Formal C semantics: CompCert and the C standard
Robbert Krebbers1 Xavier Leroy2 Freek Wiedijk1
1ICIS, Radboud University Nijmegen, The Netherlands 2Inria Paris-Rocquencourt, France
2
Formal C semantics: CompCert and the C standard Robbert Krebbers 1 - - PowerPoint PPT Presentation
Formal C semantics: CompCert and the C standard Robbert Krebbers 1 - - PowerPoint PPT Presentation
Formal C semantics: CompCert and the C standard Robbert Krebbers 1 Xavier Leroy 2 Freek Wiedijk 1 1 ICIS, Radboud University Nijmegen, The Netherlands 2 Inria Paris-Rocquencourt, France July 17, 2014 @ ITP, Vienna, Austria 1 Underspecification
SLIDE 2
SLIDE 3
2
Underspecification in C
◮ Unspecified behavior: two or more behaviors are allowed
For example: order of evaluation in expressions Non-determinism
◮ Implementation defined behavior: like unspecified
behavior, but the compiler has to document its choice For example: size and endianness of integers Parametrization
◮ Undefined behavior: the standard imposes no requirements
at all, the program is even allowed to crash For example: dereferencing a NULL or dangling pointer, signed integer overflow, . . . No semantics/crash state
SLIDE 4
3
Pros and cons of underspecification
Pros for optimizing compilers:
◮ More optimizations are possible ◮ High run-time efficiency ◮ Easy to support multiple architectures
Cons for programmers/formal methods people:
◮ Portability and maintenance problems ◮ Hard to formally reason about
SLIDE 5
4
Approaches to underspecification
CompCert (Leroy et al.)
◮ Main goal: verified optimizing compiler in ◮ Specific choices for unspecified/impl-defined behavior
For example: 32-bits ints
◮ Describes some undefined behavior
For example: dereferencing NULL, integer overflow defined
◮ Compiler correctness proof only for programs without
undefined behavior Formalin (Krebbers & Wiedijk)
◮ Main goal: compiler independent separation logic in ◮ Describes some implementation-defined behavior
For example: no legacy architectures with 0’s complement
◮ Aims to describe all unspecified and undefined behavior
SLIDE 6
5
Defined behaviors in C11, Formalin and CompCert C
C11 Formalin CompCert C
comparing with end-of-array pointers byte-wise pointer copy subtle casts subtle type punning integer overflow aliasing violations sequence point violations use of dangling block scope pointers arithmetic on pointer bytes
SLIDE 7
5
Defined behaviors in C11, Formalin and CompCert C
C11 Formalin CompCert C
comparing with end-of-array pointers byte-wise pointer copy subtle casts subtle type punning integer overflow aliasing violations sequence point violations use of dangling block scope pointers arithmetic on pointer bytes
This talk: add to CompCert so we get Formalin ⊆ CompCert
SLIDE 8
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; }
SLIDE 9
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 x1 xn−1 p end
SLIDE 10
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 xn−1 p end
SLIDE 11
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 p end
SLIDE 12
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 p end
SLIDE 13
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 + 1 p end
SLIDE 14
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 + 1 p end Bizarre: int x, y; if (&x + 1 == &y) printf("x and y are adjacent\n");
SLIDE 15
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 + 1 p end Bizarre: int x, y; if (&x + 1 == &y) printf("x and y are adjacent\n"); &x &y
SLIDE 16
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 + 1 p end Bizarre: int x, y; if (&x + 1 == &y) printf("x and y are adjacent\n"); &x &x + 1 &y
SLIDE 17
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 + 1 p end Bizarre: int x, y; if (&x + 1 == &y) printf("x and y are adjacent\n"); &x &x + 1 &y == ?
SLIDE 18
6
Comparing with end-of-array pointers (problem)
Useful: void inc_array(int *p, int n) { int *end = p + n; while (p < end) (*p++)++; } x0 + 1 x1 + 1 xn−1 + 1 p end Bizarre: int x, y; if (&x + 1 == &y) printf("x and y are adjacent\n"); &x &x + 1 &y == ? Both undefined behavior in CompCert (1.12 and before)
SLIDE 19
7
Comparing with end-of-array pointers (solution)
Solution: Comparison of pointers is defined if:
◮ Same block: both should within block bounds
- ×
SLIDE 20
7
Comparing with end-of-array pointers (solution)
Solution: Comparison of pointers is defined if:
◮ Same block: both should within block bounds
- ×
◮ Different block: both should be strictly within block bounds
- ×
SLIDE 21
7
Comparing with end-of-array pointers (solution)
Solution: Comparison of pointers is defined if:
◮ Same block: both should within block bounds
- ×
◮ Different block: both should be strictly within block bounds
- ×
Stable under compilation and gives a semantics to common programming practice with end-of-array pointers
SLIDE 22
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++;
SLIDE 23
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: q
SLIDE 24
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a q
SLIDE 25
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00 q Previously undefined, need to allow copying indeterminate bytes
SLIDE 26
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00 q Previously undefined, need to allow copying indeterminate bytes
SLIDE 27
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00 q Previously undefined, need to allow copying symbolic pointer bytes
SLIDE 28
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00
(bs1 , 0)0
q Previously undefined, need to allow copying symbolic pointer bytes
SLIDE 29
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1
q Previously undefined, need to allow copying symbolic pointer bytes
SLIDE 30
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2
q Previously undefined, need to allow copying symbolic pointer bytes
SLIDE 31
8
Byte-wise copying of objects (problem)
struct { short x; short *r; } s1 = {10, &s.x}, s2; unsigned char *p = &s1, *q = &s2; unsigned char *end = p + size_of(s1); while (p < end) *p++ = *q++; s1: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
p end s2: 0x0a 0x00
(bs1 , 0)0 (bs1 , 0)1 (bs1 , 0)2 (bs1 , 0)3
q Previously undefined, need to allow copying symbolic pointer bytes
SLIDE 32
9
Byte-wise copying of objects (solution)
Solution: extend values with pointer fragment values Inductive val: Type := | Vundef: val | Vint: int -> val | Vlong: int64 -> val | Vfloat: float -> val | Vptr: block -> int -> val | Vptrfrag: block -> int -> nat -> val. Subtleties:
◮ Dealing with arithmetic on pointer fragments ◮ Dealing with implicit casts (at assignments) ◮ More values possible, need to extend static analysis
SLIDE 33
10
Conclusion and future work
◮ Semantics to useful behaviors that were previously undefined
◮ Comparing with end-of-array pointers ◮ Byte-wise pointer copy
◮ CompCert proofs adapted for these extensions
◮ Small changes to the semantics ◮ Involves proofs of many compilation passes
◮ Needed for cross validation of CompCert and Formalin ◮ Call-by-reference passing of struct values future work
