Department of Informatics

Entity Beans

• Vue objet d’une base de données (exemples: client, compte,…)
• en général, une ligne d ’une table relationnelle (SGBD-R) ou un objet persistant (SGBD-

OO)

• sont persistant (long-lived)
• la gestion de la persistance peut être faite par le bean (bean managed persistence) ou

déléguée à son conteneur (container managed persistence)

• acceptent les accès multiples effectués par plusieurs clients
• gestion de la concurrence
• différents niveaux d ’isolation
• peuvent participer à des transactions
• survivent aux pannes d’un serveur EJB
• les pannes sont transparentes aux clients
• Le client peut soit créer un nouveau Entity Bean ou trouver un Bean existant
• La "Home interface" fournit des méthodes de recherche ("finder methods")
• findByPrimaryKey – clé unique dans un home
• Méthodes de recherche spécifiques à l'application
• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Bean: Structure

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Bean: Structure

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Beans and Database Tables

Customer

Key: Customer ID

Product Key: Product ID Order Bean

Key: Order ID Customer ID Product ID

Invoice

Key: Invoice ID Order ID

* 1 1 1 1

Order Bean Table

. . . 1 1001 3 1003 Order ID Invoice ID

. . .

9 76 1 1212 2 3

Product ID Customer ID Order ID

Invoice Table

Address . . .

2 1002 1 76

Orders Customer ID

Customer Table

2 1002 152

• 5. Enterprise JavaBeans

5.3 Entity Beans

*

Department of Informatics

Entity Bean: créer un objet

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Bean: Retrouver un objet

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Bean: Recherche d'objets

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Bean: Efficacité?

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Entity Bean: Réservoir (Pool)

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Cycle de vie des instances

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Cycle de vie vu du client

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Cycle de vie vu du client

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Persistence

Two kinds

• Bean Managed: Programmatic
• Container Managed: Declarative

Bean Managed

• Bean provider must write routines to access the data store
• Declares instance variables to contain the persistent data
• Finder method implementation written by Bean provider
• Container invokes these routines at an appropriate times in

lifecycle

• More common when underlying data store is an application
• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Persistence (2)

• Container Managed
• Allows Bean to be logically independent of data source
• e.g.: same code for relational database, IMS database, etc.
• Container generates code to access the data store
• Deployer maps the fields of the Bean to the columns of the database

– Bean provider describes Bean’s fields and relationships to other Beans in deployment descriptor

• Container may use lazy access methods and caching
• Finder methods are described in the deployment descriptor

– Description is in EJB QL – Implementation is generated when Bean is deployed

• Virtual fields are used in the Bean to contain the persistent data
• Access is via getXXX/setXXX methods.
• Relationship between Beans
• Similar to foreign keys in relational databases (one to one, many to one, one to many, many to

many)

• Allows container to ensure referential integrity
• e.g.: setting a Bean in field for a one to one relationship will automically remove the Bean from

a prior relationship

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Deployment Descriptor

Captures declarative information

Well-formed XML

Contains

Structural information

• Name of Bean, class, interfaces, Bean type, persistence

type, container managed fields, . . .

• Not all combinations of structural information make sense

Application assembly information

Security roles, method permissions, transaction

attributes, etc.

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

Deployment Descriptor Example

<!DOCTYPE ejb-jar PUBLIC "-/Sun Microsystems, Inc.//DTD EnterpriseJavaBeans 2.0//EN" "http://java.sun.com/dtd/ejb- jar_2_0.dtd"> <ejb-jar> <enterprise-beans> <entity> <ejb-name>CabinEJB</ejb-name> <home>com.titan.CabinHomeRemote</home> <remote>com.titan.CabinRemote</remote> <local-home>com.titan.CabinHomeRemote</local-home> <local>com.titan.CabinRemote</local> <ejb-class>com.titan.CabinBean</ejb-class> <persistence-type>Container</persistence-type> <prim-key-class>java.lang.Integer</prim-key-class> <reentrant>False</reentrant> </entity> </enterprise-beans> </ejb-jar>

• 5. Enterprise JavaBeans

5.3 Entity Beans

Department of Informatics

EJB QL

• A query language
• Similar to a subset of SQL
• Used in the deployment descriptor to describe the behavior of finder

(and other) methods for Beans with Container Managed Persistence

• <query>

<query-method> <method-name>findByName</method-name> <method-params> <method-param>java.lang.String<method-param> <method-params> </query-method> <ejb-ql> SELECT OBJECT(c) FROM Cruise WHERE c.name = ?1 </ejb-ql> </query>

• 5. Enterprise JavaBeans

5.3 Entity Beans
