DDoS Last Class Fault tolerance Concurrency Naming This Class Networking How DDoS works UDP Data Client Server Response TCP DDoS Distributed denial-of-service attack Attacker targets a victim from a number of

SLIDE 1

DDoS

SLIDE 2

SLIDE 3

Last Class

Fault tolerance
Concurrency
Naming

SLIDE 4

This Class

Networking
How DDoS works

SLIDE 5

SLIDE 6

UDP

Client Server

Data Response

SLIDE 7

TCP

SLIDE 8

DDoS

Distributed denial-of-service attack
Attacker targets a victim from a number of different

IP addresses

Purpose is to overwhelm victim’s resources so that

legitimate users can’t use them

SLIDE 9

SLIDE 10

Mirai Botnet

https://www.usenix.org/conference/usenixsecurity17/technical- sessions/presentation/antonakakis

SLIDE 11

Victim Population

SLIDE 12

Compromised Devices

SLIDE 13

DDoS over time

SLIDE 14

SLIDE 15

SYN Flood

SLIDE 16

Protecting against SYN flood

Filtering
Increasing Backlog
Reducing SYN-RECEIVED Timer
Recycling the Oldest Half-Open TCB
SYN Cache
SYN Cookies
Firewalls and Proxies

https://tools.ietf.org/html/rfc4987

SLIDE 17

Smurf Attack

Send ping message “from” victim to broadcast IP

address

Every computer on that network will helpfully reply

to the victim.

SLIDE 18

Ping Flood

Send a bunch of ping messages to a server
ping: ICMP "echo request"

SLIDE 19

DNS amplification

Forge a DNS query to an open DNS resolver with

victim’s IP address as return address

Victim gets overwhelmed with DNS queries they

didn’t ask for

Queries for a DNSSEC-signed zone if victim is a

DNS server

SLIDE 20

DNS amplification

dig +trace cr.yp.to any

cr.yp.to. 600 IN MX 0 a.mx.cr.yp.to. cr.yp.to. 600 IN MX 10 b.mx.cr.yp.to. cr.yp.to. 600 IN A 80.101.159.118 yp.to. 259200 IN NS a.ns.yp.to. yp.to. 259200 IN NS uz5uu2c7j228ujjccp3ustnfmr4pgcg5ylvt16kmd0qzw7bbjgd5xq.ns.yp.to. yp.to. 259200 IN NS b.ns.yp.to. yp.to. 259200 IN NS f.ns.yp.to. yp.to. 259200 IN NS uz5ftd8vckduy37du64bptk56gb8fg91mm33746r7hfwms2b58zrbv.ns.yp.t

;; Received 414 bytes from 131.193.36.24#53(f.ns.yp.to) in 32 ms

https://dankaminsky.com/2011/01/05/djb-ccc/#dnsamp

SLIDE 21

DNS amplification

http://www.pir.org. 300 IN A 173.201.238.128

pir.org. 300 IN NS ns1.sea1.afilias-nst.info. pir.org. 300 IN NS ns1.mia1.afilias-nst.info. pir.org. 300 IN NS ns1.ams1.afilias-nst.info. pir.org. 300 IN NS ns1.yyz1.afilias-nst.info. ;; Received 329 bytes from 199.19.50.79#53(ns1.sea1.afilias-nst.info) in 90 ms

http://www.pir.org. 300 IN A 173.201.238.128

http://www.pir.org. 300 IN RRSIG A 5 3 300 20110118085021 20110104085021 61847 pir.org. n5cv0V0GeWDPfrz4K/CzH9uzMGoPnzEr7MuxPuLUxwrek+922xiS3BJG NfcM9nlbM5GZ5+UPGv668NJ1dx6oKxH8SlR+x3d8gvw2DHdA51Ke3Rjn z +P595ZPB67D9Gh6l61itZOJexwsVNX4CYt6CXTSOhX/1nKzU80PVjiM wg0= pir.org. 300 IN NS ns1.mia1.afilias-nst.info. pir.org. 300 IN NS ns1.yyz1.afilias-nst.info. pir.org. 300 IN NS ns1.ams1.afilias-nst.info. pir.org. 300 IN NS ns1.sea1.afilias-nst.info. pir.org. 300 IN RRSIG NS 5 2 300 20110118085021 20110104085021 61847 pir.org. IIn3FUnmotgv6ygxBM8R3IsVv4jShN71j6DLEGxWJzVWQ6xbs5SIS0oL OA1ym3aQ4Y7wWZZIXpFK +/Z+Jnd8OXFsFyLo1yacjTylD94/54h11Irb fydAyESbEqxUBzKILMOhvoAtTJy1gi8ZGezMp1+M4L +RvqfGze+XFAHN N/U= ;; Received 674 bytes from 199.19.49.79#53(ns1.yyz1.afilias-nst.info) in 26 ms

SLIDE 22

Exercise

https://github.com/ctfs/write-ups-2013/blob/master/pico- ctf-2013/ddos-detection/syn_attack.pcap It appears a SYN-flood style DDoS has been carried out on this system. Send us a list of the IP addresses of the attackers (in any order, separated by spaces), so we can track them down and stop them. https://www.wireshark.org/docs/wsug_html_chunked/ ChapterWork.html
