SLIDE 1
CSI-FiSh: Efficient Isogeny based Signatures through Class Group - - PowerPoint PPT Presentation
CSI-FiSh: Efficient Isogeny based Signatures through Class Group - - PowerPoint PPT Presentation
CSI-FiSh: Efficient Isogeny based Signatures through Class Group Computations Ward Beullens Thorsten Kleinjung Frederik Vercauteren imec - COSIC December 3, 2019 Introduction : CSIDH [Castryck et al.] 1/34 Take the supersingular elliptic
SLIDE 2
SLIDE 3
Introduction : CSIDH [Castryck et al.]
1/34 Take the supersingular elliptic curve E0 : y2 = x3 + x mod p = 4 · 3 · 5 · . . . · 373 · 587 − 1. Let O = Endp(E0) ≃ Z(√−p). The class group cl(O) acts freely and transitively on a set of supersingular elliptic curves X = Eℓℓp(O, π).
SLIDE 4
Introduction : CSIDH [Castryck et al.]
1/34 Take the supersingular elliptic curve E0 : y2 = x3 + x mod p = 4 · 3 · 5 · . . . · 373 · 587 − 1. Let O = Endp(E0) ≃ Z(√−p). The class group cl(O) acts freely and transitively on a set of supersingular elliptic curves X = Eℓℓp(O, π). 74 “simple” ideals whose action can be computed efficiently: l1 = (3, π − 1), · · · , l74 = (587, π − 1)
SLIDE 5
Introduction : CSIDH [Castryck et al.]
1/34 Take the supersingular elliptic curve E0 : y2 = x3 + x mod p = 4 · 3 · 5 · . . . · 373 · 587 − 1. Let O = Endp(E0) ≃ Z(√−p). The class group cl(O) acts freely and transitively on a set of supersingular elliptic curves X = Eℓℓp(O, π). 74 “simple” ideals whose action can be computed efficiently: l1 = (3, π − 1), · · · , l74 = (587, π − 1) CSIDH-512: Efficient Post-Quantum Diffie-Hellman protocol based
- n this action. Reasonably fast (± 80 ms) and very small keys.
SLIDE 6
Introduction : CSIDH [Castryck et al.]
1/34 Take the supersingular elliptic curve E0 : y2 = x3 + x mod p = 4 · 3 · 5 · . . . · 373 · 587 − 1. Let O = Endp(E0) ≃ Z(√−p). The class group cl(O) acts freely and transitively on a set of supersingular elliptic curves X = Eℓℓp(O, π). 74 “simple” ideals whose action can be computed efficiently: l1 = (3, π − 1), · · · , l74 = (587, π − 1) CSIDH-512: Efficient Post-Quantum Diffie-Hellman protocol based
- n this action. Reasonably fast (± 80 ms) and very small keys.
Can we do signatures ?
SLIDE 7
Introduction : Seasign [De Feo, Galbraith]
2/34 [Rostovstev]: FS signatures from Graph Isomorphism-like identification scheme.
SLIDE 8
Introduction : Seasign [De Feo, Galbraith]
2/34 [Rostovstev]: FS signatures from Graph Isomorphism-like identification scheme. problem: We cannot uniquely represent elements g = 74
i=1 lei i .
⇒ Signatures leak secret key.
SLIDE 9
Introduction : Seasign [De Feo, Galbraith]
2/34 [Rostovstev]: FS signatures from Graph Isomorphism-like identification scheme. problem: We cannot uniquely represent elements g = 74
i=1 lei i .
⇒ Signatures leak secret key. solution: [SeaSign] Rejection sampling to prevent leakage. ⇒ Slow signing and large signatures (e.g. 17 min and 12 KB).
SLIDE 10
Introduction : Seasign [De Feo, Galbraith]
2/34 [Rostovstev]: FS signatures from Graph Isomorphism-like identification scheme. problem: We cannot uniquely represent elements g = 74
i=1 lei i .
⇒ Signatures leak secret key. solution: [SeaSign] Rejection sampling to prevent leakage. ⇒ Slow signing and large signatures (e.g. 17 min and 12 KB).
Can we do better ?
SLIDE 11
Introduction: CSI-FiSh
3/34 We compute the structure of cl(O): It is cyclic of order N =3 · 37 · 1407181 · 51593604295295867744293584889 · 31599414504681995853008278745587832204909 and generated by g = l1 = (3, π − 1). We can uniquely represent elements of cl(O) as ga with a ∈ Z/NZ. CSI-FiSh: Isogeny signatures without rejection sampling ⇒ Much more efficient (e.g. 335 ms min and 2 KB).
SLIDE 12
Outline of the talk
4/34
1 Some Isogeny-Based Crypto 2 Class group computation 3 CSI-FiSh
SLIDE 13
Outline
5/34
1 Some Isogeny-Based Crypto 2 Class group computation 3 CSI-FiSh
SLIDE 14
Elliptic curves and isogenies
6/34
Definition (Elliptic curve)
Elliptic curves are curves defined by an equation of the form y2 = x3 + ax + b .
Definition (Isogeny)
An isogeny of elliptic curves E, E′ is a non-zero algebraic group morphism from E to E′. →
SLIDE 15
Endomorphisms
7/34
Definition (Endomorphism)
An isogeny from a curve E to itself is called an endomorphism Examples: multiplication by n : P → P + P + · · · + P (n times). In characteristic p: Frobenius π : (x, y) → (xp, yp). Endomorphisms form a ring End(E): pointwise addition: (φ1 + φ2)(P) = φ1(P) + φ2(P) multiplication by composition : φ1 · φ2 = φ1 ◦ φ2 Endomorphisms defined over Fp form a Commutative subring! If Endp(E) = End(E), then E is ordinary, otherwise E is supersingular.
SLIDE 16
Separable isogenies ↔ finite subgroups
8/34 Fact 1: An isogeny E → E′ has a finite kernel. And conversely: Fact 2: For every finite subgroup H ⊂ E, there exists an isogeny φ : E → E′ with kernel H. And this E′ is unique (up to isomorphism).
SLIDE 17
Separable isogenies ↔ finite subgroups
8/34 Fact 1: An isogeny E → E′ has a finite kernel. And conversely: Fact 2: For every finite subgroup H ⊂ E, there exists an isogeny φ : E → E′ with kernel H. And this E′ is unique (up to isomorphism). Moreover, if H and E are defined over Fp, then φ and E′ are defined over Fp
Notation
Given, H ⊂ E, we write E′ = E/H.
SLIDE 18
Class group action
9/34 Let E/Fp be a curve with EndFp(E) = O and let the ideal class group of O ( denoted by cl(O) ) be the group of invertible fractional ideals modulo principal ideals. Then cl(O) acts on the set of elliptic curves defined over Fp with Fp-endomorphism ring O: [I] ⋆ E = E/
- α∈I
ker α
- Well defined because:
isogenous curves have same endomorphism ring principal ideals act trivially: [α] ⋆ E = E/ (ker α) = E
SLIDE 19
Class group action for CSIDH-512
10/34
[Castryck, Lange, Martindale, Panny, Renes]
Choose p = 4 · 3 · 5 · . . . · 376 · 587 − 1 (which is prime), then E0 : y2 = x3 + x is a supersingular elliptic curve with EndFp(E) = Z[π] ≈ Z[√−p]. Let X = {E | E is supersingular and EndFq(E) = Z[π]}. Then cl(Z[π]) acts freely and transitively on X. One can efficiently compute the action of ideal classes of the form [ℓ1] = [(3, π − 1)], · · · , [ℓ74] = [(587, π − 1)] and their inverses. A priori, we only really have a group action from Z74 on X.
SLIDE 20
Example
11/34
Images stolen from Wouter Castryck
SLIDE 21
Example
11/34
Images stolen from Wouter Castryck
SLIDE 22
Example
11/34
Images stolen from Wouter Castryck
SLIDE 23
Example
11/34
Images stolen from Wouter Castryck
SLIDE 24
Example
11/34
Images stolen from Wouter Castryck
SLIDE 25
Example
11/34
Images stolen from Wouter Castryck
SLIDE 26
Example
11/34
Images stolen from Wouter Castryck
SLIDE 27
Example
11/34
Images stolen from Wouter Castryck
SLIDE 28
Example
11/34
Images stolen from Wouter Castryck
SLIDE 29
Example
11/34
Images stolen from Wouter Castryck
SLIDE 30
Example
11/34
Images stolen from Wouter Castryck
SLIDE 31
Example
11/34
Images stolen from Wouter Castryck
SLIDE 32
Example
11/34
Images stolen from Wouter Castryck
SLIDE 33
Example
11/34
Images stolen from Wouter Castryck
SLIDE 34
Example
11/34
Images stolen from Wouter Castryck
SLIDE 35
Example
11/34
Images stolen from Wouter Castryck
SLIDE 36
Example
11/34
Images stolen from Wouter Castryck
SLIDE 37
Example
11/34
Images stolen from Wouter Castryck
SLIDE 38
Example
11/34
Images stolen from Wouter Castryck
SLIDE 39
Vectorization and Paralellization
12/34
Vectorization problem ∼ DLOG
given E, E′, hard to find [a] ∈ cl(O) such that [a] ⋆ X = Y . E E′ ?
Paralellization problem ∼ CDH
given E, [a] ⋆ E, [b] ⋆ E, hard to compute [ab] ⋆ X. X [a] ⋆ X [b] ⋆ X ? [a]⋆ [b]⋆ [a]⋆ [b]⋆
SLIDE 40
CSIDH key exchange
13/34 Trump chooses secret key [a], Zelensky chooses secret key [b]. [a] =
74
- i=1
[ℓi]ai ↓ [a] ⋆ Eb
Ea=[a]⋆E0
− − − − − − − − − − →
Eb=[b]⋆E0
← − − − − − − − − − − [b] =
74
- i=1
[ℓi]bi ↓ [b] ⋆ Ea Eavesdropper learns [a] ⋆ E0 and [b] ⋆ E0, but not [ab] ⋆ E0
SLIDE 41
CSIDH and Seasign
14/34 CSIDH Advantages: non-interactive CCA-security key size: 64 Bytes CSIDH Disadvantages: Speed: ∼ 35 ms Subexponential quantum attack
SLIDE 42
CSIDH and Seasign
14/34 CSIDH Advantages: non-interactive CCA-security key size: 64 Bytes CSIDH Disadvantages: Speed: ∼ 35 ms Subexponential quantum attack Can we do authentication/signatures? Problem is Z74 ↔ cl(O). We can’t sample uniformly from cl(O). We dont have a unique way to represent elements in cl(O).
SLIDE 43
CSIDH and Seasign
14/34 CSIDH Advantages: non-interactive CCA-security key size: 64 Bytes CSIDH Disadvantages: Speed: ∼ 35 ms Subexponential quantum attack Can we do authentication/signatures? Problem is Z74 ↔ cl(O). We can’t sample uniformly from cl(O). We dont have a unique way to represent elements in cl(O). Seasign[DeFeo,Galbraith]+[Decru,Panny,Vercauteren]: Expensive workaround by using a very redundant representation of class group elements: Public key 16 KB, signatures 4 KB, 4 minutes.
SLIDE 44
Outline
15/34
1 Some Isogeny-Based Crypto 2 Class group computation 3 CSI-FiSh
SLIDE 45
Motivation
16/34 Problem: We don’t know the class group, only a set of generators [ℓ1], · · · , [ℓ74]. We can’t sample uniformly from cl(O). We don’t have a unique way to represent elements in cl(O). Solution: Just compute structure of cl(O): cl(O) = Z/N1Z × · · · × Z/NlZ . Now sampling and unique representation of elements is trivial.
SLIDE 46
Computing class group (simplified)
17/34 Recall p = 4 · 3 · . . . · 587 − 1 and O = Z[π] = Z[√−p]. We compute cl(O) as follows:
1) Let F = {p1, · · · pn} be the set of prime ideals of norm
≤ 7000000. Assuming GRH these generate cl(O), so cl(O) ≃ Zn/Λ, where Λ = {e | n
i=1 pei i is principal }
SLIDE 47
Computing class group (simplified)
17/34 Recall p = 4 · 3 · . . . · 587 − 1 and O = Z[π] = Z[√−p]. We compute cl(O) as follows:
1) Let F = {p1, · · · pn} be the set of prime ideals of norm
≤ 7000000. Assuming GRH these generate cl(O), so cl(O) ≃ Zn/Λ, where Λ = {e | n
i=1 pei i is principal }
2) Collect relations between the [pi], by trying many (a + √−p)
and hoping that they factor over F
SLIDE 48
Computing class group (simplified)
17/34 Recall p = 4 · 3 · . . . · 587 − 1 and O = Z[π] = Z[√−p]. We compute cl(O) as follows:
1) Let F = {p1, · · · pn} be the set of prime ideals of norm
≤ 7000000. Assuming GRH these generate cl(O), so cl(O) ≃ Zn/Λ, where Λ = {e | n
i=1 pei i is principal }
2) Collect relations between the [pi], by trying many (a + √−p)
and hoping that they factor over F E.g. N(1 + √−p) = 1 + p = 4 · 3 · 5 · . . . · 376 · 587, so 2 · 3, π + 1 · . . . · 587, π + 1 is a principal ideal. ⇒ We get a relation between prime ideals in F.
SLIDE 49
Computing class group (simplified)
17/34 Recall p = 4 · 3 · . . . · 587 − 1 and O = Z[π] = Z[√−p]. We compute cl(O) as follows:
1) Let F = {p1, · · · pn} be the set of prime ideals of norm
≤ 7000000. Assuming GRH these generate cl(O), so cl(O) ≃ Zn/Λ, where Λ = {e | n
i=1 pei i is principal }
2) Collect relations between the [pi], by trying many (a + √−p)
and hoping that they factor over F E.g. N(1 + √−p) = 1 + p = 4 · 3 · 5 · . . . · 376 · 587, so 2 · 3, π + 1 · . . . · 587, π + 1 is a principal ideal. ⇒ We get a relation between prime ideals in F. One down 6999999 to go!
SLIDE 50
Computing class group (simplified)
18/34
3) We make a square matrix R of relations over the factor base.
Now det(R) divides V ol(Λ) = #cl(O). We compute det(R) to get a multiple of the class number. Repeat for R′, and compute h′ = gcd(det(R), det(R′))
4) Factor h′ and check if each of the factors is a factor of the
class number.
5) (In our case) Observe that class number is square-free, so class
group is cyclic.
SLIDE 51
Class group computation (some details)
19/34 Bottlenecks: Sieving (43 core years) Determinant computation (2 × 4.3 core years) Sieving: Large prime variation If we manage to factor (a + √−p), but some of the factors have norm > 7000000, we add these factors to F. We gathered 320 million relations over an extended factor base of 32.7 million ideals.
SLIDE 52
Class group computation (some details)
20/34 Matrix preproccessing: Apply elementary row operations and delete rows and columns to reduce the size of the matrix, while keeping it sparse. We filter to 320 million relations over an extended factor base of 32.7 million ideals to 222 thousand relations and ideals. Determinant computation:
1
block-Wiedemann algorithm to compute the determinant modulo a lot of 64 bit primes.
2
use CRT to recover determinant over the integers.
SLIDE 53
Class group computation
21/34 This is a record class group computation. Previous record was a 130 digit discriminant [Kleinjung]. Our discriminant has 154 decimal digits. The class group cl(Z[√−p]) is cyclic of order N = 3 × 37 × 1407181 × 51593604295295867744293584889 ×31599414504681995853008278745587832204909 , with generator [ℓ1] = (3, √−p − 1).
SLIDE 54
Class group computation
22/34
SLIDE 55
Computing class group action
23/34 Given a ∈ Z/NZ, how do we compute the action of [ℓ1]a ?
SLIDE 56
Computing class group action
23/34 Given a ∈ Z/NZ, how do we compute the action of [ℓ1]a ? We have the relation lattice Λ74 for the 74 prime ideals that we can efficiently act with. To evaluate the action of [ℓa
1], we reduce (a, 0, · · · , 0) modulo Λ74
(Babai’s NP) to get a short vector e ∈ Z74 with e − (a, 0, · · · , 0) ∈ Λ74. Then we compute the action of 74
i=1[ℓi]e i as usual.
SLIDE 57
Computing class group action
23/34 Given a ∈ Z/NZ, how do we compute the action of [ℓ1]a ? We have the relation lattice Λ74 for the 74 prime ideals that we can efficiently act with. To evaluate the action of [ℓa
1], we reduce (a, 0, · · · , 0) modulo Λ74
(Babai’s NP) to get a short vector e ∈ Z74 with e − (a, 0, · · · , 0) ∈ Λ74. Then we compute the action of 74
i=1[ℓi]e i as usual.
We can now uniquely represent elements of the class group, sample them uniformly (as elements of Z/NZ), and compute their action.
SLIDE 58
Computing class group action
23/34 Given a ∈ Z/NZ, how do we compute the action of [ℓ1]a ? We have the relation lattice Λ74 for the 74 prime ideals that we can efficiently act with. To evaluate the action of [ℓa
1], we reduce (a, 0, · · · , 0) modulo Λ74
(Babai’s NP) to get a short vector e ∈ Z74 with e − (a, 0, · · · , 0) ∈ Λ74. Then we compute the action of 74
i=1[ℓi]e i as usual.
We can now uniquely represent elements of the class group, sample them uniformly (as elements of Z/NZ), and compute their action. Lattice reduction is 13% of total cost.
SLIDE 59
Outline
24/34
1 Some Isogeny-Based Crypto 2 Class group computation 3 CSI-FiSh
SLIDE 60
Isogeny-based authentication
25/34 Trump chooses secret key [a], and tweets [a] ⋆ E0.
bla
− − − − − →
bla
← − − − − −
bla
− − − − − → ↓ Accept/Reject Zelensky learns that she is talking to someone who knows [a], but without learning [a]! Make non-interactive with Fiat-Shamir
SLIDE 61
Zero Knowledge proofs
26/34
com
− − − − − − →
ch
← − − − − −
rsp
− − − − − →
SLIDE 62
Zero Knowledge proofs
26/34
com
− − − − − − →
ch
← − − − − −
rsp
− − − − − →
Zero knowledge proofs are magic
SLIDE 63
Zero Knowledge proofs
26/34
com
− − − − − − →
ch
← − − − − −
rsp
− − − − − → Correctness Zero-Knowledge Soundness (with small error)
SLIDE 64
Zero knowledge for vectorization
27/34 E0 Epk [s]
SLIDE 65
Zero knowledge for vectorization
27/34 E0 Epk [s] E [r]
SLIDE 66
Zero knowledge for vectorization
27/34 E0 Epk [s] E [r]
E
− − − − →
SLIDE 67
Zero knowledge for vectorization
27/34 E0 Epk [s] E [r] [s][r]−1
E
− − − − →
SLIDE 68
Zero knowledge for vectorization
27/34 b = 0 b = 1 E0 Epk [s] E [r] [s][r]−1
E
− − − − →
0 or 1
← − − − − − − −
SLIDE 69
Zero knowledge for vectorization
27/34 b = 0 b = 1 E0 Epk [s] E [r] [s][r]−1
E
− − − − →
0 or 1
← − − − − − − −
[r] or [s][r]−1
− − − − − − − − →
SLIDE 70
Problem (and solution)
28/34 Problem: Cheating probability 1/2.
SLIDE 71
Problem (and solution)
28/34 Problem: Cheating probability 1/2. Solution: Repeat 128 times to get cheating probability ≤ 2−128. ⇒ 128 times slower and 128 times bigger signatures.
SLIDE 72
Problem (and solution)
28/34 Problem: Cheating probability 1/2. Solution: Repeat 128 times to get cheating probability ≤ 2−128. ⇒ 128 times slower and 128 times bigger signatures. Better solution: [Seasign] Use multiple secret keys. ⇒ Trade-off between signature size and public key size.
SLIDE 73
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk]
SLIDE 74
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk] E [r]
SLIDE 75
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk] E [r]
E
− − − − →
SLIDE 76
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk] E [r]
E
− − − − →
c ∈ {0,··· ,k}
← − − − − − − −
SLIDE 77
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk] E [r] [r][sc]−1
E
− − − − →
c ∈ {0,··· ,k}
← − − − − − − −
SLIDE 78
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk] E [r] [r][sc]−1
E
− − − − →
c ∈ {0,··· ,k}
← − − − − − − −
[r][sc]−1
− − − − − − − − →
SLIDE 79
Improvements
29/34 as used by Seasign [De Feo, Galbraith] E0 E(1)
pk
. . . E(k)
pk
[s1] [sk] E [r] [r][sc]−1
E
− − − − →
c ∈ {0,··· ,k}
← − − − − − − −
[r][sc]−1
− − − − − − − − → Cheating probability
1 k+1
SLIDE 80
Quadratic twists
30/34 An elliptic curve E = E0 has a quadratic twist Et. If −1 is not a square mod p, then E : y2 = x3 + Ax2 + x ↔ Et : y2 = x3 + −Ax2 + x Symmetry around E0 : if E = ga ⋆ E0, then Et = g−a ⋆ E0.
Figure: 3-isogeny CSIDH graph mod 83
SLIDE 81
Improvements with a twist
31/34 E0 E(1)
pk , E(1)t pk
. . . E(k)
pk , E(k)t pk
±s1 ±sk E r r ± s|c|
E
− − − − →
c ∈ {−k,··· ,k}
← − − − − − − − − − − − −
r±s|c|
− − − − − − − → Cheating probability
1 2k+1
SLIDE 82
Implementation results
32/34 "Commutative Supersingular Isogeny based Fiat-Shamir" (CSI-FiSh)
SLIDE 83
Implementation results
32/34 "Commutative Supersingular Isogeny based Fiat-Shamir" (CSI-FiSh) k |pk| |sig| signing time Previous work: Improved Seasign 23 512 B 11.7KB 17 min [Decru,Panny,Vercauteren]
SLIDE 84
Implementation results
32/34 "Commutative Supersingular Isogeny based Fiat-Shamir" (CSI-FiSh) k |pk| |sig| signing time Previous work: Improved Seasign 23 512 B 11.7KB 17 min [Decru,Panny,Vercauteren] CSI-FiSh 23 512 B 956 B 1.5 s CSI-FiSh has smaller |pk| + |sig| than all NIST candidates (SL I), but is much slower.
SLIDE 85
Implementation results
33/34 "Commutative Supersingular Isogeny based Fiat-Shamir" (CSI-FiSh) k |pk| |sig| signing time Previous work: Improved Seasign 23 512 B 11.7KB [Decru,Panny,Vercauteren] CSI-FiSh 23 512 B 956 B CSI-FiSh has smaller |pk| + |sig| than all NIST candidates (SL I), but is much slower.
SLIDE 86
Conclusion
34/34 Class group action is useful for Key Exchange (CSIDH), but limited because class group is unknown. We compute class group of a quadratic field with 154 digit discriminant (previous record was 130 digits). This allows us to build a signature scheme (CSI-FiSh) from the class group action. Optimizations :
Multiple public keys [De Feo,Galbraith] Add the twists · · ·
