Enabling Grids for E-sciencE EGEE SA2 / TERENA NRENs & Grids joint workshop EGEE09, 2009-09-22, Barcelona X. Jeannin, SA2 manager www.eu-egee.org


slide-1
SLIDE 1

Enabling Grids for E-sciencE

EGEE SA2 / TERENA NRENs & Grids joint workshop

  • www.eu-egee.org
  • EGEE’09, 2009-09-22, Barcelona
  • X. Jeannin, SA2 manager
slide-2
SLIDE 2

Enabling Grids for E-sciencE

FTS File Transfer Service (FTS) LB Logging &Bookkeeping System (LB) Storage Element (SE) Computing Element (CE) WMS Workload Management System (WMS)

User Interface

WN Worker Nodes (WN) WN WN WN WN

Network: the invisible layer

BDIIServer BDII SE Storage Element (SE) CE LFC Logical File Catalog (LFC)

2

Requiring the Network The role of network is crucial but its role is invisible in the eyes of the Grid

  • GRID, a complex

architecture

slide-3
SLIDE 3

Enabling Grids for E-sciencE

Grid and Network

  • “Networks work fine, QOS seems difficult to achieve and

anyway our applications are robust enough to cope with network defect” Grid application people

  • We need to improve
  • The Grid network operation
  • Identifying network trouble, Maintenance, Monitoring,

Topology

EGEE’09, 2009-09-22, Barcelona

  • X. Jeannin

3

Topology

  • The access to advance network services
  • What is available? Where? How can I use it?
  • The multi-domains challenge
  • a collaboration NRENs /

Grids around pragmatic project

  • Grid is definitely within the competence of the NREN and

the Grid is a major stake for the NRENs but we have to propose better services

slide-4
SLIDE 4

Enabling Grids for E-sciencE

Agenda

  • Advanced Network Services Session (11:00-13:00)
  • Requirement of application, access to advanced network services

thanks to the middleware. Booking system. AuthoBAHN.

  • Network monitoring session (14:30-16:00)
  • The foundation of the collaboration between Grid and network

people

EGEE’09, 2009-09-22, Barcelona

  • X. Jeannin

4

  • Troubleshooting
  • IPv6 session (16:00-16:30)
  • Project-wide Network Operation Session (17:00-18:00)
  • The network is crucial for the Grid project but network operation is

primitive (maintenance, ticketing system, bandwidth reservation … )

  • Grid middleware session (18:00-19:00)
slide-5
SLIDE 5

Enabling Grids for E-sciencE Demonstrations planning

  • 14:00PM-14:30PM: Advanced network services

– The Harmony and Phosphorus project (i2CAT) – AMPS: An automatic tool to provision premium IP circuit over European NRENs (EGEE-SA2: GRNET - video)

  • 16:30PM-17:00PM: Network grid monitoring

EGEE’09, 2009-09-22, Barcelona

  • X. Jeannin

5

  • 16:30PM-17:00PM: Network grid monitoring

– PerfSONAR: monitoring of the LHCOPN (DANTE)

  • 19:00PM: Grid middleware and Grid Operation

– Grid certificate within minutes (NDGF, UNINETT, TERENA, NORDUnet A/S, UNINETT, PDC) – Grid Operation: Ticket normalization (EGEE-SA2: GRNET)

slide-6
SLIDE 6

Enabling Grids for E-sciencE

Others Demonstrations

  • These other demonstrations will be given during the

week (on demand)

– Network troubleshooting : PerfSONAR Lite TSS: A new light tool for network troubleshooting

EGEE’09, 2009-09-22, Barcelona

  • X. Jeannin

6

PerfSONAR Lite TSS: A new light tool for network troubleshooting (EGEE-SA2: FAU) – IPv6: The 2 first IPv6 EGEE sites (EGEE-SA2: CNRS, GARR)
