slide-1
SLIDE 1

dnstap-whoami

Robert Edmonds (edmonds@fsi.io) Farsight Security, Inc.

slide-2
SLIDE 2

dnstap-whoami Slide 2 of 25

Intro

 DNS nameservers that return custom responses

– Diagnostics – Experimentation

 Result passed through to the original client  Examples:

– DNS “whoami” – OARC port and reply size tests

slide-3
SLIDE 3

dnstap-whoami Slide 3 of 25

DNS “whoami”

 Query for type A  Get resolver IPv4 address in record data

slide-4
SLIDE 4

dnstap-whoami Slide 4 of 25

$ dig +short @8.8.8.8 whoami.akamai.net 74.125.177.51

slide-5
SLIDE 5

dnstap-whoami Slide 5 of 25

Anycasted service address

$ dig +short @8.8.8.8 whoami.akamai.net 74.125.177.51

slide-6
SLIDE 6

dnstap-whoami Slide 6 of 25

Unicast resolver address

$ dig +short @8.8.8.8 whoami.akamai.net 74.125.177.51

slide-7
SLIDE 7

dnstap-whoami Slide 7 of 25

OARC port and reply size tests

 Client sends query to resolver  Nameserver forces resolver to perform multiple

queries

 Get information about source port randomization,

EDNS buffer size

slide-8
SLIDE 8

dnstap-whoami Slide 8 of 25

$ dig +short porttest.dns-oarc.net TXT porttest.y.x.w.v.u.t.s.r.q.p.o.n.m.l.k.j.i .h.g.f.e.d.c.b.a.pt.dns-oarc.net. "70.89.251.89 is GREAT: 75 queries in 2.1 seconds from 75 ports with std dev 17022"

slide-9
SLIDE 9

dnstap-whoami Slide 9 of 25

$ dig +short rs.dns-oarc.net TXT rst.x4050.rs.dns-oarc.net. rst.x4058.x4050.rs.dns-oarc.net. rst.x4064.x4058.x4050.rs.dns-oarc.net. "70.89.251.89 DNS reply size limit is at least 4064" "70.89.251.89 sent EDNS buffer size 4096" "Tested at 2015-09-23 18:26:16 UTC"

slide-10
SLIDE 10

dnstap-whoami Slide 10 of 25

dnstap-whoami

 Encode the resolver's wire query (plus metadata) into

the response RR

 Makes resolver information visible to client, e.g.:

– IPv4/IPv6 query source address – TCP/UDP query source port – EDNS buffer size – EDNS0 options (client-subnet, cookies, etc.) – 0x20

slide-11
SLIDE 11

dnstap-whoami Slide 11 of 25

dnstap-whoami

 Uses dnstap protobuf schema for encoding

✔ Compact, extensible ✘ Not human readable, requires decoder tool

slide-12
SLIDE 12

dnstap-whoami Slide 12 of 25

dnstap-whoami

 Query whoami.dnstap.info type NULL for IPv4

$ dig +short whoami.dnstap.info NULL

 Query whoami6.dnstap.info type NULL for IPv6

$ dig +short whoami6.dnstap.info NULL

slide-13
SLIDE 13

dnstap-whoami Slide 13 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL

\# 89 72550801100122044A7D2A37309FFD03408BEE8BB0054D096A312F52 3A1555001000010000000000010677686F616D6906646E7374617004 696E666F00000A0001000029100000008000000B0008000700011800 4659FB7801

slide-14
SLIDE 14

dnstap-whoami Slide 14 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ cut -f3- -d' ' | xxd -r -p | hd

00000000 72 55 08 01 10 01 22 04 4a 7d 2a 37 30 9f fd 03 |rU....".J}*70...| 00000010 40 8b ee 8b b0 05 4d 09 6a 31 2f 52 3a 15 55 00 |@.....M.j1/R:.U.| 00000020 10 00 01 00 00 00 00 00 01 06 77 68 6f 61 6d 69 |..........whoami| 00000030 06 64 6e 73 74 61 70 04 69 6e 66 6f 00 00 0a 00 |.dnstap.info....| 00000040 01 00 00 29 10 00 00 00 80 00 00 0b 00 08 00 07 |...)............| 00000050 00 01 18 00 46 59 fb 78 01 |....FY.x.| 00000059

slide-15
SLIDE 15

dnstap-whoami Slide 15 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ cut -f3- -d' ' | xxd -r -p | \ protoc --decode=dnstap.Dnstap ./dnstap.proto

message { type: AUTH_QUERY socket_family: INET query_address: "J}*7" query_port: 65183 query_time_sec: 1443034891 query_time_nsec: 791767561 query_message: "\025U\000\020\000\001\000\000\000\000\000\001\00 6whoami\006dnstap\004info\000\000\n\000\001\000\0 00)\020\000\000\000\200\000\000\013\000\010\000\0 07\000\001\030\000FY\373" } type: MESSAGE

slide-16
SLIDE 16

dnstap-whoami Slide 16 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ cut -f3- -d' ' | xxd -r -p | \ protoc --decode=dnstap.Dnstap ./dnstap.proto

message { type: AUTH_QUERY socket_family: INET query_address: "J}*7" query_port: 65183 query_time_sec: 1443034891 query_time_nsec: 791767561 query_message: "\025U\000\020\000\001\000\000\000\000\000\001\00 6whoami\006dnstap\004info\000\000\n\000\001\000\0 00)\020\000\000\000\200\000\000\013\000\010\000\0 07\000\001\030\000FY\373" } type: MESSAGE

slide-17
SLIDE 17

dnstap-whoami Slide 17 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ dnstap-ldns -xy

type: MESSAGE message: type: AUTH_QUERY query_time: !!timestamp 2015-09-23 19:01:31.791767 socket_family: INET query_address: 74.125.42.55 query_port: 65183 query_message: | ;; ->>HEADER<<- opcode: QUERY, rcode: NOERROR, id: 5461 ;; flags: cd ; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 0 ;; QUESTION SECTION: ;whoami.dnstap.info. IN NULL ;; ANSWER SECTION: ;; AUTHORITY SECTION: ;; ADDITIONAL SECTION: ;; EDNS: version 0; flags: do ; udp: 4096 ;; Data: \# 11 00080007000118004659fb

slide-18
SLIDE 18

dnstap-whoami Slide 18 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ dnstap-ldns -xy

type: MESSAGE message: type: AUTH_QUERY query_time: !!timestamp 2015-09-23 19:01:31.791767 socket_family: INET query_address: 74.125.42.55 query_port: 65183 query_message: | ;; ->>HEADER<<- opcode: QUERY, rcode: NOERROR, id: 5461 ;; flags: cd ; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 0 ;; QUESTION SECTION: ;whoami.dnstap.info. IN NULL ;; ANSWER SECTION: ;; AUTHORITY SECTION: ;; ADDITIONAL SECTION: ;; EDNS: version 0; flags: do ; udp: 4096 ;; Data: \# 11 00080007000118004659fb

slide-19
SLIDE 19

dnstap-whoami Slide 19 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ dnstap-ldns -xy

type: MESSAGE message: type: AUTH_QUERY query_time: !!timestamp 2015-09-23 19:01:31.791767 socket_family: INET query_address: 74.125.42.55 query_port: 65183 query_message: | ;; ->>HEADER<<- opcode: QUERY, rcode: NOERROR, id: 5461 ;; flags: cd ; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 0 ;; QUESTION SECTION: ;whoami.dnstap.info. IN NULL ;; ANSWER SECTION: ;; AUTHORITY SECTION: ;; ADDITIONAL SECTION: ;; EDNS: version 0; flags: do ; udp: 4096 ;; Data: \# 11 00080007000118004659fb

slide-20
SLIDE 20

dnstap-whoami Slide 20 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ dnstap-ldns -xy

type: MESSAGE message: type: AUTH_QUERY query_time: !!timestamp 2015-09-23 19:01:31.791767 socket_family: INET query_address: 74.125.42.55 query_port: 65183 query_message: | ;; ->>HEADER<<- opcode: QUERY, rcode: NOERROR, id: 5461 ;; flags: cd ; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 0 ;; QUESTION SECTION: ;whoami.dnstap.info. IN NULL ;; ANSWER SECTION: ;; AUTHORITY SECTION: ;; ADDITIONAL SECTION: ;; EDNS: version 0; flags: do ; udp: 4096 ;; Data: \# 11 00080007000118004659fb

slide-21
SLIDE 21

dnstap-whoami Slide 21 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ dnstap-ldns -xy

type: MESSAGE message: type: AUTH_QUERY query_time: !!timestamp 2015-09-23 19:01:31.791767 socket_family: INET query_address: 74.125.42.55 query_port: 65183 query_message: | ;; ->>HEADER<<- opcode: QUERY, rcode: NOERROR, id: 5461 ;; flags: cd ; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 0 ;; QUESTION SECTION: ;whoami.dnstap.info. IN NULL ;; ANSWER SECTION: ;; AUTHORITY SECTION: ;; ADDITIONAL SECTION: ;; EDNS: version 0; flags: do ; udp: 4096 ;; Data: \# 11 00080007000118004659fb

slide-22
SLIDE 22

dnstap-whoami Slide 22 of 25 $ dig +short @8.8.8.8 whoami.dnstap.info NULL | \ dnstap-ldns -xy

type: MESSAGE message: type: AUTH_QUERY query_time: !!timestamp 2015-09-23 19:01:31.791767 socket_family: INET query_address: 74.125.42.55 query_port: 65183 query_message: | ;; ->>HEADER<<- opcode: QUERY, rcode: NOERROR, id: 5461 ;; flags: cd ; QUERY: 1, ANSWER: 0, AUTHORITY: 0, ADDITIONAL: 0 ;; QUESTION SECTION: ;whoami.dnstap.info. IN NULL ;; ANSWER SECTION: ;; AUTHORITY SECTION: ;; ADDITIONAL SECTION: ;; EDNS: version 0; flags: do ; udp: 4096 ;; Data: \# 11 00080007000118004659fb

slide-23
SLIDE 23

dnstap-whoami Slide 23 of 25

Source code

 Reference decoding tool

– https://github.com/dnstap/dnstap-ldns

 Custom nameserver

– https://github.com/dnstap/dnstap-evldns

 Protobuf schema

– https://github.com/dnstap/dnstap.pb

slide-24
SLIDE 24

dnstap-whoami Slide 24 of 25

Special thanks

 Ray Bellis, for his “evldns” DNS server framework

– https://github.com/raybellis/evldns

slide-25
SLIDE 25

dnstap-whoami Slide 25 of 25

Thanks!
