CSE 802 Spring 2017 Deep Learning

Inci M. Baytas

Michigan State University February 13-15, 2017

1

Large-scale Video Classification with Convolutional Neural Networks, CVPR 2014

2

Deep Learning in Computer Vision

3

Deep Learning in Computer Vision

Microsoft Deep Learning Semantic Image Segmentation

4

Deep Learning in Computer Vision

NeuralTalk and Walk, recognition, text description of the image while walking.

5

Deep Learning in Robotics

Self Driving Cars

6

Deep Learning in Robotics

Deep Sensimotor Learning

• Natural Language Processing (NLP)
• Speech recognition and machine translation

7

Other Applications of Deep Learning

Why Should We Be Impressed?

• Automated vision (e.g., object recognition) is challenging: different

viewpoints, scales, occlusions, illumination,…

• Robotics (e.g., autonomous driving) in real life environments

(constantly changing, new tasks without guidance, unexpected factors) is challenging

• NLP (e.g., understanding human conversations) is an extremely

complex task: noise, context, partial sentences, different accent,..

Why Is Deep Learning So Popular Now?

• Better hardware
• Bigger data
• Regularization methods (dropout)
• Variety of optimization methods
• SGD
• Adagrad
• Adadelta
• ADAM
• RMS Prop

8

Criticism and Limitations of Deep Networks

• Large amount of data required for training
• High performance computing a necessity
• Non-optimal method
• Task specific
• Lack of theoretical understanding

9

10

Common Deep Network Types

Feed forward networks Convolutional neural networks Recurrent neural networks

Components of Deep Learning

11

Loss functions

• Squared loss: (y - f(x))2
• Logistic loss: log(1 + e-yf(x))
• Hinge loss: (1 + yf(x))+
• Squared hinge loss: (1 + yf(x))+

2

Non-linear activation functions

• Linear
• Tanh
• Sigmoid
• Softmax
• ReLU

12

13

Components of Deep Learning

Optimizers

• Gradient Descent
• Adagrad (Adaptive Gradient Algorithm)
• Adadelta (An Adaptive Learning Rate Method)
• ADAM (Adaptive Moment Estimation)
• RMSProp

Regularization Methods

• L2 norm
• L1 norm
• Dataset Augmentation
• Noise robustness
• Early stopping
• Dropout [12]

14

Components of Deep Learning

Number of iterations

• Less iterations: may underfitting
• More iterations: use a stopping criteria

Step size

• Very large step size: may miss optimal point
• Very small step size: takes longer to converge

Parameter Initialization

• Initializing with zeros
• Random initialization
• Xavier initialization

15

Components of Deep Learning

Batch size

• Bigger batch size: might require less iterations
• Smaller batch size: will need more iterations

Number of layers

• More layers (more depth): introducing more non-linearity, more complexity,

more parameters

• Too many layers might cause overfitting.

Number of hidden parameters

• Large number of hidden layer: more model complexity, can approximate a

more complex classifier

• Too many parameters: overfitting, increased training time

• Convolutional networks are simply neural networks that use convolution

in place of general matrix multiplication in at least one of their layers [1].

16

Convolutional Neural Networks

Convolution:

• A linear operator
• Cross-correlation with a flipped

kernel.

• Convolution in spatial domain

corresponds to multiplication in frequency domain.

• Feed forward networks that can extract topological features

from images.

• Can provide invariance to geometric distortions such as

translation, scaling, and rotation.

• Hierarchical and robust feature extraction was done before

CNNs.

• CNN is data-driven.
• Parameters of filters are learned from the data instead of

predefined values.

• At each iteration, parameters are updated to minimize the

loss.

17

Convolutional Neural Networks (CNNs)

18

Convolution Layer

• Local (sparse)

connectivity

• Reduces memory

requirements

• Fewer operations
• Parameter sharing
• Same kernel used

at every position of

the input

• How to choose the

filter size?

• Receptive field
• Equivariance

property

19

Pooling Layer (Subsampling)

• Convolution stage:
• several convolutions in

parallel to produce a set

• f linear activations
• Followed by non-linear

activation

• Then pooling layer:
• Invariance to small

translations

• Dealing with variable size

inputs

• Maps the latent

representation of input to

• utput
• Output:
• One-hot representation of class

label

• Predicted response
• Appropriate activation

function, e.g., softmax for classification.

20

Fully-Connected Layer

21

Feature Extraction with CNNs

22

Some Example CNN Architectures

LeNet-5 [2]

23

Some Example CNN Architectures

AlexNet (5 layers)

24

VGG 16 [3]

Some Example CNN Architectures

25

GoogLeNet (22 layers)

26

Tricks to Improve CNN Performance

• Data augmentation
• Flipping (commonly used in face)
• Translation
• Rotation
• Stretching
• Normalizing, Whitening (less redundancy)
• Cropping and alignment (for especially face)

27

Project

• You will implement 11-layer CNN architecture proposed in [6] to

extract features.

28

Project

• You can use a deep learning library to implement the network.
• Library will take care of convolution, pooling, dropout, and

back propagation.

• You need to define cost function and activation functions.
• The activation function of the output layer is softmax since it is

a classification problem.

• You can use tensorflow.

29

HPCC

• Data and evaluation protocol are on HPCC.
• /mnt/research/CSE_802_SPR_17
• To connect HPCC: ssh msunetid@hpcc.msu.edu and msu

email password

• To run small examples use developer mode: ssh dev-intel14
• Try to log in to HPCC and check the course research space.
• Try to use a python IDE (PyCharm). Debug your code and

understand how tensorflow works (if you are not familiar with a deep learning library).

30

Casia Dataset (Cropped Images)

• The database contains 494,414

images.

• 10,575 subjects in total
• We provide cropped and original

images under /mnt/research/CSE_802_SPR_17

31

Test Data and Evaluation Protocol

• Final evaluation on

Labeled Faces in the Wild (LFW) database [7] with 13,233 images, 5,749 subjects.

• Evaluation protocol:

○ BLUFR protocol [8]; find under /mnt/research/CSE_80 2_SPR_17

32

References

1. http://www.deeplearningbook.org/ 2. http://yann.lecun.com/exdb/lenet/ 3. https://www.cs.toronto.edu/~frossard/post/vgg16/ 4.

• A. Krizhevsky, I. Sutskever and G. E. Hinton “ImageNet Classification with Deep Convolutional Neural

Networks”, NIPS 2012: Neural Information Processing Systems, Lake Tahoe, Nevada 5. http://pubs.sciepub.com/ajme/2/7/9/ 6. Dong Yi, Zhen Lei, Shengcai Liao and Stan Z. Li. Learning Face Representation from Scratch, arXiv:1411.7923v1 [cs.CV], 2014. 7. http://vis-www.cs.umass.edu/lfw/ 8. http://www.cbsr.ia.ac.cn/users/scliao/projects/blufr/ 9. http://www.cbsr.ia.ac.cn/english/CASIA-WebFace-Database.html 10. https://www.nist.gov/programs-projects/face-recognition-grand-challenge-frgc 11. Shengcai Liao, Zhen Lei, Dong Yi, Stan Z. Li, "A Benchmark Study of Large-scale Unconstrained Face Recognition." In IAPR/IEEE International Joint Conference on Biometrics, Sep. 29 - Oct. 2, Clearwater, Florida, USA, 2014. 12. Nitish Srivastava, Geoffrey Hinton, Alex Krizhevsky, Ilya Sutskever and Ruslan Salakhutdinov, “Dropout: A Simple Way to Prevent Neural Networks from Overfitting”, Journal of Machine Learning Research 15 (2014) 1929-1958.
