SLIDE 1

Exploring the Use of TensorFlow to Predict Connection Table Information within Chemical Structures

Brodie Schroeder

SLIDE 2

Machine Learning Basics

Gives "computers the ability to learn without being explicitly programmed."
Arthur Samuel
Goal is to solve problems with “generalized” algorithms that apply to many

different problems

Unsupervised and supervised learning
Artificial Neural Networks and Deep Learning

SLIDE 3

= ?

SLIDE 4

SLIDE 5

Basic Artificial Neural Network

SLIDE 6

SLIDE 7

SLIDE 8

SLIDE 9

y = <activation func>(Wx + b)

Softmax, Sigmoid, ReLU...

SLIDE 10

= ?

SLIDE 11

y = [0,0,1,0,0,0,0,0,0,0]

The image appears to be a ‘2’

SLIDE 12

Goal for this Project

Given the XYZ coordinates of atoms and their bonding information within a chemical structure, predict a bonding table for all atoms.

SLIDE 13

Example Dataset

benzene ACD/Labs0812062058 6 6 0 0 0 0 0 0 0 0 1 V2000 1.9050 -0.7932 0.0000 C 1.9050 -2.1232 0.0000 C 0.7531 -0.1282 0.0000 C 0.7531 -2.7882 0.0000 C

0.3987 -0.7932 0.0000 C
0.3987 -2.1232 0.0000 C

2 1 1 0 0 0 0 3 1 2 0 0 0 0 4 2 2 0 0 0 0 5 3 1 0 0 0 0 6 4 1 0 0 0 0 6 5 2 0 0 0 0 M END $$$$ XYZ coordinates and the atom type. This will be the ‘x’ input in our model. Connection information for bonding between atoms. We will use this to train our model.

SLIDE 14

2.345, 1.652, 4.791, C 4.562, 8.345, 2.221, C 9.821, 3.323, 4.124, C 8.421, 5.341, 9.981, O 7.623, 3.253, 7.456, C 4.221, 6.213, 4.343, O

Parsing SDF Files

6.0, 0.0, 4.312, 6.223, 7.321, 3.221, 9.023, 6.0, 1.542, 0.0, 4.222, 8.231, 6.321, 1.999, 6.0, 2.221, 5.012, 0.0, 4.223, 6.723, 7.232, 8.0, 7.010, 3.011, 7.221, 0.0, 5.434, 7.777, 6.0, 4.312, 3.221, 3.563, 7.212, 0.0, 6.521, 8.0, 2.333, 5.321, 6.872, 6.454, 8.991, 0.0,

Atomic Number of Atom Euclidean Distance Between Atoms

SLIDE 15

2, 1, 1, 3, 1, 2, 4, 2, 2, 5, 3, 1, 6, 4, 1, 6, 5, 2,

Parsing SDF Files

0.0, 1.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0,

Boolean Array of Connections

SLIDE 16

Input and Training Data

6.0, 0.0, 4.312, 6.223, 7.321, 3.221, 9.023, 6.0, 1.542, 0.0, 4.222, 8.231, 6.321, 1.999, 6.0, 2.221, 5.012, 0.0, 4.223, 6.723, 7.232, 8.0, 7.010, 3.011, 7.221, 0.0, 5.434, 7.777, 6.0, 4.312, 3.221, 3.563, 7.212, 0.0, 6.521, 8.0, 2.333, 5.321, 6.872, 6.454, 8.991, 0.0, 0.0, 1.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 1.0, 0.0, 0.0, 0.0, 1.0, 1.0, 0.0,

6 x 7 = 42 6 x 6 = 36 x = y_ =

SLIDE 17

Build two Python lists
List ‘a’ is a list of flattened 2d NumPy matrices containing euclidean

distances and atom type

List ‘b’ is a list of flattened 2d NumPy matrices containing bonding

information for all atoms

Matrix size is capped at 28 x 29 and 28 x 28 respectively (only molecules

with less than or equal to 28 atoms are included)

If smaller than 28 atoms the matrix is padded with zeros
a[n] corresponds to b[n]

Input and Training Data

SLIDE 18

What is TensorFlow ?

“Open source software library for numerical computation using data flow
graphs. Nodes in the graph represent mathematical operations, while the

graph edges represent the multidimensional data arrays (tensors) communicated between them.”

Provides an API that makes it easy to setup, design and train deep learning

models.

SLIDE 19

Building the Model

x = tf.placeholder(tf.float32, [None, 812]) W1 = tf.Variable(tf.truncated_normal([812, 784], stddev=0.1)) b1 = tf.Variable(tf.truncated_normal([784], stddev=0.1)) W2 = tf.Variable(tf.truncated_normal([784, 784], stddev=0.1)) b2 = tf.Variable(tf.truncated_normal([784], stddev=0.1)) W3 = tf.Variable(tf.truncated_normal([784, 784], stddev=0.1)) b3 = tf.Variable(tf.truncated_normal([784], stddev=0.1)) W = tf.Variable(tf.truncated_normal([784, 784], stddev=0.1)) b = tf.Variable(tf.truncated_normal([784], stddev=0.1)) layer1 = tf.add(tf.matmul(x, W1), b1) layer1 = tf.nn.relu(layer1) layer2 = tf.add(tf.matmul(layer1, W2), b2) layer2 = tf.nn.relu(layer2) layer3 = tf.add(tf.matmul(layer2, W3), b3) layer3 = tf.nn.relu(layer3) y = tf.add(tf.matmul(layer3, W), b) y = tf.nn.sigmoid(y) y_ = tf.placeholder(tf.float32, [None, 784])

SLIDE 20 cross_entropy = tf.reduce_mean(tf.nn.sigmoid_cross_entropy_with_logits(labels=y_, logits=y)) train_step = tf.train.AdamOptimizer(0.001).minimize(cross_entropy) sess = tf.InteractiveSession() tf.global_variables_initializer().run() a, b = get_batch() train_len = len(a) correct_prediction = tf.equal(y_, y) accuracy = tf.reduce_mean(tf.cast(correct_prediction, tf.float32)) # Training for i in range(train_len): batch_xs = a[i] batch_ys = b[i] _, loss, acc = sess.run([train_step, cross_entropy, accuracy], feed_dict={x: batch_xs, y_: batch_ys}) print("Loss= " + "{:.6f}".format(loss) + " Accuracy= " + "{:.5f}".format(acc))

Building the Model

SLIDE 21 # Test trained model cumulative_accuracy = 0.0 for i in range(train_len): acc_batch_xs = a[i] acc_batch_ys = b[i] cumulative_accuracy += accuracy.eval(feed_dict={x: acc_batch_xs, y_: acc_batch_ys}) print("Test Accuracy= {}".format(cumulative_accuracy / train_len))

Building the Model

SLIDE 22

Results thus far...

SLIDE 23

Test Accuracy = 0.865

Apprx. 10,000 training sets

SLIDE 24

Future Improvements and Optimization

Cache results of parsing SDF file
Improve code for calculating distances
Improve initial values of weights
Overtraining or undertraining?
TensorBoard visualization

SLIDE 25

Questions?

View the code: https://github.com/Allvitende/chemical-modeling/
