Derek Meinke (ME, PM) Matthew Liff (ME) Tony Zhang (EE) Zaw Htoo (ISE)

Where We Are

 On schedule!  Full understanding of Customer Needs  Project Plan and Gannt Chart  Risk Assessment  Began process of Concept Generation

Long Awaited Team Logo

AMORFIX - A Morphing Fixture for Photoreceptor Charge Testing

Team’s House of Quality

Customer Requirements Customer Weights

Voltage Input (5-8kV) Surface Speed (≤1m/s) Drum Size (24-84mm) Charger Type (BCR or Scorotron) Charger Gap (1-2mm) Dielectric Thickness (~25µm) ESV distance (1-2mm) Budget ($2k) Uniform Erase Charge (-100V) Surface Charge (-300 to -800V) Uniform charge distribution 14%

9 1 3 9 1 9 3 9 3

Accept multiple photoreceptor diameters 12%

1 9 9 1 9 3 9 9 9 3

Uniform pre-charge erase 12%

3 1 3 1 9 3

Allow any charge device config 11%

3 3 3 9 9 1 9 1 3

Accurate drum speed control 11%

1 9 3 3 9 3 3 9 9

Parallel ESV axis with photoreceptor 9%

3 1 9 1 9

Easily changeable components 6%

9 9 9 3 9 1

Voltage reading across entire drum length 6%

3 3 1 1

Data for both aluminum substrate & prod. PR 6%

9 9 1 3 9 1 1 3 9

Proper safety measures 4%

9 1 1

Generate minimal ozone 3%

9 9 1 3

Below target budget 3%

3 9 9 1 1 9 1

Allow different dielectric thicknesses 2%

1 3 3 1 9 1 3 3

Easy to use data acquisition menu 0%

Customer’s House of Quality

Customer Requirements Customer Weights

Voltage Input (5-8kV) Surface Speed (≤1m/s) Drum Size (24-84mm) Charger Type (BCR or Scorotron) Charger Gap (1-2mm) Dielectric Thickness (~25µm) ESV distance (1-2mm) Budget ($2k) Uniform Erase Charge (-100V) Surface Charge (-300 to -800V) Allow any charge device config 13%

3 3 3 9 9 1 9 1 3

Easily changeable components 11%

9 9 9 3 9 1

Allow different dielectric thicknesses 11%

1 3 3 1 9 1 3 3

Voltage reading across entire drum length 9%

3 3 1 1

Parallel ESV axis with photoreceptor 8%

3 1 9 1 9

Easy to use data acquisition menu 8% Repeatability 8% Data for both aluminum substrate and prod. PR 8%

9 9 1 3 9 1 1 3 9

Uniform pre-charge erase 7%

3 1 3 1 9 3

Accurate drum speed control 6%

1 9 3 3 9 3 3 9 9

Proper safety measures 4%

9 1 1

Alignment of charger with photoreceptor 4%

9 1 3 9 1 9 3 1 3

Accept multiple photoreceptor diameters 3%

1 9 9 1 9 3 9 9 9 3

Below target budget 1%

3 9 9 1 1 9 1 Generate minimal ozone

0%

9 9 1 3

What We Learned

 Charge device configuration is most important

(previously 4th).

 Easily interchangeable parts.  Repeatability is new customer need.  Don’t assume.

Gantt Chart

Risk Assessment

Risk Management Table - Revision 1 - 12/17/2009 ID Risk Item Likelyhood Severity Importance Action to Minimize Risk Owner 6Faulty equipment 2 2 4 Obtain quality equipment, look into

• btaining MSD locker

All members 7 ESV/Erase Lamp/Charger gap problems 2 2 4 Run multiple tests to determine best location, have faculty guide review fixture, make it variable Mechanical Engineer 8Weather affecting travel 2 1 2 Have good communication, use Tortoise SVN and EDGE, online chat discussions available All members 9Customer priority changes 1 2 2Constant communication with customer All members 14Hard to change components 2 3 6 Create a manual, use more clips than screws Mechnaical Engineer 15 Aluminum substrate is in contact with motor ground 1 3 3 Include a switch, use insulating material at contact, generate many concepts Mechanical / Electrical Engineer 18Lack of Labview skillset 3 2 6 Additional research time, utilize faculty expertise Industrial Systems Engineer

*19 total risks so far

Concept Generation (ME)

 https://edge.rit.edu/content/P10511/public/Home

Concept Generation (EE)

 Power supplies will be provided to us from our

customer, Xerox.

• Trek Cor-a-trol Model 610C High Voltage Supply
• High Voltage Supply (0 to ±10kV)
• Current Supply (0 to 2mA rms)

Concept Generation (EE)

 Recommended motors and specs have also been

provided.

• For Photoreceptor Drive (S83-93)
• For ESV slide (S57-51)

Concept Generation (ISE/EE)

 LabView User Interface

Input Data Output Data Start/Stop Voltage across photoreceptor Velocity of photoreceptor Graph (Voltage Vs cross-sectional length of photoreceptor) Diameter of photoreceptor Graph (Current Vs Voltage if aluminum substrate is attached) Type of photoreceptor (Finished or Unfinished) Slope of the voltage across the photoreceptor Type of Charger

Action Items

 How much does inner diameter of photoreceptor vary

with outer diameter?

 Should ESV scan speed vary with photoreceptor

rotational speed?

 Can power supply be turned on through LabView?
