Extending Relational Databases Toon Calders t.calders@tue.nl Last Lectures Relational query languages are limited Transitive closure cannot be expressed Gaifman-locality Also w.r.t. data storage relational model is limited

slide-1
SLIDE 1

Extending Relational Databases

Toon Calders t.calders@tue.nl

slide-2
SLIDE 2

Last Lectures

  • Relational query languages are limited
  • Transitive closure cannot be expressed
  • Gaifman-locality
  • Also w.r.t. data storage relational model is limited
  • Also w.r.t. data storage relational model is limited
  • Simple data
  • No set types, arrays, …
slide-3
SLIDE 3

This lecture

  • Extending SQL
  • Recursion
  • Nested relations
  • Object-oriented and object-relational database
  • Object-oriented and object-relational database

systems

slide-4
SLIDE 4

This lecture

  • Extending SQL
  • Recursion
  • Nested relations
  • Object-oriented and object-relational database
  • Object-oriented and object-relational database

systems

slide-5
SLIDE 5

Recursion in SQL

  • SQL:1999 permits recursive view definition
  • Example: find all employee-manager pairs, where

the employee reports to the manager directly or indirectly (that is manager’s manager, manager’s manager’s manager, etc.) manager’s manager, etc.) This example view, empl, is called the transitive closure of the manager relation

slide-6
SLIDE 6

Recursion in SQL

with recursive empl (employee_name, manager_name ) as ( select employee_name, manager_name from manager union select manager.employee_name, empl.manager_name from manager, empl where manager.manager_name = empl.employee_name ) select * from empl

slide-7
SLIDE 7

This lecture

  • Extending SQL
  • Recursion
  • Nested relations
  • Object-oriented and object-relational database
  • Object-oriented and object-relational database

systems

slide-8
SLIDE 8

Nested Relations

  • Very simple example:
  • Class book

− set of authors − title − set of keywords − set of keywords

Extremely simple to model in any programming language Hard in relational database!

slide-9
SLIDE 9

Nested Relations

  • Either we ignore the multivalued dependencies

Title Author Keyword Database System Concepts Silberschatz Database Database System Concepts Korth Database

  • This table is in 3NF, BCNF

Database System Concepts Sudarshan Database Database System Concepts Silberschatz Storage Database System Concepts Korth Storage Database System Concepts Sudarshan Storage

slide-10
SLIDE 10

Nested Relations

  • Or we go to 4NF

Title Author Database System Concepts Silberschatz Database System Concepts Korth Database System Concepts Korth Database System Concepts Sudarshan Title Keyword Database System Concepts Database Database System Concepts Storage

slide-11
SLIDE 11

Nested Relations

  • 4NF design requires users to include joins in their

queries.

  • 1NF relational view
  • eliminates the need for users to perform joins,
  • but loses the one-to-one correspondence between
  • but loses the one-to-one correspondence between

tuples and objects.

  • has a large amount of redundancy
slide-12
SLIDE 12

Nested Relational Algebra

  • Types:
  • Set of constants C = {c1,c2, …}
  • If T1, …, Tk are types, then also {(T1,…,Tk)}
  • Domain:
  • Domain:
  • Dom(C) = {c1,c2, …}
  • Dom ( {(T1,…,Tk)} ) = P( { (x1,…,xk) | xi ∈

∈ ∈ ∈Ti, 1 i k} )

slide-13
SLIDE 13

Nested Relational Algebra

  • Example:
  • C = {1,2,3,…}
  • Type { (C, { ( C, { (C) } ) } ) } has domain:

− {(C)}

  • { {}, {(1)}, {(2)}, {(1),(2)}, ... }
  • Set of natural numbers
  • Set of natural numbers

− { ( C, { (C) } ) }

  • Set of pairs (c,S), c is a number,

S a set of numbers − All

  • Set of pairs (c,T), T is set of pairs (c,S)
slide-14
SLIDE 14

Nested Relational Algebra

  • Nested relation of type (T1,…,Tn)
  • Subset of Dom( {(T1,…,Tn)} ).
  • Nested relational algebra
  • The usual operators σ

σ σ σ, π π π π, × × × ×, -, ∩ ∩ ∩ ∩,∪ ∪ ∪ ∪

  • The usual operators σ

σ σ σ, π π π π, × × × ×, -, ∩ ∩ ∩ ∩,∪ ∪ ∪ ∪

  • Also Nest and Unnest:

− U$i (R): remove nesting from ith column of R − N$i1, …$ik (R): nest columns $i1 … $ik

slide-15
SLIDE 15

Nested Relational Algebra

R = { ( a, b ), ( a, c ), ( d, b ), ( d, c ) } N$2 R ={ ( a, {b,c} ), ( d, {b,c} ) } U$2 (N$2 R) produces again original R

slide-16
SLIDE 16

Flat-Flat Theorem

  • Let Q be a nested-relational algebra expression
  • Q takes a non-nested relation as input
  • Q produced a non-nested relation as output
  • Type (C,…,C)
  • (C,…,C)
  • Then:
  • Then:
  • Q can be rewritten as a normal relational algebra

expression; (i.e., one without nesting)

  • Result is actually stronger:
  • Nested d deep
  • nested d’ deep: no need for

intermediate results having depth > d, d’

slide-17
SLIDE 17

Flat-Flat Theorem

  • Importance?
  • Can be used by query optimizers
  • No need to introduce intermediate nesting
  • Standard techniques can be used
slide-18
SLIDE 18

Nesting in SQL

  • Nesting is the opposite of unnesting, creating a

collection-valued attribute

  • Many commercial database systems support nesting

in one way or another in one way or another

  • NOTE: SQL:1999 does not support nesting
  • Nesting can be done in a manner similar to

aggregation, but using the function set() in place of an aggregation operation, to create a set

slide-19
SLIDE 19

Nesting in SQL

select title, author, pub_name, pub_branch, set(keyword) as keyword-list from flat-books groupby title, author, pub_name, pub_branch select title, set(author) as author-list, pub_name, pub_branch, set(keyword) as keyword-list from flat-books groupby title, pub_name, pub_branch,

slide-20
SLIDE 20

Nesting (Cont.)

  • Another approach to creating nested relations is to

use subqueries in the select clause.

select title, ( select author from flat-books as M where M.title=O.title) as author-set, pub-name, pub-branch, (select keyword from flat-books as N where N.title = O.title) as keyword-set from flat-books as O

slide-21
SLIDE 21

This lecture

  • Extensions to SQL
  • Recursion
  • Enumeration types
  • Nested relations
  • Object-oriented and object-relational database

systems

slide-22
SLIDE 22

Motivation for OO Databases

  • Many applications require the storage and

manipulation of complex data

  • design databases
  • geometric databases
  • …
  • …
  • Object-Oriented programming languages manipulate

complex objects

  • classes, methods, inheritance, polymorphism
slide-23
SLIDE 23

Motivation for OO Databases

  • In many applications persistency of the data is

nevertheless required

  • protection against system failure
  • consistency of the data
  • Mapping: object in OO language
  • tuples of atomic

values in relational database is often problematic

  • Impedance mismatch
slide-24
SLIDE 24

Motivation for OO Databases

  • Need for object-oriented features in databases
  • Object-Oriented Databases
  • Object-Relational Databases
  • Need for more powerful data manipulation
  • Need for more powerful data manipulation
  • Extend expressive power of SQL; include functions,

recursion

slide-25
SLIDE 25

Motivation for OO Databases

  • Often we want to manipulate the data in the database

itself

  • no data transmission costs
  • client has limited computation power
  • Expressive power of SQL is quite limited
  • allows for efficient query optimization
  • disallows complex data operations
slide-26
SLIDE 26

Motivation for OO Databases

  • Whole spectrum:

Relational Object Persistent OO Database

  • Relational
  • Programming

Database Language Database Language

slide-27
SLIDE 27

Complex Types and SQL:1999

  • Extensions to SQL to support complex types

include:

  • Collection and large object types

− Nested relations are an example of collection types types

  • Structured types

− Nested record structures like composite attributes

  • Inheritance
  • Object orientation

− Including object identifiers and references

slide-28
SLIDE 28

Structured Types and Inheritance in SQL

  • Structured types can be declared and used in SQL

create type Name as (firstname varchar(20), lastname varchar(20)) final create type Address as create type Address as (street varchar(20), city varchar(20), zipcode varchar(20)) not final

  • Note: final and not final indicate whether subtypes can be

created

slide-29
SLIDE 29

Structured Types and Inheritance in SQL

  • Structured types can be used to create tables with

composite attributes create table customer ( name Name, address Address, address Address, dateOfBirth date )

  • Dot notation used to reference components:

Name.firstname

slide-30
SLIDE 30

Methods

  • Can add a method declaration with a structured type.

method ageOnDate (onDate date) returns interval year

  • Method body is given separately.

create instance method ageOnDate (onDate date) create instance method ageOnDate (onDate date) returns interval year for CustomerType begin return onDate - self.dateOfBirth; end

slide-31
SLIDE 31

Inheritance

  • Suppose that we have the following type definition for

people:

slide-32
SLIDE 32

Object-Identity and Reference Types

  • Define a type Department with a field name and a

field head which is a reference to the type Person, with table people as scope: create type create type Department ( name varchar (20), head ref (Person) scope people)

  • We can then create a table departments as follows

create table departments of Department

slide-33
SLIDE 33

Persistent Programming Languages

  • Languages extended with constructs to handle

persistent data

  • Programmer can manipulate persistent data directly
  • no need to fetch it into memory and store it back to disk

(unlike embedded SQL) (unlike embedded SQL)

  • Persistent objects:
  • by class - explicit declaration of persistence
  • by creation - special syntax to create persistent objects
  • by marking - make objects persistent after creation
  • by reachability - object is persistent if it is declared

explicitly to be so or is reachable from a persistent

  • bject
slide-34
SLIDE 34

Object Identity and Pointers

  • Degrees of permanence of object identity
  • Intraprocedure: only during execution of a single

procedure

  • Intraprogram: only during execution of a single

program or query program or query

  • Interprogram: across program executions, but not if

data-storage format on disk changes

  • Persistent: interprogram, plus persistent across data

reorganizations

slide-35
SLIDE 35

Object Identity and Pointers

  • Persistent versions of C++ and Java have been

implemented

  • C++

− ODMG C++ − ObjectStore − ObjectStore

  • Java

− Java Database Objects (JDO)

slide-36
SLIDE 36

Comparison of O-O and O-R Databases

  • Relational systems
  • simple data types, powerful query languages, high

protection.

  • Persistent-programming-language-based OODBs
  • complex data types, integration with programming

language, high performance. language, high performance.

  • Object-relational systems
  • complex data types, powerful query languages, high

protection.

  • Note: Many real systems blur these boundaries
  • E.g. persistent programming language built as a

wrapper on a relational database offers first two benefits, but may have poor performance.

slide-37
SLIDE 37

Self-Study

  • Read Chapter 9 of the book “Database System

Concepts, 5th edition”.

  • Corresponds roughly to Chapters 8 and 9 of the 4th

edition, except the parts on ODMG (sections 8.5.1 and 8.5.2) which are not present in the 5th edition anymore.

  • During the lecture of next Friday 20/02/09 there will be

time for questions and answers regarding the topics covered in this book chapter.
