Generalized Type-Based Disambiguation of Meta Programs with Concrete - - PowerPoint PPT Presentation

Mar 06, 2024 469 likes •1.05k views

Generalized Type-Based Disambiguation of Meta Programs with Concrete Object Syntax GPCE 2005 Martin Bravenboer, Rob Vermaas, Jurgen Vinju and Eelco Visser Department of Information & Computing Sciences Universiteit Utrecht, The Netherlands

slide-1
SLIDE 1

Generalized Type-Based Disambiguation of Meta Programs with Concrete Object Syntax

GPCE 2005 Martin Bravenboer, Rob Vermaas, Jurgen Vinju and Eelco Visser

Department of Information & Computing Sciences Universiteit Utrecht, The Netherlands

September 30, 2005

slide-2
SLIDE 2

Meta Programming: Implementing Code Generators generator input

  • utput
  • utput
  • utput
  • utput
  • utput
if(propertyChangeListeners == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < propertyChangeListeners.size(); c++) { ((PropertyChangeListener) propertyChangeListeners.elementAt(c)).propertyChange(event); }

input

slide-3
SLIDE 3

Meta Programming: Implementing Code Generators generator input input

if(propertyChangeListeners == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < propertyChangeListeners.size(); c++) { ((PropertyChangeListener) propertyChangeListeners.elementAt(c)).propertyChange(event); }

slide-4
SLIDE 4

Meta Programming: Implementing Code Generators generator input input

if(propertyChangeListeners == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < propertyChangeListeners.size(); c++) { ((PropertyChangeListener) propertyChangeListeners.elementAt(c)).propertyChange(event); }

slide-5
SLIDE 5

Meta Programming with String Literals

String vName = "propertyChangeListeners"; jsc.add("if ("); jsc.append(vName); jsc.append(" == null) return;"); jsc.add("PropertyChangeEvent event = new "); jsc.append("PropertyChangeEvent"); jsc.append("(this, fieldName, oldValue, newValue);"); jsc.add("for (int i = 0; i < "); jsc.append(vName); jsc.append(".size(); i++) {"); jsc.indent(); jsc.add("((PropertyChangeListener) "); jsc.append(vName); jsc.append(".elementAt(i))."); jsc.append("propertyChange(event);"); jsc.unindent(); jsc.add("}");

slide-6
SLIDE 6

Meta Programming with String Literals

String vName = "propertyChangeListeners"; jsc.add("if ("); jsc.append(vName); jsc.append(" == null) return;"); jsc.add("PropertyChangeEvent event = new "); jsc.append("PropertyChangeEvent"); jsc.append("(this, fieldName, oldValue, newValue);"); jsc.add("for (int i = 0; i < "); jsc.append(vName); jsc.append(".size(); i++) {"); jsc.indent(); jsc.add("((PropertyChangeListener) "); jsc.append(vName); jsc.append(".elementAt(i))."); jsc.append("propertyChange(event);"); jsc.unindent(); jsc.add("}");

Uses the Java syntax: the syntax of the domain. No syntactic checks of the generated code. Escaping to the meta lan- guage is difficult. Code generator tries to do some pretty printing. Further processing of the code is impossible.

slide-7
SLIDE 7

Meta Programming with Abstract Object Syntax

VariableDeclarationFragment fragment = _ast.newVariableDeclarationFragment(); fragment.setName(_ast.newSimpleName("event")); ClassInstanceCreation newi = _ast.newClassInstanceCreation(); newi.setType(_ast.newSimpleType( _ast.newSimpleName("PropertyChangeEvent"))); List<Expression> args = newi.arguments(); args.add(_ast.newThisExpression()); args.add(_ast.newSimpleName("fieldName")); args.add(_ast.newSimpleName("oldValue")); args.add(_ast.newSimpleName("newValue")); fragment.setInitializer(newi); VariableDeclarationStatement vardec = _ast.newVariableDeclarationStatement(fragment); vardec.setType(_ast.newSimpleType( _ast.newSimpleName("PropertyChangeEvent")));

slide-8
SLIDE 8

Meta Programming with Abstract Object Syntax

VariableDeclarationFragment fragment = _ast.newVariableDeclarationFragment(); fragment.setName(_ast.newSimpleName("event")); ClassInstanceCreation newi = _ast.newClassInstanceCreation(); newi.setType(_ast.newSimpleType( _ast.newSimpleName("PropertyChangeEvent"))); List<Expression> args = newi.arguments(); args.add(_ast.newThisExpression()); args.add(_ast.newSimpleName("fieldName")); args.add(_ast.newSimpleName("oldValue")); args.add(_ast.newSimpleName("newValue")); fragment.setInitializer(newi); VariableDeclarationStatement vardec = _ast.newVariableDeclarationStatement(fragment); vardec.setType(_ast.newSimpleType( _ast.newSimpleName("PropertyChangeEvent")));

Extremely verbose and un- clear: 90 lines of code! Does not correspond to the structure of the code to be generated. Syntactically checked by meta compiler and further process- ing is possible. Don’t worry about the layout.

slide-9
SLIDE 9

Meta Programming with Concrete Object Syntax

String x = "propertyChangeListeners"; List<Statement> stms = stmt* | [ if(#(id)[x] == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < #(id)[x].size(); c++) { ((PropertyChangeListener) #(id)[x].elementAt(c)).propertyChange(event); } ] |;

slide-10
SLIDE 10

Meta Programming with Concrete Object Syntax

String x = "propertyChangeListeners"; List<Statement> stms = stmt* | [ if(#(id)[x] == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < #(id)[x].size(); c++) { ((PropertyChangeListener) #(id)[x].elementAt(c)).propertyChange(event); } ] |;

Quotation: | [ Java (Object) ] |

slide-11
SLIDE 11

Meta Programming with Concrete Object Syntax

String x = "propertyChangeListeners"; List<Statement> stms = stmt* | [ if(#(id)[x] == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < #(id)[x].size(); c++) { ((PropertyChangeListener) #(id)[x].elementAt(c)).propertyChange(event); } ] |;

Anti-Quotation: #[ Java (Meta) ]

slide-12
SLIDE 12

Meta Programming with Concrete Object Syntax

String x = "propertyChangeListeners"; List<Statement> stms = stmt* | [ if(#(id)[x] == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < #(id)[x].size(); c++) { ((PropertyChangeListener) #(id)[x].elementAt(c)).propertyChange(event); } ] |;

Uses the syntax of the domain: Java. Syntax of the generated code is checked and further processing is possible. Support for interaction be- tween the generated code and the meta language. Separate pretty-printer: don’t worry about the layout.

slide-13
SLIDE 13

Architecture for Realizing Concrete Object Syntax

Parsing Assimilation

Meta program with concrete object syntax Abstract syntax tree meta+object language Meta program Object syntax Meta syntax Combined syntax Assimilation Rules Assimilator Parser

slide-14
SLIDE 14

Ambiguities in Concrete Object Syntax

String x = "propertyChangeListeners"; List<Statement> stms = stmt* | [ if(#(id)[x] == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < #(id)[x].size(); c++) { ((PropertyChangeListener) #(id)[x].elementAt(c)).propertyChange(event); } ] |;

Syntactic clutter of explicit typing. Intimate knowledge of syntactic structure re- quired. Limited number of quota- tions and anti-quotations are supported.

slide-15
SLIDE 15

Ambiguities in Concrete Object Syntax

String x = "propertyChangeListeners"; List<Statement> stms = | [ if(#[x] == null) return; PropertyChangeEvent event = new PropertyChangeEvent(this, fieldName, oldValue, newValue); for(int c=0; c < #[x].size(); c++) { ((PropertyChangeListener) #[x].elementAt(c)).propertyChange(event); } ] |;

slide-16
SLIDE 16

Ambiguities: Quotations

  • Single quotation symbol
  • Multiple object non-terminals

Example:

  • |

[ class Foo {} ] |

TypeDeclaration

package bar; class Foo {}

CompilationUnit

class Foo {}

Statement

class Bar { void fred() { class Foo {} } }

slide-17
SLIDE 17

Ambiguities: Anti-Quotations

  • Single anti-quotation symbol
  • Multiple object non-terminals
  • Syntactical category of meta code unknown

Examples:

  • |

[ return #[x ]; ] |

  • x can be Expression
  • x can be SimpleName
  • x can be String (identifier)
  • |

[ foo(#[xs ]) ] |

  • xs can be Expression
  • xs can be List<Expression>
  • . . .
slide-18
SLIDE 18

Ambiguities: Current Solutions

Use Different (Anti-)Quotation Symbols

  • JTS, DMS, Stratego, Template Haskell, Jumbo
  • Redundant
  • Support for (anti-)quotations irregular

Type-based Disambiguation by Context-Sensitive Parsing

  • Meta-AspectJ, Aasa (ML)
  • Excellent usability
  • Parsing and type-checking tangled
  • Object language specific, no multiple object languages
slide-19
SLIDE 19

Generalized Type-based Disambiguation

We need a general architecture for type-based disambiguation.

  • Introduce type-based disambiguation
  • Single quotation and anti-quotation symbol
  • Preserve modular syntax definition
  • Fully automatic parser generation
  • Preserve modular assimilation
  • Embedding multiple object languages

Define only syntactical embedding and assimilation rules

slide-20
SLIDE 20

Generalized Type-based Disambiguation

Parsing Assimilation

Meta program with concrete object syntax Abstract syntax tree meta+object language Meta program Object syntax Meta syntax Combined syntax Assimilation Rules Assimilator Parser

slide-21
SLIDE 21

Generalized Type-based Disambiguation

Parsing Assimilation Type checking

Meta program with concrete object syntax Abstract syntax forest meta+object language Abstract syntax forest meta language Meta program Object syntax Meta syntax Combined syntax Assimilation Rules Assimilator Parser Meta type checker Type checker

slide-22
SLIDE 22

Example: Syntax Definition and Parsing

context-free syntax "| [" CompilationUnit "] |" -> MetaExpr {cons("ToMetaExpr")} "| [" TypeDec "] |" -> MetaExpr {cons("ToMetaExpr")} "| [" ClassBodyDec* "] |" -> MetaExpr {cons("ToMetaExpr")} context-free syntax "#[" MetaExpr "]"-> ID {cons("FromMetaExpr")} "#[" MetaExpr "]"-> Expr {cons("FromMetaExpr")} | [ package bar; class Foo {} ] | ToMetaExpr( CompilationUnit( Some(PackageDec([], PackageName([Id("bar")]))), [] , [ ClassDec( ClassDecHead([], Id("Foo"), None, None, None) , ClassBody([]) ) ]))

slide-23
SLIDE 23

Example: Syntax Definition and Parsing

dec = | [ class Foo {} ] | Assign(ExprName(Id("dec")), amb([ ToMetaExpr( CompilationUnit(... ClassDec(... Id("Foo")...) ...) ) , ToMetaExpr( ClassDec(... Id("Foo") ...) ) , ToMetaExpr([ ClassDec(... Id("Foo") ...) ] ) , ToMetaExpr( ClassDecStm(ClassDec(... Id("Foo") ...) )) , ToMetaExpr([ ClassDecStm(ClassDec(... Id("Foo") ...) )]) ]))

slide-24
SLIDE 24

Example: Assimilation

dec = | [ class Foo {} ] | Assign(ExprName(Id("dec")), amb([ {| CompilationUnit cu_0 = _ast.newCompilationUnit(); ... TypeDeclaration class_0 = _ast.newTypeDeclaration(); class_0.setName(_ast.newSimpleName("Foo")); ... | cu_0 |} , ToMetaExpr( ClassDec(... Id("Foo") ...) ) , ToMetaExpr([ ClassDec(... Id("Foo") ...) ] ) , ToMetaExpr( ClassDecStm(ClassDec(... Id("Foo") ...) )) , ToMetaExpr([ ClassDecStm(ClassDec(... Id("Foo") ...) )]) ]))

slide-25
SLIDE 25

Example: Assimilation

dec = | [ class Foo {} ] | Assign(ExprName(Id("dec")), amb([ {| CompilationUnit cu_0 = _ast.newCompilationUnit(); ... TypeDeclaration class_0 = _ast.newTypeDeclaration(); class_0.setName(_ast.newSimpleName("Foo")); ... | cu_0 |} , {| TypeDeclaration class_1 = _ast.newTypeDeclaration(); class_1.setName(_ast.newSimpleName("Foo")); ... | class_1 |} , ToMetaExpr([ ClassDec(... Id("Foo") ...) ] ) , ToMetaExpr( ClassDecStm(ClassDec(... Id("Foo") ...) )) , ToMetaExpr([ ClassDecStm(ClassDec(... Id("Foo") ...) )]) ]))

slide-26
SLIDE 26

Example: Assimilation

dec = | [ class Foo {} ] | Assign(ExprName(Id("dec")), amb([ {| CompilationUnit cu_0 = _ast.newCompilationUnit(); ... TypeDeclaration class_0 = _ast.newTypeDeclaration(); class_0.setName(_ast.newSimpleName("Foo")); ... | cu_0 |} , {| TypeDeclaration class_1 = _ast.newTypeDeclaration(); class_1.setName(_ast.newSimpleName("Foo")); ... | class_1 |} , {| List<BodyDeclaration> decs_0 = new ArrayList<BodyDeclaration>(); decs_0.add( ... ); ... | decs_0 |} , ToMetaExpr( ClassDecStm(ClassDec(... Id("Foo") ...) )) , ToMetaExpr([ ClassDecStm(ClassDec(... Id("Foo") ...) )]) ]))

slide-27
SLIDE 27

Example: Assimilation

dec = | [ class Foo {} ] | Assign(ExprName(Id("dec")), amb([ {| CompilationUnit cu_0 = _ast.newCompilationUnit(); ... TypeDeclaration class_0 = _ast.newTypeDeclaration(); class_0.setName(_ast.newSimpleName("Foo")); ... | cu_0 |} , {| TypeDeclaration class_1 = _ast.newTypeDeclaration(); class_1.setName(_ast.newSimpleName("Foo")); ... | class_1 |} , {| List<BodyDeclaration> decs_0 = new ArrayList<BodyDeclaration>(); decs_0.add( ... ); ... | decs_0 |} , _ast.newTypeDeclaratonStatement(...); , ToMetaExpr([ ClassDecStm(ClassDec(... Id("Foo") ...) )]) ]))

slide-28
SLIDE 28

Example: Assimilation

dec = | [ class Foo {} ] | Assign(ExprName(Id("dec")), amb([ {| CompilationUnit cu_0 = _ast.newCompilationUnit(); ... TypeDeclaration class_0 = _ast.newTypeDeclaration(); class_0.setName(_ast.newSimpleName("Foo")); ... | cu_0 |} , {| TypeDeclaration class_1 = _ast.newTypeDeclaration(); class_1.setName(_ast.newSimpleName("Foo")); ... | class_1 |} , {| List<BodyDeclaration> decs_0 = new ArrayList<BodyDeclaration>(); decs_0.add( ... ); ... | decs_0 |} , _ast.newTypeDeclaratonStatement(...); , {| List<Statement> stms_0 = new ArrayList<Statement>(); stms_0.add(_ast.newTypeDeclaratonStatement(...)); ... | stms_0 |} ]))

slide-29
SLIDE 29

Type-based Disambiguation

ambiguity

1 2 3 4

node

slide-30
SLIDE 30

Type-based Disambiguation

ambiguity

1 2 3 4

node

2 4

node

slide-31
SLIDE 31

Type-based Disambiguation

ambiguity

1 2 3 4

node

4

node type error

slide-32
SLIDE 32

Type-based Disambiguation

4 4 4

ambiguity

1 2 3 4

node ambiguity

1 2 3

node node node

slide-33
SLIDE 33

Type-based Disambiguation

4 4 4

ambiguity

1 2 3 4

node ambiguity

1 2 3

node node node

slide-34
SLIDE 34

Example: Type-based Disambiguation

dec = | [ class Foo {} ] |

Assign(ExprName(Id("dec")), amb([ CompilationUnit , TypeDeclaration , List<BodyDeclaration> , TypeDeclaratonStatement , List<Statement> ])) amb([ Assign(ExprName(Id("dec")), CompilationUnit) , Assign(ExprName(Id("dec")), TypeDeclaration) , Assign(ExprName(Id("dec")), List<BodyDeclaration>) , Assign(ExprName(Id("dec")), TypeDeclaratonStatement) , Assign(ExprName(Id("dec")), List<Statement>) ])

slide-35
SLIDE 35

Example: Type-based Disambiguation

dec = | [ class Foo {} ] |

Assign(ExprName(Id("dec")), amb([ CompilationUnit , TypeDeclaration , List<BodyDeclaration> , TypeDeclaratonStatement , List<Statement> ])) amb([ Assign(ExprName(Id("dec")), CompilationUnit) , Assign(ExprName(Id("dec")), TypeDeclaration) , Assign(ExprName(Id("dec")), List<BodyDeclaration>) , Assign(ExprName(Id("dec")), TypeDeclaratonStatement) , Assign(ExprName(Id("dec")), List<Statement>) ])

slide-36
SLIDE 36

Example: Anti-Quotation

Expression expr = ... Statement stmt = | [ return #[expr]; ] | Return( Some( amb([ FromMetaExpr(ExprName(Id("expr"))) , ExprName([ FromMetaExpr(ExprName(Id("expr"))) ]) , ExprName([ Id(FromMetaExpr(ExprName(Id("expr")))) ]) ]))) Expression expr = ... Statement stmt = {| ReturnStatement return_1 = _ast.newReturnStatement(); return_1.setExpression(amb([expr, _ast.newSimpleName(expr)])); | return_1 |};

slide-37
SLIDE 37

Example: Anti-Quotation

Expression expr = ... Statement stmt = | [ return #[expr]; ] | Return( Some( amb([ FromMetaExpr(ExprName(Id("expr"))) , ExprName([ FromMetaExpr(ExprName(Id("expr"))) ]) , ExprName([ Id(FromMetaExpr(ExprName(Id("expr")))) ]) ]))) Expression expr = ... Statement stmt = {| ReturnStatement return_1 = _ast.newReturnStatement(); return_1.setExpression(amb([expr, _ast.newSimpleName(expr)])); | return_1 |};

slide-38
SLIDE 38

Example: Anti-Quotation

Expression expr = ... Statement stmt = | [ return #[expr]; ] | Return( Some( amb([ FromMetaExpr(ExprName(Id("expr"))) , ExprName([ FromMetaExpr(ExprName(Id("expr"))) ]) , ExprName([ Id(FromMetaExpr(ExprName(Id("expr")))) ]) ]))) Expression expr = ... Statement stmt = {| ReturnStatement return_1 = _ast.newReturnStatement(); return_1.setExpression(expr); | return_1 |};

slide-39
SLIDE 39

Explicit Disambiguation

Suppose you still want to indicate the type of a quotation.

  • Some expressions can stay ambiguous
  • Some systems support disambiguation syntax (e.g.

Meta-AspectJ, Stratego)

‘(CompUnit)[ class Foo {} ] ‘(ClassDec)[ class Foo {} ]

Type-based disambiguation supports casting for disambiguation.

(CompilationUnit) | [ class Foo {} ] | (TypeDeclaration) | [ class Foo {} ] | (List<Statement>) | [ class Foo {} ] |

Any object language construct can be disambiguated.

slide-40
SLIDE 40

Experience

JavaJava

  • Embedding of Java in Java
  • Assimilation to Eclipse Java AST (JDT Core DOM)
  • Eclipse Java AST is not yet parameterized

Meta-AspectJ

  • Partial implementation of Meta-AspectJ
  • Assimilation to Meta-AspectJ AST.
  • Support for more complex typing situations
  • No object language specific conversions (reification)
  • Distinct syntactical categories implement common interfaces.
  • No implementation of kwinfer
slide-41
SLIDE 41

Assumptions and Possible Extensions

  • Manifest typing (types explicitly given in declarations)
  • Other statically typed languages?
  • Disambiguation and type inferencing?
  • Sufficiently typed representation is very important
  • Distinct syntactical categories → different type
  • Parameterized collections
  • Object language specific type checking
  • Object language specific conversions (reification)
  • Explicit ambiguities in (formal) type systems
slide-42
SLIDE 42

Conclusion

Parse first, solve ambiguities later. Enablers

  • Generalized-LR parsing produces all alternatives
  • Separate type checking on ambiguous program

Results

  • Modular syntactical embedding and assimilation
  • Object language independent disambiguation
  • Extensible type checker
  • General architecture extended with type-based disambiguation

We would like to work with you to embed

  • bject languages for your applications!
slide-43
SLIDE 43

Appendices

slide-44
SLIDE 44

Type Checking First?

Parsing Assimilation Type checking

Meta program with concrete object syntax Abstract syntax forest meta+object language Abstract syntax forest meta language Meta program Object syntax Meta syntax Combined syntax Assimilation Rules Assimilator Parser Meta type checker Type checker

slide-45
SLIDE 45

Type Checking First?

Parsing Type checking

Meta program with concrete object syntax Abstract syntax forest meta+object language Abstract syntax tree meta+object language Meta program Object syntax Meta syntax Combined syntax Assimilation Rules Assimilator Parser Meta type checker Type checker

Assimilation

Obect type rules

slide-46
SLIDE 46

Type Checking First?

Parsing Type checking

Meta program with concrete object syntax Abstract syntax forest meta+object language Abstract syntax tree meta+object language Meta program Object syntax Meta syntax Combined syntax Assimilation Rules Assimilator Parser Meta type checker Type checker

Assimilation

Obect type rules

slide-47
SLIDE 47

Algorithm

disambiguate(node ) = if node is ambiguous then return resolve(node ) else if node has ambiguous child then return resolve(lift-ambiguity(node )) else return node resolve(node ) = node’ := remove from node all alternatives which are not type correct if #node’ == 0 then report type error else if #node’ == 1 then return node’ else if #node’ > 1 then if node’ contains a meta statement or declaration then report ambiguity error else return node’ lift-ambiguity(node ) = if node == c [1> node1 2> node2 ... j> nodej ] then return 1> c [node1 ] 2> c [node2 ] ... j> c [nodej ]

slide-48
SLIDE 48

Interesting Situations

void generate() { TypeDeclaration dec = foo(| [ return; ] |); } TypeDeclaration foo(List<Statement> list) { ... } TypeDeclaration foo(Statement list) { ... } void generate() { TypeDeclaration dec = foo(| [ return; ] |); } List<TypeDeclaration> foo(List<Statement> list) TypeDeclaration foo(Statement list) void generate() { foo(| [ return; ] |); } <T> void foo(List<T> list)

slide-49
SLIDE 49

More Interesting Situations

| [ class Foo() { #[type] getBar() ... } ] |

  • type can be Type, Id
  • type can be BodyDeclaration
  • type can be List<BodyDeclaration>
  • type can be Modifier
  • type can be List<Modifier>
slide-50
SLIDE 50

More and More Interesting Situations

#[ | [ ] | ]

Is not identity.

#[ foo( | [ ] | ) ]

slide-51
SLIDE 51

Object Language Specific Conversions

  • This is allowed:

String x; e = | [ #[x] ] |;

  • This is not:

e = x

  • list of identifiers to list of expressions
  • reification (e.g. meta-level array to object-level array constant)
slide-52
SLIDE 52

Explosion of ambiguities?

  • No lifting beyond the statement level
  • Statement is unit of disambiguation
  • Cannot be more context information
  • Number of ambiguities
  • Depends on number of quotations and anti-quotations
  • Not on size of quoted object code fragments
  • Ambiguities in anti-quotations are immediately resolved if

there is no quotation in the meta code.

  • n-unary ’object’ operators: amb0 ∗ amb1 ∗ . . . ∗ ambn
slide-53
SLIDE 53

Compositional Assimilation Rules

Assimilate(r) : InterfaceDec(InterfaceDecHead(mod* , Id(y ), typeparams , extends ), decs )

  • > e |

[ {| TypeDeclaration x = _ast.newTypeDeclaration(); x.setInterface(true); x.setName(e1 ); bstm* | x |} ] | where ... Assimilate(r) : InterfaceDec(InterfaceDecHead(mod* , y , typeparams , extends ), decs )

  • > e |

[ {| TypeDeclaration x = _ast.newTypeDeclaration(); x.setInterface(true); x.setName(e1 ); bstm* | x |} ] | where ...

slide-54
SLIDE 54

Example: Assimilation

  • Embedded object fragments to meta language
  • Results in an ambiguous meta program

Example Assimilation Rules

Assimilate(rec) : | [ return; ] | -> | [ _ast.newReturnStatement() ] | Assimilate(rec) : | [ e.y (e* ) ] | -> | [ {| MethodInvocation x = _ast.newMethodInvocation(); x.setName(~e:<AssimilateId(rec)> y ); x.setExpression(~e:<rec> e ); bstm* | x |} ] | where <newname> "inv" => x ; <AssimilateArgs(rec | x )> e* => bstm*

slide-55
SLIDE 55

More Ambiguities in Concrete Object Syntax

Lexical state: tokens depend on context

  • Current solutions:
  • Union of lexical syntax (introduces new keywords)
  • Maintain lexical state, fixed quotation symbols.
  • Interaction between lexer and parser
  • Not an issue in scannerless parsing.
slide-56
SLIDE 56

Experience: Meta-AspectJ

  • Partial implementation of Meta-AspectJ
  • Assimilation to Meta-AspectJ AST.

Interesting issues

  • Syntactical embedding of AspectJ in Java is trivial
  • AspectJ has a non-trivial lexical syntax.
  • No reserved keywords
  • Assimilation takes most LOC
  • Support for more complex typing situations
  • No object language specific conversions (reification)
  • Distinct syntactical categories implement common interfaces.
  • No implementation of infer
