FatTire: Declarative Fault Tolerance for SDN Mark Reitblatt - PowerPoint PPT Presentation

Feb 03, 2023 •40 likes •380 views

FatTire: Declarative Fault Tolerance for SDN Mark Reitblatt (Cornell) (TU Berlin UC Louvain) Marco Canini (Cornell UMass Amherst) Arjun Guha Nate Foster (Cornell) 1 Friday, August 16, 13 In a Perfect World... 2 Friday, August 16,

  1. FatTire: Declarative Fault Tolerance for SDN Mark Reitblatt (Cornell) (TU Berlin → UC Louvain) Marco Canini (Cornell → UMass Amherst) Arjun Guha Nate Foster (Cornell) 1 Friday, August 16, 13

  2. In a Perfect World... 2 Friday, August 16, 13

  3. But in Reality... 3 Friday, August 16, 13

  4. Fault-Tolerance Mechanisms Traditional Networks • MPLS local path protection • Global path protection • IEEE 802.1ag • and others... Software-Defined Networks • Controller reacts to failures • Fast failover group actions (OpenFlow 1.1+) 4 Friday, August 16, 13

  5. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  6. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  7. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  8. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  9. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  10. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  11. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  12. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  13. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  14. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  15. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  16. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  17. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  18. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  19. • Connectivity from GW to A • SSH traffic traverses IDS • SSH is 1-link fault tolerant S1 GW IDS A S2 Traffic 5 Friday, August 16, 13

  20. OpenFlow Fast Failover Match Instructions inPort = GW , tpDst = 22 Group 1 inPort = IDS , tpDst = 22 Group 2 Match Instructions inPort = S2 , tpDst = 22 Group 2 tpDst = 22 Group 1 Group Type Actions Group Type Actions h Fwd IDS i , h Fwd S2 i 1 FF S1 h Fwd S1 i , h Fwd S2 i h Fwd A i 1 FF 2 FF GW IDS A Match Instructions S2 inPort = IDS , tpDst = 22 Group 1 inPort = S1 , tpDst = 22 Group 2 inPort = GW , tpDst = 22 Group 2 Group Type Actions h Fwd A i , h Fwd S1 i 1 FF h Fwd IDS i 2 FF 6 Friday, August 16, 13

  21. Why not Frenetic? • Frenetic provides a declarative language for expressing forwarding policies... • ... in terms of hop-by-hop forwarding steps • Example: ¡ ¡(GW ¡ ¡ � ¡S1) ¡+ ¡(S1 ¡ � ¡IDS) ¡ + ¡(IDS ¡ � ¡S2) ¡+ ¡(S2 ¡ � ¡A) • What to do if next hop fails? GW S1 IDS S2 A 7 Friday, August 16, 13

  22. Our Approach: FatTire “Fault Tolerating Regular Expressions” Key Ingredients: • Hop-by-hop forwarding → paths • Deterministic → non-deterministic • Explicit fault-tolerance constructs Challenges: • FatTire programs may specify overlapping paths • OpenFlow tables are deterministic • Global analysis to provide fault-tolerance guarantees 8 Friday, August 16, 13

  23. ¡ ( All ¡ � ¡[GW ¡* ¡A] ) • Connectivity from GW to A ∩ ¡ ¡SSH ¡ � ¡[* ¡IDS ¡*] ( ) • SSH traffic traverses IDS ¡ ¡ ∪ ¡¬SSH ¡ � ¡[*] ∩ ¡ ¡SSH ¡ � ¡[*] ¡with ¡1 ¡ • SSH is 1 link fault tolerant ( ) ¡ ¡ ∪ ¡¬SSH ¡ � ¡[*] S1 GW IDS A S2 Traffic 9 Friday, August 16, 13

  24. Programming in FatTire Write programs in terms of regular expressions on forwarding paths • [GW ¡* ¡A] • [GW ¡(S1 ¡| ¡S2) ¡A] Use annotations to specify desired fault tolerance • SSH ¡ � ¡[*] ¡with ¡1 • ¬SSH ¡ � ¡[*] ¡= ¡¬SSH ¡ � ¡[*] ¡with ¡0 10 Friday, August 16, 13

  25. Programming in FatTire Can combine policies with intersection and union: • Intersection adds restrictions on paths ( All ¡ � ¡[GW ¡* ¡A]) ¡ ∩ ¡(SSH ¡ � ¡[*] ¡with ¡1) = SSH ¡ � ¡[GW ¡* ¡A] ¡with ¡1 • Union loosens restrictions on paths ( All ¡ � ¡[GW ¡S1 ¡A]) ¡ ∪ ¡(All ¡ � ¡[GW ¡S2 ¡A]) = All ¡ � ¡[GW ¡(S1 ¡| ¡S2) ¡A] 11 Friday, August 16, 13

  26. FatTire Compiler ∪ ... ∪ 1. Normalize into Disjunctive Normal Form ∩ ∩ ∩ ∩ 2. Partition into traffic equivalence classes ... 3. Compute fault-tolerant forwarding graph GW S1 S2 4. Output hop-by-hop Frenetic policy and IDS IDS S1 compile to OpenFlow rules !!((GW!! ! !S1)! ⊕ !(GW! ! !S2))! +!((S1! ! !IDS)! ⊕ !(S2! ! !IDS)) 12 Friday, August 16, 13

  27. Implementation • Full working prototype implemented in OCaml • Based on an extension of the Frenetic controller with support for OpenFlow 1.3 • Tested on CPqD 1.3 software switch • See paper for preliminary experimental evaluation using Mininet • Code available from https://github.com/frenetic-lang/fattire under an open-source license 13 Friday, August 16, 13

  28. Future Work • Extend to handle quantitative path properties • Bandwidth • Latency • Provide first-class support for other topology changes such as switch failures • Investigate applications of non-deterministic network programs • Investigate other recovery mechanisms 14 Friday, August 16, 13

  29. Thank You FatTire Team: Marco Canini Mark Reitblatt Papers, source code, examples, tutorials, etc. http://frenetic-­‑lang.org Arjun Guha Nate Foster 15 Friday, August 16, 13

  30. Backup Slides 16 Friday, August 16, 13

  31. Update consistency • Semantics of failure recovery => per-packet consistency 17 Friday, August 16, 13

  32. Regular Expression Derivatives 18 Friday, August 16, 13

  33. Path Expressions as verification spec • Dual use as verification specification? 19 Friday, August 16, 13

  34. Interaction of paths ¡ ¡All ¡ � ¡[S1.FW.S3] ¡ ∪ ¡ALL ¡ � ¡[S2.FW.S4] S1 S3 FW S2 S4 20 Friday, August 16, 13
