CSC 2400: Computer Systems Stack Buffer Overflow Attacks

Summary

• Invoking a function

! CALL: call the function ! RET: return from the instruction

• Stack Frame for a function call includes

! Function arguments ! Return address ! Local variables ! Saved registers

• Base pointer EBP

! Fixed reference point in the Stack Frame ! Useful for referencing arguments and local variables

Function Calls

• main calls add3

! Push arguments on the stack ! Push return address on stack ! Jump to add3 ! Allocate local variables on stack, save registers, etc.

• Returning to main

! Clear the stack frame for add3 ! Pop return address from stack

int add3(int a, int b, int c) { int d; d = a + b + c; return d; } int main() { int sum, avg; sum = add3(3, 4, 5); avg = sum / 3; return avg }

Return Addr. Address

ESP

5 4 3 Stack Frame for add3

Return Address

Stack Frame for main

Computer Malware

• Normal stack
• Low
• Address
• High
• Address

buffer valid address New Return Address Malicious code

• Buffer Overflow Attack

buffer Saved EBP Return Address

• Overflowed
• region

q

Stack buffer overflow attacks:

q

Heap buffer overflow are also common (overwrite pointer addresses)

EBP EBP-4

Return Address (0x08048424) Old EBP buf[0] buf[1] buf[2] buf[3]

EBP EBP-4

Return Address (0x08048424) Old EBP buf[0] buf[1] buf[2] buf[3] Return Address (0x08048424) Old EBP 0x31 0x32 0x33 0x00 Before gets After gets

EBP EBP-4

Return Address (0x08048424) Old EBP buf[0] buf[1] buf[2] buf[3] Return Address (0x08048424) ... 0x31 0x32 0x33 0x34 Before gets After gets 0x00

EBP EBP-4

Return Address (0x08048424) Old EBP buf[0] buf[1] buf[2] buf[3] Return Address (0x08048424) 0x31 0x32 0x33 0x34 Before gets After gets 0x35 0x36 0x37 0x00

EBP EBP-4

Return Address (0x08048424) Old EBP buf[0] buf[1] buf[2] buf[3] 0x31 0x32 0x33 0x34 Before gets After gets 0x30 0x30 0x30 0x30 0x35 0x36 0x37 0x38 0x00

EBP EBP-4

Return Address (0x08048472) Old EBP buf[0] buf[1] buf[2] buf[3] 0x38373635 0x00000000 0x31 0x32 0x33 0x34 0x00

Before gets After gets

EBP EBP-4

Return Address (0x08048472) Old EBP buf[0] buf[1] buf[2] buf[3] Address of Fire Some valid address 0x00 0x00 0x00 0x00

Before gets After gets

#include <string.h> void foo (char *bar) { char c[12]; strcpy(c, bar); // no bounds checking } int main (int argc, char **argv) { foo(argv[1]); return 0; }
