CSE443 Compilers

• Dr. Carl Alphonce

alphonce@buffalo.edu 343 Davis Hall

Weekly team meetings with me:

• Doodle poll link in Piazza

Wednesday (4/ 4) will be a workshop Wednesday

• Post questions you'd like addressed

in Piazza by Sunday (4/1) evening

Announcements

Phases of a compiler

Figure 1.6, page 5 of text

Intermediate Representation (IR): specification and generation

Intermediate Representations

Sizes of types

type string: 1 -> character 8 bytes + length of string * size

• f character (= 1 byte)

# of dimensions size of dimension 1 (integer) (0) (1) (2) (3) (4) 1 5 V A X E S

https:/ / en.wikipedia.org/wiki/VAX Q: Since the number of dimensions is part of the type, do we need to store it at runtime? A: No.

Sizes of types

type string: 1 -> character 4 bytes + length of string * size

• f character (= 1 byte)

https:/ / en.wikipedia.org/wiki/VAX

size of dimension 1 (integer) (0) (1) (2) (3) (4) 5 V A X E S

Sizes of types

What is the size of a multi- dimensional array of type T? sizes of dimensions (Si): X*4 bytes data: (∏i∈X Si) * sizeOf(T)

size of first dimension 2 size of second dimension 3 a(0,0) first row a(0,1) a(0,2) a(1,0) second row a(1,1) a(1,2)

Figure 6.16, p 375

T B C C 𝜁 C int [2] [3]

T = int w = 4 t = int w = 4 t = array(3,int) w = 12 t = array(2,array(3,int)) w = 24 t = array(2,array(3,int)) w = 24

For the purposes of type checking the number of dimensions is relevant, but the size of each dimension is not. Q: if a and b are compatible array types, what are the semantics of a := b ?

Figure 6.16, p 375

T B C C 𝜁 C

character w = 1

[2] [3]

w = 6 w = 3 9+array(2,arr(3,character)) w = 9 + 6 * 1 = 15 w = 2 * 3

What if type info comes after dimensions?

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

definition —> type identifier ':' dblock { st.put(identifier.lexeme, TYPE, dblock.type, dblock.width } dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); } declaration-list —> declaration ';' declaration-list declaration-list —> declaration declaration —> identifier ':' { id-list.type = identifier; } <— however you store types identifier-list (maybe pointer into st?) identifier-list —> identifier ( sBinOp constant ) ',' { st.put(identifier.lexeme, VAR, identifier-list.type, offset);

• ffset = offset + identifier-list.type.width; }

identifier-list identifier-list —> identifier ( sBinOp constant ) { st.put(identifier.lexeme, VAR, identifier-list.type, offset);

• ffset = offset + identifier-list.type.width; }

Just suggestions, not to be taken literally Just suggestions, not to be taken literally

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

definition —> type identifier ':' dblock { st.put(identifier.lexeme, TYPE, dblock.type, dblock.width } dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); } declaration-list —> declaration ';' declaration-list declaration-list —> declaration declaration —> identifier ':' { id-list.type = identifier; } <— however you store types identifier-list (maybe pointer into st?) identifier-list —> identifier ( sBinOp constant ) ',' { st.put(identifier.lexeme, VAR, identifier-list.type, offset);

• ffset = offset + identifier-list.type.width; }

identifier-list identifier-list —> identifier ( sBinOp constant ) { st.put(identifier.lexeme, VAR, identifier-list.type, offset);

• ffset = offset + identifier-list.type.width; }

Just suggestions, not to be taken literally Just suggestions, not to be taken literally

We can specialize due to the structure of our grammar: see next slide!

dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); }

{ ( integer : x , y ) { ( real : x , z ) … … } { ( Boolean : y ; character : z ) … … } }

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

integer: x integer: y

Since declarations must be gathered together at the start of an sblock, and cannot themselves be directly nested, we can do better:

• ffset = 0
• ffset = 4
• ffset = 8
• ffset = 8

push offset = 8 onto stack

• ffset = 16
• ffset = 24

pop offset = 8 from stack push offset = 8 onto stack

• ffset = 9
• ffset = 10

pop offset = 8 from stack integer: x integer: y real: x real: z integer: x integer: y

• ffset = 8

dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); }

{ ( integer : x , y ) { ( real : x , z ) … … } { ( Boolean : y ; character : z ) … … } }

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

integer: x integer: y

Since declarations must be gathered together at the start of an sblock, and cannot themselves be directly nested, we can do better:

• ffset = 0
• ffset = 4
• ffset = 8
• ffset = 8

push offset = 8 onto stack

• ffset = 16
• ffset = 24

pop offset = 8 from stack push offset = 8 onto stack

• ffset = 9
• ffset = 10

pop offset = 8 from stack

AT RUNTIME

• ffset = 8

dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); }

{ ( integer : x , y ) { ( real : x , z ) … … } { ( Boolean : y ; character : z ) … … } }

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

integer: x integer: y

Since declarations must be gathered together at the start of an sblock, and cannot themselves be directly nested, we can do better:

• ffset = 0
• ffset = 4
• ffset = 8
• ffset = 8

push offset = 8 onto stack

• ffset = 16
• ffset = 24

pop offset = 8 from stack push offset = 8 onto stack

• ffset = 9
• ffset = 10

pop offset = 8 from stack integer: x integer: y real: x real: z

AT RUNTIME

• ffset = 8

dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); }

{ ( integer : x , y ) { ( real : x , z ) … … } { ( Boolean : y ; character : z ) … … } }

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

integer: x integer: y

Since declarations must be gathered together at the start of an sblock, and cannot themselves be directly nested, we can do better:

• ffset = 0
• ffset = 4
• ffset = 8
• ffset = 8

push offset = 8 onto stack

• ffset = 16
• ffset = 24

pop offset = 8 from stack push offset = 8 onto stack

• ffset = 9
• ffset = 10

pop offset = 8 from stack

AT RUNTIME

• ffset = 8

dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); }

{ ( integer : x , y ) { ( real : x , z ) … … } { ( Boolean : y ; character : z ) … … } }

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

integer: x integer: y

Since declarations must be gathered together at the start of an sblock, and cannot themselves be directly nested, we can do better:

• ffset = 0
• ffset = 4
• ffset = 8
• ffset = 8

push offset = 8 onto stack

• ffset = 16
• ffset = 24

pop offset = 8 from stack push offset = 8 onto stack

• ffset = 9
• ffset = 10

pop offset = 8 from stack integer: x integer: y

AT RUNTIME

• ffset = 8

dblock —> '[' { Env.push(st); st = new Env(); Stack.push(offset); offset = 0; } declaration-list ']' { dblock.type=record(st); dblock.width=offset; st=Env.pop(); offset=Stack.pop(); }

{ ( integer : x , y ) { ( real : x , z ) … … } { ( Boolean : y ; character : z ) … … } }

dblocks (6.3.5 and 6.3.6)

records (in separate symbol table), sequence of declarations at start of sblock

integer: x integer: y

Since declarations must be gathered together at the start of an sblock, and cannot themselves be directly nested, we can do better:

• ffset = 0
• ffset = 4
• ffset = 8
• ffset = 8

push offset = 8 onto stack

• ffset = 16
• ffset = 24

pop offset = 8 from stack push offset = 8 onto stack

• ffset = 9
• ffset = 10

pop offset = 8 from stack

AT RUNTIME

• ffset = 8
