Chilled Beam Design Principles
How is capacity measured?
- Tested & reported as an assembly
- Is not simply a sum of component capacity
- ASHRAE Standard 200
How is capacity certified? AHRI Standard 1240/1241 certification program
More information:
3
Chilled Beam Design Principles
Agenda
- WBCS Concept
- Occupant Comfort
- Establishing Primary Airflow Rate
- Energy Impact
- Demand Control Ventilation
- WBCS Concept
- Occupant Comfort
- Establishing Primary Airflow Rate
- Energy Impact
- Demand Control Ventilation
4 2015-12-15 Establishing Primary Airflow
Focusing on what our customers care about
5 2015-12-15 Establishing Primary Airflow
- Comfort vs. Capacity
- System Design vs. Product Features
VS.
Water Borne Climate System Concept
6 2015-12-15
Transportation Costs
7 2015-12-15 Company Presentation
Air
10” duct Capacity 9900 Btuh (20 ft/s Δt 14F)
Water
3/4” pipe Capacity 9900 Btuh (110 ft/m Δt 7F)
- How a chilled beam works
WBCS Basics
9
- 1-Way
2-Way 4-Way 1-Way 1-Way
Chilled Beams and Occupant Comfort
11 2015-12-15
Heating/Cooling Capacity & Air Distribution
- A chilled beam is a combination energy source
and air distribution system so the selection is doubly important.
- The space air distribution is equally important
to capacity in determining the comfort level. Poor air distribution will result in poor comfort no matter how much capacity is available.
- A chilled beam is a combination energy source
and air distribution system so the selection is doubly important.
- The space air distribution is equally important
to capacity in determining the comfort level. Poor air distribution will result in poor comfort no matter how much capacity is available.
Chilled Beam – Energy source + air diffuser
14
Controllable by chilled beam Metabolic rate x Clothing insulation x Air temperature
- Radiant temperature
x Air speed
- Air direction / throw
- Humidity
x User adjustability
- ASHRAE Standard 55 Comfort Considerations
Air Distribution
Mixed Systems Mixed Systems
- All the air in the space is
mixed to same the same temperature
- Overhead mixed air
systems use Coanda effect
- Most beams are based
- n mixed air approach
(overhead)
- All the air in the space is
mixed to same the same temperature
- Overhead mixed air
systems use Coanda effect
- Most beams are based
- n mixed air approach
(overhead) Displacement Systems Displacement Systems
- Air is introduced at floor
level at very low velocities
- Space is deliberately
stratified
- Only the occupant zone is
conditioned
- Air is introduced at floor
level at very low velocities
- Space is deliberately
stratified
- Only the occupant zone is
conditioned
15 2015-12-15 Company Presentation
!
Coanda effect
"# $% "% $
Thanks to the negative pressure, the air follows the ceiling instead of falling straight down when it leaves the module When the air reaches the occupied zone, it has attained a temperature and speed that reduces the risk of draft
17
Induction and Coanda Effect
Creating Coanda Effect
18
Diffuser nozzle design
- Beams have built in “Diffuser” technology
- Beam selection and placement to ensure comfort is
an important as when selecting diffusers
- “One big beam in a space may meet cooling load but
may not deliver the comfort that two smaller beams would deliver”
Airflow Pattern
19 2015-12-15 Company Presentation
- Beams can offer wide range of airflow patterns to
suit space
20 2015-12-15 Indoor Climate Systems - Water based or Air?
2-way discharge strategy
- Uses only small area of the ceiling
- Air volume distributed into narrow region
4-way discharge strategy
- Maximizes use of available ceiling area
- Air volume distributed diffusely, more slowly
- Flexible discharge patterns / field adjustable
Beam Selection For Comfort
WBCS Primary Airflow Analysis
21 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Compare Office Vs. School
2015-12-15 Company Presentation 22
Cooling Load Summary
23 2015-12-15 Company Presentation
Sensible Load Latent Load Total Load SHR Btu/h Btu/h-ft² Btu/h Btu/h-ft² Btu/h Btu/h-ft² Classroom 24756 24.8 7795 7.8 32551 32.6 0.76 Office 23116 23.1 2573 2.6 25688 25.7 0.9
Cooling Load Calculations
- Loads same regardless of
HVAC system
- Fancoil, WSHP, GSHP and
VRF need zone latent and sensible loads separate from outdoor air load
- WBCS need zone sensible
load separate from zone latent load and outdoor air latent and sensible load
- Loads same regardless of
HVAC system
- Fancoil, WSHP, GSHP and
VRF need zone latent and sensible loads separate from outdoor air load
- WBCS need zone sensible
load separate from zone latent load and outdoor air latent and sensible load
24 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
WBCS Primary Airflow Design
- The primary airflow rate must be the larger of;
- The air flow rate to meet the ventilation rate required
to deliver acceptable indoor air quality.
- The airflow rate to provide latent cooling in the zone.
- The airflow rate required to assist in meeting the zone
sensible cooling rate.
- The primary airflow rate must be the larger of;
- The air flow rate to meet the ventilation rate required
to deliver acceptable indoor air quality.
- The airflow rate to provide latent cooling in the zone.
- The airflow rate required to assist in meeting the zone
sensible cooling rate.
25 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Ventilation Rate
- Office
- Ventilation rate = 10 x 5 cfm
+ 0.06 x 1000 ft² = 110 cfm
- = 0.11 cfm/ft²
- Classroom
- Ventilation rate = 30 x 10 cfm
+ 0.12 x 1000 ft² = 423 cfm
- = 0.42 cfm/ft²
- Office
- Ventilation rate = 10 x 5 cfm
+ 0.06 x 1000 ft² = 110 cfm
- = 0.11 cfm/ft²
- Classroom
- Ventilation rate = 30 x 10 cfm
+ 0.12 x 1000 ft² = 423 cfm
- = 0.42 cfm/ft²
26 2015-12-15 Company Presentation
Latent Rate
27 2015-12-15 Company Presentation 75 °F DB 50% RH 64.6 gr/lb HR
Qp = Platent/(0.68 x (Wr- Wprimary air))
Sensible Rate
28 2015-12-15 Company Presentation 75 °F DB 50% RH 64.6 gr/lb HR
Qp = Psensible /(1.085 x ((Tr – Tp) + IR x (Tr – Ta))
Primary Airflow Summary
- Can’t go below ventilation rate
- Latent load usually dominates
- Offices 0.4 to 0.6 cfm/ft², 53 °F off coil
- Classroom 0.6 to 0.8 cfm/ft², 49 °F off coil (reheat
required)
- Can’t go below ventilation rate
- Latent load usually dominates
- Offices 0.4 to 0.6 cfm/ft², 53 °F off coil
- Classroom 0.6 to 0.8 cfm/ft², 49 °F off coil (reheat
required)
Ventilation Rate Latent Rate Sensible Rate Btu/h cfm/ft² Btu/h cfm/ft² Btu/h cfm/ft² Classroom 423 0.43 740 0.75 761 0.76 Office 110 0.11 461 0.46 333 0.33
29 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Primary Airflow Summary
- The zone sensible cooling load should be
between 20 to 40 Btu/h·ft².
- The primary airflow will be most likely set by
the zone latent load. A good range is 0.4 to 0.6 cfm/ft².
- A good office system has 1/3 of the load met
by the primary air and 2/3 of the load met by the chilled beam coil.
- Assume an induction ratio between 2.5 to 3.5.
Start with 3.
- The zone sensible cooling load should be
between 20 to 40 Btu/h·ft².
- The primary airflow will be most likely set by
the zone latent load. A good range is 0.4 to 0.6 cfm/ft².
- A good office system has 1/3 of the load met
by the primary air and 2/3 of the load met by the chilled beam coil.
- Assume an induction ratio between 2.5 to 3.5.
Start with 3.
30 2015-12-15 Company Presentation
Primary Airflow Summary
- The chilled water supply temperature should
be 2-3 °F above space dew point. 57 °F is a common supply water temperature.
- The chilled water temperature range will be 4
to 6 °F. Consider putting the primary air system in series with the chilled beams.
- The chilled water supply temperature should
be 2-3 °F above space dew point. 57 °F is a common supply water temperature.
- The chilled water temperature range will be 4
to 6 °F. Consider putting the primary air system in series with the chilled beams.
31 2015-12-15 Company Presentation
WBCS Energy Considerations
32 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Design vs. Annual Energy Usage
33 2015-12-15 Company Presentation Fans 25% Chiller 56% Pumps 14% Tower 5%
Design Day
Fans 44% Chiller 32% Pumps 21% Tower 3%
Annual
Annual Cooling Load Profile
34 2015-12-15 Company Presentation
50 100 150 200 250 300 350 400 450 500 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 Hours Percent Cooling Load
Standard DOAS Unit
35 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Primary Airflow vs. Delta Humidity Ratio
12/15/2015 36
- All points of curve deliver same amount latent cooling to space
Platent = 0.68*Qp* (Wr – Wprimary air )
10 20 30 40 50 60 70 80 90 100 3.8 6.1 8.3 10.5 12.6 14.6 16.5
Primary Airflow (cfm) Delta Humidity Ratio (gr/lb)
Cooling Capacity of Primary Airflow
37 12/15/2015
10 20 30 40 50 60 70 80 90 100 2062 1352 1043 864 753 678 625
Primary Airflow (cfm) Primary Air Sensible Capacity (Btu/h)
- Primary cooling capacity drops off as airflow is reduced
- Shifts load to beam
Primary Airflow vs. Induction Ratio
38 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
10 20 30 40 50 60 70 80 90 100 1.1 2.8 4.4 5.9 7.4 8.9 10.2
Priamry Airflow (cfm) Induction Ratio
- Higher beam load requires higher induction rate
- APD and noise become issue
DOAS Energy Model Design Parameters
Off Coil DB SA DB SA HR Delta HR SA Airflow F F gr/lb gr/lb cfm 55 56 62.6 3.8 100 54 55 60.3 6.1 62 53 54 58.1 8.3 46 52 53 55.9 10.5 36 51 52 53.8 12.6 30 50 51 51.8 14.6 26 49 50 49.9 16.5 23
39 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Annual Energy Usage Std DOAS Unit
40 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
0.0 100.0 200.0 300.0 400.0 500.0 600.0 700.0 100 62 46 36 30 26 23
Annual Energy Usage (kWh) Primary Airflow (cfm)
Rotor BIN Watts kWh SA Fan BIN Watts kWh Chiller Plant BIN Watts kWh HW Plant BIN Watts kWh RA Fan BIN Watts kWh
Energy Analysis Summary
- Fan work is dominant
- Generally shifting sensible load to beams from primary
is more efficient
- Practical limitation on induction ratio (5) and primary
air temperature (53 °)
- Reheat increases operating cost – only do it if you
have to (schools)
- Fan work is dominant
- Generally shifting sensible load to beams from primary
is more efficient
- Practical limitation on induction ratio (5) and primary
air temperature (53 °)
- Reheat increases operating cost – only do it if you
have to (schools)
41 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
Demand Control Ventilation
Demand Control Ventilation
- Classrooms occupied 35%
- Offices occupied 22-38%
- ASHRAE Std 90.1
- 500 ft²
- 25 people per 1000 ft²
- greater than 3000 cfm
- ASHRAE Std 62
- Minimum airflow ≥ building load
component (Ra x Az)
- Classrooms occupied 35%
- Offices occupied 22-38%
- ASHRAE Std 90.1
- 500 ft²
- 25 people per 1000 ft²
- greater than 3000 cfm
- ASHRAE Std 62
- Minimum airflow ≥ building load
component (Ra x Az)
43 2015-12-15 Company Presentation
Demand Control Ventilation
- Vary Primary airflow based on
- Occupancy
- Temperature
- CO2
- VOC
- Vary Primary airflow based on
- Occupancy
- Temperature
- CO2
- VOC
44 2015-12-15 Company Presentation
06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00
- 150
200 250
&
- 100
Impact of Reduced Primary Airflow on Induction
50 100 150 200 250 300 350 400 10 20 30 40 50 60 70 80 90 100 110 120 130
- Induced
Primary Chilled Beam with Integral Damper Discharge, chilled beam with upstream VAV damper
12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
45
Demand Control Ventilation Demand Control Ventilation
' ZONE DOAS
Demand Control Ventilation Summary
- DCV increases chilled beam turndown from 3 to 1 to
10 to 1
- Improves occupant comfort
- Spaces are rarely at design occupancy
- DCV allows significant fan power savings
- DCV control can be based on
- Occupancy sensor (single occupant office)
- CO2 or VOC (modulating for multi occupant
spaces)
- DCV increases chilled beam turndown from 3 to 1 to
10 to 1
- Improves occupant comfort
- Spaces are rarely at design occupancy
- DCV allows significant fan power savings
- DCV control can be based on
- Occupancy sensor (single occupant office)
- CO2 or VOC (modulating for multi occupant
spaces)
47 12/15/2015 Intro to ComVent - Establish loads and Primary Airflow
