SOLAR ENERGY

ABSOLICON JOAKIM BYSTRÖM

ABSOLICON SOLAR COLLECTORS

Food Products Ltd

• Manufacturing and marketing high-quality

food and beverage products

• Several factories
• Potential installation at UB 16/31
• Hot water used for solar cooling
• 80°C input and 70°C return temperature
• Installation in 1-2 years

Absolicon T10

• Tracks the sun during the day

for maximum performance

• Swedish quality, built for

25 years of operation

• No overheating
• Wind safe
• Minimum maintenance

Suitable roof space

• Area A can hold 800 m2 of

Absolicon X10

• Attachment to rooftop need to

be investigated

• Absolicon structure inclusive

collectors is 20 kg/m2

• Collectors may be placed on

six feet / 60 m2 when attached to roof structure

Installation examples

Roof-top mounted

School connected to district heating Electrochemical Industry

Solar production T10 800 m2

• Excellent solar conditions
• Maximum peak power 430 kW
• 1093 kWh hot water / m2 / annum
• 875 MWh/annum

Solar Central

• Absolicon can offer a plug-and-

play solar central

– Solar tracking Control Unit – PLC for solar thermal control – Pumps, Heat exchangers, Values, Expansion vessels

Need of storage

• Solar collectors can operate at

higher temperatures to store energy in pressurized water tanks

• Feeding tanks with 100ºC only

reduce production with 5%

• A high temperature in the tanks

reduces tank volume (1/2 size)

• Dimensioning of tanks possible

when we have load distribution during the day and the week

Energy cost

• The Customer is using natural gas to power one or two 430kW

LPG Gas Boilers to heat up the water for the HVAC system which is maintained at around 80ºC

• Burner on 500 kW uses 64 Liter/h = 7,8 kWh/liter (low?)
• Gas cost €0,5/Liter makes €64/MWh energy cost
• Expected energy increase 5% annually

Absolicon Power and Energy Warranty

• Absolicon guarantees that the final installation has the

promised peak power in full sun

• Absolicon guarantees that the yearly production, taken

the specific years solar radiation into account, is consistent with the calculated performance

• Measurement accuracy is 10%

Cost division

Absolicon Collectors T6 271 000 € (€339/m2) Absolicon Solar Central 37 900 € Tanks, installation, piping 70 000 € Planning 35 000 € Total cost 382 760 €
