SLIDE 1

DEMOCRATIC CONSENSUS:

A COMPARATIVE INTRODUCTION TO THE GRAPHENE BLOCKCHAIN

RYAN R. FOX RYAN@RYANRFOX.COM

https://linkedin.com/in/ryanrfox

SLIDE 2

RYAN R. FOX RYAN@RYANRFOX.COM

SLIDE 3

A COMPARATIVE IN INTRODUCTION

TO GRAPHENE USING BITCOIN AS THE REFERENCE

Will compare:

Genesis State
Participants
P2P network
Consensus algorithm
Objects
Security
Performance

What Graphene Offers:

Democratic Consensus (Stake Voting)
High Performance FinTech Platform
Hierarchical Named Account Authorities
Decentralized Exchange
Smart Coins
User Issued Assets
Pegged Assets
Price Feeds
Referral System
Worker Proposals

SLIDE 4

HISTORY OF GRAPHENE

Concept and original design: Daniel Larimer (2010)
Formed company: Invictus Innovations, Inc. (2013)
Distributed Autonomous Corporation DAC (2013)
Mined identity: Keyhotee (2013)
Momentum PoW algorithm: ProtoShares (2013)
Predecessor codebase: BitShares 0.9 (2014)

SLIDE 5

A BRIEF OVERVIEW OF GRAPHENE

Toolkit for blockchain development
Developed by Cryptonomex, Inc.
Offered under MIT License
Download: https://github.com/cryptonomex/graphene/
Derived works:
BitShares 2.0

decentralized exchange (2015)

Steem

blogchain (2016)

PeerPlays

decentralized gaming (2016)

DISCLAIMER: RYAN R. FOX DOES NOT REPRESENT CRYPTONOMEX, INC. INFORMATION PRESENTED IS HIS OPINION

SLIDE 6

GRAPHENE KEY DESIGN INITIATIVES

LEARN FROM BITCOIN, RIPPLE, LMAX EXCHANGE, ETHEREUM, ET AL.

Make PoS secure
Focus on speed and scalability
Make security approachable
Build a financial services platform

SLIDE 7

GENESIS STATE

NOTHING | EVERYTHING INCLUDING THE KITCHEN SINK

Initial stakeholders
Consensus parameters
Reserve Pool
Puzzle
Rewards
Maximum supply

SLIDE 8

BLOCKCHAIN PARAMETERS

FIXED | DYNAMIC

Tune running code
Proposal and Vote
Elected Committee
Rigid coded rules
Hard fork

SLIDE 9

P2P COMMUNICATION

GOSSIP | PUSH

Rapid propagation
Receive message
Validate
Forward
Conversation
Query peer inventory
Request deltas
Validate

SLIDE 10

CONSENSUS ALGORITHM

POW MINER | DPOS WITNESS

Election Round Production Validation

SLIDE 11

BLOCK REWARD

ISSUE NEW BITCOIN | TAP RESERVE POOL

Blocks Probabilistic
Inflation Predictable
Blocks Prescriptive
Deterministic
Predictable
Inflation Fx ( Recycling Rate )

SLIDE 12

VALUE REPRESENTATION

ADDRESS | NAMES ACCOUNTS & BALANCES

Bitcoin:

Identity and value hashed

into a ScriptSig

Distinct, secured by crypto
Difficult to read, compute
Balance sum UTXO

Graphene:

Identity is Named Account
Name ref. Account objectID
Distinct, deterministic
Easy to read, compare
Balance attribute of Account

SLIDE 13

STRUCTURE: OBJECTS

HASH | OBJECT

Bitcoin:

Calculated hash of script
2 ScriptSig formats
P2PK
P2SH
Examples
P2PK=12C5rBJ7Ev3YGBCbJPY6C8nkGhkUTNqfW9
P2SH=342ftSRCvFHfCeFFBuz4xwbeqnDw6BGUey

Graphene:

Deterministic assigned Object
Space . Type . Instance
Space: Defines where used
Type: Classification of object
Instance: Unique Space.Type
Examples
1.2.x Users
1.3.x Assets
1.11.x Operations

SLIDE 14

STRUCTURE: OBJECT STORAGE

HASH | OBJECT

Bitcoin:

Hashes stored in database
2 ScriptSig formats
P2PK = 20-bytes
P2SH = 32-bytes
Full hash transmitted on wire
20-bytes or 32-bytes

Graphene:

objectID stored in database
(Space.Type.Instance)=8-bytes
(uInt-8.uInt-8.uInt-48)=64-bits
Only instantID sent on wire
6-bytes

SLIDE 15

TRANSACTION OPERATIONS

GRAPHENE TRANSACTION

Operation ID Amount Asset ID Amount Asset ID Memo Amount Op Fee From (Account ID) To (Account ID) Extentions Signed Transaction Transfer Operation

SLIDE 16

STRUCTURE: ACCOUNT & AUTHORITY

Graphene:

Account
Authority Type
Threshold
Authorities
Key
Weight
Hierarchy within Accounts
Owner
Active

Alice

1.2.12

Balances

1.3.0 100.00

Authorities Owner

100% GHPDk…

Active

CORE

Weight 100% Threshold 50% Threshold 1.2.12

Alice

GHPYnJ… Weight 25% 1.2.12

Carol

GHPLzx… Weight 25% 1.2.12

Bob

GHPc8n… Weight 25% 1.2.12

Doug

Other Account Attributes

SLIDE 17

MULTI-SIGNATURE TRANSACTION

M:N | HIERARCHICAL THRESHOLD

Bitcoin:

Assemble multisig address
M validator addresses
N required signatures
Pay: to new address
Spend: N signatures on Trx
Must bring keys together
Must present complete Trx
Compromise one, rekey all

Graphene:

Assign Authorities
Assign Weight
Set Threshold
Pay: to existing named account
Spend: Threshold of Authority
Propose Trx on chain
Add Signature Operation
If Threshold, Trx valid
Individual can update their keys
Authority tied to Identity

SLIDE 18

MULTI-SIGNATURE TRANSACTION

REAL WORLD EXAMPLE

Corp

1.2.37

Active

50%

GPHb.. 40% GPHc.. 30% GPHd.. 20%

CEO CFO

Accounting

GPHf.. 10%

Bookkeeper

CFO

1.2.12

Active

100%

GPHc.. 90% GPHd.. 20%

CFO

CFO2FA

Account

1.2.12

Active

80%

GPHd.. 60%

Accounting

GPHf.. 30%

Acct2FA

SLIDE 19

LIGHT WALLET DESIGN

Separate wallet Authorization from block Validation
Active Key in wallet
Connect via WebSocket to trusted node(s)
Send signed transaction

SLIDE 20

A COMPARATIVE IN INTRODUCTION

TO GRAPHENE USING BITCOIN AS THE REFERENCE

Compared:

Genesis State
Participants
P2P network
Consensus algorithm
Objects
Security
Performance

Future Discussion Topics:

Decentralized Exchange
Smart Coins
User Issued Assets
Pegged Assets
Price Feeds
Referral System
Worker Proposals

SLIDE 21

DEMOCRATIC CONSENSUS:

A COMPARATIVE INTRODUCTION TO THE GRAPHENE BLOCKCHAIN

RYAN R. FOX RYAN@RYANRFOX.COM
