EnviroConnect – Environment Quality Monitoring System

SLIDE 2

Envir viroC

Connect

nnect About AIPL Case Studies

SLIDE 3

Web based Environment Quality Monitoring System for Stack Emissions Ambient Air Quality Water Quality ETP / STP output quality

EnviroConnect

Designed with Indian Central Pollution Control Board (CPCB) Guidelines

SLIDE 4

EnviroConnect Applications

Stack Emissions and Ambient Air Quality

monitoring within Power Plants, Steel Plants, Cement Plants etc.

Water Quality monitoring in Effluent Treatment

Plants, Sewage Treatment Plants, etc.

Process gas monitoring
Nationwide network for Stack and Ambient Air

monitoring

Sending air and water quality data to pollution

control boards

SLIDE 5

Deployment Diagram

SLIDE 6

EnviroConnect Features

Data Acquisition

Data acquisition from multiple Ambient Analyzers,

CEMS Analyzers, Flue Gas Analyzers, Water analyzers, SPM Analyzers, Dust Monitors Flow meters, Weather Stations etc. at single or multiple locations

All data collected on EnviroConnect web server
Accessible to clients from anywhere, anytime

(24x7)

Clients use a standard browser on PC / tablet / cell

phone

SLIDE 7

Connectivity Device drivers available for gas analyzers, SPM analyzers, dust monitors from following companies and the list is growing –

Forbes Marshall CODEL
Thermo fisher
Siemens
Teledyne API
Met One
PCME
Eco Physics
Horiba
Recordum (airpointer)
Standard drivers like Modbus, GSI available
Others developed on request

SLIDE 8

Visualization

Hierarchical tree view of all

sites at a glance

System and device level

dashboards with customized widgets

Real-time data trends and

values

Real time display on digital

display boards

SLIDE 9

Historical Data

Historical data – average, min, max
Historical trend
Choose from 5 / 10 / 30 / 60 minutes and daily

averages

Data export to excel (.csv), html, pdf formats
Data flagging for
Total range
Measurement range
Permissible range
% validity
Calibration and maintenance

SLIDE 10

Alarm definition

Define alarms for instantaneous values of

CEMS crossing permissible range. These can be defined per industry as per individual limits set by PCB

Ambient data alarms according to National

Ambient Air Quality Standards, e.g. PM10 – 24 hr avg. should not exceed 100 µg/m3

Define alarms for water quality parameters
n approved permissible ranges

Alarm generation

When any thresholds are crossed, alarms

are generated

Audio-visual display on browser
Alerts by SMS / email

Alarm Management

SLIDE 11

Facility to request for data correction in case of any

abnormal data values

Workflow for regulator to review and accept / reject

data correction with time stamping

Data Correction / Time Stamping

SLIDE 12

Remote calibration of analyzers from server
UI to configure complete calibration sequence
Possibility to schedule calibration sequence at a set

time

On demand calibration

Remote Calibration

Will work only if analyzer supports remote calibration

SLIDE 13

Reports

Standard reports
Station Report – daily/weekly/monthly
Multi-station Report
Parameter Comparison Report
Abnormal Data Report
Calibration Report
Data correction Report
Robust reporting engine for development of custom reports
Automatic report scheduling and delivery by email / print
Can publish reports on company website

SLIDE 14

Charts

Various charts for data analysis
Wind rose
Poll rose
Histogram
Trend
Any other custom charts can be

developed

SLIDE 15

Configuration Extensive configuration tool to configure sites, devices, parameters, users in minutes Remote configurable DAS General public can view data using a browser User authentication and authorization for device control and system configuration Secure and long term data storage on server

User Access & Data Security

SLIDE 16

EnviroConnect Components

Software Components
EnviroConnect Server
A single web server with static IP address to monitor and control

multiple sites

Data Acquisition Server (DAS)
On site to acquire data from analyzers.
Alternatively analyzers can directly send data to

EnviroConnect Server

Browser based client – PC, tablet, mobile
Hardware Components
Server – customer owned or hosted by AIPL
DAS hardware – AIPL supplied or customer supplied
IO modules, if required for data acquisition directly

from sensors

SLIDE 17

Case e Studies ies About AIPL EnviroConnect

SLIDE 18

Case Studies List Brief summary of each case study is given here. For details visit http://www.plantconnect.net/index.php/case-studies/plantconnect-air- quality-monitoring-system-casestudy.html

1.Local installation – Ambient Air Quality 2.Local installation – CEMS 3.Local installation – Water Quality Monitoring 4.Nationwide server in CPCB for Forbes Marshal CODEL 5.MPCB Server 6.ETS Server

Note: At the time of the above deployments the product was named PlantConnect-EQMS, which has since been renamed as EnviroConnect.

SLIDE 19

Case I : Local installation – Ambient

Installations for Ambient Air Quality Monitoring for

Thermo Fisher analyzers

Data acquisition from Thermo i series, FH62 series

analyzers, Met One analyzers and Dynalab AWS

Data viewing at Local station as well as industry level

central station

Data sent to MPCB / CPCB
Remote calibration of analyzers

SLIDE 20

Local installation for CEMS in
ver 100 industries for Forbes

Marshall CODEL analyzers

Data acquisition from CODEL

DCEM and GCEM

Local viewing and reporting
Data sent to MPCB Server
Interface with ETS Bridge

Software

Case II : Local installation - CEMS

SLIDE 21

Local installation for Water Quality Monitoring for Forbes

Marshall water analyzers

Data acquisition from FM water analyzers
Local viewing and reporting
Data sent to CPCB,GPCB Server and more

Case III : Local installation – Water

SLIDE 22

Case IV : CPCB Server for FM

EnviroConnect server installed in CPCB
n behalf of Forbes Marshal CODEL
Real time CEMS and ETP data collection

from various plants throughout the country

Same system accessed by industries and

regulators

SLIDE 23

Case V : MPCB Server

EnviroConnect server setup in

Maharashtra Pollution Control Board

Currently data from more than 100+

CEMS and Ambient stations in various industries in Maharashtra collected

Aim is to bring all CEMS and Ambient

stations online and make validated data available to general public

SLIDE 24

Case VI : ETS Server

Emission Trading Scheme (ETS) is a path breaking project by MoEF

and CPCB. For details visit http://www.cpcb.nic.in/upload/NewItems/NewItem_202_CEMS_Spec s_v21-11-13v_cpcb.pdf

First time in the world emission trading will be done using continuous

monitoring for Particulate Matter emissions from stationary sources

Pilot is underway in Maharashtra and Gujarat with a customized

version of PlantConnect (previous version of EnviroConnect) Server

AIPL has also created ETS Bridge Software that is used for data

collection.

SLIDE 25

Customers / Partners

EnviroConnect is sold through our Partners who are Analyzer Manufacturers / Distributors or System Integrators Installations in more than 50 industries across India

SLIDE 26

EnviroConnect Case Studies About ut AIPL

A little bit about company…

SLIDE 27

AIPL

Ascent Intellimation (AIPL) is a thought leader in convergence of IT and Industrial Automation

AIPL has served customers across globe for more than 15 years creating several products in industrial automation domain covering the entire lifecycle form concept to completion and further maintenance and support. The applications include remote monitoring, data logging, plug n play instrumentation platforms etc.

SLIDE 28
