliver them filtered

• Dedicated cache for the TUs
• Each SM has an L1 cache
• More precisely 64KB mem that can be set to

○

16KB L1 + 48KB shared ○ 48KB L1 + 16KB shared

• In rendering: 16KB L1 + 48KB shared

L2 cache

• 768KB, shared by all SM-s
• Read, write, coherent memory

PolyMorph Engine

• Controls the primitive processing step of the graphics pipeline
• It is itself a 5 stage pipeline
• The resulting primitives are passed to the rasterizer stage

Raster Engine

• 4 Raster Engine in parallel (1 / GPC)
• 3 stage pipeline
• Edge Setup: set up equations for the sides of the triangles
• 8 pixel/cycle/Raster Engine
• Hierarchical Z-culling (tile-based)

• The graphics API calls originate from your application

(using gl* commands in OpenGL, etc.)

• These go into a pushbuffer (called command buffer)
• And then comes the fun part:

https://fgiesen.wordpress.com/2011/07/09/a-trip-thro ugh-the-graphics-pipeline-2011-index/ ○ If you are serious about graphics, you SHOULD check this site

CPU

GPU . . .

Communication within the SM

Communication between every GPC’s every SM

Rendering details

https://developer.nvidia.com/content/life-triangle-nvidias-logical-pipeline

Kepler

Kepler (2012)

• Successor to Fermi (GeForce 680)
• Enhancing performance (especially double precision - HPC to the forefront!)
• Also focus on efficiency (new mantra is “performance per watt”)

Kepler setup

• 4 GPC
• 8 SMX (just how they called SMs in Kepler)
• 4 memory controllers

SMX

SMX

• 192 single precision CUDA core, with FMA
• 32 SFU
• Core clocks reduced to GPU clock (it was twice previously)
• SMX schedules 4 warps each clock

○ Up to 2 independent commands of the same warp

• Simplified scheduler

○ Some complex control logic moved into compilers (reshuffling math lines, etc.)

• A single thread can be as wide as 255 registers

○ And these registers could be shuffled between the threads of the warp! Essentially, that’s free communication between the warps, bypassing L1

Memory

• Configrable 64KB memory per SMX, like in Fermi
• +48KB-s read-only cache
• 1536KB L2 cache (shared by all SMX)

Maxwell

Maxwell (2014)

• Focus on efficiency
• Served GeForce 750, 8xx, and GeForce 9xx
• Setup:

○ 4 GPC ○ 4 Maxwell SM (SMM) per GPC - 16 in total ○ 4 memory controllers

• Some rationalizations:

○ Memory bus: from 192 bits to 128 ○ CUDA cores per SMM: 128 (Kepler had 192 per SMX!) ○ etc.

SMM

SMM

• 128 CUDA cores

○ In units of 32 ○ Each unit of 32 has its own dedicated scheduler and command buffer

• 1 PolyMorph Engine
• 8 texturing unit
• Simplified design to ease on control logic
• Memory layout revamp:

○ L1 cache shared with texture cache ○ 96KB dedicated shared memory ○ L2 cache 2048 KB

SMM

• 4 warp scheduler:
• Each warp scheduler

○ Schedules 2 commands per cycle ○ Works with its own dedicated 32 CUDA cores ○ 8 L/S units ○ 8 SFU units

Pascal

Pascal

• Full Pascal spec (remember: these are the 1080s)

○ 6 GPC ○ 10 Pascal SM per GPC - 60 in total ○ 30 TPC in total ○ 8 pieces of 512 bit memory controllers

• 1 GPC:

○ 10 SM

• 1 SM:

○ 64 CUDA cores ○ 4 texture units

• That totals to 3840 single precision CUDA cores and 240 (!) texture units

Pascal (2016)

• Increased computation capacity (deep learning craze)

○ 5.3 TFLOPS FP64 (~double), 10.6 TFLOPS FP32 (~float), 21.2 TFLOPS FP16 (~half)

• NVLink for high bandwidth connectivity
• Modified memory architectures

Floating point precision

Floating Point Bitdepth Largest value Smallest value1 Decimal digits of precision 32-bit Float 3.4028237 × 1038 1.175494 × 10-38 7.22 16-bit Float 6.55 × 104 6.10 × 10-5 3.31 14-bit Float 6.55 × 104 6.10 × 10-5 3.01 11-bit Float 6.50 × 104 6.10 × 10-5 2.1 10-bit Float 6.50 × 104 6.10 × 10-5 1.8

Pascal

• NVLink for high speed GPU-GPU data transfer: 160 GByte/s

High Bandwidth Memory (HBM)

• For the workstation Tesla P100-s
• HBM stacked memory layout
• In short, layered layout of memory, each with its own dedicated controller
• HBM2 can stack up to 8 layers
• Even with ECC
• AMD started HBM1 in 2008

Memory compression

• Try to compress everything you can
• Delta color compression (DCC) for textures:

○ Divide pixels into blocks ○ Assign a reference color to each block ○ Store block pixels by their deviation from reference color

• New modes in Pascal

Load balancing

• Maxwell: subdivided the cores between compute and graphics before the fact
• Pascal can do some sort of a dynamic load balancing

Simultaneous Multi-Projection Engine

Simultaneous Multi-Projection Engine

Pascal

• A single unified virtual memory space for the CPU and GPU (at least up to

512 TB)

• Compute preemption on command level (Kepler/Maxwell was

threadblock-level)

Volta

Volta (2017)

• Primarily for the HPC community (Titan V), not for consumers
• Many goodies, like cooperative groups
• And some incremental dev:

○ Modified dispatch (FP32 and INT32 can co-issue) ○ L1 cache and shared memory merged

• And there is this new processing unit...

Volta SM

Tensor core

Tensor core

X12 the speed that of Pascal

Tensor core

• 64 FP16/FP32 mixed-precision FMA operations per clock

New scheduling

Scheduling before

Scheduling on Volta

Scheduling on Volta

Phasma Phasma

Turing

Turing (2018)

• September 20, 2018: GeForce 2080 RTX
• Real time raytracing engine for consumers

○ It’s essentially the equivalent of the polymorph engine for ray tracing

• New shading additions

○ VRS, MVR ○ Mesh shading

Turing SM

Turing SM

• Divided into 4 pipelines, each housing

○ 16 FP32 ○ 16 INT32 ○ 2 Tensor core ○ 1 warp scheduler ○ 1 dispatch

• 96 KB L1/shared

○ 64 KB is “shader RAM” (per SM) when executing graphics works

• L0 instruction cache

Memory latencies

A*B + C

Raytracing

Raytracing “before”

Raytracing “now”

DXR

Raytracing in practice

• Hybrid solutions to minimize the number of rays

○ Low sample counts usually come with extreme noise - denoising to the forefront of research ■ https://www.youtube.com/watch?v=5pxnDsFLAuY ■ https://research.nvidia.com/publication/interactive-reconstruction-monte-carlo-image-seq uences-using-recurrent-denoising ■ https://www.youtube.com/watch?v=mtdRfl4fmvQ

• Acceleration Structures mean a considerable increase in GPU memory
• Decrease payload sizes as much as you can

Raytracing in practice

DXR

Mesh shader - motivation

Mesh shaders

Mesh shaders

• Task shader: threads in workgroups. Each can launch an arbitrary number

(including zero) mesh shader workgroups

• Mesh shader: each thread can create primitives.

Mesh shaders

Mesh shaders

Mesh shaders

Texture space shading

• Turing feature, only available via extensions (just like mesh shading)
• Store the shaded fragments of a triangle in a separate texture
• Independent of visibility
• Re-sample this stashed texture instead of re-evaluating the full shading
• Unless we moved around too much
• For certain applications it’s almost a given that we are at least roughly at the

same place for a frame: VR left and right eyes

Classic

Texture space

Texture space shading

• https://devblogs.nvidia.com/texture-space-shading/
• https://www.youtube.com/watch?v=Rpy0-q0TyB0

References

• Fermi whitepaper:

○ http://www.nvidia.com/content/pdf/fermi_white_papers/p.glaskowsky_nvidia's_fermi-the_first_complete_gpu_a rchitecture.pdf ○ http://www.nvidia.com/content/pdf/fermi_white_papers/nvidia_fermi_compute_architecture_whitepaper.pdf

• Kepler whitepaper: https://www.nvidia.com/content/PDF/kepler/NVIDIA-Kepler-GK110-Architecture-Whitepaper.pdf
• Maxwell whitepaper:

○ http://international.download.nvidia.com/geforce-com/international/pdfs/GeForce-GTX-750-Ti-Whitepaper.pdf ○ http://international.download.nvidia.com/geforce-com/international/pdfs/GeForce_GTX_980_Whitepaper_FIN AL.PDF

• Pascal whitepaper:

○ http://international.download.nvidia.com/geforce-com/international/pdfs/GeForce_GTX_1080_Whitepaper_FIN AL.pdf ○ https://images.nvidia.com/content/pdf/tesla/whitepaper/pascal-architecture-whitepaper.pdf

• Volta whitepaper:

○ http://images.nvidia.com/content/volta-architecture/pdf/volta-architecture-whitepaper.pdf

• Turing whitepaper:

○ https://www.nvidia.com/content/dam/en-zz/Solutions/design-visualization/technologies/turing-architecture/NVI DIA-Turing-Architecture-Whitepaper.pdf

References

The lowest level details are unfortunately only available via reverse-engineering:

• Volta: https://arxiv.org/abs/1804.06826
• Turing: https://arxiv.org/pdf/1903.07486.pdf

Ampere

In numbers

• 7 GPCs
• Each GPC contains

○ 6 TPCs ○ 1 raster engine ○ (NEW) 2 ROP partitions ○ (NEW) 8 ROP units per ROP partition

• Each TPC contains

○ 2 SMs ○ 1 polymorph engine

• Each SM contains

○ 128 CUDA cores ○ 4 Texture units ○ 4 Tensor Cores (3rd gen) ○ 1 RT Core (2nd gen) ○ 256 KB register file partitioned into 4 64 KB parts ○ 128 KB of configurable L1/Shared memory

In numbers

• 12 x 32 bit memory controllers (384 bit)
• 512 KB L2 cache per controller (6144 KB in total)
• An SM partition can now service 2 FP32 operations (in Turing: it could only

double issue a float-int operation pair)

SM

SM

• Re-arranged the two main datapaths:

○ 1 with 16 FP32 CUDA Cores ○ 1 with 16 FP32 CUDA Cores and 16 INT32

• Tricky: each clock, an SM partition can

○ either execute 32 FP32 operations ○

• r execute 16 FP32 and 16 INT32 operations
• They kept the Turing double-speed FP16 operations (HFMA)

Unified shared memory

• Graphics mode: 64 KB L1 data/texture cache + 48 KB shared + 16 KB

reserved for the graphics pipeline operations

• In compute mode:

L1 Shared 128 KB 0 KB 120 KB 8 KB 112 KB 16 KB 96 KB 32 KB 64 KB 64 KB 28 KB 100 KB

Tensor cores

• 4 per SM
• 256 FP16/32 FMA per clock
• 3rd gen now supports FP16, BF16 (alternative to IEEE FP16), TF32 (‘tensor

float’), FP64, INT8, INT4, binary (INT1)

○ FP16/BF16 has 16x larger throughput in tensor cores than FP32

• TF32 basically retains the exponent range of FP32 but discards mantissa bits

beyond what is representable with FP16

• Faster execution if your input matrices are (lower bound) matches of

particular sparsity patterns

Tensor cores

NVIDIA types

RT cores

• Some caching and throughput optimizations
• And some other nice goodies

Ampere whitepapers

• https://www.nvidia.com/content/dam/en-zz/Solutions/geforce/ampere/pdf/NVI

DIA-ampere-GA102-GPU-Architecture-Whitepaper-V1.pdf

• https://www.nvidia.com/content/dam/en-zz/Solutions/Data-Center/nvidia-amp

ere-architecture-whitepaper.pdf
