SUTECH GROUP OF COMPANY NEW PRODUCTS DEVELOPMENT FOR SUGAR INDUSTRY Aug 1 st ,2019. By SUTECH ENGINEERING CO.,LTD. SURANAREE UNIVERSITY OF TECHNOLOGY TONGATT HULLET - SOUTH AFRICA 1 st August, 2019 1 Sutech Group Presentation SUTECH GROUP

slide-1
SLIDE 1

SUTECH GROUP OF COMPANY

NEW PRODUCTS DEVELOPMENT FOR SUGAR INDUSTRY

Aug 1st,2019.

By

SUTECH ENGINEERING CO.,LTD. SURANAREE UNIVERSITY OF TECHNOLOGY TONGATT HULLET - SOUTH AFRICA

1 Sutech Group Presentation 1st August, 2019

slide-2
SLIDE 2

SUTECH GROUP OF COMPANY

2 Sutech Group Presentation

OUTLINE ➢ Cylindrical Continuous Vacuum Pan (CCVP) ➢ Calcium Carbonate Recycle System for Sugar Refinery ➢ Study of Lactic Acid Production from Cane Molasses

slide-3
SLIDE 3
  • CYLINDRICAL CONTINUOUS PAN (CCVP)

3 Cylindrical Continuous Pan Presentation

The Tongaat Hulett Cylindrical Continuous Vacuum Pan (CCVP)

slide-4
SLIDE 4

CYLINDRICAL CONTINUOUS PAN (CCVP)

4 Cylindrical Continuous Pan Presentation

A new continuous pan has been developed by Tongaat Hulet in 2008. This new patented design consist of two stacked calandrias stacked inside a cylindrical vessel . Three new CCVP has been installed in Mozambique in year 2008-2009 consist of

  • 1 set of A pan 120 m3
  • 2 set of A,B pan 100 m3
slide-5
SLIDE 5

CYLINDRICAL CONTINUOUS PAN (CCVP)

5 Cylindrical Continuous Pan Presentation

➢ Cylindrical vessel ➢ Two floating calandrias ➢ Common vapor space ➢ Top and bottom each six compartments ➢ Each calandria can be boiled independently ➢ Massecuite flow similar to horizontal CVP

slide-6
SLIDE 6

6 Cylindrical Continuous Pan Presentation

CYLINDRICAL CONTINUOUS PAN (CCVP)

  • Xinavane A-Pan 120 m3

installation in 2008.

slide-7
SLIDE 7

7 Cylindrical Continuous Pan Presentation

CYLINDRICAL CONTINUOUS PAN (CCVP)

  • Segment of Calandria

“Pie Slice”

slide-8
SLIDE 8

8 Cylindrical Continuous Pan Presentation

Down take Transfer Ports Vapor duct CYLINDRICAL CONTINUOUS PAN (CCVP)

slide-9
SLIDE 9

9 Cylindrical Continuous Pan Presentation

➢ XN Pans commissioned 2009 (‘A’ and ‘B’ pans) ➢ Very good circulation ➢ Massecuite quality is good ➢ Low encrustation rates ➢ Performance on a Par with the HCVP

CYLINDRICAL CONTINUOUS PAN (CCVP)

slide-10
SLIDE 10

10 Cylindrical Continuous Pan Presentation

➢ Three (3) cell CCVP ➢ 100 cu.m./cell with “Vacuum Cooling Crystallizer “ for R1-mc ➢ Refinery 3,000 T/D.RSO ➢ Two cell operating ,one cell for cleaning.

Cylindrical Continuous Pan (CCVP)

slide-11
SLIDE 11

11 Cylindrical Continuous Pan Presentation

For R1 massecuite ➢ Double effect evaporation pans

Cylindrical Continuous Pan (CCVP)

slide-12
SLIDE 12

12 Sutech Group Presentation

CYLINDRICAL CONTINUOUS PAN (CCVP) CYLINDRICAL CONTINUOUS PAN (CCVP)

slide-13
SLIDE 13

13 Sutech Group Presentation

CYLINDRICAL CONTINUOUS PAN (CCVP)

slide-14
SLIDE 14

January 2016 Sutech Group Presentation 14

CYLINDRICAL CONTINUOUS PAN (CCVP)

slide-15
SLIDE 15

CYLINDRICAL CONTINUOUS PAN (CCVP)

15 Cylindrical Continuous Pan Presentation

New continuous pan technology More steam saving in pan boiling Can be installed in existing batch pan position Smaller footprint than horizontal pan Design can accommodate: ➢ Two separate massecuite grades in one pan ➢ Use of different grades of vapor in a single pan ➢ On-the-run boilout of pan. Improved circulation characteristics

slide-16
SLIDE 16

16 Rotary Lime Kiln Presentation

  • ROTARY LIME KILN

Rotary Lime Kiln

By

SUTECH ENGINEERING CO., LTD.

slide-17
SLIDE 17

17 Rotary Lime Kiln Presentation

➢ The wet cake (Calcium carbonate cake ) from sugar refinery is the solid waste which need to dispose in the specific area under the law/regulation of each country. ➢ The composition of wet cake consist of Calcium carbonate ( 65-70 %), water ( 30- 35 % ), organic matters, etc. ➢ SUTECH Rotary lime kiln is mainly used for “Calcining” the wet cake from sugar refinery to produce calcium oxide and reuse in Liming of Carbonation system. ➢ Wet cake is calcined in rotary kiln at temperature 900 to 1,200 degree C. water vapor(H2O) and Carbon Dioxide (CO2) will be released from kiln.

ROTARY LIME KILN

slide-18
SLIDE 18

18 Rotary Lime Kiln Presentation

➢ SUTECH’s first unit of “Rotary Lime Kiln” is installing in sugar refinery 3,000 TRD in Bangladesh. CaCO3(s) . H2O(l) CaO(s) + CO2(g) + H2O(g)

ROTARY LIME KILN

slide-19
SLIDE 19

19 Rotary Lime Kiln Presentation

ROTARY LIME KILN

slide-20
SLIDE 20

20 Rotary Lime Kiln Presentation

After calcination Before calcination

ROTARY LIME KILN

Test Result Available lime(calculated as CaO), 85.1 %

slide-21
SLIDE 21

21 Rotary Lime Kiln Presentation

ROTARY LIME KILN

slide-22
SLIDE 22

January 2016 Sutech Group Presentation 22

ROTARY LIME KILN

slide-23
SLIDE 23

23 Rotary Lime Kiln Presentation

ROTARY LIME KILN

slide-24
SLIDE 24
  • LACTIC ACID

Study of Lactic Acid Production from Cane Molasses

By

SUTECH ENGINEERING CO., LTD. SURANAREE UNIVERSITY OF TECHNOLOGY

24 Lactic Acid Presentation

slide-25
SLIDE 25

LACTIC ACID

25 Lactic Acid Presentation

➢ Lactic acid (CH3CH(OH)COOH) is an organic acid that can be produced by fermentative

  • r

chemical

  • synthesis. The production by fermentation process

has attracted interest due to its advantages, lower cost compared with chemical synthesis.

slide-26
SLIDE 26

LACTIC ACID

26 Lactic Acid Presentation

➢ There are many cheap and renewable raw materials used for lactic acid production, such as

  • raw sugar

molasses,

  • cassava,

wheat ,corn,potato, rice

  • lignocelluloses
  • and others.
slide-27
SLIDE 27

January 2016 Sutech Group Presentation 27

FEED STOCK

➢ Lactic acid is widely used in the food preservative, cosmetic, pharmaceutical and biodegradable plastic.

➢ Cosmetic ➢ Biodegradable plastic ➢ Pharmaceutical

slide-28
SLIDE 28

January 2016 Sutech Group Presentation 28

slide-29
SLIDE 29

Lactic Acid

29 Lactic Acid Presentation

Lactic acid production from Cassava with pilot plant by Dr. Apichat Boontawan ( 2011-2017 )

Cassava root Liquefaction

Lactic acid Bacteria seed

Fermentation

72 HRS

Filter

Cell

Ca(OH)2

CaLac Saccharification

Enzyme CaSO4

Acid Hydrolysis

H2SO4

Filter Crude Lactic acid MF & NF membrane Filtration L-Lactic acid

slide-30
SLIDE 30

Lactic acid production pictures from pilot plant

.

30

slide-31
SLIDE 31

LACTIC ACID “ PRODUCTION STUDY ” FROM CANE MOLASSE

31 Lactic Acid Presentation

➢ The study of Lactic acid production from cane molasses in laboratory is done by Suranaree University of technology in Thailand. The study consist

  • f bacteria screening, fermentation & HPLC analysis. The study will be

finished in 2019 and will continue with scale-up project with Sutech in year 2020 to develop the equipment and preliminary engineering design parameters for fermentation and purification.

slide-32
SLIDE 32

Lactic Acid

32 Lactic Acid Presentation

Lactic Acid Process Block Diagram no.1 for scale up project

Cane Molasses Inversion

Lactic acid Bacteria seed

Fermentation Filter

Cell

Ca(OH)2

CaLac Sterilization

Enzyme CaSO4

Acid Hydrolysis

H2SO4

Filter Butyl Lactate Crude Lactic acid Solvent Extraction Reactive Distillation /Esterification Butanol/Lactic acid Butanol Hydrolysis Distillation L-Lactic acid

slide-33
SLIDE 33

33

Diagram for LA recovery using reactive distillation

General schematic for lactic acid recovery

Solevnt Extraction

slide-34
SLIDE 34

Lactic Acid

34 Lactic Acid Presentation

Lactic Acid Process Block Diagram no.2 using membrane filtration

Cane Molasses Inversion

Lactic acid Bacteria seed

Fermentation Filter

Cell

Ca(OH)2

CaLac Sterilization

Enzyme CaSO4

Acid Hydrolysis

H2SO4

Filter Crude Lactic acid MF & NF membrane Filtration, Resin deminerization Short Path Distillation L-Lactic acid Evaporation

slide-35
SLIDE 35

Conclusion of Study

I. Successful in Bacteria screening for Cassava and Molasses fermentation

  • II. Lactic yield from fermentation not less than

90 %

January 2016 Sutech Group Presentation 35

Lactic Acid

slide-36
SLIDE 36

Lactic Acid

36 Lactic Acid Presentation

Scale up equipment for Lactic acid production at Suranaree U.

Fermentation

slide-37
SLIDE 37

Lactic Acid

37 Lactic Acid Presentation

Reactive Distillation

slide-38
SLIDE 38

Bio refinery Scientists Leader of Thailand

January 2016 Sutech Group Presentation 38

slide-39
SLIDE 39

THANK YOU

By

SUTECH GROUP OF COMPANY SURANAREE UNIVERSITY OF TECHNOLOGY TONGATT HULLET - SOUTH AFRICA

39
