Alan Gray, Developer Technology Engineer, NVIDIA GTC, March 26-29 2018

PERFORMANCE OPTIMIZATION FOR SCIENTIFIC APPLICATIONS

2

AGENDA

• Introduction
• Single-GPU
• Exposing parallelism
• Memory Coalescing
• Data Management Optimization
• Interoperability
• ESCAPE performance results
• Multi-GPU
• CUDA-aware MPI
• AlltoAll optimization
• DGX-2 (with NVSwitch) vs DGX-1V

3

INTRODUCTION

4

ESCAPE

• NVIDIA’s role is to take existing GPU-enabled codes and optimize.

5

ECMWF

• European Centre for Medium Range Weather Forecasts (ECMWF) are an

intergovernmental org.

• Global forecasts:
• used by more than 22 countries to drive their regional forecasts.
• provide accurate weekly, monthly and seasonal predictions, including early warnings of

severe events.

• In 2012 ECMWF provided the most accurate prediction for the trajectory and landfall
• f Hurricane Sandy: information that undoubtedly saved lives.
• We are working closely with ECMWF (and other partners) in ESCAPE to evaluate and

improve the algorithms, techniques and software on GPUs.

• This is done through use of dwarves: mini-apps designed to represent the key

properties of the real simulation applications.

ESCAPE Project Leaders

6

ESCAPE DWARVES

• Info in “grid-point” space can be equivalently represented in “spectral” space, i.e. in

terms of the frequencies of the fluctuating waves, which is more suited to some calculations.

• IFS therefore repeatedly transforms between these representations, Fourier

transforms (FFTs) in longitude and Legendre transforms (DGEMMs) in latitude, with AlltoAll data movement in-between.

• This dwarf represents the spectral transforms from IFS.
• NB. Number of points varies (e.g. most round equator, fewest at poles). Additionally,

there exist multiple altitude “levels”, in third dimension away from surface of earth, each with 3 “fields”.

• ECMWF’s Integrated Forecasting System (IFS) is a global prediction

system: entire earth’s atmosphere is represented as a spherical grid.

Spherical Harmonics (SH) Dwarf

7

ESCAPE DWARVES

• Advection: horizontal transport
• Uses unstructured grid with

nearest-neighbour stencils

• MPDATA scheme already used

within COSMO-EULAG (PSNC), and

• f interest to ECMWF for future

developments

• Both SH and MPDATA Dwarves Fortran+OpenACC+MPI. SH also has interfacing to

CUDA libraries.

• Many of the optimizations I will present are transferable to other

applications/languages etc.

MPDATA Dwarf

8

SINGLE-GPU: EXPOSING PARALLELISM

9

EXPOSING PARALLELISM

Loop over timesteps … Loop over 1st dimension … Loop over 2nd dimension … Loop over fields … Operation (involving multidimensional arrays) … Another Loop over dimensions… …

OpenACC Loop Mapping

Typical Structure of Application (usually spanning multiple routines/files):

Aim is to expose as much parallelism in this red box as possible, as flexibly as possible

10

EXPOSING PARALLELISM

Loop over 1st dimension … Loop over 2nd dimension … Loop over fields … Operation

OpenACC Loop Mapping

Before Optimization:

SH

• Loop over 1st dimension was sequential:

parallelism not exposed to GPU MPDATA

• Naïve mapping of loops, using “kernels”

and/or “loop” directives without restructuring.

• Resulting decomposition chosen by

compiler did not work well since runtime loop extents didn’t map well to GPU architecture.

11

EXPOSING PARALLELISM

$!ACC parallel loop collapse(3) Loop over 1st dimension Loop over 2nd dimension Loop over fields … Operation

OpenACC Loop Mapping

• Assuming loops are independent,

better to restructure such that loops are tightly nested, and use “collapse” clause.

• Loops will be collapsed into a

single loop, and compiler will map all parallelism to GPU blocks/threads in an efficient way.

• This can require extensive

restructuring, depending on how application is originally written.

12

EXPOSING PARALLELISM

$!ACC parallel loop collapse(2) Loop over 1st dimension Loop over 2nd dimension $!ACC loop seq Loop with dependencies … Operation

OpenACC Loop Mapping

• Sometimes we have loop-carried

dependencies.

• These can be performed

sequentially by each thread at the innermost level.

• Can still perform well if there is

enough parallelism in outermost loops.

13

EXPOSING PARALLELISM

do i=1, N do j=1, i do k=1, P … Operation

OpenACC Loop Mapping

$!ACC parallel loop collapse(3) do i=1, N do j=1, MAX_J do k=1, P if(j .le. i) then … Operation

• Sometimes extent of a loop depends
• n index of another (outer) loop

which prevents loop collapsing.

• Can replace extent with max value,

and use conditional statement in loop body.

14

SINGLE-GPU: MEMORY COALESCING

15

KERNEL OPTIMIZATION

$!ACC parallel loop collapse(3) do k=1, … do j=1, … do i=1, … … Array(i,j,k)=…

Memory Coalescing: data layout

• For memory coalescing, fastest moving index in array access should correspond to

vector level (CUDA thread), which will correspond to innermost collapsed loop index. $!ACC parallel loop collapse(2) do m=1, … do n=1, … $!ACC loop seq do p=1, … … Array(n,m,p)=…

16

KERNEL OPTIMIZATION

!$ACC parallel loop tile(16,32) do j=1, … do i=1, … … array_t(i,j)=array(j,i)

Memory Coalescing: transposing with tile clause

• If you need to transpose, either

read or write will be in wrong layout for coalescing.

• But can use OpenACC “tile” clause

to improve performance

• Compiler tiles the operation by

generating new innermost loops

• For each tile, data is staged on-chip
• Results in better global memory

access patterns

• Experiment with tile sizes

17

KERNEL OPTIMIZATION

Memory Coalescing: transposing within CUDA BLAS

• In some of our cases, the transpose kernels were adjacent to CUDA BLAS matrix

multiplication (DGEMM) calls.

• Coalescing was facilitated through replacing C = AB matrix multiplications by

equivalent 𝐷𝑈 = 𝐶𝑈𝐵𝑈.

• This allows transpose operations to be pushed into the DGEMM library calls,

which have much higher-performing implementations of transposed data accesses

18

SINGLE-GPU: DATA MANAGEMENT OPTIMIZATION

19

DATA MANAGEMENT OPTIMIZATION

Loop over timestep: … loops over spatial dims …

Minimizing data allocation and movement

• Important to keep as much data as possible

resident on GPU within timestep loop.

• All allocations/frees should be outside timestep

loop.

• Copies for constant data should be outside main

timestep loop.

• Re-use temporary scratch arrays on device
• Any necessary repeated copies (e.g. halo

regions in MPI code): volume copied should be minimized. Data allocation and movement is expensive Many codes have:

20

SINGLE-GPU: INTEROPERABILITY

21

INTEROPERABILITY

Simple example: Calling C/CUDA from PGI Fortran

!main.f90 program main interface subroutine kernel_from_f(arg) & bind(C,name='kernel_wrapper') use iso_c_binding integer(c_int),value :: arg end subroutine kernel_from_f end interface call kernel_from_f(1) end program main //kernel.cu #include <stdio.h> __global__ void kernel(int arg){ if (threadIdx.x==0) printf("hello from kernel\n"); return; } extern "C" void kernel_wrapper(int arg){ kernel <<<1,1>>> (arg); cudaDeviceSynchronize(); return; } $ nvcc -c -arch=sm_60 kernel.cu -o kernel.o $ pgf90 -c main.f90 -o main.o $ pgf90 main.o kernel.o -o code -L $CUDA_HOME/lib64 –lcudart $ ./code hello from kernel

CUDA libraries can be called from C code in the usual manner.

22

INTEROPERABILITY AND LIBRARIES: SH DWARF

cuFFT cuFFT cublasDgemm cublasDgemm

Base language Fortran, MPI for multi-GPU communications.

OpenACC OpenACC OpenACC OpenACC OpenACC OpenACC

23

BLAS/FFT LIBRARY CALLS IN SH DWARF

• At each timestep, SH dwarf performs transforms using Matrix Multiplications and FFTs.
• Multiple operations - one for each:
• Field (associated with vertical levels)
• Longitude (Matmult) / Latitude (FFT)
• Can batch over fields, since sizes are the same. But different longitudes/latitudes

have different sizes: not supported by batched versions of cublasDgemm/cuFFT.

• So, originally we had many small calls: low parallelism exposure and launch latency

sensitivity.

• For DGEMM, we pad with zeros up to largest size and batch over longitudes as well as

fields: single call to library; extra operations do not contribute to result.

• But FFT does not allow padding in the same way. Worked around launch latency

problem by removing sync after each call: allows launch latency to be hidden behind execution.

• As will be seen, however, this is the only part of the dwarf which remains suboptimal.

Future: batched FFT with differing sizes should improve performance.

24

SINGLE-GPU: ESCAPE RESULTS

25

MPDATA OPTIMIZATION: P100

Before: After:

26

OPTIMIZED MPDATA: P100 VS V100

P100 V100

27

ESCAPE DWARF V100 PERFORMANCE

28

MPDATA KERNEL PERFORMANCE

• 100% Roofline is STREAM benchmark throughput, since all kernels are memory bandwidth bound

29

ESCAPE DWARF V100 PERFORMANCE

30

SH KERNEL PERFORMANCE

• 100% Roofline is peak DP Performance (compute bound kernels) or STREAM benchmark

throughput (memory bandwidth bound kernels)

Experiments with batching (using av. size) show 4.6X speedup

31

MULTI-GPU: CUDA-AWARE MPI

32

CUDA-AWARE MPI

• Modern MPI implementations are CUDA-aware. This means that pointers to GPU

memory can be passed directly into the MPI calls, avoiding unnecessary transfers (both in the application and in the underlying MPI implementation).

!non CUDA-aware: !$ACC update host(array,…) call MPI_Alltoallv(array,…) !$ACC update device(array,…) !CUDA-aware: !$ACC host_data use_device(array,…) call MPI_Alltoallv(array,…) !$ACC end host_data

• Also for point-to-point etc. Note that if explicit buffer packing is involved, this will

also need to be ported from CPU to GPU.

33

MULTI-GPU: ALLTOALL OPTIMIZATION

34

ALLTOALL: 4 GPUS ON DGX-1

• SH dwarf performs AlltoAll operations. Even with CUDA-aware MPI, there are

inefficiencies:

• Can instead use CUDA IPC directly with CUDA streams to
• verlap.
• Future MPI implementations are expected to take care of this

35

CUDA IPC ALLTOALL

As a starting point, used the 0_Simple/simpleIPCcode from the CUDA samples. Setup:

• On each MPI rank, get IPC memory handle for array locally
• Share IPC memory handles via MPI
• Setup CUDA streams

AlltoAll:

• On each rank, loop over all targetranks (including own)
• targetrank=(targetrank+rank)%number_of_gpus (for better balance)
• Push message to targetrank (in stream[targetrank])
• Sync all streams

36

SH RESULTS ON 4 GPUS

37

MULTI-GPU: DGX-2 (WITH NVSWITCH) VS DGX-1V

38

SPHERICAL HARMONICS: SCALING BEYOND 4 GPUS

• When using all 8 GPU in DGX-1V:
• No AlltoAll NVLINK Connectivity – some

messages go through PCIe and system memory

• This limits performance
• When using 16 GPUs across 2 DGX-1V

servers

• Some messages go across Infiniband

network

• Further bottleneck

39

DGX-2 WITH NVSWITCH

• AlltoAll network architecture with NVSwitch maps perfectly to the problem.
• Full bandwidth between each GPU pair.

40

SPHERICAL HARMONICS: DGX-2 VS DGX-1V

41

SUMMARY AND FUTURE WORK

• Optimizing the exposure of parallelism, memory coalescing and data management

can have dramatic effects on performance.

• MPDATA single-GPU performance is now optimal.
• MPDATA multi-GPU: halo-exchange currently implemented via MPI abstracted CPU-

based ATLAS library (also developed by ECMWF). To be fully optimized, ATLAS needs to be made CUDA aware, and this is currently being worked on by others.

• SH single-GPU performance is vastly improved, but FFT part remains sub-optimal.
• Implementation of batching where different sizes are allowed within each batch

would expectedly fix this.

• DGX-2/NVSwitch all-to-all connectivity allows SH to scale to all 16 GPUs.
• These results give indications that multi-GPU systems can be effectively exploited

to allow forecasting agencies to continue to further improve weather predictions.
