FAST CHARGING FOR ELECTRIC VEHICLES and COFFEE

Fuji Electric Corp. of America

Larry Butkovich – lbutkovich@fecoa.fujielectric.com

1

About Fuji Electric

Fuji Electric Corporation, Ltd. (based in Tokyo, Japan)

• Established in 1923
• leader in industrial manufacturing
• $8 billion in annual revenue
• 25,000 employees worldwide
• EV business began in 2007—To date, over 300 DC Quick

Chargers have been deployed

• Global businesses in Asia, China, Europe, and Americas
• All products manufactured for commercial or industrial use;

Durability and reliability are common themes across all Fuji Electric products Fuji Electric Corporation of America (based in Edison, NJ)

• Wholly owned subsidiary of Fuji Electric Co, Ltd.
• Established in 1970
• Responsible for the sales, marketing and distribution

throughout the Americas

• 16 business units with products ranging from

Semiconductors and Drives to Radiation Detection Equipment and Power Supply products. Fuji Electric Corporation, Ltd. (based in Tokyo, Japan)

• Established in 1923
• leader in industrial manufacturing
• $8 billion in annual revenue
• 25,000 employees worldwide
• EV business began in 2007—To date, over 300 DC Quick

Chargers have been deployed

• Global businesses in Asia, China, Europe, and Americas
• All products manufactured for commercial or industrial use;

Durability and reliability are common themes across all Fuji Electric products Fuji Electric Corporation of America (based in Edison, NJ)

• Wholly owned subsidiary of Fuji Electric Co, Ltd.
• Established in 1970
• Responsible for the sales, marketing and distribution

throughout the Americas

• 16 business units with products ranging from

Semiconductors and Drives to Radiation Detection Equipment and Power Supply products.

2

Confidential and Proprietary Information to Fuji Electric Corporation of America

What is Quick charging?

3

DC Quick Charging Level 2 AC Charging 3Φ 208V 1Φ 240V 1Φ 240V

300-500V DC +CAN 25-50 kW 3-6 kW 16-24 kWh 16-24 kWh 3-6 kW

• 3 phase 208V AC is

Converted to DC.

• DC is sent directly

to the EV Battery.

• BMS commands

charging current via CAN

• 208V AC is sent

through the charger to the Vehicle

• The On-Board

Charger converts the AC to DC

• DC Charging is

limited to the Power of the On- Board Charger

Confidential and Proprietary Information to Fuji Electric Corporation of America

Charging Power Over Time

Less than 7 minutes Additional charge time Both Chargers at or below 25kW

Battery Electric Vehicle

Where is Quick Charging Installed?

5 Level 1 and Level 2 Charging

DC Quick Charging

• Three Phase Power Supply
• PFC on Charger. Balanced loading
• Able to plan infrastructure upgrades with planned

installations in high traffic areas

• Network statistics can track usage trends and allow for

demand response and tiered billing to create incentive to increase usage during off peak hours

• Drivers are more likely to be “topping off” and will be

more flexible around charging times

• Power for 25kW Charger is easer to accommodate

with out infrastructure upgrades than 50kW Charger DC Quick Charging

Level 1 and Level 2 Charging

• Single Phase Power Supply
• Limited Ability to Control Usage
• Potential for Smart Grid / Demand Response to manage

charge times in evening

• Distributed infrastructure. Many potential points to

upgrade

• Difficult to plan infrastructure upgrades to meet

increased demand (rely on permitting house surveys to find high EV adoption locations)

Confidential and Proprietary Information to Fuji Electric Corporation of America

Electric Vehicle Charging – Real World Applications

Level 1 - AC Charging 8 Hours for Full Charge

Home (Garage) Train Station Airport

Level 2 - AC Charging 4 Hours for Full Charge

Movie Theater Workplace

Level 3 – DC Quick Charging <60 Minutes for Full Charge

Retail Store Pharmacy Hotel Highways / Interstates

ChargePoint Network

• First DC Quick Charger on

ChargePoint Network

• Full features of ChargePoint Network

integrated into the operation of the charger

• Utilizing existing Vending Machine

network gateway interface to integrate ChargePoint Network.

• Gateway is network agnostic and

capable of future improvements and network integration through simple programming.

San Juan Capistrano Usage

Free $10 to $15 per hr

Fuji Electric 25kW DC Quick Charger for EVs (208V 3Phase Input) First DC Quick Charger on ChargePoint Network Location: San Juan Capistrano, CA Energy Dispensed: Over 4MWh since 11/2012 Average Charge Time: 30 min Average Output: 16kW

NOTES:

• One single DC Quick Charger charger supports

many charge events in one day

• Short charge duration ensures minimal usage

conflicts

DC Quick Charging Use Trends

DC Quick Charger Level II AC Charge Duration 0.5 to 1 hour 4 to 8 hours Charge Time Waking Hours Morning & Evening Location Pathway Retail Hospitality Home Work

Virginia – Ahead of the Curve in the EV Industry

• Virginia has been listed as one of the Top 10 States for Hybrid Adoption and Incentive

Programs

• Fuji Electric Press Release statistics show that Virginia is among the Top 3 states for

readership on all EV-related announcements

• Small business owners must use this information to their advantage, and prepare for the

continued growth of the EV industry by installing infrastructure to support the statewide adoption of EV’s

Fuji Electric Press Release Views by State Top 3 States

Thank You Charger Demonstration

Fuji Electric Corp. of America

Larry Butkovich – lbutkovich@fecoa.fujielectric.com

11
