Fate of HIV-1 infected cells under suppressive ART Fabian Otte - - PowerPoint PPT Presentation

Fabian Otte Molecular Virology DBM Basel AREVIR cologne 03.05.2019

Fate of HIV-1 infected cells under suppressive ART

2

Infection without therapy

• In early infection patients harbor 80-90 % R5 viruses
• In absence of therapy X4 proportion in 50% of patients increases concomitant with

transition to AIDS

Regoes, R. R. & Bonhoeffer, S. The HIV coreceptor switch: a population dynamical perspective. doi:10.1016/j.tim.2005.04.005

3

Infection wi with therapy

• In early infection patients harbor 80-90 % R5 viruses
• In absence of therapy X4 increases concomitant with transition to AIDS in 50% of patients
• under successfull therapy X4 viruses are markedly reduced 1
• Patients presenting as R5 at

beginning of cART stay R5

• In 80% of patients no increase in X4

viral frequency

• MOTIVATE Study 2

☛ Synergy of cART and recovering immune system that readily detects X4 (less glycosylation)

1 Bader, J. et al. Therapeutic immune recovery prevents emergence of CXCR4-tropic HIV-1. Clin. Infect. Dis. ciw737 (2016). doi:10.1093/cid/ciw737 2 Westby, M. et al. Emergence of CXCR4-Using Human Immunodeficiency Virus Type 1 (HIV-1) Variants in a Minority of HIV-1-Infected Patients following Treatment

with the CCR5 Antagonist Maraviroc Is from a Pretreatment CXCR4-Using Virus Reservoir. J. Virol. 80, 4909–4920 (2006).

4

Observations: GALT major HIV reservoir

• GALT ( encompasing >50% of IS) gets depleted during acute phase of HIV infection and

does not recover 1

• total body SIV burden almost solely in GALT after therapy 2

1Guadalupe, M. et al. T-Cell Depletion in Gut Lymphoid Tissue during Primary Human Immunodeficiency Virus Type 1 Infection and Substantial Delay in Restoration

following Highly Active Antiretroviral Therapy. J. Virol. 77, 11708–11717 (2003).

2 Estes, J. D. et al. Defining total-body AIDS-virus burden with implications for curative strategies. Nat. Publ. Gr. (2017). doi:10.1038/nm.4411

Therapy naÏve LTNP HIV neg Therapy naÏve LTNP HIV neg

5

5

Observations: Compartmentalization

• GALT ( encompasing >50% of IS) gets depleted during acute phase of HIV infection and never

recovers 1

• provirus stable after initial decay 3
• no recombination of X4 and R5 virus 4

3 Besson, G. J. et al. HIV-1 DNA Decay Dynamics in Blood During More Than a Decade of Suppressive Antiretroviral Therapy. doi:10.1093/cid/ciu585

4 Zhou, S., Bednar, M. M., Sturdevant, C. B., Hauser, B. M. & Swanstrom, R. Deep Sequencing of the HIV-1 env Gene Reveals Discrete X4 Lineages and Linkage Disequilibrium between X4 and R5 Viruses in the V1/V2 and V3 Variable Regions. J. Virol. 90, 7142–58 (2016).

6

Hypothesis

I. The differences in tropism (X4 vs R5) leads to district compartmentalization (e.g. due to half-life, immune clearance) , assessable by homing properties of the CD4 T cells II. GALT-homing plays a key role in HIV persistence, and gut-associated lymphatic cells represent an important reservoir for HIV-persistence III. GALT depletion is a continuous consequence of viral pressure (and therefore dependent on the „GALT homing viral tropism“) ☛ which cells are involved in these “viral dynamics during suppressive therapy” & which respective lymphoid tissue is involved in reservoir formation, stability and viral clearance

Buggert et al. Everything in its right place - resident memory CD8+ T cell immunosurveillance of HIV infection. Current Opinion in HIV and AIDS: 2019-03-V14-2 p93-99

HIV viral reservoir

1 Baxter AE et al. Beyond the replication-competent HIV reservoir: transcription and translation-competent reservoirs. Retrovirology201815:18 2 Ho, Y. C. et al Replication-Competent Noninduced Proviruses in the Latent Reservoir Increase Barrier to HIV-1 Cure 3 Bruner, K. M. et al. Defective proviruses rapidly accumulate during acute HIV-1 infection. Nat Med 22, 1043–1049 (2016).

Bruner et al 2016 3 Ho et al 2013 2 Baxter et al 2018 1 “Detectability”

• f viral

reservoir

8

Proviral enrichment and lymphoid homing

Anti-CD19- Biotin Anti-Biotin- beads

CD19 CD4+ CD4- CD8 CD4- CD4+

Arbitrarily chosen SHCS surplus material:

• Depletion of unrelevant cells: CD8 (CTL), CD19 (B-cells) -> negative control
• Enrichment for cells of interest: CD4+ vs CD4- (Vpu,Nef), CCR7+ vs CCR7-,

Integrin ß7+ vs ß7-

• Proviral loads of sorted cells

☛ first indications of proviral enrichment (of intact viruses)? Adapted from Miltenyi Biotec

9

MACS: gut (Integrin ß7) vs LN (CCR7)

10

Identification of the viral reservoir

1) Staining 2) Data Acquisition and Analysis (tSNE)

• 2. ICS GAG
• 1. Surface +

Env staining Surface HIV-1 Env and intracellular Gag expression Activation 36-40h

HIV-1 chronically infected cell line

HUT4-3: chronically infected cell line SupT1: uninfected lymphpcyte cell line, susceptible to HIV-1 DP DN

Lymphocyte infection

HIV-1 “Mal” : Subtype D, R5-tropic HIV-1 “Bru” : Subtype B, X4-tropic

Cells Supernatant

CD4+ T-cell infection

HIV-1 “Bru”: Subtype B, X4-tropic HIV-1 “ALA”: Subtype B, X4-tropic

Cells Supernatant

tSNE visualization of patient cells

15

Summary: Identification of the viral reservoir

1) Staining 2) Data Acquisition and Analysis (tSNE) 3) Patient cell sorting

• 1. Sort

RNA seq, FLIP seq

• 2. ICS GAG
• 1. Surface + Env

staining Surface HIV-1 Env and intracellular Gag expression Activation 36-40h

I. Viral compartmentalization (X4 vs R5) II. Viral integration, transcriptome and proviral landscape

• III. Lymphoid homing tropism

16

Outlook

• tSNE: Patients > 10‘000 HIV DNA/10^6 cells: 3-9X10^6 cryo-preserved cells
• FACSorts of viable patient cells for deep HIV Immuno

characterisation of patients (UZH: BSL-3, 4-way) to characterize reactivated virus by SGS/MIP-sequencing

• CyTOF experiments with Dr. Bengsch using PBMC and/or biopsies
• C. Apetrei, I. Pandrea: SIV experiments in simian models regarding

X4- vs R5-tropic infection

• HIV+ Lymph nodes/GALT biopsies for CODEX imaging

17

Acknowledgements

Molecular Virology Lab

• Prof. Thomas Klimkait

Rahel Bircher Jennifer Brown Silvia Caimi Nina Marty Siro Ellenberger Benjamin Schwob Ulrike Seeburg Lorena Urda

PACommitte:

• Prof. C. Dehio (Biozentrum),
• Dr. M. Stöckle (USB)

FACS Core Facility DBM DBM Basel

• Dr. J. Spagnuolo

Uni-Klinik Köln Florian Klein Rolf Kaiser

• Dr. C. Wiethe (Biolegend)

Andrin Wacker, Alain Hirschy (Miltenyi)

Thanks ks for yo your attention!

18

Now is your chance! We urgently need patient cells of either untreated, newly diagnosed or patients with recent treatment initiation We would be very happy to collaborate  Thanks
