From something that fits in your pocket ... ... to, well, this. The future? ... Energy A look at cluster computers and datacenters Tarun Prabhu, Radha Venkatagiri Datacenters Datacenters Most (all?) of you probably know what they are Most
SLIDE 2
SLIDE 3
... to, well, this.
SLIDE 4
The future? ...
SLIDE 5
Energy
A look at cluster computers and datacenters
Tarun Prabhu, Radha Venkatagiri
SLIDE 6
Datacenters
SLIDE 7
Datacenters
Most (all?) of you probably know what they are Most (all?) of you know what they are used for
SLIDE 8
Energy usage in datacenters
Used 76,000,000,000 kWH in 2010 2% of all electricity produced in the US ≈1.3% of all electricity produced globally †
†Koomey, J. “Growth in Data Center Electricity Use 2005 to 2010”, Analytics Press, 2011
SLIDE 9
Increasing datacenter efficiency
Reduce infrastructure overheads Reduce ancillary (non-computing) costs Reduce computing costs
SLIDE 10
How efficient are these?
PUE(Power Energy Effectiveness): indicates how much energy is used for non-computing functions. Average PUE is 1.8 (this means that for every 1 Watt used for computing, another 0.8 Watts is used in overheads) † Company PUE Comments Facebook 1.07 Google 1.14 Individual facility goes to 1.06 Yahoo – Individual facility goes to 1.08 Amazon 1.45 Assumption by Amazon themselves Microsoft 1.25 Target for April 2013 Apple – They shall never tell ...
Table : Efficiency of datacenter giants‡
†http://www.datacenterknowledge.com/archives/2011/05/10/uptime-institute-the-average-pue-is-1-8/ ‡http://gigaom.com/cloud/whose-data-centers-are-more-efficient-facebooks-or-googles/
SLIDE 11
Infrastructure overheads - What are they?
SLIDE 12
Infrastructure overheads - Cooling, power etc.
Heat management to reduce hot spots Natural cooling
Air - Buffalo(Yahoo), Lulea(Facebook) Sea-water - Hamina(Google) Evaporative cooling - Prineville(Facebook)
Optimize power distribution
Efficient power-supplies Minimize AC/DC conversion stages
Nifty new ideas, for instance
- il baths
SLIDE 13
Ancillary costs ...
What Facebook did
SLIDE 14
Ancillary costs ...
What Facebook did Toss everything and go back to the drawing board.
SLIDE 15
Ancillary costs ...
What Facebook did Toss everything and go back to the drawing board. Literally
SLIDE 16
Open Compute Project
Facebook custom-designed ... everything † Kept only what was strictly necessary 38% more efficient, 24% cheaper Made all specifications (CAD drawings etc.) publicly available http://www.opencompute.org
- motherboards
power supplies
- server chassis
- server racks
- battery cabinets
†https://www.facebook.com/notes/facebook-engineering/building-efficient-data-centers-with-the-open- compute-project/10150144039563920
SLIDE 17
Reducing computing costs
SLIDE 18
Reducing computing costs
Tackle under-utilization and overprovisioning
SLIDE 19
Server utilization
Average server utilization in datacenters is ≈ 50%
SLIDE 20
Reasons for under-utilization
Planning for traffic spikes Reliability considerations System-software maintenance is safer
SLIDE 21
Real reason
Clients get cranky!
SLIDE 22
Energy-proportional computing
Under-utilization is a problem because, as things stand today, power consumed is not proportional to work done Ideally, the dynamic range of energy consumption should be
- increased. In this, no power will be consumed when idle, little
power will be consumed when doing minimal work and the consumption would increase gradually until the machine is fully loaded
SLIDE 23
Reducing compute costs - I
Tackling under-utilization with operating system support Turn/off suspend hosts during low-usage periods Intelligent load-balancing Resource-aware scheduling Power-aware scheduling
SLIDE 24
Google’s warehouse computing
Google’s approach to building datacenters Treat entire datacenter as one BIG computer Centralized resource management. Provides greater flexibility in decision-making to improve metrics
SLIDE 25
Reducing compute costs - II
Customizing hardware to applications
SLIDE 26
An example - FAWN
Fast Array of Wimpy Nodes Single-core AMD Geode processor(500 Mhz) 256 MB DDR SDRAM (400 Mhz) 4GB CompactFlash storage Intel Atom front-end
SLIDE 27
Academic research
Jointly optimize computing and cooling energy (ICDCS ’12) Data-centric approaches by focusing on where to place data to minimize energy consumption (SC ’12) Improving network and interconnect efficiency by scaling network up and down based on traffic demands (USENIX ’10) Intelligent allocation of work to compute-units based on job characteristics, environmental conditions etc.
SLIDE 28
Supercomputers
SLIDE 29
Supercomputers
Tens of thousands (or more) of compute elements operating together TB’s (now PB’s) of memory PB’s (nearing EB’s of storage)
SLIDE 30
Uses of supercomputers
Molecular dynamics Fluid dynamics: Airframe design Modelling astrophysics phenomena Earthquake system science Simulation of spread of contagion Cosmology (formation of the first galaxies) Climate modelling and hypothesis confirmation
SLIDE 31
Uses of supercomputers
Molecular dynamics Fluid dynamics: Airframe design Modelling astrophysics phenomena Earthquake system science Simulation of spread of contagion Cosmology (formation of the first galaxies) Climate modelling and hypothesis confirmation (of global warming perhaps)
SLIDE 32
Top 500 List
SLIDE 33
Top 500 List
# Name Location Cores PFLOPS Power(MW) 1 Titan USA 560K* 17.59 8.21 2 Sequoia USA 1572K 16.32 7.89 3 K Computer Japan 705K 10.5 12.66 4 Mira USA 786K 8.16 3.95 5 JuQueen Germany 131K 4.14 1.97 6 SuperMUC Germany 147K 2.89 3.42 7 Stampede USA 204K* 2.66 8 Tianhe-1A China 186K 2.56 4.04 9 Fermi Italy 163K 1.72 0.82 10 DTS USA 63K 1.51 3.57
Table : Power consumption of world’s fastest computers
http://www.top500.org/list/2012/06/100
SLIDE 34
How efficient is this?
These machines can simulate a rat’s brain
SLIDE 35
How efficient is this?
WARNING: Some math here
SLIDE 36
How efficient is this?
WARNING: Some Bad math here
SLIDE 37
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡
†http://faculty.washington.edu/chudler/facts.html
SLIDE 38
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡ ∴ Prat brain ≈ 2 1400 × 30 = 0.043W
†http://faculty.washington.edu/chudler/facts.html
SLIDE 39
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡ ∴ Prat brain ≈ 2 1400 × 30 = 0.043W Metabolism fraction Prat ≈ Wrat Whuman × Phuman = 0.4 62 × 100 §‡ = 0.64 W
†http://faculty.washington.edu/chudler/facts.html ‡http://hypertextbook.com/facts/2001/JacquelineLing.shtml
SLIDE 40
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡ ∴ Prat brain ≈ 2 1400 × 30 = 0.043W Metabolism fraction Prat ≈ Wrat Whuman × Phuman = 0.4 62 × 100 §‡ = 0.64 W Prat brain = 0.05 × Prat = 0.032W
†http://faculty.washington.edu/chudler/facts.html ‡http://hypertextbook.com/facts/2001/JacquelineLing.shtml
SLIDE 41
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡ ∴ Prat brain ≈ 2 1400 × 30 = 0.043W Metabolism fraction Prat ≈ Wrat Whuman × Phuman = 0.4 62 × 100 §‡ = 0.64 W Prat brain = 0.05 × Prat = 0.032W
†http://faculty.washington.edu/chudler/facts.html ‡http://hypertextbook.com/facts/2001/JacquelineLing.shtml
SLIDE 42
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡ ∴ Prat brain ≈ 2 1400 × 30 = 0.043W Metabolism fraction Prat ≈ Wrat Whuman × Phuman = 0.4 62 × 100 §‡ = 0.64 W Prat brain = 0.05 × Prat = 0.032W
†http://faculty.washington.edu/chudler/facts.html ‡http://hypertextbook.com/facts/2001/JacquelineLing.shtml
SLIDE 43
How efficient is this?
WARNING: Some Bad math here Brain weight comparison Whuman = 1400 gms† Wrat = 2 gms† Phuman ≈ 30 W‡ ∴ Prat brain ≈ 2 1400 × 30 = 0.043W Metabolism fraction Prat ≈ Wrat Whuman × Phuman = 0.4 62 × 100 §‡ = 0.64 W Prat brain = 0.05 × Prat = 0.032W
†http://faculty.washington.edu/chudler/facts.html ‡http://hypertextbook.com/facts/2001/JacquelineLing.shtml §http://www.biomedcentral.com/1471-2458/12/439
SLIDE 44
One of these ...
SLIDE 45
is equivalent to ...
SLIDE 46
is equivalent to ...
SLIDE 47
Exascale?
SLIDE 48
Exascale?
Enough computing power to simulate the human brain (2019?)
SLIDE 49
Exascale?
Needs 700 MW or more?
SLIDE 50
Exascale?
Needs 700 MW or more?
http://farm5.staticflickr.com/4011/4710638282 5e226f00f6.jpg
SLIDE 51
Exascale?
Needs 700 MW or more?
http://farm5.staticflickr.com/4011/4710638282 5e226f00f6.jpg http://images4.wikia.nocookie.net/ cb20100331223557/simpsons/images/0/0c/Springfield Nuclear Power Plant 1.PNG
SLIDE 52
Exascale?
Typical nuclear power plant produces 400-1200MW Needs 700 MW or more?
http://farm5.staticflickr.com/4011/4710638282 5e226f00f6.jpg http://images4.wikia.nocookie.net/ cb20100331223557/simpsons/images/0/0c/Springfield Nuclear Power Plant 1.PNG
SLIDE 53
Improving efficiency of clusters
Clusters Datacenters Tightly coupled execution Requests are typically independent Usually compute-intensive Usually data-intensive I/O tends to occur in waves Small amount of I/O most of the time Drastically different application characteristics makes tuning nearly impossible Workload for any one applica- tion is the same, so clusters of machines can be tuned
SLIDE 54
Improving efficiency of clusters
Modelling power consumption at a fine-granularity is even harder
SLIDE 55
Improving efficiency of clusters
Modelling power consumption at a fine-granularity is even harder Where do you stick the meter?
SLIDE 56
Improving efficiency of clusters
Divide application into phases and run each phase in the best power mode Reconfigurable network interconnects Minimize communication in the program. Or else, exploit patters in the communication and allocate interacting processes to nearby compute units Use dynamic voltage and frequency scaling intelligently
SLIDE 57
Improving efficiency of clusters
Divide application into phases and run each phase in the best power mode Reconfigurable network interconnects Minimize communication in the program. Or else, exploit patters in the communication and allocate interacting processes to nearby compute units Use dynamic voltage and frequency scaling intelligently Fallback on heterogeneity (each component of the cluster
- ptimized for a specific task e.g. wimpy nodes for IO, GPU’s
for matrix operations)
SLIDE 58
The hard way
Programmer explicitly coding for energy-efficiency? Potentially nightmarish, but tool support might be possible (gcc -P2)?
SLIDE 59
Clusters: Green 500 List
# Name Country GFlops/W Power(kW) Top 500 # 1 Beacon USA 2.499 44.89 253 2 SANAM KSA 2.351 179.5 53 3 Titan USA 2.142 8209 1 4 Todi Sui 2.121 129 91 5 JuQueen Ger 2.102 1970 5 6 (UoT) Can 2.101 41.09 401 7 (LLNL) USA 2.101 41.09 399 8 (IBM) USA 2.101 41.09 400 9 (IBM) USA 2.101 82.19 140 10 CADMOS Sui 2.100 82.19 141
SLIDE 60
How green are the Top 500?
# Name Power(MW) Green 500 # 1 Titan 8.21 3 2 Sequoia 7.89 30 3 K Computer 12.66 85 4 Mira 3.95 29 5 JuQueen 1.97 5 6 SuperMUC 3.42 82 7 Stampede 2.66 142 8 Tianhe-1A 4.04 87 9 Fermi 1.72 23 10 DTS 1.51 159
SLIDE 61
What we really need to do is ...
