FT-UNSHADES2.

H.G. Miranda, M.A. Aguirre, J. Barrientos, L. Sanz

Electronic Engineering Dpt. School of Engineering. University of Sevilla (SPAIN)

Sevilla, March 2014

FT

• UNSHADES goals

 FT

• UNSHADES is a tool for SEE EMULATION, at netlist level.

 Emulation is the use of programmable hardware structures to

perturb the design under test.

 It is a highly flexible and simple solution from the designer point of

view.

 The goal is to perform the injections in a deterministic manner.  Combines Massive Injections with cycle accurate analysis, in the

same tool

 Exploits the mechanisms of Xilinx FPGA, named Partial

Reconfiguration, Snapshot and Readback Other features:

 Remote access  Internal analysis  Test in the beam  Targeting FPGAs for analysis

What for, FTU2?

• 1. Check the protection level
• 2. Hierarchical assessment of the submodules
• 3. Check protections
• 4. Selective redundancies
• 5. Reset and initialization policy
• 6. Digital SETs
• 7. MBU studies
• 8. SEE detailed analysis

FT-UNSHADES2 in a ASIC mode

 FTU2 is a contract with ESA: “High Capacity, High Speed IC Test System for

Automatic Fault Injection and Analysis (FT-UNSHADES 2)”

 FTU2 is a platform designed to assess the reliability of a netlist at design

level.

 The processing is determined knowing a priori where, when and how to

inject the faults over USER REGISTERS.

 In FTU2 both sights are implemented: fault campaigns and single fault

detailed analysis

 Several SEEs models are implemented: SEU and MBU, and under certain

conditions, SETs.

 The design flow has been is reduced to a FPGA standard implementation and

a simulation.

 The PARTIAL RECONFIGURATION feature of Xilinx FPGAs is exploited to

generate bit-flips into the USER REGISTERS, LUTs, BRAMs…

Originally FTU was thought trough the assessment of ASIC netlist. FTU2 has been extended to inject on SRAM-FPGAs configuration.

FTU2 in FPGA mode

• The basic mechanism to inject over the FPGA

CONFIGURATION is the same than USER REGISTERS.

• It is not constrained to a specific FPGA
• Analyzes in detail the propagation of a fault in the

configuration, and the possible corruption of the user logic.

• The study of techniques for scrubbing policy

FT

• UNSHADES2 in a nutshell: the structure
• f the hardware

Two twin FPGAs hosts two copies of the netlist. The design runs along in parallel

• Bitstream
• Injection Batch
• Workload

Control FPGA Target FPGA Target FPGA SELECTMAP I / Os I / Os

D R A M

FT

• UNSHADES2 in a nutshell: the structure
• f the hardware

Service FPGA Target FPGA Control FPGA DRAM Memory

FT

• UNSHADES2 in a nutshell: the design preparation flow

High Level Description Synthesis High Level Simulation Workload Technology Level Simulation Workload Place & Route Technology

Constraints Realiability Assessment

ASIC prototype High Level Description Synthesis High Level Simulation Workload Technology Level Simulation Workload Place & Route FPGA Technology

Constraints Realiability Assessment

FPGA description

• 1. Fit your design in the target FPGA
• 2. Allocate I/Os
• 3. Simulate and extract inputs
• 4. Finish the standard flow
• Bitstream (.bit)
• Bit allocation file (.ll)
• Port location (.pin)
• VCD stimuli (*.vcd)

For FPGA flow

• Configuration

allocation (*.cl)

LOCAL COMPUTER FTUNSHADES SERVER Design (HDL) Design.pin Design.vcd Make User ConstraintsFile Design.ucf Design.pin Xilinx Synthesis & PAR Simulation ISE Make stimuli file Design.dat Design.bit Design.ll Design.bit Design.ll FTU2 files

THE HARDWARE….

FTU2: Physical Layer

 FTU2 is built from a MB and 2 DBs:

• The MB is a

Xilinx ML510

PCIE sockets for the DBs PCI socket for USB interface with the server Control FPGA (XC5VFX130T) DDR2 sockets for DIMM modules (512MB)

FTU2: Physical Layer

 FTU2 is built from a MB and 2 DBs:

• The design of the

DB is original

PCIE x16 card edge ATX power connector Target FPGA V5 FF1136 Package Service FPGA (XC5VFX70T)

FTU2: Physical Layer

 FTU2 is built from a MB and 2 DBs:

• The design of the

DB is original

Virtex5 FF1136 package:

• XC5VLX50T
• XC5VLX85T
• XC5VLX110T
• XC5VLX155T
• XC5VSX50T
• XC5VSX95T
• XC5VFX70T
• XC5VFX100T

FTU2: Physical Layer

 FTU2 is linked to the uff-tnt server via

USB:

• FTDI FT2232HQ minimodule:
• Configured as USB to FIFO
• Two interfaces available
• USB2.0

FTU2: Physical Layer

 The system is assembled into an ATX

tower

Motherboard GOLD Daughterboard SEU Daughterboard USB-PCI board holding the 2232H minimodule

THE FIMWARE AND THE SOFTWARE…

FT-Unshades2 Firmware

 Functionality has been divided between all five FPGAs:  Control FPGA: Experiment control, communications with PC  “Gold” Service-FPGA: Feed stimuli, sample responses  “Seu” Service-FPGA: Feed stimuli, sample responses, Inject Faults  “Gold” Target-FPGA: 100% User design!  “Seu” Target-FPGA: 100% User design!

FT-Unshades2 Firmware

FT-Unshades2 Firmware

 Interesting features:  PCIexpress physical layer

• Serialize stimuli and responses. Allow up to 512 I/Os for the Target FPGA.
• Each PCIe endpoint allows up to 2 Gbps of user data (full duplex)

 Embedded bit-flip injector

• Main bottleneck in FTU1 was in the partial reconfiguration procedure used to

inject the faults: frames had to travel to the PC to be modified and back again to the board  DDR2 Memory controller:

• Up to 512 MB for bitstream + stimuli + batch commands

FT-Unshades2 FW: Lessons Learned

 Embedded bitstream manipulation module solves bottleneck

detected in previous version (FTU1)

 Manipulating stimuli and responses with the PPC creates a new

bottleneck

• PPC is great for prototyping, but sub-optimal for speed
• Bottleneck emerges with large number of test vectors

 Good news: This can be solved without modifying the hardware, only

with firmware updates

• 1st step: Comparison module: increase speed if using compressed stimuli
• 2nd step: Vector feeder: increase speed by skipping PPC when reading from DDR2

FT-Unshades2 Software

 Solves complexity and presents an User Friendly Framework

FTU2 in numbers

• 1. Fault rate achieved: 10.000 faults/sec

(this figure will be improved in new versions)

• 2. 512 I/Os, the capacity depends on the

model of the target device.

• 3. Current configurations

Virtex 5, LX50T and FX70T (FF1136 package)

FTU2 future actions

• 1. Improve the fault rate
• 2. Continue the development of FTU2-UFF
• 3. Construct a “farm” of devices, support

the system

• 4. Work with the “microprocessor mode”
• 5. Extend the system to a test fixture for

beam testing and diagnose

• 6. Go ahead with the FPGA mode

Access to FTU2

For Academia:

 Access is available to public academia for research

purposes via internet.

 An agreement between the third institution and the USE  User/Password is given  Also support beta users coordinated by ESA

For industrial customers:

 An agreement with UoS  Training and support  Install the FTU2 in their headquarter intranet  Sell the system and support

Thank you for your attention Q &A
