Custom Wireless Solutions - powered by RFOS Who is Venture Technologies? delivering sub-systems or full service product A Product Development development. company, who are. ultra low power, low expert in optimized, cost, miniaturized,

slide-1
SLIDE 1

Custom Wireless Solutions

  • powered by RFOS
slide-2
SLIDE 2

Who is Venture Technologies?

2

A Product Development company, who are…. expert in optimized, integrated radios, able to …. bring products to market quickly and efficiently, using …. RFOS, our modular, customizable, wireless platform.

ultra low power, low cost, miniaturized, integrated with core, challenging RF, long range, custom networks, ranging / location, etc… also incorporating any and all standards – Zigbee, BT / BLE, ANT, ModBus, GPS, Wifi, etc, delivering sub-systems

  • r full service product

development.

slide-3
SLIDE 3

About Us

  • 11,000 sf facilities north of

Boston.

  • Electronics labs, model shop,

project rooms, test facilities.

  • Core team: analog & digital

electronics, RF, embedded software, low power design, mechanical.

  • Extended team & network:

industrial design, antenna design, modeling, FEA, energy harvesting.

slide-4
SLIDE 4

Venture Markets/Products

Governmental / Military

Pressure controller for military aircraft Tank warrior communications Robot battery system Intelligent vehicle scanner

Consumer

Wireless dog leash Wireless toy applications Remote audio for Lexus/Toyota DVD player Audio FM transmitter Wireless HVAC controllers

Industrial / Scientific

Ozone detection pH and other electrochemical instruments IR temperature measurement H2 detector Tank farm wireless level sensors LED lighting power supply & wireless controllers

Medical Devices

Infusion pump Defibrillator Glucose meter Laser skin treatment system Wireless hospital hygiene monitor

Life Sciences

Automated Western Blot test Precision incubator Electronic pipette

slide-5
SLIDE 5

Venture’s RFOS Wireless Solutions

  • Proven technology
  • Can be customized to

meet specific product needs

  • Reliable RF

communications

  • Design ready to meet

FCC Part 15

slide-6
SLIDE 6

Venture’s RFOS Features

Up to 250K baud data rate Reliable communication Many years battery life Energy harvesting options Data packet integrity Data bursts buffering Full duplex ms response times Range up to 1 mile Spread spectrum (FHSS or DSSS) 902-928 Mhz, 433 Mhz and 2.4 Ghz ISM bands Various network topologies 2 units (cable replacement) Star network Store and Forward Mesh networks Hybrid mesh-star FCC Part 15.247 compliant

slide-7
SLIDE 7

Why use RFOS?

Module vs Custom? – RFOS: best of both worlds

Advantages of Module Advantages of Full Custom

  • Easy and less costly

to develop

  • FCC certification is easy

(or already done)

  • Requires little knowledge
  • f RF system
  • Lower BoM cost
  • Optimize product for

cost, size, shape

  • Maximum performance

– radio, power

  • Fully integrated into

product design – lower component count, less PCB real estate

slide-8
SLIDE 8

Example Products built on RFOS

Shopping Cart Billboard System Automotive Windshield De-icing Dog Training System Thermostat Interface Tank Level Monitoring Hand Sanitization Monitoring System Street Lamp Control

slide-9
SLIDE 9

9

Shopping cart wireless billboard system

Message Publishing Message Authoring

INTERNET

slide-10
SLIDE 10

10

Automotive Windshield De-icing

Aftermarket windshield de-icing system

.

slide-11
SLIDE 11

Thermostat Interface

12

  • Wireless Retrofit to Existing Thermostats
  • Eliminates Need for Wiring
  • 900MHz ISM Band
  • 5-Year Battery Life
slide-12
SLIDE 12

Tank Monitor System Configuration

  • Up to 64 Tanks
  • Monitor battery life 5 years
  • Sense (nominally) every 4 hours
  • High reliability communication
slide-13
SLIDE 13

Hand Sanitization Monitoring System

  • Reduce communicable diseases spread by hand
  • Verify compliance with hand sanitization policy
  • Worldwide
  • 3+ year battery lifetime
  • 1000 handwash stations / installation

Handwas h Station Remote Server

slide-14
SLIDE 14

15

Hand Sanitization Typical Installation

Hub Gateway Dispenser in Each Room

slide-15
SLIDE 15

Municipal Lighting Control

  • Commands issued from

PC to Controller over LAN

  • Controller communicates

with lights within range

  • Lights relay to other

units out of range of controller

  • Number of hops not

limited

  • Network self-configures
  • Communication is Bi-

directional

slide-16
SLIDE 16

Other Wireless Systems

Sports monitor (ANT, GPS, zigbee) Military Microwave (no case study) Microwave imaging

slide-17
SLIDE 17

Athletic Performance Monitoring

  • Compact
  • Light Weight
  • Contains 3 Radios
slide-18
SLIDE 18

Performance Monitor with GPS

802.15.4 Radio & Antenna ANT+ Radio & Antenna

2.0” 3.0”

slide-19
SLIDE 19

Walleye

  • A handheld microwave

camera that lets you see through walls

  • Walleye Technologies worked

with Venture to develop an initial functional prototype

  • TIME magazine puts

invention on list of “Top 50 Inventions for 2009”

slide-20
SLIDE 20

Elemé Medical

Multi-Watt Cosmetic Laser. Design Challenges

  • Thermal

management

  • Laser power

management

  • Laser safety controls
slide-21
SLIDE 21

Thermo-Chuck Temperature Controller

22

  • Temperature Stability ±0.1°C
  • Temperature Range -65C to 200C
  • Precise temperature control and

accuracy

  • Ramp/soak/cycle programming is

controllable from front panel or via remote interface.

  • IEEE-488 and RS232 remote

interface included.

slide-22
SLIDE 22

Williamson

  • New line of infrared

remote temperature sensor

  • Migrated from analog to

digital

  • Intelligent calibration and

self test/adjust

  • Low cost common platform

design

  • Highly successful, leading

to new market growth

"I just wanted to thank you and your team for being such a good partner over the last 5

  • years. The high performance product line that

your team helped us develop along with the continued support you have given through these years has allowed us to improve our market share and enter markets that would not have been possible without the innovative features included in the new line." William Barron, Jr Vice President & Owner

slide-23
SLIDE 23

24

How We Work Together

  • Understand Your Needs

—Functional Requirements —Development Cost & Schedule —Manufacturing Cost —Definition of “Success”

  • Document the Specifications
  • Develop Project Plan
  • Report on / Review Status
  • Deliver As Promised
slide-24
SLIDE 24

25

Key to Success

Since 1984 we have partnered with customers to deliver real business value Venture provides senior technical experts The solution will be planned with you and executed according to that plan Timely project communications The goals we set will be measurable Long Term Development Partnership

slide-25
SLIDE 25

26

Next Steps

Understanding Your Business Needs Aligning Venture’s Capabilities with Your Needs Proposing Approach Reviewing Proposal With You Formalizing Relationship Executing the Plan

Creating your new product and addressing your needs with a cost-effective solution begins with:

slide-26
SLIDE 26

Venture Technologies, Inc 85 Rangeway Rd. North Billerica, MA 01862 Phone: 978-667-9890
